Pantech G670 User manual

6320013600 REV00
G670
User’s Manual
6320013600
6
3
2
0
0
1
3
6
0
0

1
SPECIFICATION
SPECIFICATION
Display
Dual clamshell TFT LCD both Main & Sub.
Main LCD : 260,000 TFT Color Display (128 X 160)
Sub LCD : 260,000 TFT Color Display (128 X 160)
Animation Message, Variable Icon
Melody
64 Poly Orchestra Music Bell Sound
Camera
High Sensitive Digital Camera with Flash
Dimension & Weight
80X40X21 mm with Standard Battery
85g with Standard Battery
Performance
Talk Time: up to 210 minutes (with 780 mAh Battery)
Standby Time: up to 200 hours (with 780 mAh Battery)
Operating Frequency
GSM 900MHz / 1800MHz Dual Band

2
SAFETY PRECAUTIONS
SAFETY PRECAUTIONS
For your safety and proper operation of the cell phone, please read
the following information carefully and observe the simple
guidelines provided. For detailed information, please refer to the
Appendix.
Antenna
Do not use any antenna not authorized by Pantech. Using such
antenna may cause malfunction or serious damage to the phone.
Traffic Safety
You should check and observe your local traffic regulations before
using your cell phone. Do not use your phone while driving.
If unavoidable, use a hands-free device in a safe area.
Effects on Electronic Devices Inside the Car
RF (Radio Frequency) signals may adversely affect the electronic
devices or systems in your car.
Hands-free Device
Installing an in-vehicle hands-free device on the area of deployment
of an airbag or within the coverage of airbag inflation may cause
serious injury.
Effects on Electronic Devices
RF signals emitted from your cell phone may adversely affect the
electronic devices that are inadequately shielded against such
signals.

Medical Devices
Turn off your cell phone in healthcare facilities and make sure to
observe facility rules and regulations.
As external RF signals may interfere with a pacemaker(s) or another
medical device(s), turn off your cell phone when near such devices.
Consult a physician or the manufacturer of the medical device if
you have any questions about using your phone in a healthcare
facility.
Public Place
Turn off your cell phone in public areas where the use of cell
phones is prohibited.
Boarding an Aircraft
Turn off your cell phone before boarding an aircraft.
Using a cell phone inside the aircraft may seriously affect aircraft
operation.
Potentially Explosive Atmosphere
Turn off your cell phone in any area with a potentially explosive
atmosphere, and obey all posted signs and instructions in the area.
Do not separate the battery from your phone in an area with a
potentially explosive atmosphere.
3
SAFETY PRECAUTIONS
SAFETY PRECAUTIONS

4
SAFETY PRECAUTIONS
SAFETY PRECAUTIONS
User Guide
Do not allow another person to use your phone without your
permission.
If the phone is lost or stolen, contact your service provider
immediately.
If the phone does not function properly, take it to the nearest
service center.
Use only approved accessories and batteries. Do not attempt to
connect incompatible devices.
Avoid prolonged exposure to RF (radio frequency) signals emitted
from the phone as it may adversely affect the human body.
Remember to make a backup copy of important data such as
telephone numbers.
Exposure to Radio Waves
Your phone is comprised of a radio transmitter and receiver. It was
designed and manufactured not to exceed the radio wave energy
limit or exposure recommended by an independent scientific
organization after extensive scientific studies.
Use only the batteries, chargers and accessories approved by
authorized manufacturers so as to not exceed the recommended
exposure guidelines. Use of unauthorized items may result in a
failure to comply with the guidelines. In such a case, the safety of
all users, regardless of their age and health condition, cannot be
guaranteed.

Using Your Phone Properly
Use your cell phone in normal operating position (as a hand-held
telephone is normally held).
Do not touch or bend the antenna while using the phone, as it may
degrade the call quality or even affect battery performance.
Do not attempt to disassemble the phone. Non-expert handling may
damage the phone.
Use only the batteries, chargers and accessories which are
authorized or supplied with the phone.
Use of any unauthorized item may result in the invalidation of the
warranty.
5
SAFETY PRECAUTIONS
SAFETY PRECAUTIONS

