Pantech Breeze IV User manual

User Guide
Thank you for choosing the Pantech Breeze IV.
The Pantech Breeze IV has many features
designed to enhance your mobile experience.
From its EZ to read menus, to its sleek, stylish
design, we know you will enjoy the entire
Breeze IV experience.
This User Guide contains important and useful
information that will maximize your familiarity
with all that the Pantech Breeze IV has to offer.

3
2
Specifications
Design
Clamshell phone with internal
and external display
Displays
•WQVGALCDwith3.0”internal
display
•qqVGATFTLCDwith1.44”
external display
•9linesfortextinbasicmode
with24pointfont
•Twosoftkeysandfour-way
scroll and pressing
Melodies
MIDI,i-Melody,MP3,AMR,WAV,
AAC,AAC+,WMA
Camera
Integrated3MCMOSCamera
• Resolutionupto2048x1536
(3MAFpixels)
•3GPVideorecording/playingup
to15f/s(QVGAsize)
•Self-timerfunction(Off/5secs/
10secs)
•Photoalbumandvideoalbum
•LEDCameraFlash(SupportOn/
Off)

3
2
Dimensions & Weight
Weight:102g(withstandard
battery)
Dimensions:106.5mmX53mm
X17.4mm
Power Management
(Performance)
Battery
Type Capacity Standby Time
Talk
Time
Standard
Lithium-
Ion
(Li-ion)
Up to
1030mAh
Up to
250
hours
Up to
3
hours
Operating Frequency
•GSM/GPRS/EDGE850/900/
1800/1900MHz,UMTS/
HSDPA850/1900/2100MHz
networksinNorthAmerica,
SouthAmerica,Europe,Africa,
andAsia-Pacicwherethese
networks are supported
•Automaticbandswitching

5
4
Specifications ................................... 2
Phone overview ................................8
Using Shortcuts..............................10
Menu overview................................. 11
Quick & Easy .................................... 14
SIM card and battery ..................... 17
Turning the phone on/off............ 20
Essential display indications...... 20
Setting the phone mode ..............23
Entering text ...................................24
Quick call keys................................ 26
PC Suite.............................................27
Memory card ...................................28
Breeze Mode
1. Calls and address book
Making,receivingandendinga
call........................................................ 34
Optionsduringacall ....................36
Checking all calls ...........................40
Speeddialing....................................41
Using address book......................42
Using your headset.......................44
Fixed dialing number ...................45
2. Messaging
Receivingmessages....................48
Creating and sending text
messages .........................................49
Creating multimedia
messages .........................................50
Managing messaging memory ...56
Email ................................................... 57

Contents
5
4
3. Multimedia
Camera ..............................................60
Photo album ....................................66
Video album.....................................68
4. Useful Features
Magnier ........................................... 72
Calendar............................................ 72
Alarmclock....................................... 74
PillReminder.................................... 75
User Guide ....................................... 76
Calculator ......................................... 77
Tip calculator .................................. 77
Stopwatch........................................ 78
SayaCommand............................. 78
ReadoutMode ................................80
SlowSpeech .....................................81
5. Connectivity
Bluetooth..........................................84
Using the web browser................ 87
6. Settings
Phone status....................................92
Sounds&alerts ..............................92
Displaysettings..............................93
Voice command setting.............93
Advanced Mode
1. Calls and address book
Making,receivingandending
a call.....................................................96
Call settings ....................................101
Checking all calls ..........................101
Speeddialing.................................103
Using address book....................104
Using your headset..................... 107
Fixed dialing number ................. 107
Calleridentication ....................108
SlowSpeech ..................................108

7
6
2. Messaging
Receivingmessages...................110
Creating and sending text
messages .........................................112
Creating multimedia
messages ........................................ 113
Message templates..................... 118
Message settings ......................... 118
Managing messaging
memory...........................................120
Email ...................................................121
3. Multimedia
Camera .............................................124
Photo album ..................................130
Video album....................................132
Audioalbum .................................. 134
Music player................................... 136
Music player settings.................. 141
Media player................................... 142
Otherles ....................................... 145
Managing memory ..................... 145
Playing games............................... 145
4. Useful Features
Magnier ......................................... 148
Calendar..........................................149
Alarmclock.....................................150
PillReminder................................... 151
User Guide ......................................152
Calculator ........................................153
Tip calculator .................................153
Stopwatch...................................... 154
Notepadandvoicememo ...... 154
Worldtime ...................................... 156
Converter........................................ 156
Timer..................................................157
SayaCommand............................157
ReadoutMode .............................. 159

