Panasonic NA-F70B5 Product guide

Model No.
NA-F70B5
NA-F65B5
NA-F62B5
NA-F62B3
Thank you very much for purchasing
Panasonic Product.
Before operating this washing machine,
please read these instructions completely,
paying special attention to Safety Precautions.
Contents
Safety Precautions .................. 2
Part Names ............................... 3
Operation Panel ....................... 4
Variety of Courses ................... 5
Washing .................................... 6
Washing Options ..................... 8
• Delicate
• Soak
• Bed sheets
• Air Dry
• Wash/Rinse/Spin
Convenient Functions............ 10
Maintenance ........................... 10
Installation .............................. 12
Troubleshooting .................... 14
Error Messages ...................... 15
Specifications ......................... 16
Preparations How to Use When Necessary
W9901-9UL00
H0315-0
Printed in India
March 2015
Operating & Installation
Instructions
Fully Automatic Washing Machine
(Domestic use)
NA-F706562B5F62B3India.indd1NA-F706562B5F62B3India.indd1 2015/02/1014:53:552015/02/1014:53:55

22
Safety Precautions
WARNING May cause serious
injury or death. CAUTION May cause minor or
moderate injury or
property damage.
To prevent the risk of danger to humans or property damages, make sure to follow the precautions described below.
■The descriptions are classified according to the degree of harm or damage caused by misuse.
WARNING
Make sure to provide a ground.
(To prevent electric shock by short circuit)
●Ask a service person for grounding work.
■For Power Plug and Cord
Prohibited matters
(To prevent fire or electric shock)
●Do not damage, modify, immoderately bend, twist,
pull, or bundle them. Do not put them close to heating
appliances. Do not put anything heavy on them.
●Do not connect/disconnect them with wet hand.
●Do not hold the cord when pulling out of the socket.
●Do not use a damaged cord and power plug. Also, do
not use them when the socket is loose.
Never disassemble, repair or remodel.
(To prevent fire or abnormal operation, resulting in
injury.)
Do not touch the tub until it
completely stops.
(Your fingers may be entangled in the laundry even
during slow rotation, resulting in injury.)
If the tub does not stop within 15 seconds when the
lid is opened during spin cycle, switch off the washing
machine immediately and call a service person.
Keep fire away from the main unit.
(To prevent fire)
Matters to be observed
(To prevent fire or electric shock)
●Use a socket solely that satisfies the rating
requirement. (Using in combination with other
appliances could cause fire.)
●Insert the power plug all the way seated.
●Wipe the plug periodically with dry cloth.
(Accumulated dust collects moisture, which may
cause insulation failure, resulting in fire.)
●Pull out the cord before cleaning or when not used for
a long period of time.
●If the power cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons to avoid a hazard.
Do not splash water over the
washing machine. Do not install at
a damp place or a place which may
be exposed to rain, water, etc.
(To prevent electric shock or fire)
●Balcony, bathroom, etc.
■For Tub and Main Unit
Do not allow children to use alone.
●This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
●Children should be supervised to ensure that they do
not play with the appliance.
In case of emergency or operation
failure, stop using the washing
machine immediately and pull out
the power plug.
(To prevent fume, fire or electric shock)
●No operation even at power on, accumulated dust
and moisture on the power plug, abnormal sound in
operation, burnt odour, etc.
→Consult a service person for
inspection and repair
immediately.
NA-F706562B5F62B3India.indd2NA-F706562B5F62B3India.indd2 2015/02/1014:53:552015/02/1014:53:55