6
PRECAUTION USING THERMOMETER
PRECAUTION USING THERMOMETER
This is non-critical and non-medical device and just you can take a
temperature for your body as interesting function.
Thermometer measures the infrared heat generated by the forehead
and surrounding tissues. The technical accuracy requirement for the
system is defined by a ±1.0˚C maximum measurement deviation.
Important
•The operating ambient temperature range for this thermometer is
18˚C~35˚C.
•Do not expose the thermometer to temperature extremes (Below
-20˚C or over 50˚C) nor excessive humidity (over 95%)
•Available measurement range is 34˚C ~ 40˚C
•Keep the distance from thermometer to forehead as 2cm.
•The use of thermometer is not intended as a substitute for
consultation with your physician.
•This thermometer is intended for household use only.
•Start measuring 10 minutes after power of the phone is initially
turned on.
•When the place for taking a measurement is moved, the
thermometer needs about 30 minutes of stabilization.
•Avoid taking measurement immediately after a call or charging.
Take measurement after getting stabilized more than 30 minutes.
•Do not heat the exposed part of the sensor on the back of the
phone, or avoid any physical contact.
•If body temperature is taken near the air conditioner or heater, the
measurement might not be correct. Please avoid taking a
measurement around those places.
•Body temperature might not be correct if taken immediately after
exercising or bath or coming home. Please take a measurement
after you rest for more than 30 minutes within the house.
•For the correct measurement, wash away the sweat or makeup
from the surface of your forehead when you take a measurement.

•Body temperature taken at the right side or left side of your
forehead might be different. Please take a measurement at the
same side all the time.
•It is important to keep an eyebrow, eye, or hair out of the part
where the temperature is being taken.
Lens Washing
Since the lens is very delicate, it is very important not to touch it
with a hand or any other thing.
When you need to clean the lens to remove the dust or dirt, use a
cotton swab soaked with water or a little bit of alcohol. Be sure not
to press the lens. Do not use the thermometer for at least 30
minutes after cleansing the lens.
Body temperature guide
Normal body temperature is a range. The below table shows that
this normal range also varies by site. Therefore, readings from
different sites should not be directly compared.
Normal body temperature of each body part
1. Chamberlain, J.M., MD, and Terndrup, T.E., “New Light on Ear
Thermometer Readings”, Contemporary Pediatrics; March 1994.
7
PRECAUTION USING THERMOMETER
PRECAUTION USING THERMOMETER
Measured part Body temperature
Auxiliary 34.7˚C~37.3˚C
Oral 35.5˚C~37.5˚C
Inner Ear 35.8˚C~38.0˚C
Rectal 36.6˚C~38.0˚C

8
PRECAUTION USING THERMOMETER
PRECAUTION USING THERMOMETER
Normal body temperature by age
2. Chamberlain, J.M., MD, and Terndrup, T.E., “Determination of
Normal Ear Temperature with an Infrared Emission Detection
Thermometer”, Annals of Emergency Medicine; January 1995.
The thermometer is initially calibrated at the time of manufacture.
If this thermometer is used according to the use instructions,
periodic re-calibration is not required.
Ages Body temperature
1~2 36.1˚C~37.7˚C
3~10 35.8˚C~37.5˚C
11~65 35.6˚C~37.6˚C
Older than 65 35.5˚C~37.2˚C

9
MEMO
MEMO

10
TABLE OF CONTENTS
TABLE OF CONTENTS
COMPONENTS ..................................................................... 14
HANDSET DESCRIPTION .................................................... 15
INTERNAL LCD (MAIN LCD) ................................................ 16
• Main LCD Screen .............................................................. 16
SUB-LCD MENU OPTIONS .................................................. 18
FUNCTION KEYS FUNCTION KEYS .................................... 19
QUICK START ....................................................................... 21
• Installing the Battery ........................................................ 22
• Charging the Battery ........................................................ 22
Getting started
TURNING YOUR PHONE ON .............................................. 24
TURNING YOUR PHONE OFF ............................................. 24
MAKING A CALL .................................................................. 25
ENDING A CALL ................................................................... 26
ANSWERING A CALL ........................................................... 26
ADJUSTING THE EARPIECE VOLUME ............................... 27
BROWSING THE MAIN MENU ............................................ 27
INPUTTING CHARACTERS AND NUMBERS ...................... 28
Basic Functions
SPEED DIALING ................................................................... 30
MAKING AN INTERNATIONAL CALL .................................31
MAKING AN EMERGENCY CALL ........................................ 31
MISSED CALLS .................................................................... 31
PHONE BOOK SHORTCUT .................................................. 32
LAST NUMBER DIALLED/RECEIVED/MISSED ................... 32
CALL WAITING ..................................................................... 33
DURING A CALL (OPTIONS DURING A CALL) .................. 34
T9 GUIDELINE ...................................................................... 35

