Panasonic NA-127VC5 Operating instructions

Read Before Using 02
SAFETY PRECAUTIONS 05
Washing Instructions 20
Optional Functions 30
Maintenance 31
Troubleshooting 35
Installation Instructions 39
Operating Instructions
& Installation Instructions
Washing Machine
(Domestic use)
Model No.
NA - 148VB5
NA - 128VB5
NA - 147VB5
NA - 127VB5
NA - 147VC5
NA - 127VC5
®
Thank you for purchasing this appliance.
- For optimum performance and safety, please read these instructions
carefully.
- Before connecting, operating or adjusting this appliance, please read the
instructions completely. Please keep this manual for future reference.
EN G L I S H
NA-148VB5_English_UK.indb 1 2013-12-13 17:28:23

2 - Read Before Using
Electrical Connection (UK and Republic of Ireland only)
For your safety, please read the
following text carefully.
This appliance is supplied with a moulded
three pin mains plug for your safety and
convenience.
A 13-ampere fuse is fitted in this plug.
Should the fuse need to be replaced,
please ensure that the replacement fuse
has a rating of 13 ampere and that it is
approved by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI
mark on the body of the fuse.
If the plug contains a removable fuse cover
you must ensure that it is refitted when the
fuse is replaced.
If you lose the fuse cover, the plug must
not be used until a replacement cover is
obtained. A replacement fuse cover can be
purchased from your local dealer.
Warning
If the fitted moulded plug is
unsuitable for the mains socket in
your home then the fuse should be
removed and the plug cut off and
disposed of safely.
There is a danger of severe
electrical shock if the cut off plug is
inserted into any 13-ampere socket.
How to replace the fuse
The location of the fuse differs according
to the type of AC mains plug (figures A and
B).
Confirm the AC mains plug fitted and follow
the instructions below. Illustrations may
differ from actual AC mains plug.
Open the fuse cover with a screwdriver
and replace the fuse and close or attach
the fuse cover.
Figure A-
Figure B-
NA-148VB5_English_UK.indb 2 2013-12-13 17:28:24

Read Before Using - 3
Consider the Environment
Disposing of packaging
The packaging used to protect the
washing machine from damage during
transportation is all recyclable. For
information on recycling, contact your local
authority.
Disposing of Waste
Electrical & Electronic
Equipment
Information on disposal for users of
waste electrical & electronic equipment
(private households)
This symbol on the products and/or
accompanying documents means that
used electrical and electronic products
should not be mixed with general
household waste.
For proper treatment, recovery and
recycling, please take these products to
designated collection points, where they
will be accepted on a free of charge basis.
Alternatively, in some countries you may be
able to return your products to your local
retailer upon the purchase of an equivalent
new product.
Disposing of this product correctly will
help to save valuable resources and
prevent any potential negative effects on
human health and the environment which
could otherwise arise from inappropriate
waste handling. Please contact your local
authority for further details of your nearest
designated disposable point.
Penalties may be applicable for incorrect
disposal of this waste, in accordance with
national legislation.
Information on disposal in other
countries outside the European Union
This symbol is only valid in the European
Union.
If you wish to discard this product, please
contact your local authorities or dealer and
ask for the correct method of disposal.
Eco-friendly Laundry
Keep to the load limit of each-
programme.
The washing machine automatically-
adjusts the operating time of each
programme depending on the load.
You only need to use a preliminary wash-
if your laundry is heavily soiled.
Using the 60 °C Cotton programme-
instead of the 90 °C Cotton one will save
energy, and will remove ordinary stains.
For lightly soiled laundry, using the 20°C-
Wash programme instead of the 40 °C
Quick programme will save more energy.
Detergent amount
Use the correct amount of detergent-
based on the detergent pack instructions
and local water hardness.
Adjust the amount of detergent-
depending on how soiled your laundry is.
When using a tumble dryer
To save energy, please select the correct
spin speed according to the instruction of
your tumble dryer.
This product complies with the directives
2006/95/EC and 2004/108/EC.
NA-148VB5_English_UK.indb 3 2013-12-13 17:28:24