33
Preparations
Keep away magnetic objects such
as magnet from the operation panel.
(The tub may rotate even with the lid open, resulting in injury.)
■During Use
Do not put in flammable things or
clothes with such things attached.
Keep them away from the washing
machine.
(To prevent explosion or fire)
●Kerosene, gasoline, benzine/thinner, alcohol, etc.
CAUTION
Do not wash, rinse, or spin
waterproof sheets and clothes.
(Intense vibration during spin or falling of the machine
may result in injury, damages to the main unit, wall,
floor, etc., damage to the laundry, water leakage, etc.)
●Raincoat, wet suit, diaper cover, car cover, waterproof
sheet, etc.
Prohibited matters
●
The new hose-sets supplied with the appliance are to
be used and the old hose-sets should not be reused.
●Do not insert your hand or foot under the main unit.
(To prevent from getting caught in the rotation part,
resulting in injury.)
●Do not climb up or put heavy things on the washing
machine.
●
If the lid is broken, stop using this machine immediately.
(To prevent deformation and breakage, resulting in injury)
●Do not connect to a water heater or directly pour
water of 50 °C or more into the tub.
(The plastic parts may be deformed, resulting in
electrical leakage or electric shock.)
●Do not install at uneven or unstable locations.
Turn off the water faucet after
operation is complete.
(To prevent water leakage)
Part Names
●Water supply
hose (1)
●Screw (6)
• For bottom
cover
●Water tap
adaptor (1)
●External drain
water hose (1)
Accessories
Tub
●Bottom cover (1)
External drain
water hose
Pulsator
Adjustable leg
Lint filter Lid
Bleach / Liquid
detergent inlet
Operation
panel
Softener
inlet
Power cord
and plug
Water supply valve
Tub
NA-F706562B5F62B3India.indd3NA-F706562B5F62B3India.indd3 2015/02/1014:53:562015/02/1014:53:56

44
●Start.
●Pause.
●Select Wash/
Rinse/Spin. (P.9)
●Select the course.
(P.5)
NOTE ●At power-on, 1
Normal course is displayed.
●The type of course cannot be changed after start.
Operation Panel
●The operation panel for NA-F70B5 is used in this manual.
Reserve
Press this button to set how many hours later
the operation will be complete. (2 to 24 hours
by the hour.)
●3 Delicate, 7 Air Dry and 8 Tub Hygiene
courses cannot be reserved.
e.g.) 8 hours later
Change water level
Press the button while the
water level is being displayed.
(Some water levels cannot be
selected, depending on the
course.)
●You can select water amount
of 20 L manually.
●If this button is pressed while
remaining time is displayed,
you can check the water
level.
●Power On/Off
The power will be
turned off if the
washing machine is
left unattended for
10 minutes without
starting.
Detergent volume guideline
The detergent volume guideline
corresponding to the water level
indication is shown below.
(: 1 scoop of detergent)
Detergent volume
Water level
Water level/Remaining time
Indicates water amount
automatically adjusted according to
the amount of laundry after start.
Indicates approximate remaining
time (min).
Indicates the selected course (No.)
Auto Restart
In case of power failure during
operation, when the power is
recovered, the operation will
resume from the point where the
operation stopped.
(The indicator lights up when the
operation resumes.)
NA-F706562B5F62B3India.indd4NA-F706562B5F62B3India.indd4 2015/02/1014:53:562015/02/1014:53:56

55
Preparations
Everyday
clothes Daily washing 1Normal (P.6) 7.0 kg
6.5 kg6.2 kg
Speedy washing
for light soil
2Quick (P.6) 2.0 kg2.0 kg2.0 kg
Delicates Washing
delicates gently 3Delicate (P.8) 3.5 kg3.5 kg3.5 kg
Soak (90 min)
Washing heavily
soiled laundry
4Soak (P.8) 7.0 kg6.5 kg6.2 kg
Clothes for baby & people
with sensitive skin
Rinsing
thoroughly 5Baby-care (P.6) 7.0 kg6.5 kg6.2 kg
Bed Sheets 6Bed Sheets (P.9) 4.2 kg4.2 kg4.2 kg
Tub cleaning
To prevent black
mould and smell
7Air Dry (P.9)
8
Tub Hygiene (P.11)
―
―
―
―
―
―
If black mould or
smell is present
8
Tub Hygiene (P.11)
―――
Drying synthetic fibre clothes 7Air Dry (P.9) 2.0 kg2.0 kg2.0 kg
NOTE ●Normal course is recommended for a normally soiled load at the rated capacity of this washing machine.
Variety of Courses
Purpose Course (Number)
For clothes easily losing colour,
Wash separately.
For delicate underwear only
Use laundry nets.
• Underwire brassiere
→Select 3
Delicate course.
(To prevent the wire from sticking out)
• Lacy clothes, lingerie and stockings
When using a net
• Do not overpack.
• Put the claw of the zipper into the cover.
(To prevent damage to clothes and main unit)
• Do not use
7
Air Dry course.
(To prevent uneven dry and wrinkle)
Laundry preparation and check
Pre-laundry check
■To prevent malfunction and drainage
failure
• Remove metallic fragments and coins.
• Fasten buttons and close zippers.
• Do not wash things (paper diaper, etc.)
other than laundry.
■To prevent damage to clothes
• Reverse fluffy clothes.
• Using a brush, remove hairs of pet and
person, or sands, etc.
• Tie strings, etc.
Maximum
capacity
NA-
F70B5
NA-
F65B5
NA-
F62B5/
NA-
F62B3
NA-F706562B5F62B3India.indd5NA-F706562B5F62B3India.indd5 2015/02/1014:53:572015/02/1014:53:57

