Panduit NET-ACCESS SN7TCDW User manual

INSTRUCTIONS V00029AK
© Panduit Corp. 2013
FOR TECHNICAL SUPPORT www.panduit.com/resources/install_maintain.asp
Page 1 of 2
Top of Cabinet Divider Wall - Screw Installation
• Pre-assemble screws and square nuts to divider wall
•DO NOT completely tighten screws
- INSTALL -
[4] M6 Torx Screws
(use T25 Torx bit)
N ET -A CCESS N-Type and S-Type Top of Cabinet
Divider Wall
(SN7TCDW, SN8TCDW )
- INSTALL -
[4] M6 Square Nuts

INSTRUCTIONS V00029AK
For Instructions in Local Languages
and Technical Support:
www.panduit.com/resources/install_maintain.asp
E-mail:
[email protected]
Phone: [phone]
www.panduit.com
Page 2 of 2
Top of Cabinet Divider Wall - Installation
• Position [2] square nuts of Top of Cabinet Divider Wall above [2] square cutouts of Top of Cabinet Cable Manager
• Insert [2] square nuts into square cutouts of Top of Cabinet Cable Manager
• Slide Top of Cabinet Divider Wall along slot until other set of [2] square nuts is above square cutouts
• Insert remaining set of [2] square nuts into square cutouts
• Slide Top of Cabinet Divider Wall to desired position and tighten screws
- TIGHTEN -
[4] M6 Torx Screws
(use T25 Torx bit)
Slide Top of Cabinet
Divider Wall to
desired position
- INSERT -
M6 Square Nuts into
Square Cutouts
