Pantech breEZe C520 User manual

Thank you for choosing the Pantech Breeze C520,
our latest mobile phone.
The Pantech Breeze C520 has many features
designed to enhance your mobile experience. From
its EZ to read menus, to its sleek, stylish design,
we know you will enjoy the entire Breeze C520
experience.
This User Guide contains important and useful
information that will maximize your familiarity with all
that the Pantech Breeze C520 has to offer.
Breeze C520
User Manual

2
Specifications
Design
Clamshell phone with internal and external display
Displays
• 260k colors TFT LCD with 2.2” internal display
• 65k colors STN LCD with 1.04” external display
• 7 lines for text in basic mode with 16 point font
• Two soft keys and four-way scroll and selection
@ keys
Melodies
MP3, AAC, AAC+, WMA, AMR-NB, MIDI,
SP-MIDI
Camera
Integrated VGA (300k) CMOS Camera
• Resolution up to 640x480 (330,000 pixels)
•
Mpeg4 Video recording/playing up to 15f/s (QCIF size)
• Self-timer function (5 seconds or 10 seconds)
• Photo album and video album
Dimensions & Weight
• Weight: 96g (with standard battery)
• Dimensions: 99.3 mm x 50 mm x 19.6 mm
Power Management (Performance)
Battery Type Capacity Standby Time Talk Time
Standard
Lithium-Ion
(Li-ion)
Up to
920 mAh Up to 250 hours Up to 3 hours
Operating Frequency
• GSM 850Mhz, GSM 900Mhz, DCS 1800Mhz,
and PCS 1900Mhz networks in North America,
South America, Europe, Africa, and Asia-Pacific
where these networks are supported.
• Automatic band switching.

3
1 Address Book
2 Messaging
3 My Stuff
4 Tools
5 Settings
6 Phone Status
Phone overview
Earpiece
Internal display
Navigation key
Scroll through the menu options
Left/Right Soft key
Perform the functions shown
at the bottom line of the display
OK key or access MEdia Net
Press to enter menu system
Camera key
Power on&off/Menu exit
key/End key
Turns phone on/off, ends calls,
exits menus
Clear key and Calendar
Returns to previous screen or
deletes characters in text mode.
Access Calendar menu
One-touch
Quick Call
Speaker Mode
Send key
Voicemail
Vibrate mode
Microphone
Menu features (Breeze Mode)
Address Book Messaging My Stuff
Tools Settings Phone Status
note: Holding device at internal antenna
area might affect call quality reception.
Camera
Speaker
Side
key
External
display
Internal antenna

4
Example: Accessing the
Phone Mode menu.
1. Press the Menu.
2. Press the
5 for
Settings.
3. Press the
1 for
Phone Mode.
4. Press the
U / D
scroll key to select
the mode.
Numbered menu
items, such as menus,
sub-menus, and
options can be quickly
accessed by using
their shortcut numbers.
In Menu mode,
Main Menus can be
accessed by pressing
the number keys
(1 to 0) corresponding
to their location on the
screen.
Address Book
Contact List ¦P28
New Contact ¦P28
Speed Dial ¦P27
My Phone Number
Messaging
Write New ¦P38
Inbox ¦P36
Sent ¦P38
Voice Mail ¦P42
Email ¦P43
IM ¦P43
Settings ¦P41
My Stuff
Photo Album ¦P51
Video Album ¦P52
Audio ¦P72
Graphics ¦P51
Games & Apps ¦P54
Using Shortcuts Menu overview
Breeze mode menu
NOTE: The steps vary by mode and that throughout
the manual it will be notated by [EZ] for EZ Mode or
[ADV] for Advanced Mode.

5
S SIM dependent N Network dependent
Tools
Phone Status ¦P62
Camera ¦P46
Alarm ¦P58
Calendar ¦P58
Notepad ¦P60
Voice Memo ¦P60
Calculator ¦P59
Settings
Phone Mode ¦P18
Sounds & Alerts ¦P72
Ring Volume ¦P72
Wallpaper ¦P72
Backlight Timer ¦P73
Answer Type ¦P25
Phone Status
My Phone Number
Signal Strength
Battery Remaining
Sound & Alerts
Alarm
New Messages
Email & IM
Mobile Email ¦P43
IM ¦P43
Messaging
Write New ¦P37
Inbox ¦P36
Sent ¦P38
Outbox
Voice Mail ¦P42
Settings ¦P41
Memory Info ¦P53
Advanced mode menu

6
Recent Calls
Missed Calls ¦P26
Received Calls ¦P26
Dialed Calls ¦P26
Delete Call ¦P26
Logs
¦
Call Time ¦P26
GPRS Info ¦P27
MEdia Net
MEdia Net ¦P68
Home
¦
Bookmarks ¦P68
Go to URL ¦P68
Profiles ¦P68
Options
Security ¦P68
Version
AT&T Mall
Shop Tones
Shop Games
Shop Graphics
Shop Multimedia
Shop Applications
MEdia Net Home
Games & Apps

