Panduit smartzone G5 User manual

Customer Service: [e-mail] 800.777.3300 Technical Support: [e-mail] 866.405.6654 page 1
IM036 Rev 00
INSTALLATION GUIDE
Electronic Swinghandle without Card Reader
SWINGHANDLE INCLUDED INSTALLATION PARTS
ACE01:
Electronic Swinghandle
without Card Reader
Cam
Screw
Standard
Stop Disc
Extended
Stop Disc
Top Mounting
Bracket
Bottom Mounting
Bracket
Top Mounting
Screw (14mm)
Bottom Mounting
Screws (25mm)
Keys

Customer Service: [e-mail] 800.777.3300 Technical Support: [e-mail] 866.405.6654 page 2
IM036 Rev 00
INSTALLATION GUIDE
Swinghandle Lock Mounting Option for Front and Rear Door
1. If needed, remove any existing lock mechanism. Save the Cam (latch) for later steps.
NOTE: The Swinghandle’s lock requires a cut-out of 150x25mm. Reference Figure 2for the following steps. Use a
#1 POZIDRIV driver when securing the mounting screws for Top and Bottom Mounting Brackets.
2. Position the lock body within the cut-out and flush to the outer face of the cabinet door. Use the 14mm Top
Mounting Screw and Top Mounting Bracket to secure the lock to the door.
3. Select a suitable Stop Disc (standard or extended) and mount the cam assembly from Step 1. Secure using the
included Cam Screw. Pay careful attention to the orientation of the Stop Disc according to your installation
requirements.
Figure 1: Swinghandle Installation onto Cabinet Door
4. Ensure that the orientation of the lock plug corresponds to the orientation of the Bottom Mounting Bracket and
install the Bracket using the included 25mm Bottom Mounting Screws.