Menu functions
MESSAGES .......................................................................... 38
•SMS/EMS .......................................................................... 38
•MMS .................................................................................. 46
•Voicemail ........................................................................... 52
•Cell broadcasts .................................................................. 53
CALL LOGS ........................................................................... 55
•Received Calls ................................................................... 55
•Dialled Calls ....................................................................... 55
•Missed Calls ...................................................................... 56
•Clear Logs .......................................................................... 57
•Call Info .............................................................................. 58
•GPRS Info .......................................................................... 60
SOUND ................................................................................. 61
•Ringing Settings ............................................................... 61
•Message Alert ................................................................... 62
•Key Tone ............................................................................ 62
•Flip Open Tone .................................................................. 63
•Sound Effect ...................................................................... 63
SETTINGS ............................................................................. 66
•Display ............................................................................... 66
•Date & Time ...................................................................... 70
•Language ........................................................................... 72
•Reset Settings ................................................................... 72
•Information ........................................................................ 73
•Auto Power Alarm ............................................................ 74
•Answering machine .......................................................... 74
•Voice LED .......................................................................... 77
NET SERVICES ..................................................................... 78
•Divert Calls ........................................................................ 78
•Call Settings ...................................................................... 80
11
TABLE OF CONTENTS
TABLE OF CONTENTS

12
TABLE OF CONTENTS
TABLE OF CONTENTS
•Network Settings .............................................................. 82
•Security Settings ............................................................... 84
ORGANIZER ORGANIZER ................................................... 90
•Alarm ................................................................................. 90
•Scheduler .......................................................................... 92
•Memo ................................................................................. 95
•Calculator .......................................................................... 96
•Converter ........................................................................... 96
•Stop Watch ........................................................................ 97
FUN & TOOLS ...................................................................... 98
•Game ................................................................................. 98
•Downloaded ...................................................................... 99
•Voice record .................................................................... 103
•Thermometer .................................................................. 104
•Wap .................................................................................. 105
•JAVA ................................................................................ 111
•Camera ............................................................................ 114
•Memory info..................................................................... 120
STK ...................................................................................... 121
PHONEBOOK ...................................................................... 122
•Group search ................................................................... 122
•Name Search ................................................................... 123
•Photo search ................................................................... 124
•Add New Name ............................................................... 125
•Speed Dial List ................................................................ 125
•Settings ............................................................................ 126
MY MENU ........................................................................... 128
•Register in My Menu ...................................................... 128
•Using a registered menu ................................................ 128
•Deleting registered menus. ............................................ 128
•Reference ......................................................................... 128

Appendix
ALL ABOUT PERFORMANCE AND SAFETY .................... 130
TROUBLESHOOTING TROUBLESHOOTING ................... 131
•When the “Insert SIM Card”message appears: .......... 131
•When the “Handset locked enter password”
message appears: ........................................................... 131
•When the “Enter PIN1”message appears: .................. 131
•When the “No service”or “Network failure”
message appears: ........................................................... 131
•When audio quality is poor: ........................................... 132
•When the other party cannot hear you speaking: ........ 132
•When battery lifetime is shorter than usual: ................ 132
•When your cell phone does not turn on: ...................... 132
•When you are unable to send a message: ................... 132
•When you are unable to make a call: ............................ 132
•When you are unable to charge the battery: ................ 133
•
When you are unable to input data into the Phone Book:
.... 133
•When you are unable to select a certain function: ...... 133
BATTERY USE .................................................................... 134
SAFETY INFORMATION .................................................... 135
•Road Safety ..................................................................... 135
OPERATING ENVIRONMENT ............................................ 135
Malfunction of Nearby Electronic Devices ....................... 136
Emergency Calls ................................................................ 136
13
TABLE OF CONTENTS
TABLE OF CONTENTS

14
COMPONENTS
COMPONENTS
The pictures shown below are for general user reference only.
Individual items of the cell phone package may vary depending on
the policy of your service provider.
The Cell Phone AC Adapter

