Pantech Link II User manual

UserGuide

Some of the contents in this manual may differ from your phone depending on the software
of the phone. Actual color may vary.
Your phone is designed to make it easy for you to access a wide variety of content. For your
protection, we want you to be aware that some applications that you enable may involve
the location of your phone being shared. For applications available through AT&T, we
offer privacy controls that let you decide how an application may use the location of your
phone and other phones on your account. However, the AT&T privacy tools do not apply
to applications available outside of AT&T. Please review the terms and conditions and the
associated privacy policy for each location-based service to learn how location information
will be used and protected. In addition, your AT&T phone may be used to access the internet
andtodownload,and/orpurchasegoods,applications,andservicesfromAT&Torelsewhere
from third parties. AT&T provides tools for you to control access to the Internet and certain
Internet content. These controls may not be available for certain devices which bypass AT&T
controls.
Service provided by AT&T Mobility. Portions © 2011 AT&T Intellectual Property. All rights
reserved. AT&T, the AT&T logo and all other AT&T marks contained herein are trademarks
of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks contained
herein are the property of their respective owners.
Copyright © 2011. Pantech. All Rights Reserved.

3
Specifications
Design
QWERTY bar
Displays
• 262kcolorsTFTLCDwith2.4”display
• 320*240resolution
• 5linesfortextinbasicmodewith16-pointfont
• Twosoftkeysandfour-wayscrollandOKkey
Melodies
.mp3,.midi,.iMelody,.wav
Camera
Integrated2MCMOSCamera
• Resolutionupto1600x1200(1,920,000pixels)
• Mpeg4Videorecording/playingupto15f/s(QVGAsize)
• Self-timerfunction(Off,3seconds,5secondsor10seconds)
• Photoalbumandvideoalbum
Dimensions&Weight
• Weight:3.3oz.(withstandardbattery)
• Dimensions:115.9mmx61mmx9.95mm

4
PowerManagement (Performance)
BatteryType Capacity Standby Time TalkTime
Standard
Lithium-Ion(Li-ion) 1000 mAh Minimum 10days(250hrs)
Minimum
3hrs
OperatingFrequency
• GSM/GPRS/EDGE850/900/1800/1900MHz,UMTS/HSDPA850/1900MHznetworksinNorth
America, South America, Europe, Africa, and Asia-Pacific where these networks are supported.
• Automaticbandswitching.

Receiver
Display
Left/Right softkey
Perform the functions
shown at the bottom
line of the display.
Clearkey
Return to previous screen
or delete characters in
textmode.
Poweron&off/ Menuexit
key/ Endkey
Turn phone on/off, end
calls,exitmenus.
Deletekey
Press to delete a number
or letter.
Enterkey
Press to move to the
nextrow.
Spacekey
Press to enter a space.
Navigation
Up:WriteNewSMS
Down:Contacts
Left:Mobile Email
Right:YPmobile
Center:OK/Web
Speaker phone key
Sendkey
CAPS/Shiftkey
To type a single uppercase
letter, press this key then
a letter.
Functionkey
To enter a number or
a symbol, press the
function key, and press the
corresponding key.
Phoneoverview
5

Leftsidekey
Volumeupanddown
Chargerslot/Earmic
Camera
Camerakey
Internalantennaarea
Speaker
6
note: Holding the device by the internal antenna area might affect the quality of all calls.

7
Menuoverview
Messaging MobileEmail YPmobile
Web
Home
Bookmarks
Feed
Enter Address
History
Manage

8
AddressBook
Contacts
Groups
Favorites
LocalSearch
Settings
FixedDialNumbers
MyPhoneNumber
S
ServiceNumbers
AppCenter
AppManager
AT&T GPS
AT&TNavigator
AllSportGPS
Maps
AT&T Family Map

9
Tools
Recent Calls
Camera
VideoCamera
Media Player
Alarm Clock
Calendar
Notepad
VoiceMemo
World Time
Calculator
Tip Calculator
Converter
Stopwatch
Timer
MyStuff
App Manager
Games&Apps
Audio
Music
Video
Tools
my AT&T
CityID
ApplicationData
OtherFiles
Memory
AT&T Music
Music Player
Shop Music
AT&T Radio
Settings
Profiles
Display
nCall
Phone
Connectivity
SSecurity
nAT&T Software
Update
Reset
TTY
Phone Information
SSIM dependent NNetworkdependent

