Installation Instructions – SW3-606
GPSB Series
Introduction
A.
The GPSB series is a high performance combination quad function
antenna in an OEM style shark fin housing. The antenna has an active
GPS antenna with a 26dB gain LNA suitable for 3 to 5 volt supply via
the GPS coax cable.The GPSB is suitable for fitment to standard vehicle
panels of up to 4mm (0.16”) thickness.
Heat shrink tubes are included in the kit, to enable the coaxial connections
to be sealed as an extra precaution if required.
SW3-606 - Document Version 1.2
Mounting requirements and selecting location
B.
This antenna must be fitted on a conductive ground plane of minimum ½ wavelength diameter at the lowest frequency of
operation; to calculate see below:
150 / frequency in MHz = ½ wavelength (m)
Examples: 150MHz =100cm (39.4”); 400MHz = 38cm (15”); 900MHz =16cms (6.3”).
When fitting on a non-metallic panel, a ground plane plate of suitable size should be fabricated and fitted under the mounting
panel; the securing washer and nut must make a low resistance electrical contact with this plate (< 0.2Ω). Select a mounting
location, checking for roof curvature to ensure that the antenna base will have a flat mounting surface. The antenna should
be located as far as possible from surrounding roof mounted items (e.g light bar, air con unit). Ensure that there is adequate
under panel clearance and that there is no double skin panel or cross brace present. Measure to check for central position
if applicable.
Prepare and drill hole
C.
Mask panel area around hole position to protect paintwork and headliner.
Drill a pilot hole, and then increase to 19mm (3/4”), ensuring that drill/cutter bit does
not contact headliner. Clean area around the hole, carefully removing all swarf.
Remove paint and primer from under panel surface to ensure adequate earth contact
by washer and nut. Apply some petroleum jelly or paint around the hole to prevent
corrosion.
Hole
∅19
Fitting the antenna
D.
Remove protective backing from underside of antenna, feed coaxial cable(s) through panel. Position the antenna over the
hole ensuring correct orientation and stick to panel by applying firm downward pressure. Assemble washer and nut from
underside and tighten - recommended torque is 5Nm (3.7ft/lbs). Remove blanking cap and screw comms antenna whip
securely to mounting stud (if applicable).
Electrical Safety Note
This product contains an active GPS/GNSS antenna (part number SR8-HG26-04FJ). Rated voltage: 3-5VDC
Rated current: 20mA maximum.
The supply to these devices must be provided with overcurrent protection of 1A maximum.

Commission and test
F.
Check GPS cable:
• ChecktheGPScablewithDCtomeasurehighresistance.
• ConnecttheGPScabletotheGPSreceiverandcheckforsatelliteacquisition.
Check comms cable(s):
• Earthcontinuity:connectorbodytovehiclegroundshouldmeasure<0.2Ω;
• Connectorbodytocentrepinshouldmeasureopencircuit.
• CarryoutVSWRcheck,shouldmeasure<2.5:1intransmitband(antennatypedependent).
• ConnectGSM/Cellular,LTE&WLANcablesorstowunusedpigtails.
European Waste Electronic Equipment Directive 2002/96/EC
Please ensure that your old Waste Electricals and Electronics are recycled do not throw them away into
standard waste.
RF Safety Note
This antenna should be mounted in such a way that no person is within 20cm (8”) of the antenna during use.
Notices
G.
SW3-606 -www.panorama-antennas.com
Panorama Antennas Ltd | 61 Frogmore, Wandsworth, London, SW18 1HF, UK | Phone: [phone]
Routing and terminating coaxial cable(s)
E.
If heat shrink tubes are to be used, slide onto antenna cable tails prior to connecting extension cables – it is recommended
that these are heat shrunk only after tests have been satisfactorily completed. Connect extension coaxial cables to antenna
and route to equipment, taking care to avoid running adjacent to existing vehicle wiring or fouling any moving vehicle com-
ponent. The cables must not be routed in front of any airbag device. Fit correct coaxial connector or adapter to cables as
required.
R&TTE: DIRECTIVE 1999/5/EC of 9 March 1999 on radio equipment and telecommunications terminal
equipment and the mutual recognition of their conformity. Compliance is declared according to: EN 301
489-1 V1.9.2 – Electromagnetic compatibility and radio spectrum matters (ERM); Electromagnetic com-
patibility (EMC) standard for radio equipment and services; Part 1: Common technical requirements - Ref-
erencing EN 301 489-3 V1.6.1 and EN 300 440-1 V1.6.1 (2010-08) – Electromagnetic compatibility
and radio spectrum matters (ERM); short range devices; radio equipment to be used in the 1GHz to 40GHz
frequency range; Part 1: Technical characteristics and Test methods in accordance with EN 300 440-2
V1.4.1 (2010-8) - Electromagnetic compatibility and radio spectrum matters (ERM); short range devices;
radio equipment to be used in the 1GHz to 40GHz frequency range; Part 2: Harmonised EN covering the
essentialrequirementsofarticle3.2oftheR&TTEDirective.
Low Voltage Directive: Directive 2006/95/EC (Electrical Equipment designed for use within certain
voltage limits) of August 2007. Compliance is declared according to:
EN60950-1: Safety of information technology equipment – according to test specification EN 60950-
1:2006 +A11:2009 +A1:2010 +A12:2011.
EN60950-1: Safety of information technology equipment – according to test specification
EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011.
Waiver: This document represents information compiled to the best of our present knowledge. It is not intended to as a representation or warranty of fitness of the
products described for any particular purpose. This document details guidelines for general information purposes only. Always seek specialist advice when planning
installations and ensure that antennas are always installed by a properly qualified installer in compliance with local laws and regulations.