7
S SIM dependent N Network dependent
My Stuff
Audio ¦P72
Graphics ¦P51
Photo Album ¦P51
Video Album ¦P52
Other Files ¦P53
Tools
Memory Info ¦P53
Address Book
Contact List ¦P28
New Contact ¦P28
Speed Dial ¦P27
Groups ¦P29
My Business Card ¦P61
My Phone Number ¦P62
Memory Info ¦P36
Service NumbersS
Settings
Phone Mode ¦P18
Sounds & Alerts ¦P72
Display ¦P72
Call
Phone
Flight Mode ¦P81
Connectivity ¦P66
SecurityS ¦P30
Software
Reset ¦P74
TTY ¦P75

8
Quick & easy
Keys Functions
< > Perform the functions shown at the bottom line of the display by using these Soft keys.
Scroll through the menu options in Menu mode. In standby mode,
Left Scroll: Access My Stuff menu
Right Scroll: Access Alarm menu
Up Scroll: Access Write New menu
Down Scroll: Access Contact List menu
@
Select a menu function or store user-input information, such as names. Also use this key for
confirmation (as the [OK] key).
Launch the MEdia Net directly if pressed in standby mode.
CDelete characters from the display, or return to previous menu.
Open Calendar view if pressed quickly in standby mode.
SMake or receive a call. Show the recent call list in standby mode.
Re-dial the last call number if pressed and held in standby mode.

9
Keys Functions
EComplete the current call. Turn on/off the phone if pressed and held.
Cancel user input and return to standby mode while in Menu mode.
1Quickly connect to the voice mail server if pressed and held in standby mode.
0~9Enters numbers, letters or special characters. Go to the dial screen if pressed in standby mode.
*
Enter or exit from vibrate mode if pressed and held in standby mode.
Show the symbol input screen if pressed and held in text input mode.
Work in Word search mode if pressed in the Predictive text input mode.
0Enter the + sign prefix for international dialing if pressed and held.
Enter the space character in text input mode.
#Change various text input modes if pressed and held at the text-editing screen.
Adjust the earpiece volume while making a call.
Control the Ringtone volume, vibrate mode and silent all mode in standby.
Mute the ringtone of an incoming call.
Reject the incoming call if pressed and held when you receive an incoming call.
QTurn camera capture mode on. Work as a camera shutter in capture mode.
NTurn the speaker mode on.

Contents
Specifications.............................2
Phone overview ..........................3
Using Shortcuts .........................4
Menu overview ...........................4
Quick & easy ...............................8
1. Getting started
Package contents .................14
SIM card and battery ............15
Turn on/off the phone ...........16
Keypad lock ..........................16
Essential display indications ..17
Setting theme .......................18
EZ quick call keys .................19
Updating software ................19
2. Calls & address book
Making, receiving and
ending a call .........................22
Options during a call .............23
Call setting ............................25
Checking all calls ..................26
Speed dialing ........................27
Using address book ..............28
Caller identification...............29
Using your headset ..............29
Service number and
fixed dialing...........................30
3. Messaging
Entering text .........................34
Messaging ............................35
Receiving messages ............36
Creating and sending
text message ........................37
Creating a multimedia
message ............................... 38
Message template ................41
Message settings ................41
Setting voice message .........42
Email .....................................43
Using instant messenger ......43
4. Multimedia
Camera .................................46
Photo album .........................51

Video album ..........................52
Other files .............................53
Managing the memory .........53
Playing games .....................54
5. Useful features
Calendar ...............................58
Alarm ....................................58
Calculator, converter and
stopwatch .............................59
Notepad and voice memo ....60
Business card .......................61
Phone status .........................62
6. Connectivity
Bluetooth ..............................66
Using the browser ................68
Profiles setting......................69
7. Settings
Language ..............................72
Time and date .......................72
Ringtones ............................72
Decorating the display ..........72
Locks ....................................73
To enable fixed dialing ........74
Reset ....................................74
TTY .......................................75
8. Appendix
Alert message .......................78
Troubleshooting checklist .....79
Safety information ................80
Safety precautions ................80
About the battery usage .......82
Hearing aid compatibility
with mobile phones ..............83
FCC regulatory compliance ....84
Warranty ...............................86
Contents

Breeze
1
C520

08
07
06
05
04
03
02
01
Package contents
SIM card and battery
Turn on/off the phone
Keypad lock
Essential display indications
Setting theme
EZ quick call keys
Updating software
Getting started
Getting started
Calls & address book
Messaging
Multimedia
Useful features
Connectivity
Settings
Appendix

