Panduit PA22193A01 User manual

CUTTING TOOL
For Cutting
PANDUCT Plastic Wiring Duct or
Cover, and Heat Shrink Tubing
© Panduit Corp. 1996
For Technical Support:
www.panduit.com/location/index.asp
Email: cs panduit.com
Fax: [phone]
Page: 1 of 1
PA22193A01
REV.: 03 6-2004
INSERT
BLADE
HOOK
SPRING
DCT
LATCH
DCT
Part No. DCT
WARNING: SAFETY GLASSES MUST BE WORN AT ALL TIMES WHEN
USING THE DCT TOOL.
USE CARE WHEN HANDLING TOOL; BLADE IS SHARP!
CAUTION: This precision tool has been engineered and designed for use with
P
ANDUCT
Plastic Wiring Duct or Cover, and Heat Shrink Tubing. It is not
intended for use on any other products or materials.
OPERATION
1. Determine (mark) the cut location as required.
2. Release the handle latch at the end of the handles. The handle spring allows the handles to be
normally open.
3. Position the cutting blade at the marked location and squeeze the handles together until the material is cut through,
and the blade bottoms out in the blade insert. If the cut is not long enough, also cut from the opposite side, across from
the first cut.
4. Latch the tool handles in the locked position when the tool is not being used and during transport.
REPLACEMENT PARTS
DCT-BLD Blade Replacement Kit (includes replacement blade and insert)
DCT-RI Replacement Insert (includes insert only)
Blade Replacement: Unhook spring from hook on blade. Using a wide blade standard screwdriver and 10mm hex
wrench, remove nut and screw. Slide blade upward, out of tool, and replace with new blade.
Fasten using existing screw and nut. Remember to hook spring onto hook on blade.
Insert Replacement: Carefully pry out existing insert. Apply a small amount of Loctite Black Max (or equivalent) to
bottom of replacement insert. Place insert into lower jaw of tool with the slotted side up.
www.panduit.com
DUCT CUTTINGTOOL
OPERATING INSTRUCTIONS