66
Washing
Preparation: ●Check whether the washing machine has been properly installed. (P.12)
●Turn on the water faucet.
1After loading the laundry,
turn the power on.
2
According to the type of laundry and soil,
select the course.
e.g.) Normal course
■For reservation (P.4)
After selecting the course,
select how many hours later you wish
to complete the entire operations.
(Indications other than “Reserve” turn off
in 2 minutes after start.)
●After reservation is set
• Change or cancel
→
Press “Off” and do the procedure again.
•
Check the course
→Press “Program”.
• Check the reservation time
→Press “Reserve”.
• Check the water level
→Press “Water Level”.
3Start.
The pulsator operates without water
and measures the load.
(approx. 5 seconds)
●When Quick course is selected, the
water level is displayed immediately.
Water level indication
(approx. 5 seconds)
Remaining time indication
●To check the water level
→Press “Water Level”.
Water begins to be supplied.
NOTE
●When powdered detergent is poorly soluble, dissolve in
warm water before putting in.
Water of approx. 30 °C
(approx. 5 L)
• Put in the detergent little by
little while stirring to prevent
it from getting hard or
remaining in a powder state.
●If there are many thick or large clothes (jeans, sheets, etc.)
in the tub, the detergent may remain dissolved. Dissolve
the detergent according to the above method, or reduce the
amount of laundry.
●If excessive bubbles form, reduce the amount of detergent
or change the detergent.
4According to the water level,
put in the detergent.
(Follow the instruction
described on each
detergent’s container.)
Put in the powdered
synthetic detergent
Softener (P.7)
Liquid detergent
●
Dilute sticky type
of detergent with
water before putting
in.
5Close the lid.
The operation is complete with the
buzzer sound.
For reservation Select the course.
Turn the power on.
Start.
NA-F706562B5F62B3India.indd6NA-F706562B5F62B3India.indd6 2015/02/1014:53:572015/02/1014:53:57

77
How to Use
Put the softener in the softener inlet
according to the water level indication.
●Automatically added on the final rinse.
●To add in operation, press “Pause” first.
●Do not use a separated or solidified softener.
●Softener easily becomes hard. Do not leave in the softener
compartment for many hours (12 hours or longer).
Undiluted
softener
Water Water
●Well mix in another
container before putting in.
(To facilitate smooth flow)
●Follow each softener’s
instructions.
■Concentrated type
Dissolve softener.
●If “Pause” is pressed during spin cycle, the softener will be
added too early and its effectiveness will decrease.
●The softener will not be added automatically if not put in by
the time “Wash” cycle is complete.
●Turn the tub with hand when it is difficult to put in the
softener. (P.10)
NOTE
●Do not use a bleach for 3
Delicate course.
●Do not use a chlorine bleach for coloured and printed
clothes. (Loss of colour may result.)
●If a chlorine bleach is used, wash the tub with 8
Tub
Hygiene course without bleach.
NOTE
■Oxygen powder bleach
Put the bleach
in directly
during water
supply after
start.
Follow each bleach’s
instructions.
■Liquid bleach
Undiluted
bleach
Water
+
After diluting with the same
amount of water,
put the bleach in
the bleach inlet
before start.
Using softener Using bleach
NA-F706562B5F62B3India.indd7NA-F706562B5F62B3India.indd7 2015/02/1014:53:572015/02/1014:53:57

