© Panduit Corp. 2016 INSTALLATION INSTRUCTIONS
For Technical Support: www.panduit.com/resources/install_maintain.asp
V00029LA
Page 1 of 2
D-Type Finger Bracket Kit
Part Number(s) : D12FBB, D15FBB
Finger Bracket Installation
• Remove Shipping Brackets.
• Install Finger Brackets.
Note: Front E-Rails should be located a minimum of 126mm (4.96”) from the front or rear of the cabinet.
12
REAR
2x Shipping
Bracket
Use caution
handling once
the shipping
bracket is
removed
M5 x 0.8
T25 Torx head
screws
Tools needed:
• T25 Torx driver

© Panduit Corp. 2016 INSTALLATION INSTRUCTIONS V00029LA
Page 2 of 2
For Instructions in Local Languages
and Technical Support:
www.panduit.com/resources/install_maintain.asp
E-mail:
[email protected]
Phone:
866-405-6654
www.panduit.com
• Locate Fingers so the distance between ngers is centered in RU spacing.
• If applying the Finger Bracket Kit to the rear E-Rails follow the same Installation process on the rear E-Rails.
Position Finger opening over center of RU space
(Noted by the notch in center Cage Nut opening)
Placement
C
L
Notch
