Panther H6240 User manual

Hydraulic Table Cart
MODEL H6240
Introduction
The Model H6240 Hydraulic Table Cart (Figure 1)
will move and raise material weighing up to 600
lbs. to a maximum comfortable working height of
291⁄4" above the floor.
The Model H6240 was carefully packed when it
left our warehouse. If you discover this hydrau-
lic table cart is damaged after you have signed
for delivery, please immediately call Customer
Service at [phone] for advice.
Save the containers and all packing materials for
possible inspection by the carrier or its agent.
Otherwise, filing a freight claim can be difficult.
When you are completely satisfied with the condi-
tion of your shipment, you should inventory the
contents.
Figure 2 - Inventory.
A. Cart (Not Shown) ....................................... 1
B. Handle ........................................................ 1
C. Foot Pedal .................................................. 1
D. Hex Bolts M8-1.25 x 40 .............................. 2
E. Hex Bolts M8-1.25 x 20 .............................. 1
Figure 2. Inventory.
B
E
CD
This table cart is not a toy. DO NOT allow
children to use this cart. Serious injury may
occur if this cart is used incorrectly.
Figure 1. 600 lb. Capacity hydraulic table cart.

1. Slide the lifting pedal into the pedal shaft,
and insert the M8-1.25 x 20 hex bolt through
the hole in the side of the pedal shaft and into
the lifting pedal (Figure 3).
2. Place the handle in the handle sockets and
secure with the M8-1.25 x 40 hex bolts
(Figure 3).
ASSEMBLY
Figure 3. Assembly.
1. Balance the load evenly in the center of the
cart.
2. Pump the lifting pedal to raise the table.
3. Push the pressure release pedal to lower the
table. Note—Always lower the table when
not in use.
OPERATIONS
1. Fully lower the tabletop when not in use.
2. Wipe all dirt and dust off the table cart.
3. Apply light oil to the surface of the hydraulic
jack ram.
4. Remove the plug on the top of the hydraulic
jack to check the oil level. Add oil if neces-
sary, replace the plug, then pump the handle
several times with the pressure release valve
open to bleed the air out of the system.
If you need additional help with this procedure,
call our service department at: [phone].
MAINTENANCE
Handle
Lifting Pedal
Keep hands out of the scis-
sor lift to prevent serious
crushing injuries.
Failure to follow these instructions will
result in serious personal injury:
1. Keep hands out of the scissor lift to prevent
serious pinching and crushing injuries.
2. DO NOT exceed the 600 lb. load capacity.
3. Lock the rear casters when loading and
unloading the cart.
4. Balance the load evenly in the center of the
cart.
5. Transport the load in the fully lowered posi-
tion to prevent tipping.
Lifting Pedal
Hex Bolt

REF PART # DESCRIPTION
1 PH6240001 TABLETOP
2 PH6240002 PIVOT PIN
3 PR06M EXT RETAIN RING 16MM
4 PH6240004 SCISSOR LIFT
6 PH6240006 WHEEL
7 PH6240007 BASE
8 PH6240008 PIVOT PIN
9 PH6240009 HYDRAULIC JACK
10 PB23M HEX BOLT M10-1.5 X 100
11 PH6240011 BUSHING
12 PH6240012 FRONT WHEEL
13 PW04M FLAT WASHER 10MM
14 PN02M HEX NUT M10-1.5
15 PH6240015 SPRING
16 PH6240016 SPRING CAP
17 PB09M HEX BOLT M8-1.25 X 20
REF PART # DESCRIPTION
18 PH6240018 SWIVEL CASTER
19 PLW04M LOCK WASHER 8MM
20 PN03M HEX NUT M8-1.25
21 PB15M HEX BOLT M8-1.25 X 40
22 PH6240022 PIVOT PIN
23 PH6240023 CONNECTING PLATE
24 PH6240024 PIVOT PIN
25 PH6240025 PEDAL SHAFT
26 PH6240026 COTTER PIN
27 PB26M HEX BOLT M8-1.25 X 30
28 PW01M FLAT WASHER 8MM
29 PH6240029 LIFTING PEDAL
30 PH6240030 HANDLE
31 PH6240031 PIVOT PIN
32 PR09M EXT RETAIN RING 20MM
33 PH6240033 DOWN PEDAL
COPYRIGHT © AUGUST, 2004 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#EW6463 PRINTED IN CHINA