88
NOTE
●Use a liquid detergent for stylish garments.
●Do not use a bleach.
Load the laundry.
Put in the laundry evenly.
●First, put in things that easily float on the
water, and press the laundry from above.
●Use a commercially sold net for delicate
clothes.
●Amount of laundry that can be washed at
one time
42 L 3.5 kg
37 L 2.0 kg
Delicate Soak
Washing Options
Preparation: Turn on the water faucet.
1Turn the power on.
2
Select
4
Soak course.
3Start.
4According to the water
level indication
(approx. 5 seconds),
put in the
detergent.
5Close the lid.
The operation is complete with the
buzzer sound.
●Take out the laundry immediately.
(To prevent wrinkle and colour staining)
Preparation: Turn on the water faucet.
1Turn the power on.
2
Select
3
Delicate course.
3Start.
4
Put in the
liquid detergent.
5Close the lid.
The operation is complete with the
buzzer sound.
●Take out the laundry immediately.
(To prevent wrinkle and colour staining)
This course gently washes delicate clothes and stylish garments.
Select operation contents.
NA-F706562B5F62B3India.indd8NA-F706562B5F62B3India.indd8 2015/02/1014:53:572015/02/1014:53:57

99
How to Use
Preparation: Turn on the water faucet.
1After putting the bed sheets
included in the net in the tub,
turn the power on.
●Face the zipper part of the net up.
(To prevent damage to the laundry
net)
2
Select
6
Bed Sheets course.
●Water level indication
NA-F70B5: 52 L
NA-F65B5: 48 L
NA-F62B5: 46 L
NA-F62B3: 46 L
●Water level cannot be changed.
3Start.
4
Put in the
liquid detergent.
5Close the lid.
The operation is complete with the
buzzer sound.
Bed Sheets
Wash/Rinse/Spin
Air Dry
Preparation: Turn on the water faucet.
1After loading the laundry,
turn the power on.
2According to the purpose,
select operation contents.
●Change the water level as necessary.
●You cannot select Rinse alone.
3After closing the lid,
start.
The operation is complete with
the buzzer sound.
This extracts water from clothes by air blow utilising the tub rotation.
(Agitation is performed approx. every 30 minutes to untangle
the laundry.)
■Clothes that can be dried
●Material: Synthetic fibre
●Weight: 2 kgmax.
1After loading the laundry and closing
the lid,
turn the power on.
2Select 7Air Dry course.
3After closing the lid,
Start.
The operation is complete after
90 minutes with the buzzer sound.
■Washable bed sheets
●Material: Synthetic fibre 100 %/Cotton 100 %
●Weight: 4.2 kgmax.
●Bed sheets with a washable tag attached
●The laundry may not be sufficiently dried depending on
the amount of the load, type of clothes, temperature, and
installation condition of the washing machine. (Since no
heater is used for this function, some users may feel the
laundry is cold and not dry.)
NOTE
Select 3 Delicate/ 4 Soak/ 6 Bed Sheets/ 7 Air Dry course.
Turn the power on.
Start.
Roll
Net
NA-F706562B5F62B3India.indd9NA-F706562B5F62B3India.indd9 2015/02/1014:53:582015/02/1014:53:58