* For detail usage of key
15
HANDSET DESCRIPTION
HANDSET DESCRIPTION
Antenna
Antenna
Thermo sensor
(lens)
Side Key
Camera
Sub display
Flash
Camera
OK key
Power Adaptor
Connectors
Power Adaptor
Connectors
Thermo sensor
(lens)
Clear key
LCD display
MENU key
Microphone
Earpiece
Navigation
keys
Alphanumeric
keys

16
INTERNAL LCD (MAIN LCD)
INTERNAL LCD (MAIN LCD)
There are two LCD displays: main-LCD and sub-
LCD. One displays only icons to show the status of
the phone while the other shows messages,
telephone numbers, icons, or other information.
Main LCD Screen
An icon(s) is displayed when a certain function is activated, a
message has been received or idle mode.
The figure above displays a list of all the possible icons that may be
positioned at the top of the screen.
The function of each icon is described below.
Shows the strength of the RF signal. The
greater the number of bars, the stronger
the signal.
Indicates that a call is in progress.
Indicates that your ring type is in melody
mode.
Indicates that your ring type is in either
vibration mode or etiquette mode
(Vibration mode: yellow / Etiquette mode:
blue).
Indicates that your ring type begins with
either vibration-melody mode or
vibration followed by melody mode.
Indicates that there is an unread
message(s). When messages are stored in
the SIM to the maximum storage
capacity, this icon will change to .
Indicates that an alarm has been set.
/
Signal strength
Call-active
Melody
Vibration
Vib then Ring/
Vib and Ring
SMS Message
Alarm

17
INTERNAL LCD (MAIN LCD)
INTERNAL LCD (MAIN LCD)
Indicates that roaming service is
available.
Shows remaining battery power.
This icon will appear when you insert
the SIM card that supports the GPRS
function and when your phone is in
GPRS service area (This means that your
phone is camped to the GPRS service
area.)
Indicates that the auto-answering
functionality has been activated. If the
recorded messages are full (10 messages),
it changes to .
Indicates that there are recorded
messages that are unchecked.
Auto-
Answering
Roaming
Battery
GPRS
Recorded

18
SUB-LCD MENU OPTIONS
SUB-LCD MENU OPTIONS
You can select several options with Sub-LCD Menu. The Sub-LCD
options are shown below.
Camera
1. While the flip is closed, press and hold the key to enter the
camera mode.
2. If the key is pressed after focusing the screen you want by
referring to the sub-LCD screen, the current image on the screen
will be photographed. To save it, press the key again in this
condition. To cancel and enter the camera mode again, press the
key, and to return to the standby screen, press the key.
3. If you press the key in the camera mode, the brightness will be
changed.
Flash ON
While the flip is closed, the camera flash can be used as an
emergency light.
1. On standby mode, press and hold the key to turn on the flash.
2. Release the key to turn off the flash.
Sublcd Menu
You can use the SMS Inbox, All calls, and Check Temperature
menus while the flip is closed.
1. To enter the menu, press and hold the key in standby mode.
Then, a list of menu will appear.
2. After the menu you want is placed using either or key, you
can press the key to enter the menu.

19
FUNCTION KEYS
FUNCTION KEYS
Function keys
The following table shows a list of function keys, each of which has
one or more functions.
Key Icon Name Key Function
SEND KEY
Press this key to make a call or answer
an incoming call when the answer type
is ANY KEY & SEND KEY. If you wish to
see the list of all recent calls, press this
key once.
END KEY
Press this key to end a call or to convert
to standby mode from menu mode.
Press and hold this key to turn your
phone on or off. Press the END key
when call is incoming, then incoming
call will be rejected.
OK KEY Press this key to select or activate the
menu displayed on the screen.
MEMU KEY
Press this key to enter into the main
menu & pop up menu.
CLEAR KEY
Press this key to delete a single character,
or press and hold this key to delete all
characters. Press this key to return to the
previous screen.
Press one of the four keys (left, right, up,
and down) to move the cursor in the
menu list or editor. During a call, press
the [Up] key to see the list of recent calls
made or the [Down] key to see the list of
calls received. If you press this key on
the idle screen, you can easily access
the Phonebook, Sound Setting, SMS, or
My Menu (Hot Folder).
NAVIGATION
KEYS with
shortcut keys
to Hot Folder,
Sound setting,
Message and
Phonebook