10
Quick&Easy
Keys Functions
<> Performs the functions shown at the bottom line of the display.
Scrolls through the menu options in Menu mode. In standby mode,
Left:AccessMobileEmailmenu
Right:AccessYPmobile menu
Up:AccessNew Message menu
Down:AccessContacts menu
WorksinWordsearchmodeifpressedinthePredictivetextinputmode.
O
Selects a menu function or store user-input information, such as names. Also
uses this key for confirmation.
LaunchestheWeb directly if pressed in standby mode.
NTurns on the speaker mode.
CDeletescharactersfromthedisplay,orreturntopreviousmenu.
SSends or receives a call. Shows the recent call list in standby mode.
ECompletes the current call. Turns on/off the phone if pressed and held.
Cancels user input and return to main screen while in Menu mode.
1Quickly connects to the voice mail server if pressed and held in standby mode.
0~9Entersnumbers,lettersorspecialcharacters.Goestothedialscreenifpressed
in standby mode.
BEntersorexitsfromvibratemodeifpressedandheld.
qEntersaninternationaldialingprexifpressedinstandbymode.

11
Keys Functions
mChangesvarioustextinputmodesifpressedatthetext-editingscreen.
lLocksthekeypadifpressedandheldinstandbymode.
Displaysspecialcharactersthatarenotplacedonthekeypad.
Adjusts the earpiece volume during a call.
Controls the Ringtone volume, vibrate mode and silent all mode in standby.
Mutes the ringtone of an incoming call.
Rejects an incoming call if pressed and held.
QTurns camera capture mode on.
Works as a camera shutter in capture mode.

12
Specifications ......................................................3
Phone overview...................................................5
Menu overview.....................................................7
Quick & Easy........................................................10
1. GettingStarted
SIM card and battery .......................................16
Turning the phone on/off .............................18
Keypadunlock....................................................18
Essential display indications........................19
Memory card .....................................................20
Assigning the menu ....................................... 22
Updatingsoftware ..........................................22
UsingtheQWERTYkeypad .........................23
UsingtheMultitask menu.............................24
2. Callsandaddress book
Making, receiving and ending calls ..........28
Optionsduringacall ......................................30
Call settings .......................................................32
Checking all calls..............................................32
Speed dialing.....................................................34
Usingtheaddressbook................................35
Address book settings .................................. 37
Caller identification.........................................38
Usingyourheadset.........................................39
Servicenumbersandxeddialing...........39
3. Messaging
Enteringtext......................................................42
Receiving messages......................................43
Creatingandsendingtextmessages.....44
Creating multimedia messages ...............45
Message templates........................................49
Message settings ............................................50
Managing memory..........................................52
Email......................................................................53
4. Multimedia
Camera ................................................................56
Photo album ..................................................... 60
Videoalbum.......................................................62
Audio album.......................................................64
Music player .......................................................66
Music player settings .....................................69
Media player.......................................................70
Otherles............................................................ 72
Managing memory ......................................... 72
Playing games .................................................. 72

13
5. UsefulFeatures
Alarm.....................................................................76
Calendar..............................................................76
Notepadandvoicememo........................... 77
World time ..........................................................79
Calculator, tip calculator, and
converter ............................................................79
Stopwatch and timer..................................... 80
Memory information .......................................81
6. Connectivity
Bluetooth ............................................................84
UsingWeb ..........................................................86
Profile settings .................................................88
7. Settings
Language............................................................92
Time&Date........................................................92
Ring Tone ............................................................92
Display..................................................................93
Security................................................................94
Reset .....................................................................95
TTY.........................................................................96
8. Appendix
Alert message................................................ 100
Troubleshooting checklist..........................101
Safety information........................................102
Safety precautions........................................103
About battery usage....................................104
FCCHearing-AidCompatibility(HAC)
RegulationsforWirelessDevices...........105
FCC Regulatory Compliance....................108
Warranty.............................................................110