1010
Lint filter
After each operation
■If removing the filter is difficult
Turn the tub. (See left.)
■If the filter is broken
Buy a new filter at nearest Panasonic Service Centre.
●Do not wash laundry with the filter removed.
(To prevent damage to clothes)
NOTE
Maintenance
1
Hold the upper
part and remove.
2Open the filter
and remove
the lint.
●If removal is difficult,
soak the filter in water
and wash.
3Attach to the original position.
Click
1
3 4
2
Cancelling end buzzer
Setting Child Lock
Turning the tub with hand
●If there is water in the tub or “Start” is pressed, the tub
cannot be turned.
NOTE
Convenient
Functions
Pressing down, press.
●To reset, do the same procedure.
pi pi
pi pi
Then hold on
for 3 seconds. pi pi
If the lid is opened during operation with this function activated,
the buzzer continues to beep until the lid is closed. If the lid is
opened for 10 seconds or more, the water is forcibly drained.
(To prevent children from falling in the tub and drowning)
●This function does not lock the lid and button operations.
●
Set the drain hose in the condition where water can be drained.
●If water is drained forcibly, “U99” is displayed. (P.15)
1After closing the lid,
turn the power on.
2Press 5 seconds. pi pi
●To cancel, do the same procedure.
pi pi
pi pi
When it is difficult to remove the lint filter or add softener
1Turn the power on.
2When clicking sound is heard after approx.
15 seconds,
turn the tub.
(Clockwise only)
NA-F706562B5F62B3India.indd10NA-F706562B5F62B3India.indd10 2015/02/1014:53:592015/02/1014:53:59

1111
When Necessary
1Turn off the faucet.
2
Turn the power on.
3After closing the lid,
start.
4After approx. 40 seconds,
turn the power off.
5Loosen the nut.
6Remove the
hose and
water supply
filter.
Water supply filter
7Remove the
dust of water
supply filter.
Wipe with a soft cloth.
(To prevent damage to resin or metal corrosion)
●For heavy soil, use a neutral detergent for kitchen and wipe
off.
(Do not use other detergents or directly pour water.)
Water supply filter
Main unit/Lid
If water does not flow smoothly
If detergent or softener stains are found
Once a month (Wash)
Once a week (Dry)
Tub <Air Dry/Tub Hygiene>
Preparation: Turn on the water faucet.
1
Turn the power on without
laundry in the tub.
2Select 8Tub Hygiene
course.
3Start.
4When water supply is complete,
pause.
5Put the bleach
in the tub.
●Use a chlorine bleach for clothes.
Approx. 200 ml
6After closing the lid,
start.
The operation is complete
after approx. 2 and half hours.
1After operation is complete,
operate the washing machine
with 7Air Dry course without
laundry in the tub. (P.9)
●Make sure to observe the following procedure to prevent
spatter of water.
NA-F706562B5F62B3India.indd11NA-F706562B5F62B3India.indd11 2015/02/1014:53:592015/02/1014:53:59

1. Check the installation location.
3. Attach the external drain water hose.
2. Attach the bottom cover.
1212
Installation
■Avoid the following locations for installation.
• Locations where there is a possibility of freezing.
• Locations exposed to direct sunlight
(To prevent malfunction or deformation)
• Uneven or unstable locations
(on blocks, timbers, table with wheels attached, etc.)
●Do not block the opening of the bottom face with carpet, etc.
●Insert all the way seated.
NOTE
Connect to the
connection port.
■Hose arrangement
Slide the hose
band in the arrow
direction.
1 2
10 cm
or less
NG
3 m or less
●Do not put the hose tip
under the water.
●The height should be
10 cm or less.
●The extension length
should be 3 m or less.
(Bottom face)
Water supply
hose
Water tap adaptor
Water
supply
valve
screw
Preparation: Set a cardboard, etc. and lay the washing machine on it, avoiding
product damage and deformation. (Face the front side down.)
1Insert along the guides, and set 3 holes to the
corresponding projections.
Hole
Projection
Guide
Hole
2Fix with screws.
(6 locations for right, left and top)
Screw hole
■If the installation, test run and inspection of the washing machine are not
carried out following this installation method, Panasonic will not be liable
for any accident or damage caused.
■
Make sure to ask a service person for installation. Do not install by yourself.
Hose band
External drain water hose
Main unit rear side
Hose band
NA-F706562B5F62B3India.indd12NA-F706562B5F62B3India.indd12 2015/02/1014:54:002015/02/1014:54:00

