Panasonic MC-E6003 Building instructions

© 2006 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and distribu-
tion is a violation of law.
Order No.VCB0612005SE
Vacuum Cleaner
MC-E6003
MC-E6003K
MC-E6001
MC-E6001K
Destination : Europe
Subject : Setting of a New Service Part Number.
We will start to supply the “cord reel support unit” in order to increase
repair efficiency.
Please file and use this supplement manual together with the service manual for Model No.MC-E6003/MC-
6003K,MC-E6001/MC-E6001K, Order No.MAES040611C2, Supplement Order No.ECD0505002S2.

2
TABLE OF CONTENTS
PAGE PAGE
1 Specifications ------------------------------------------------------2 2 Exploded View and Replacement Parts List------------- 3
1 Specifications
• Specifications are subject to change without notice for further improvement
Model MC-E6003/MC-E6003K MC-E6001/MC-E6001K
Power source AC230V~50Hz AC230V~50Hz
AC230-240V~50Hz AC230-240V~50Hz
Input power (max.) 1600W 1500W
Water lift 22kPa 20kPa
Cord length 5 m(only UK) /6.5m 5m
Cord length 7 m(only UK) /8.5m 7m
Dimensions (LxWxH)mm 380x215x285 380x215x285
Attachments: Floor nozzle OO
Telescopic wand O
Extension wand O
Metal telescopic OO

3
2 Exploded View and Replacement Parts List
2.1. MC-E6001,E6003 EXPLODED VIEW (BODY UNIT)
48
Filter case packing A
Filter case
packing B
13-1
53
26
20
24
18 22
21
23

4
2.2. PARTS LIST (BODY UNIT)
Ref. No. Part No. Part Name & Description Remarks
27 AMC8P01BM023 Cord reel support MC-E6001/MC-E6001K/ White
27 AMC8P01BM039 Cord reel support MC-E6003/MC-E6003K/ Light gray
28 AMC8P99BM000 Contact spring unit
29 XTN4+16K Tapping screw
30 AMC8P96BM023 Brake lever unit MC-E6001/MC-E6001K/ White
30 AMC8P96BM039 Brake lever unit MC-E6003/MC-E6003K/ Light gray
31 AMC8P22BM000 Brake spring
53 AMC8P91BM023 Cord reel support unit MC-E6001/MC-E6001K/ White
53 AMC8P91BM039 Cord reel support unit MC-E6003/MC-E6003K/ Light gray
