Pantech CDM8635 User manual

CDM8635
Thank youforchoosing theCDM8635, ourlatestmobile phone.
The CDM8635 has many features, such as Clear Hearing,
designed to enhance your mobile experience. From its EZ to
read menus, to its sleek, stylish design, we know you will enjoy
the entire CDM8635 experience.
This User Guide contains important and useful information
that will maximize your familiarity with all that the CDM8635
has to oer.
User Guide

2
Specifications
Design
Clamshell phone with internal and external displays
Displays
• 260k colors TFT LCD with 2.2” internal display
• 4 gray STN LCD with 1.5” external display
• 5 lines for text in basic mode with 22 point font
• Two soft keys and four-way scroll and selection OK keys
Melodies
MP3, PMD, SP-MIDI
Camera
Integrated SXGA (1.3M) CMOS Camera
• Resolution up to 1280 x 960
• Photo album
Dimensions &Weight
• Weight: 100 g (with standard battery) 3.52 oz
• Dimensions: 98 mm x 50 mm x 20.2 mm
3.85” X 1.96” X 0.79”
Power Management (Performance)
BatteryType Capacity Standby
Time
Talk Time
Standard
Lithium-Ion
(Li-ion)
920 mAh 330 hours 250min

note: Holding device at internal antenna area
might aect call quality reception.
R
Earpiece
Internal display
Alarm key
Picture Gallery key
Left/Right Soft key
Perform the functions shown at
the bottom line of the display.
OK key
Press to enter menu system.
911 key
End key
Turns phone on/o, ends calls,
exits menus.
Clear key
Returns to previous screen or
deletes characters in text mode.
Microphone
Navigation key
Scroll through the
menu options
Zoom key
Speaker phone key
ICE key
In Case of Emergency
key
Send key
Voicemail key
Prex international
call key
Vibrate mode key
Volume key
Headset jack
Camera lens
Speaker
AVR key
Camera key
Internal antennaExternal display
Charging connector
3
Phone overview

4
Menuoverview
Contacts
Emergency Contact
Contact List
Add Contact
Edit Contact
Erase Contact
Groups
Speed Dials
My Name & Number
Recent Calls
All Calls
Missed Calls
Dialed Calls
Received Calls
Blocked Calls
CallTimers
Messaging
Create Message
Inbox
Sent
Drafts
Voicemail
Settings
Media Gallery
Picture Gallery
Camera
Sound Gallery
easyedgesm
easyedgesm

5
easyedgesm
easyedgesm
Tools
Alarm Clock
Calculator
Tip Calculator
Calendar
Voice Memo
Stop Watch
World Clock
Notepad
Tone Room
Launching Tone Room
Wizard
Voice Commands
Help Balloon
Clear Hearing
Settings
Sound Settings
Display Settings
Call Settings
Advanced
Phone Info
Setting dependent

6
Quick & easy
Keys Functions
q / p
Perform the functions shown at the bottom line of the display by using these soft keys.
W
Scroll through the menu options in Menu mode. In Standby mode,
Left Scroll: Access Calendarmenu
Right Scroll: Access Messaging menu
Up Scroll: Access easyedgesm menu
Down Scroll: Access Calculator menu
P
Select a menu function or store user-input information, such as names.
Also use this key for conrmation as the P key.
L
Delete characters from the display, or return to previous menu.
F
Make or receive a call. Show the recent call list in Standby mode.
O
Complete the current call.Turn phone on/o if pressed and held.
Cancel user input and return to standby mode while in Menu mode.
1
Quickly connect to the voicemail server if pressed and held in Standby mode.
0 ~ 9
Enters numbers, letters or special characters. Go to the dial screen if pressed in standby mode.
#
Enter or exit Vibrate mode if pressed and held in Standby mode.
Enter a space in text input mode.

7
Keys Functions
0
Work in Word Search mode if pressed in the Predictive Text input mode.
*
Enter the + sign prex for international dialing if pressed and held.
Change various text input modes if pressed and held at the text-editing screen.
y
Adjust the earpiece volume while making a call.
Control the Ringtone volume, Vibrate mode and Silent mode in standby.
Mute the ringtone of an incoming call.
Q
Turn Camera Capture mode on.
Work as a camera shutter in Capture mode.
h
Access to AVR menu
l
Zoom in/out the font when entering
m
Turn the Speakerphone mode on/o
n
Set the alarm
o
Enter to the photo album
k
Available to contact most important 3 persons in case of emergency
x
Make a emergency call