5. Connect the power plug and grounding wire.
7. Perform a trial operation.
6. Check the horizontal state.
4. Connect the water tap adaptor and water supply hose.
●Check if there is no water leakage, abnormal sound or error messages.
1313
When Necessary
●Ask a service person for grounding work.
■
Adjusting height with the adjustable leg knob.
1) Turn the adjustable leg knob to the left side and loosen
as indicated with the left pointing arrow. Then, turn the
adjustable leg to adjust the levelness.
2) Turn the adjustable leg knob to the right side and
tighten securely as indicated with the right pointing
arrow.
Adjustable leg
knob
Tighten
Loosen
Adjustable leg
To raise To lower
1Connect the water tap adaptor
to the faucet.
1) Turn Apart to the left until approx.
4 mm of the thread becomes visible.
2) Loosen 4 screws.
3) Connect to the faucet and tighten the
screws.
2Fix.
●Turn Apart to the right side and
tighten securely.
(To prevent water leak)
3Connect the water supply hose
to the water tap adaptor.
●Pushing down the lever, insert and hook
the claw of the lever on the flange of the
adaptor.
4Connect the water supply hose
to the water supply valve screw.
●Slightly lift up the elbow and tighten the
nut.
●Check if the elbow is not loose.
Elbow
Water supply
valve screw
Nut
A
part
Screw
thread
Lever
CAUTION
●Tighten the nut firmly.
(To prevent water leak)
●Do not forcibly bend the water
supply hose.
(To prevent water leak caused by
the bent hose)
Lever
Claw Flange
NA-F706562B5F62B3India.indd13NA-F706562B5F62B3India.indd13 2015/02/1014:54:002015/02/1014:54:00

1414
Troubleshooting
Check the following before requesting service.
Symptoms Checkpoints
Time
Remaining time fluctuates. ●Remaining time is corrected during the process and displayed.
(Time indication is an approximation.)
Main unit
No operation.
●Power failure?
●Is the lid closed completely?
●Is the power fuse or the breaker cut off?
●Is the power plug plugged in completely?
●Is the water faucet turned on?
●Is the “Start” button pressed?
●Has the Reserve program been set?
Cannot change the operation
contents. (after start)
●The contents can be changed in Wash process by pressing “Pause”. To
change the course or to change the contents after Rinse process, turn the
power off and then on again.
Wash
No water supply.
●Is the water faucet turned on?
●Water failure?
●Is the water supply filter clogged with dust? (P.11)
Water is supplied in the middle
of Wash process.
●When level goes down, water is supplied automatically.
●With large amount of laundry, water is supplied several times automatically.
The water level is too high for
the amount of laundry.
●If the laundry is wet or if there is water in the tub before operation, the water
level may be higher.
The water level is too low for the
amount of laundry. ●With light clothes (synthetic fibre, etc.), the water level may be lower.
Rinse/Spin
The operation started with Rinse
process, however, water is not
supplied.
●If there is no water in the tub, water is supplied after spin.
●If there is water in the tub, water is supplied after water discharge.
The operation suddenly changes
to rinse process in the middle of
spin process./
Only spin is desired, however,
the operation starts with rinse.
●If the laundry is unevenly placed in the tub, the machine starts to rinse and
automatically corrects the arrangement.
(Put the laundry as evenly as possible.)
Irregular rotation during spin. ●The tub rotation speed is adjusted to reduce bubble foaming during spin.
Others
Power failure./
The breaker has tripped.
●The operation will stop. When power is recovered, the operation will resume.
(“Auto Restart” indicator lights up.)
Water failure. ●After water supply is recovered, remove the water supply hose to release
muddy water from the faucet, and start the operation.
Operation does not finish even
after the reservation time.
●Operation time will become longer if laundry leans to one side or water
supply or drainage is ill-conditioned.
NA-F706562B5F62B3India.indd14NA-F706562B5F62B3India.indd14 2015/02/1014:54:002015/02/1014:54:00

NA-F706562B5F62B3India.inddA-1NA-F706562B5F62B3India.inddA-1 2015/02/1014:54:002015/02/1014:54:00