Contents
7
6
5. Connectivity
Bluetooth........................................ 162
UsingUSBMode.......................... 165
Using the web browser.............. 165
Settingproles ............................. 167
6. Settings
Language........................................ 170
Time and date............................... 170
Voice command setting........... 170
Soundsandalerts ........................ 171
Displaysettings............................. 171
Security.............................................173
Updating software .......................174
Reset..................................................175
TTY..................................................... 176
7. Appendix
Alertmessage...............................180
Troubleshooting checklist ....... 181
Safetyinformation ...................... 184
Safetyprecautions ..................... 185
Aboutthebatteryusage ...........187
FCCHearing-AidCompatibility
(HAC)regulationsforwireless
devices.............................................. 191
FCCRegulatoryCompliance.... 195
Warranty..........................................199
SpeakerPhone&
Noise Cancel ................................206
DynamicNoiseSuppression
fromAudience............................. 207
earSmart™technology............208

Clear key
Returntopreviousscreenordeletes
characters in text mode.
Power on & off / Menu exit / End key
Turnphoneon/off,endscalls,exit
menus
Camera key
OK key or access Browser
Press to enter menu system
Left/Right Soft key
Perform the functions shown at the
bottom line of the display
Internal display
Earpiece
Navigation key
Scrollthroughthe
menu options
Quick Call Keys
Vibrate mode
Microphone 1
Voicemail
9
8
Send key
Voice Command
Phone overview

External Display Camera
Flash
LED Indicators
Message, Call,
Battery
Internal antenna
area
Microphone 2
Speaker
Micro USB
(Ear Mic. &
Charger)
note:Holdingthedevicebytheinternalantennaareamightaffectthequalityofallcalls.
9
8
Volume up /
down

11
10
note: The phone has integrated
advancednoisesuppressiontechnology.
Toensurevoicequality,pleasedonot
covermicrophoneentriesasindicated.
Using Shortcuts
Numbered menu items, such as
menus,sub-menus,andoptions
canbequicklyaccessedby
using their shortcut numbers.
In Menu mode, Main Menus
can be accessed by pressing
thenumberkeys(1to#)
corresponding to their location
on the screen.
Example:AccessingthePhone
Mode menu.
1.SelectMenu.
2.Press for Settings.
3.Press for Phone Mode.
4.PresstheU/D scroll key to
select the mode.
note:Thestepsmayvarybymodeand
thismanualprovidesinstructionsfor
both Breeze Mode and Advanced Mode
respectively.

11
10
Address Book
Contacts
Groups
Favorites
Settings
FixedDial
Numbers
SService
Numbers
Messaging
Conversations
Options
Create Message
 Delete
 Delete 
  Conversations
Templates
 Settings
Memory
Camera
Take Pictures
RecordVideos
My Pictures
My Videos
AT&T Services
SayaCommand
AT&TFamilyMap
AT&TNavigator
AT&TMusic
Games&Apps
myAT&T
MyAccount
Mobile Email
Browser
Tools
Magnier
Calendar
AlarmClock
PillReminder
User Guide
Calculator
Tip Calculator
StopWatch
Settings
PhoneStatus
Sounds&Alerts
Bluetooth
FontSize
Wallpaper
SlowSpeech
Voice Command
 Settings
Phone Mode
Menu overview
Breeze mode
menu
SSIMdependent

13
12
Advanced mode menu
Address
Book
Contacts
Groups
Favorites
Settings
FixedDial
Numbers
SService
Numbers
Messaging
Conversations
Options
Create
Message
Delete
Delete
Conversations
Templates
Settings
Memory
Mobile
Email
AT&T GPS
AT&T
Navigator
AT&T
FamilyMap
Browser
Home
Bookmarks
Enter
Address
History
Manage
My Stuff
Applications
Audio
Games
Video
Tools
OtherFiles
UsedSpace
SSIMdependentNNetwork dependent

13
12
Video Tools
Magnier
RecentCalls
Camera
Video Camera
Media Player
AlarmClock
Calendar
PillReminder
User Guide
Notepad
Voice Memo
WorldTime
Calculator
Tip Calculator
Converter
StopWatch
Timer
SayaCommand
AT&T Music
Music Player
ShopMusic
myAT&T Settings
Phone Mode
SoundProles
Display
NCall
Phone
Network
Connections
Network
Connectivity
SSecurity
NAT&T
Software
Update
Reset
TTY
Phone
Information

15
14
Quick & Easy
Keys Functions
Perform the functions shown at the bottom line of the display
by using these soft keys.
ScrollthroughthemenuoptionsinMenumode.Instandby
mode,
LeftScroll:AccessMy Stuff menu
RightScroll:AccessCalendar menu
UpScroll:AccessCreate Message menu
DownScroll:AccessContacts menu
Selectamenufunctionorstoreuser-inputinformation,such
asnames.Alsousethiskeyforconrmation.
LaunchtheBrowser menu directly if pressed in standby
mode.
Deletecharactersintextmode,orreturntopreviousmenu.