Contents
Specifications...................................2
Phone overview...............................3
Menu overview................................4
Quick & Easy.....................................6
1. Getting Started
Battery..........................................12
Turn phone on/o........................13
Language......................................13
Essential display indicators ..........13
In case of emergency key.............14
Entering text.................................14
2. Calls & address book
Making,receiving and ending a call ..18
Options during a call ....................19
Checking all calls ..........................20
Speed dialing................................21
Call setting....................................21
Using address book ......................22
Caller identication......................23
Voice Command (VR)...................23
Setting VR settings.......................24
Using your headset.......................25
3. Messaging
Messaging....................................28
Receiving messages.....................28
Creatingandsendingtextmessages .29
Creating a picture message..........29
Message template........................29
Message settings..........................30
4. Multimedia
Camera..........................................34
Photo album.................................35
Sound album................................35
8

5. Useful Features
Alarm............................................38
Calculator and tip calculator.........38
Calendar........................................38
Voice memo and notepad............39
Stopwatch.....................................40
Help balloon.................................40
Clear hearing ................................40
6. Settings
Ringtones and alert......................44
Display..........................................44
Language......................................44
Locks.............................................44
Information..................................45
7. Appendix
Safety information for wireless
handheld phones.........................48
Other safety guidelines................50
About the battery usage..............51
Safety information for FCC RF
exposure.......................................51
SAR information...........................52
Hearing aid compatibility (HAC)
for Wireless Telecommunications
devices..........................................53
FDA Consumer update..................54
Avoid potential hearing loss.........59
FCC compliance information........60
12 Month Limited Warranty.........61
9

1
Battery
Turn phone on/o
Language
Essential display indicators
In case of emergency key
Entering text
Getting Started

12
Battery
About your battery
Your phone uses a Li-Ion battery. Make sure to use an authorized
battery and charger only. For more details, please inquire at your
nearest dealer.
note: Your phone is powered by a Lithium Ion (Li-Ion) battery. This
means that, unlike other forms of battery technology, you can recharge
your battery while some charge remains without reducing your phone’s
autonomy due to the “battery memory eect” inherent in those
technologies.
Installing/removing battery
To charge your battery
1. To charge, open the protective cover
on the bottom left side and connect
the charger adapter. The arrow on
the charger should face the top of the
phone.
2. To remove the adapter connection, pull
the adapter away.(1).
1. Remove the battery cover from the unit.
Push down and forward. To replace cover,
t on guide rails and push back in place.
2. Put the contacts of the battery into the
hole located at the bottom of the unit
insert and press the upper side of the
battery until you hear the “click”. Make sure you align the
gold contacts at the battery end with contacts on the phone.
If the contacts at the battery are not properly aligned,
damage could occur to the phone and the battery.
3. To remove the battery, push the
battery forward and up (2) and
remove (2) the battery.

02
03
04
05
06
07
01
13
Incorrect
Correct
Incorrect
Correct
Turn phone on/off
To turn on
1. Press and hold O .
To turn off
1. Press and hold O .
Language
Setting up
1. Press Menu> Phone Settings > Advanced >Language.
2. Select the language > OK.
Essential display indicators
Signal strength. The greater the number of bars, the stronger
the signal. When network is in searching mode is displayed.
Flight mode is active (Menu> Settings> Advanced >
Airplane Mode)
A call is being made
Received text message
Received text message and voice message
Received voice message
An alarm is set
Set the location mode on
Set the TTY mode to TTY Full/TTY + Talk/TTY + Hear
Received missed call
Battery strength. When the battery charge is low, isdisplayed

14
In case of emergency key
Getting in touch with those you call most is now as EZ as 1-2-3.
note: The following direction is an example with assigning Contact 1.The
usage of Contact 2and Contact 3 key will be same as the following.
To assign an existing contact
1. Press k .
2. Select one of Contact 1, Contact 2 or Contact 3.
3. Press ASSIGN > From Contacts.
4. Select a contact > OK.
To assign a new contact
1. Press k .
2. Select one of Contact 1, Contact 2 or Contact 3.
3. Press ASSIGN >Add Contact.
4. Enter the information in the elds and press SAVE.
To call using one touch key
1. Press k .
2. Select the name > View> Call.
To reassign contact
1. Press k .
2. Select the name > ASSIGN.
3. Select From Contacts or Add Contact.
The steps are as same as‘To assign existing contact’or‘To
assign a new contact’.
Entering text
You can enter standard, predictive, numeric or symbol text.
Useful keys
0 Press to view the next matching word in predictive mode
# Add space
*
Press to change Capital mode.
Press to change between abc Abc ABC, and press and hold to
change from standard to predictive to numeric
Standard
abc Abc ABC (all small caps / rst letter caps /
all caps)
Predictive word Word WORD (all small caps / rst letter caps /
all caps)
Number 123
Key characters by language
Each of the following keys will scroll through these sequential
options listed by language.

