Pantech Breeze User manual

Thank you for choosing the Pantech Breeze C520,
our latest mobile phone.
The Pantech Breeze C520 has many features
designed to enhance your mobile experience. From
its EZ to read menus, to its sleek, stylish design,
we know you will enjoy the entire Breeze C520
experience.
This User Guide contains important and useful
information that will maximize your familiarity with all
that the Pantech Breeze C520 has to offer.
Breeze C520
User Manual

2
Specifications
Design
Clamshell phone with internal and external display
Displays
• 260k colors TFT LCD with 2.2” internal display
• 65k colors STN LCD with 1.04” external display
• 7 lines for text in basic mode with 16 point font
• Two soft keys and four-way scroll and selection
@ keys
Melodies
MP3, AAC, AAC+, WMA, AMR-NB, MIDI,
SP-MIDI
Camera
Integrated VGA (300k) CMOS Camera
• Resolution up to 640x480 (330,000 pixels)
•
Mpeg4 Video recording/playing up to 15f/s (QCIF size)
• Self-timer function (5 seconds or 10 seconds)
• Photo album and video album
Dimensions & Weight
• Weight: 96g (with standard battery)
• Dimensions: 99.3 mm x 50 mm x 19.6 mm
Power Management (Performance)
Battery Type Capacity Standby Time Talk Time
Standard
Lithium-Ion
(Li-ion)
Up to
920 mAh Up to 250 hours Up to 3 hours
Operating Frequency
• GSM 850Mhz, GSM 900Mhz, DCS 1800Mhz,
and PCS 1900Mhz networks in North America,
South America, Europe, Africa, and Asia-Pacific
where these networks are supported.
• Automatic band switching.

3
1 Address Book
2 Messaging
3 My Stuff
4 Tools
5 Settings
6 Phone Status
Phone overview
Earpiece
Internal display
Navigation key
Scroll through the menu options
Left/Right Soft key
Perform the functions shown
at the bottom line of the display
OK key or access MEdia Net
Press to enter menu system
Camera key
Power on&off/Menu exit
key/End key
Turns phone on/off, ends calls,
exits menus
Clear key and Calendar
Returns to previous screen or
deletes characters in text mode.
Access Calendar menu
One-touch
Quick Call
Speaker Mode
Send key
Voicemail
Vibrate mode
Microphone
Menu features (Breeze Mode)
Address Book Messaging My Stuff
Tools Settings Phone Status
note: Holding device at internal antenna
area might affect call quality reception.
Camera
Speaker
Side
key
External
display
Internal antenna

4
Example: Accessing the
Phone Mode menu.
1. Press the Menu.
2. Press the
5 for
Settings.
3. Press the
1 for
Phone Mode.
4. Press the
U / D
scroll key to select
the mode.
Numbered menu
items, such as menus,
sub-menus, and
options can be quickly
accessed by using
their shortcut numbers.
In Menu mode,
Main Menus can be
accessed by pressing
the number keys
(1 to 0) corresponding
to their location on the
screen.
Address Book
Contact List ¦P28
New Contact ¦P28
Speed Dial ¦P27
My Phone Number
Messaging
Write New ¦P38
Inbox ¦P36
Sent ¦P38
Voice Mail ¦P42
Email ¦P43
IM ¦P43
Settings ¦P41
My Stuff
Photo Album ¦P51
Video Album ¦P52
Audio ¦P72
Graphics ¦P51
Games & Apps ¦P54
Using Shortcuts Menu overview
Breeze mode menu
NOTE: The steps vary by mode and that throughout
the manual it will be notated by [EZ] for EZ Mode or
[ADV] for Advanced Mode.