4 - Read Before Using
Contents
Read Before Using
Electrical Connection (UK and
Republic of Ireland only) .........2
Consider the Environment........3
SAFETY PRECAUTIONS ........9
Checking Your Washing Machine . 12
Your washing machine ............12
Accessories.....................12
Before You Start Washing .......13
Before use, check ................13
Before initial use . . . . . . . . . . . . . . . . .13
Preparing the laundry .............13
Adding Detergent and Other
Chemicals ...................15
Detergent compartment ...........15
Softener compartment.............17
Prewashing compartment ..........17
Using the Buttons and Dials .....18
Buttons and dial .................18
Display ........................19
Unlocking the door ...............19
Washing Instructions
Washing.....................20
Setting washing..................20
Required time ...................21
Setting the buzzer ................21
Changing settings ................21
Selecting the Programme .......22
Power and Water Consumption...23
Details of Programmes .........26
Washing Delicates.............28
Wool programme.................28
Wool laundry loads ...............28
Tips for washing delicates..........28
Washing Blankets and
Bedspreads ..................29
Bedding programme . . . . . . . . . . . . . .29
Putting bedding into the drum .......29
Optional Functions.............30
Extra Rinse . . . . . . . . . . . . . . . . . . . . .30
Speed/Eco......................30
Child lock.......................30
Preset timer.....................30
Easy Iron.......................30
Maintenance
Maintenance .................31
Cleaning the outside of the
appliance.......................31
Cleaning the door seal and window . .31
Cleaning the drain filter ............31
Cleaning the drum................32
Cleaning the detergent drawer ......32
Cleaning the water-supply filter......33
Preventing a frozen water-supply
hose ..........................34
Troubleshooting
Fault Checklist................35
Error Display .................38
Installation Instructions
Choosing the Right Location .....39
Carrying the appliance ............39
The right place for the appliance.....39
Installing a built-in washing machine..39
Moving and Installing...........40
Removing the anchor bolts .........40
Moving the appliance .............40
Levelling the appliance . . . . . . . . . . . .41
Connecting Hoses and Power
Supply . . . . . . . . . . . . . . . . . . . . . . 42
Hoses and cable lengths...........42
Water-supply hose ...............42
Water-drain hose.................43
Connecting to the power supply .....44
Checking After Installation.......45
Installation checklist ..............45
Specifications ................46
Washing machine - Product fiche ..47
NA-148VB5_English_UK.indb 4 2013-12-13 17:28:24

Read Before Using - 5
SAFETY PRECAUTIONS
Please read and follow these safety precautions.
WARNING
This describes issues which could cause death or
serious injury.
General Use
This appliance can be used by children-
aged from 8 years and above and
persons with reduced physical, sensory
or mental capabilities or lack experience
and knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be
made by children without supervision.
Do NOT place a stand or a chair close to-
the appliance.
Children may be able to reach the control
panel or climb onto or into the appliance.
NA-148VB5_English_UK.indb 5 2013-12-13 17:28:24

6 - Read Before Using
SAFETY PRECAUTIONS
Turn off the water supply to the appliance if it-
is not going to be used for a prolonged period,
such as during a holiday. This is especially
important if there is no drainage around the
appliance.
If the water supply is left on, the water pressure
may unnecessarily increase and result in a
leak.
Do NOT install the appliance in a damp location-
or in a location exposed to the weather.
This may result in malfunction, deterioration,
electric shock, or fire.
Do NOT pour or spill water directly onto any-
part of the appliance.
This may result in malfunction, electric shock,
or fire.
Keep sources of ignition, such as candles or-
cigarettes, away from the appliance.
They may cause a fire or damage to the
appliance.
Keep flammable materials away from the-
appliance, for example, gasoline, thinner,
alcohol, or clothing soaked with these materials.
They may cause an explosion or a fire.
NA-148VB5_English_UK.indb 6 2013-12-13 17:28:24