NA-F706562B5F62B3India.inddA-2NA-F706562B5F62B3India.inddA-2 2015/02/1014:54:002015/02/1014:54:00

Error Messages
1515
When Necessary
Symptoms Checkpoints
Water cannot be drained.
■Check the drain water hose for the following abnormality.
●Is it crushed?
●Is lint clogged?
●Is the tip soaked in water?
●Is a part of hose at a height of over 10 cm midway? (P.12)
●Is the extension hose longer than 3 m? (P.12)
The lid is open.
●Is the lid open?
Spin or Air Dry
does not work.
●Is the laundry on one side?
→Arrange the laundry evenly in the tub, and then close the lid.
●Is the washing machine on an unstable location or inclined floor surface?
→The operation will resume by opening/closing of the lid.
Water cannot be
supplied.
●Is the water faucet turned on?
●Water failure?
●Is the water supply filter clogged with dust? (P.11)
●Water is forcibly drained since the lid has been open for 10 seconds or more with Child
Lock (P.10) function set.
→Pull out the power plug and reconnect after 5 seconds.
●Inspection is required.
→Pull out the power plug. Then, contact a service person and explain the displayed
content (2-digit number after “H”).
The operation will
resume by opening/
closing of the lid.
The operation will
resume by opening/
closing of the lid.
If the buzzer sounds and “U”/“H” and “Number” are alternately displayed, check the following.
If the problem persists or any other malfunctions occur, pull out the power plug and contact a service person for service.
●Cancel Child Lock (P.10) when it is active.
NA-F706562B5F62B3India.indd15NA-F706562B5F62B3India.indd15 2015/02/1014:54:002015/02/1014:54:00

1616
Specifications
NA-F70B5 NA-F65B5 NA-F62B5/
NA-F62B3
Rated voltage 230 V
Rated frequency 50 Hz
Rated power consumption 423 W 408 W 400 W
Standard water amount 52 L 48 L 46 L
Maximum capacity 7.0 kg6.5 kg6.2 kg
Product dimensions 525 mm (W) × 571 mm (D) × 969 mm (H) 525 mm (W) × 571 mm (D) × 929 mm (H)
Product weight 31 kg30 kg
Pressure of tap water 0.03 - 1 MPa (0.3 - 10 kgf/cm2)
Declaration of Conformity with the requirements of the
e-waste (Management and Handling) Rules, 2011
(adopted by Notification S.O.1035(E) of Ministry of
Environment and Forests)
The Product is in conformity with the requirements of
Rule 13 of the e-waste Rules.
The content of hazardous substance with the
exemption of the applications listed in SCHEDULE II of
the e-waste Rules:
1. Lead (Pb) – not over 0.1 % by weight;
2. Cadmium (Cd) – not over 0.01 % by weight;
3. Mercury (Hg) – not over 0.1 % by weight;
4. Hexavalent chromium (Cr6+) – not over 0.1 % by
weight;
5. Polybrominated biphenyls (PBBs) – not over 0.1 %
by weight;
6. Polybrominated diphenyl ethers (PBDEs) – not over
0.1 % by weight.
Disposing of Waste Electrical & Electronic Equipment
For the purpose of recycling to facilitate effective
utilization of resources, please return this product to
a nearby authorized Collection Centre, registered
Dismantler or Recycler, or Panasonic Service Centre
when disposing of this product.
Please see the Panasonic website for further
information on Collection Centres, etc.
http://www.panasonic.com/in/corporate/sustainability/
panasonic-india-i-recycle-program.html
NA-F706562B5F62B3India.indd16NA-F706562B5F62B3India.indd16 2015/02/1014:54:012015/02/1014:54:01

MEMO
NA-F706562B5F62B3India.indd17NA-F706562B5F62B3India.indd17 2015/02/1014:54:012015/02/1014:54:01

Panasonic Corporation
http://www.panasonic.com
© Panasonic India Pvt. Ltd. 2015
NA-F706562B5F62B3India.indd20NA-F706562B5F62B3India.indd20 2015/02/1014:53:552015/02/1014:53:55