5
S SIM dependent N Network dependent
Tools
Phone Status ¦P62
Camera ¦P46
Alarm ¦P58
Calendar ¦P58
Notepad ¦P60
Voice Memo ¦P60
Calculator ¦P59
Settings
Phone Mode ¦P18
Sounds & Alerts ¦P72
Ring Volume ¦P72
Wallpaper ¦P72
Backlight Timer ¦P73
Answer Type ¦P25
Phone Status
My Phone Number
Signal Strength
Battery Remaining
Sound & Alerts
Alarm
New Messages
Email & IM
Mobile Email ¦P43
IM ¦P43
Messaging
Write New ¦P37
Inbox ¦P36
Sent ¦P38
Outbox
Voice Mail ¦P42
Settings ¦P41
Memory Info ¦P53
Advanced mode menu

6
Recent Calls
Missed Calls ¦P26
Received Calls ¦P26
Dialed Calls ¦P26
Delete Call ¦P26
Logs
¦
Call Time ¦P26
GPRS Info ¦P27
MEdia Net
MEdia Net ¦P68
Home
¦
Bookmarks ¦P68
Go to URL ¦P68
Profiles ¦P68
Options
Security ¦P68
Version
AT&T Mall
Shop Tones
Shop Games
Shop Graphics
Shop Multimedia
Shop Applications
MEdia Net Home
Games & Apps

7
S SIM dependent N Network dependent
My Stuff
Audio ¦P72
Graphics ¦P51
Photo Album ¦P51
Video Album ¦P52
Other Files ¦P53
Tools
Memory Info ¦P53
Address Book
Contact List ¦P28
New Contact ¦P28
Speed Dial ¦P27
Groups ¦P29
My Business Card ¦P61
My Phone Number ¦P62
Memory Info ¦P36
Service NumbersS
Settings
Phone Mode ¦P18
Sounds & Alerts ¦P72
Display ¦P72
Call
Phone
Flight Mode ¦P81
Connectivity ¦P66
SecurityS ¦P30
Software
Reset ¦P74
TTY ¦P75

8
Quick & easy
Keys Functions
< > Perform the functions shown at the bottom line of the display by using these Soft keys.
Scroll through the menu options in Menu mode. In standby mode,
Left Scroll: Access My Stuff menu
Right Scroll: Access Alarm menu
Up Scroll: Access Write New menu
Down Scroll: Access Contact List menu
@
Select a menu function or store user-input information, such as names. Also use this key for
confirmation (as the [OK] key).
Launch the MEdia Net directly if pressed in standby mode.
CDelete characters from the display, or return to previous menu.
Open Calendar view if pressed quickly in standby mode.
SMake or receive a call. Show the recent call list in standby mode.
Re-dial the last call number if pressed and held in standby mode.

9
Keys Functions
EComplete the current call. Turn on/off the phone if pressed and held.
Cancel user input and return to standby mode while in Menu mode.
1Quickly connect to the voice mail server if pressed and held in standby mode.
0~9Enters numbers, letters or special characters. Go to the dial screen if pressed in standby mode.
*
Enter or exit from vibrate mode if pressed and held in standby mode.
Show the symbol input screen if pressed and held in text input mode.
Work in Word search mode if pressed in the Predictive text input mode.
0Enter the + sign prefix for international dialing if pressed and held.
Enter the space character in text input mode.
#Change various text input modes if pressed and held at the text-editing screen.
Adjust the earpiece volume while making a call.
Control the Ringtone volume, vibrate mode and silent all mode in standby.
Mute the ringtone of an incoming call.
Reject the incoming call if pressed and held when you receive an incoming call.
QTurn camera capture mode on. Work as a camera shutter in capture mode.
NTurn the speaker mode on.

Contents
Specifications.............................2
Phone overview ..........................3
Using Shortcuts .........................4
Menu overview ...........................4
Quick & easy ...............................8
1. Getting started
Package contents .................14
SIM card and battery ............15
Turn on/off the phone ...........16
Keypad lock ..........................16
Essential display indications ..17
Setting theme .......................18
EZ quick call keys .................19
Updating software ................19
2. Calls & address book
Making, receiving and
ending a call .........................22
Options during a call .............23
Call setting ............................25
Checking all calls ..................26
Speed dialing ........................27
Using address book ..............28
Caller identification...............29
Using your headset ..............29
Service number and
fixed dialing...........................30
3. Messaging
Entering text .........................34
Messaging ............................35
Receiving messages ............36
Creating and sending
text message ........................37
Creating a multimedia
message ............................... 38
Message template ................41
Message settings ................41
Setting voice message .........42
Email .....................................43
Using instant messenger ......43
4. Multimedia
Camera .................................46
Photo album .........................51