Read Before Using - 7
SAFETY PRECAUTIONS
WARNING
Power source and cable
Unplug the mains lead when cleaning the-
appliance.
Check the mains lead and mains plug for-
any damage.
If the mains lead is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons to avoid
a hazard.
Do NOT use a mains plug adaptor or-
extension cable. There is a possibility of
overheating which may cause a fire. Use an
unused household mains socket, fully rated
at AC 220 V to 240 V. If you are not sure,
contact a qualified electrician.
ENSURE the mains plug is fully inserted-
into the household mains socket. If the
mains plug is not fully pushed in, a loose
connection may overheat and cause an
electric shock or fire.
Do NOT touch the mains lead or mains plug-
with wet hands.
Possibility of an electric shock.
NA-148VB5_English_UK.indb 7 2013-12-13 17:28:24

8 - Read Before Using
SAFETY PRECAUTIONS
Do NOT pull the mains lead but hold the-
mains plug to unplug the appliance.
Otherwise, there is possibility of damage
to the mains lead, which may lead to an
electric shock or fire.
To Prevent Injury
The installation of the appliance should-
be done by the manufacturer’s dealer or
service agent.
If the installation, test run and inspection of
the appliance are not carried out following
the installation method outlined in these
instructions, the manufacturer will not be
liable for any accident or damage caused.
Do NOT dismantle, repair or modify the-
appliance.
There is a possibility the appliance may
malfunction which may result in a fire or an
injury. If repairs are needed, contact your
local Customer Communications Centre.
Do NOT touch the laundry inside the drum-
until it has completely stopped, as there is a
possibility of injury. Keep children away from
the rotating laundry.
NA-148VB5_English_UK.indb 8 2013-12-13 17:28:24

Read Before Using - 9
SAFETY PRECAUTIONS
CAUTION
This describes issues which could cause injury or
damage your belongings.
General Use
Prior to use, turn on the tap and check the-
hose and connections for any leaks.
Improper connection could cause leaks.
The new hose-sets supplied with the-
appliance are to be used and that old hose-
sets should not be reused.
This appliance is only suitable for textiles-
labelled washing machine washable.
Do NOT connect to the hot water supply.-
This appliance works ONLY with cold water.
Do NOT apply pesticide, hair spray or-
deodorant to the appliance.
NA-148VB5_English_UK.indb 9 2013-12-13 17:28:24

10 - Read Before Using
SAFETY PRECAUTIONS
Do NOT put any electrical equipment, for-
example, TVs, radios or battery chargers,
on or near the appliance.
Do NOT put too much laundry or detergent-
into the appliance.
This may cause damage to the appliance.
REMOVE the anchor bolts before installing-
the appliance using a spanner or similar
tool. The anchor bolts are used to transport
the appliance.
If the anchor bolts are not removed, the
appliance will strongly vibrate during use.
To Prevent Injury
Do NOT climb onto the appliance.-
This may cause injury or damage to the
appliance.
Keep fingers away from the door hinge-
when opening and closing the door.
Do NOT slide your hand (or unprotected-
foot) underneath the appliance when in use.
NA-148VB5_English_UK.indb 10 2013-12-13 17:28:24

Read Before Using - 11
SAFETY PRECAUTIONS
CAUTION
Check all washing and remove all objects-
such as nails, pins, coins, clips, metal wires,
etc.
They may cause damage to other laundry or
the appliance.
Do NOT use the appliance to wash-
waterproof sheets or clothing. There is a
possibility of excessive vibration or failure
during the spin cycle that may result in an
injury, damage to the appliance or a water
leak.
BE CAREFUL when draining hot water or-
any detergent out of the drum.
BE CAREFUL not to get laundry caught in-
the door seal when it is closed. This may
result in a water leak or damage to the
laundry during the wash cycle.
NA-148VB5_English_UK.indb 11 2013-12-13 17:28:24