02
03
04
05
06
07
01
15
key English Spanish
1 . @ ? ! - , & : ‘ / 1
2 abc2 aábc2
3 def3 deéf3
4 ghi4 ghiÍ4
5 jkl5
6 mno6 mnñoó6
7 pqrs7
8tuv8 tuúv8
9 w x y z 9
0 0
Predictive mode (Word)
The Predictive mode automatically compares your keystrokes
with an internal linguistic dictionary to determine the correct
word. The most commonly used word will appear rst. To use
Word mode, pressAbc> Word.
1. Press and hold * to change the mode to Word.
2. Press 2 to 9 to input text. For example, to enter‘hello’
press 43556 .
Alphabet input mode
Press the key labeled with the target letter once for the rst
letter; press it twice for the second letter, and so on.
1. Press and hold * to change the mode to Abc.
2. Press 2 to 9 to input text repeatedly. To enter the
letter “C”, press 2 3 times. To input number 2 press 2
four times.
Numeric mode
You can input numbers in this mode.
1. Press and hold * to change the mode to 123.
2. Press 1 to 9 and 0 to input numbers.
Symbol mode
You can input symbols.
1. Press Abc > Symbols to change the mode to symbols.
2. Select the symbols using S / T / U / V .

2
Making, receiving and ending a call
Options during a call
Checking all calls
Speed dialing
Call setting
Using address book
Caller identi cation
Voice Command (VR)
Setting VR settings
Using your headset
Calls & address book

18
Making, receiving and ending a call
Making a call
1. Enter the area code and phone number.
2. Press F .
Answering a call
1. Press F .
Ending a call
1. Press O .
Once the call is completed, a call summary is displayed.
Rejecting a call
1. Press O or Ignore.
Making a call using call list
Your phone logs up to 90 dialed, received and missed call
numbers.
1. Press F to display the All Calls list.
2. Select All Calls, Missed Calls, Received Calls, or Dialed
Callsby pressing the S / T .
3. Select a number.
4. Press F to dial the selected number.
note: To redial the last number in the Recent Callslist, press F .
Making a call during a call
1. Enter the phone number.
2. Press F to dial the second call. The rst call is
automatically put on hold.
Switching between two calls
1. Press F .
Making an international call
1. Press and hold * key for the international prex until the
‘+’character appears.
2. Type the country code, area code, and phone number.
3. Press F .
Making a 911 emergency call
1. Press 911 key and select Yes.
2. Or, press ICE Key and press F .
note: To set the location emergency number, press Menu > Settings>
Advanced> Location.
Replying to a missed call
1. Press Viewto display the list of missed calls.
2. Select a number to call by pressing the S / T .
3. Press F .

02
03
04
05
06
07
01
19
Answering a second call
1. Press F . The rst call is automatically put on hold.
2. Press O to end all calls.
Options during a call
Microphone off and on
Switching your phone’s microphone off
1. Press Mute.
Switching your phone’s microphone back on
1. Press Unmute.
Talking on speaker
1. Press the m to turn on the speaker.To turn o the speaker,
press the m again.
Putting a call on hold and return
Putting a call on hold
1. Press F .
Returning to a held call
1. Press F again.
Adding a pause / wait
Pauses are used for automated systems (i.e., voice mail or calling
cards). Insert a pause after a phone number and then enter
another group of numbers.The second set of numbers is dialed
automatically after the pause.This feature is useful for dialing
into systems that require a code.
Adding pause
1. Enter the phone number.
2. Press Options > Add 2-Sec Pause.The phone waits
2 seconds before sending the next string of digits
automatically.
Adding wait
1. Enter the phone number.
2. Press Options> AddWait.The phone stops dialing until
you press the F to advance the next number.
3-way calling
You can talk up to 2 person or conference call.
Making 3-way call
1. Call the rst participant.

20
2. Call the second participant. The rst call is automatically put
on hold.
3. When the second party is connected, press F again.
note: If one of the people you called hangs up during your call, you and
the remaining caller will disconnected.
Searching a number in address book during a call
1. Press Options> Contact List.
Searching for a name or group in address book
Enter the rst letters of the name for Name Search. The entries
are displayed starting with the rst entry matching your input.
Finding a name manually in address book
1. Press the U / V key.
Viewing the details of highlighted entry in address book
1. Press VIEW.
Fordetailsonaddressbook,seepage22.
Reading a message during a call
1. Press Options > Main Menu > Messaging.
2. PressInbox > select a message > VIEW.
Writing a message during a call
1. Press Options> New Message.
2. Select Text Message or Picture Message.
Fordetailsoncreatingatextmessage,seepage 29.
note: During the call, you can only send text messages. Picture messages
cannot be sent.
Checking all calls
You can view information about all Recent Calls. Press F to
view all Recent Calls.
Viewing all calls
1. Press Menu > Recent Calls > All Calls.
Viewing missed calls
1. Press Menu >Recent Calls >Missed Calls.
Viewing dialed calls
1. Press Menu >Recent Calls >Dialed Calls.
Viewing received calls
1. Press Menu >Recent Calls >Received Calls.
Viewing blocked calls
1. Press Menu >Recent Calls >Blocked Calls.