14
Package contents
Phone Battery Travel charger User Manual

02
05
04
03
06
08
07
15
01
Getting Started
SIM card and battery
About your SIM card
When you subscribe to your network operator,
you receive a SIM (Subscriber Identity Module)
card containing your registration information,
PIN code, etc.
Like a credit card, it should be kept secure and
handled carefully. Do not bend, scratch or expose
it to moisture. Avoid static electricity. To avoid
corrupting your SIM card’s memory, always switch
your phone off before removing or inserting your
SIM card.
About your battery
Your phone uses a Li-Ion battery. Make sure to
use an authorized battery and charger only. For
more details, please inquire at your nearest dealer.
note : Your phone is powered by a Lithium
Ion (Li-Ion) battery. This means that, unlike
other forms of battery technology, you can
recharge your battery while some charge remains
without reducing your phone’s autonomy due
to the “battery memory effect” inherent in those
technologies.
Installing/removing SIM card
and battery
1. Remove the battery cover
from the unit. To fit the battery
cover, put it on the guide rail
and push up.
2. Insert the SIM card into the
slot. The gold contacts of the
SIM card should go against
the metal contacts of the
phone. Put the contacts of the
battery into the hole located at

16
the upper side of the unit, then
insert and press the bottom
side of the battery until you
hear the “click”.
3. To remove the battery push
the bottom of the battery to
upwards (1) and remove (2)
the battery. Push the SIM card
in the arrow direction as shown.
To charge your battery
1. To charge, open the protective
cover on the top left side and
connect the charger adapter.
The arrow on the charger have
to face the top of the phone.
2. To remove the adapter
connection press the
adapter’s side buttons (1)
and pulling the adapter
away (2).
Turn on/off the phone
To turn on
1. Press and hold E .
To turn off
1. Press and hold E .
Keypad lock
Locking the keypad
1. Press Menu > * to lock.
Unlocking the keypad
1. Press Unlock > * within 3 seconds to
unlock.

02
05
04
03
06
08
07
17
01
Getting Started
Essential display indications
Signal strength. The greater the number of
bars, the stronger the signal. When network is
in searching mode is displayed.
Flight mode is active.
A call is being made. When you are in no
service area is displayed
Call forwarding
N
is active
FAX mode
N
is active
Data
N
folder
Incoming calls set to ring only (Normal)
Incoming calls set to Vibrate then Ring
Incoming calls set to Vibrate Only
Incoming calls set to Silent
Received one or more text messages
Received one or more multimedia messages
Received one or more WAP push messages
Received one or more FAX messages
Received one or more other messages
Received one or more voice messages
A message is being sent
A message is being received
An alarm is set
Bluetooth is active
Headset is connected
TTY is active
An EDGE signal is available. It is displayed
when there is an active EDGE session
A GPRS signal where only 2G is available. It is
displayed when there is an active GPRS session.
WAP is connected. When the security is set
is displayed.
Battery strength. When the battery charge is
low, is displayed
N
Network dependent

18
< Breeze Mode> <Advanced Mode>
To change the theme
1. Press Menu > Settings > Phone Mode.
2. Select Breeze Mode or Advanced Mode.
Assigning the menu
In Breeze Mode, you can set the most commonly
used menu in Options in standby mode.
1. Press Options in standby mode > select
Unassigned.
2. Press Options > Edit.
3. Select the menu and sub menu.
Available, Away, Invisible Status of AIM
Online, Away, Busy, Offline Status of MSN
Available, Busy, Invisible Status of YAHOO
You have received one or more IM messages
Setting theme
Your phone has two customized themes, Breeze
and Advanced. The default is set to Breeze mode
which provides EZ access to the functions used
most frequently. In the Breeze mode, you view an
abbreviated menu: Address Book, Messaging,
My Stuff, Tools, Settings and Phone Status.
The Advanced mode allows access to all menu
items.

02
05
04
03
06
08
07
19
01
Getting Started
EZ quick call keys
Getting in touch with those you
call most is now as EZ as 1-2-3.
note: The following direction is an example with
using
x key. The usage of y and z key will
be same as the following.
To assign a contact
1. Press x .
2. Press Option > Assign Contact.
3. Select a contact > Options >
@ .
To use call using one touch key
1. Press and hold x to call.
To send a message using one touch key
1. Press x .
2. Press Option > Send Message.
Updating software
You can update your software without visiting your
nearest dealer.
To update the software
ADV
1. Press Menu > Settings > Software >
Software Update.
2. Press Phone Information to check software
version of your phone.
3. After checking your software version, press
@ .
4. Press Check for Update > Yes.
To view the version of software
ADV
1. Press Menu > Settings > Software >
Software Version.

Breeze
C520
2