12 - Read Before Using
Checking Your Washing Machine
Your washing machine
Caution
Do NOT bend the mains lead when the appliance is running.
Accessories
Make sure that all the accessories are
supplied with the appliance.
Elbow (see page 43)
For fixing the water-drain hose
Liquid detergent level plate
(see page 16)
Cover cap (x4) (see pages 40-41)
Water-supply hose (see page 42)
Either one of these hoses is supplied with
the appliance.
Detergent drawer
(see page 15)
Door
Water-drain hose
Adjustable feet
(see page 41)
Drain filter cover
(see page 31)
Mains lead/
Mains plug
Door seal
Drum
(Washing/
spin-drying tub)
Standard
Hose
Hose with
water-supply valve
(Not available for UK models)
NA-148VB5_English_UK.indb 12 2013-12-13 17:28:25

Read Before Using - 13
Before You Start Washing
Before use, check
For the appliance’s initial operation or
after a prolonged period of non-operation,
perform the following procedures:
Secure the water-supply hose.1.
Open the tap.2.
Connect the power.3.
Make sure that the water-drain hose4.
is positioned towards a drain.
For more details, see page 43.
Before initial use
For the appliance’s initial operation, select
the 40 ºC Cotton programme to operate
it WITHOUT any detergent or clothing to
rinse out residue or moisture.
Note
There may be drops of water or
condensation in the appliance due
to the factory inspection prior to
shipment. This is not a malfunction.
Preparing the laundry
Sorting clothing
Read clothing washing labels to help-
you sort them into different loads.
Sort the laundry by colour, by type of-
fabric, and by how soiled it is. Doing
so will help you choose the correct
programme and temperature for each
wash.
Clothes that are not colour fast should-
be washed separately. Wash denim
separately.
You should put bras with metal wires,-
tights, lace clothing and small items of
clothing into a laundry net to prevent
them or the appliance from getting
damaged.
Caution
Do NOT wash water-repellent
clothing.
There is a possibility of excessive
vibration or failure during the spin-
drying cycle that may result in an
injury, damage to the appliance or a
water leak.
NA-148VB5_English_UK.indb 13 2013-12-13 17:28:25

14 - Read Before Using
Before You Start Washing
Treating stains
Apply stain remover to stained portions.
For dirt and solid stains, wash lightly by
hand first.
Checking clothing
Check that pockets on clothing do not-
contain any objects that may damage
the clothes or the appliance.
To avoid clothes being damaged, check-
and tie up loose strings, close zips, turn
clothing with raised fabrics and zips
inside out.
Remove any hair, animal fur, sand,-
and other materials with a brush before
washing.
Note
Do not wash clothes that are heavily
stained with large quantities of
vegetable oil or cosmetic oil (aroma oil,
etc.). Failure to observe this may result
in the door seal swelling, causing
the water to overflow and leading to
malfunctions.
NA-148VB5_English_UK.indb 14 2013-12-13 17:28:26

Read Before Using - 15
Adding Detergent and Other Chemicals
Pull out the detergent drawer and add detergent or softener to the correct
compartment. Check the packages for the appropriate recommended amounts.
Caution
Do NOT use the appliance when the detergent drawer is removed.
This may result in a water leak.
Detergent compartment
The following detergents and additives may
be added to this compartment:
Detergent-
Water softening agent-
Stain remover-
Tub cleaning detergent or bleach-
If you use multiple chemicals in this
compartment for washing, add them in the
following order:
1. Detergent
2. Water softening agent
3. Stain remover
Detergent
Use only detergents that are recommended
for fully-automated washing machines.
Please use low suds detergents.
Caution
If the instructions on the package
indicate that detergent should be
placed in the drum, do NOT put it
into the detergent drawer.
These detergents may not flow well
and remain in the detergent drawer.
Do not overfill with detergent. Failure
to observe this may result in the
detergent blocking the water supply,
causing the water to overflow from
the front of the detergent drawer and
leading to malfunctions.
Liquid detergent1.
Note
Do NOT use liquid detergent with the-
Prewash function. It may flow away
during the prewash.
Add liquid detergent before you start-
washing.
Prewashing compartment
Softener compartment
Detergent compartment
NA-148VB5_English_UK.indb 15 2013-12-13 17:28:26