1
SIM card and battery
Turning the phone on/off
Keypadunlock
Essential display indications
Memory card
Assigning the menu
Updatingsoftware
UsingtheQWERTYkeypad
UsingtheMultitask menu
GettingStarted
1. GettingStarted

16
SIM cardandbattery
AboutyourSIMcard
Whenyousubscribetoyournetworkoperator,youreceiveaSIM(SubscriberIdentityModule)
cardcontainingyourregistrationinformation,PINcode,etc.
Likeacreditcard,itshouldbekeptsecureandhandledcarefully.Donotbend,scratchorexpose
it to moisture. Avoid static electricity.
To avoid corrupting your SIM card’s memory, always turn off your phone before removing or
inserting your SIM card.
Aboutyourbattery
YourphoneusesaLi-Ionbattery.Makesuretouseanauthorizedbatteryandchargeronly.For
more details, please inquire at your nearest dealer.
note:YourphoneispoweredbyaLithiumIon(Li-Ion)battery.Unlikeotherformsofbatterytechnology,youcan
recharge your battery while some charge remains without reducing your phone’s autonomy due to the “battery
memoryeffect”inherentinthosetechnologies.
Installing/removingSIM cardand battery
1. Remove the battery cover from the unit.
Toremovethebatterycover,pushthebatterycoverdownward(1)and
slideit(2)asshownright.
2. Insert the SIM card into the slot. The gold contacts of the SIM card
should go against the metal contacts of the phone.

02
03
04
05
06
07
08
01
17
Put the contacts of the battery into the hole located at the bottom of
the unit. Insert and press the upper side of the battery until you hear
the“click”.Make sure you align the gold contacts at the battery end with
contacts on the phone. If the contacts at the battery are not properly
aligned, damage could occur to the phone and the battery.
3.Toremovethebattery,pushthebottomofthebatterytoupwardsand
remove the battery. To remove the SIM card, slide the SIM card in the
direction of the arrow as shown.
4.Totthebatterycover,putitontheguiderailandpushup.
Charging your battery
1. To charge, connect the charger adapter as shown right.
Make sure you align the connector as shown right. If not, it will damage
the charging connector on the phone and will not charge.
2. To remove the adapter connection, pull the adapter away as shown
right.

18
Incorrect
Correct
Incorrect
Correct
Turningthe phoneon/off
Toturnon
1. Press and holdE.
Toturnoff
1. Press and holdE.
Keypadunlock
Unlockingthekeypad
1. Press Unlock > Yes.

02
03
04
05
06
07
08
01
19
Essentialdisplayindications
Signal strength. The greater the number of bars, the stronger the signal. When
network is in searching mode, is displayed.
A call is being made. When you are in no service area, is displayed.
Call forwardingNis active.
Incoming calls set to Normal.
Incoming calls set to Outdoor.
Incoming calls set to VibrateOnly.
Incoming calls set to Silent.
Flight Mode is active.
Receivedoneormoretextmessages.
Received one or more multimedia messages.
Received one or more WAP push messages.
Received one or more configuration messages.
Received one or more voice messages.
A message is being sent.
A message is being received.
An alarm is set.
Appointment Alarm is set.
Browser is active, secured and being downloaded.
Bluetooth is active.
Bluetooth hands-free headset is connected.
BluetoothA2DPheadsetisconnected.
Bluetoothhands-free+A2DPheadsetisconnected.

20
DatatransferviaBluetooth.
Headset is connected.
USBisconnected.
TTY is active.
AGPRSsignalisavailable.ItisdisplayedwhenthereisanactiveGPRSsession.
AnEDGEsignalisavailable.ItisdisplayedwhenthereisanactiveEDGEsession.
AmicroSDcardisinserted.
Battery strength. When the battery charge is low, is displayed.
BGMisplay,pauseandbeingstopped.
NNetworkdependent
Memory card
You can use amicroSDcardasamemorycard.
It gives you more space to save pictures, videos, music, etc.
Insertingand removinga memorycard
1. Openthebatterycover.
2. Insert the card. The icon will be displayed.
3.Toremovethememorycard,slidethememorycardoutintheopposite
direction of the arrow.