15
14
Keys Functions
Makeorreceiveacall.Showtherecentcalllistinstandbymode.
Re-dialthelastcallnumberifpressedandheldinstandby
mode.
Completethecurrentcall.Turnon/offthephoneifpressed
and held. Cancel user input and return to standby mode while
in Menu mode.
Quicklyconnecttothevoicemailserverifpressedand
held in standby mode.
~
Enter numbers, letters or special characters. Go to the dial
screen if pressed in standby mode.
Assignthenumberasaspeeddialwhenitispressedandheld.
Enterorexitfromvibratemodeifpressedandheldinstandby
mode.Showthesymbolinputscreenifpressed in text input
mode.
Enterthe+signprexforinternationaldialingifpressedandheld.
Enter the space character in text input mode.

17
16
Keys Functions
Changevarioustextinputmodesifpressed atthetext-editing
screen.
Adjusttheearpiecevolumewhilemakingacall.
ControltheRingtonevolume,vibratemodeandsilentallmode
in standby.
Mutetheringtoneoftheincomingcallifthevolumeupkeyis
pressed.
Rejecttheincomingcallifthevolumedownkeyispressedand
heldwhenyoureceiveanincomingcall.
LaunchtheMultitaskingbypressingandholdingthevolume
up key.
Turn camera capture mode on.
Workasacamerashutterincapturemode.
Turn the Voice Commands on.

17
16
SIM card and battery
About your SIM card
Whenyousubscribetoyour
networkoperator,youreceivea
SIM(SubscriberIdentityModule)
card containing your registration
information, PIN code, etc.
Likeacreditcard,itshould
be kept secure and handled
carefully.Donotbend,scratch
orexposeittomoisture.Avoid
static electricity.
ToavoidcorruptingyourSIM
card’s memory, always switch off
yourphonebeforeremovingor
insertingyourSIMcard.
About your battery
YourphoneusesaLi-Ionbattery.
Make sure to use an authorized
battery and charger only. For
moredetails,pleaseinquireat
your nearest dealer.
note: Your phone is powered by a
LithiumIon(Li-Ion)battery.Thismeans
that, unlike other forms of battery
technology, you can recharge your
battery while some charge remains
without reducing your phone’s
autonomy due to the “battery memory
effect”inherentinthosetechnologies.

19
18
Installing/removing SIM card
and battery
1.Removethe
batterycover
from the unit.
Totthebattery
cover,putiton
the guide rail and
push up.
Incorrect
Correct
2.InserttheSIMcard
into the slot.
The gold contacts
oftheSIMcard
should go against
the metal contacts
of the phone.
Put the contacts
of the battery into
the hole located at
the top of the unit and then
insert and press the lower
side of the battery until you
hearthe“click”. Make sure you
align the gold contacts at the
battery end with contacts on

Getting started
19
18
the phone. If the contacts at
the battery are not properly
aligned, damage could occur
to the phone and the battery.
Incorrect
Correct
3.Toremovethe
battery, push the
bottom of the
battery to upwards
(1)andremove(2)
the battery.
 PushtheSIMcard
in the arrow
direction as shown.
To charge your
battery
1.Tocharge,
connect the
charger adapter
as shown right.
Incorrect
Correct
Incorrect
Correct

21
20
2.Toremove
the adapter
connecting, pull
the adapter
away as shown
right.
Turning the phone on/off
To turn on
1.Pressandhold .
To turn off
1.Pressandhold .
Essential display
indications
Signalstrength.Thegreaterthe
number of bars, the stronger
thesignal.Whennetworkisin
searching mode is displayed.
Flightmodeisactive.
Acallisbeingmade.When
youareinnoservicearea, is
displayed.
Call forwardingNSisactive.
Incoming calls set to ring only
(Normal).
Incoming calls set to Vibrate
and Ring.