16 - Read Before Using
Adding Detergent and Other Chemicals
Fit the liquid detergent level plate (included
with the accessories) into the detergent
compartment and use it as a mark to set
the amount of liquid detergent. Make sure
to detach the plate before running the
programme.
Note
Leaving the liquid detergent level
plate in the detergent drawer while the
programme is running may result in
water leakage, or diminished washing
and spinning performance.
For the Wool programme, use mild liquid
detergent.
Powdered detergent2.
Detergent reaches the drum only when
water flushes through the detergent
drawer. Thus, if you forget to add
detergent, run the Drain programme.
Then, add detergent and start washing
again.
To prevent powdered detergent from
remaining in the drawer, perform the
following:
Dry the inside of the drawer with a cloth.-
Make sure that the detergent is not-
lumpy when you add it as this may
cause a blockage over time.
Amount of Detergent
The amount of detergent you should use
depends on the following factors:
How soiled the laundry is-
The amount of the laundry-
Water hardness-
The amount of foam varies according to
the amount and type of detergent, how
soiled the laundry is, and the hardness and
temperature of the water.
Water softening agent
If you live in a hard water area, we
recommend the usage of a water softening
agent. For more details on water hardness,
contact your local water authority.
Use of a water softening agent can help
reduce the amount of detergent that is
required for each wash and help prevent
the formation of limescale deposits, which
may damage the appliance.
NA-148VB5_English_UK.indb 16 2013-12-13 17:28:26

Read Before Using - 17
Adding Detergent and Other Chemicals
Undiluted
softener Water
Softener compartment
The following additives may be added to
this compartment:
Fabric softener-
Laundry starch-
Fabric Softener
To prevent static, add softener before you
start washing. It will be automatically added
in the final rinse cycle.
Dilute concentrated softeners before you
add them. Add up to only 125 ml to the
compartment to avoid overflowing.
Rinse out the remaining softener with
a splash of water or a damp cloth after
washing. If it sticks to the compartment,
pull out the drawer and clean it out. (See
page 32-33.)
Note
Follow the directions on the softener
packages for the appropriate amounts.
If too much softener is added, it may
remain in the detergent drawer.
Laundry starch
Simply add laundry starch to the softener
compartment. It will be automatically added
to the clothing as part of the final rinsing
process. Make sure that you do not fill the
compartment over the MAX level.
If it is hard to pour, you can dilute the
starch slightly with water before adding it.
Note
After using starch, clean the detergent
drawer, especially the softener cover
(see page 32-33). Then, run the Rapid
15 programme WITHOUT detergent to
remove any excess starch in the drum.
Prewashing compartment
Detergent for prewashing
Whenever you use the Cotton (Prewash)
programme (
+
) always put
detergent for the prewash in this
compartment.
NA-148VB5_English_UK.indb 17 2013-12-13 17:28:26

18 - Read Before Using
Using the Buttons and Dials
Cotton
Cotton
Easy Care
Wool
Rinse
Colours
Mixed
20℃ Wash
Shirts
Quick
Rapid 15
Spin
Bedding
Sportwear
Off
Drain
Start
Pause
r/min Extra
Rinse
Easy
Iron
Speed
Eco
Time
Eco
ChildLock
20
1
4
25 6 7 83
Model NA-148VB5
Buttons and dial
Programme selection dial1.
Use this dial to choose the best
programme for the laundry. (See pages
22.)
Start/Pause button2.
Press this button to start or pause the
wash programme.
Temperature button3.
For choosing water temperatures
ranging from cold to 90 ºC. (90 ºC is
available only with the Cotton and the
Cotton (Prewash) programmes.) You
can choose hotter temperatures for
whites, cottons, or soiled laundry.
Spin speed button4.
For choosing the spin speed for the
programme you have selected.
The maximum spin speed of models are
as follows.
148VB5, 147VB5 and 147VC5:-
1400 r/min
128VB5, 127VB5 and 127VC5:-
1200 r/min
Time button5.
For presetting the time for when the
wash is to start. (See page 30.)
Extra Rinse6.
Press this button to select the Extra
Rinse function. (See page 30.)
Easy Iron button7.
Press this button to select the Easy Iron
function. (See page 30.)
Speed/Eco and Child Lock button8.
Press this button to select the Speed/-
Eco function. (See page 30.)
Press and hold this button for 5-
seconds to set the child lock. The
controls will be locked. Perform the
same operation to release the child
lock. (See page 30.)
NA-148VB5_English_UK.indb 18 2013-12-13 17:28:27

Read Before Using - 19
Using the Buttons and Dials
Display
4 5 6 7 8 9
1 2 3
Time bar indicator1.
The number of displayed bars increases
with time.
Process2.
This indicator shows the current process-
of the programme. The process consists
of wash , rinse , and spin .
- is displayed only when the Drain
programme.
The indicator goes off when the wash is-
finished.
Lock3.
- is displayed if the door is locked.
- is displayed if the child lock is
activated. (See page 30.)
Temperature4.
Cold setting5.
This indicator is displayed when you turn
on the Cold setting.
Spin speed6.
Remaining time7.
This indicator shows the approximate
time until the washing finishes. For
example, ‘2:05’ means 2 hours and 5
minutes.
Time8.
This indicator is displayed if the time
for when the wash is to start has been
preset.
Option functions9.
These indicators are displayed when
their respective functions have been
programmed. The option functions that
display here are the Extra Rinse , Easy
Iron , Eco , and Speed functions.
Unlocking the door
The door automatically locks while in use,
and the symbol is shown while the door
is locked. A click will be heard when the
door locks or unlocks.
Note
While the door is locked, if the-
appliance is switched off, or if there
is a power interruption, the door will
unlock after 1 or 2 minutes.
Press the Start/Pause button to unlock
the door during operation.
In the following cases, the door can’t be
unlocked even if operations are paused.
During spin-drying-
When the water level is beyond a certain-
level
Note
If you want to unlock the door, set-
the programme selection dial to Off,
and then select a programme (ex.
Cotton).
Caution
If you have to unlock the door
mid-programme, make sure that
water from the drum does not
overflow onto the floor.
Water and soap suds might come out
of the door and the door opening. You
may need a towel to soak them up.
Model NA-148VB5
NA-148VB5_English_UK.indb 19 2013-12-13 17:28:28

20 - Washing Instructions
Washing
Open the door and put the laundry1.
into the drum.
For details about preparing and sorting
the laundry, see pages 14 and 22.
Caution
Make sure to place the laundry-
within the drum so that it does not
get caught in the door.
Failure to observe this may-
result in damage to the door seal,
leading to malfunctions.
Do NOT overload the drum.-
This may cause excessive vibration
or damage to the appliance.
Correct Incorrect
Note
When loading a big amount of laundry,
make sure to evenly distribute the
laundry throughout the drum.
Close the door.2.
Turn the programme selection dial3.
either way to switch on the appliance
and select the programme.
A wash time will be displayed.
For more details about each
programme, see pages 26-27.
20°C Wash programme
This programme achieves the same
cleaning strength with 20°C low-
temperature washing as 40 °C programme
(except for greasy stains).
Spin programme
With the Spin programme, the operation
starts from the drain process whether
there is water in the drum or not. After the
water drains out to a preset level, the spin
process starts.
Select optional functions.4.
For more details about available
functions and settings for each
programme, see pages 26-27.
Add detergent to the detergent5.
drawer.
(See pages 15-17.)
Setting washing
Cotton
Cotton
Easy Care
Wool
Rinse
Colours
Mixed
20℃ Wash
Shirts
Quick
Rapid 15
Spin
Bedding
Sportwear
Off
Drain
Start
Pause
r/min Extra
Rinse
Easy Speed
Eco
Time
Eco
ChildLock
20
Iron
63
Model NA-148VB5
NA-148VB5_English_UK.indb 20 2013-12-13 17:28:28
