Papa Protect Qube BT6010 User manual

Owner’s Guide
Model - BT6010
PORTABLE SPEAKER

2
Powered with a ultra-high battery, this Papa Protect Qube
Bluetooth Speaker is capable of delivering a long-lasting
entertainment experience for music playback and phone conversa-
tion with impeccable sound quality. Owing to dual mode connec-
tion (Wireless Bluetooth and Aux-in connection), the premium
Bluetooth speaker is amazingly fashionable to play anywhere
conveniently.
Bluetooth Speaker : 1 unit
Micro USB Charging Cable : 1 unit
Aux Cable : 1 unit
User Manual : 1 unit
Carry Case : 1 unit
PACKING LIST
DESCRIPTION

Speaker
2 x 5 W
Working mode
Bluetooth / Aux-in / MicroSD
Bluetooth version
V4.2
Bluetooth profile
A2DP, AVRCP, HFP, HSP
Transmission distance
10m
Charging interface
Micro USB, 5V/1A input
Charging time
3 hours
Working time
8 hours
Dimension
159 x 76 x 46 mm
3
Weight
0.391kg
SPECIFICATIONS

M
1 2 3 4
5
6
7
1. Receive / End Call 2. Volume (-) / Previous Track
3. Play Pause 4. Volume (+) / Next Track
5. Battery / Mode Indicator 6. Mode Swticher
7. Microphone
PRODUCT ILLUSTRATION
4

8. MicroSD Slot 9. Charging port
10. Power Button 11. AUX In port
12. Power Bank Output
TF
AUX OUT
DC IN 5V ON/OFF
8 9 10
11 12
5

Press to switch between MicroSD, AUX and Bluetooth modes.
MicroSD is skipped if no card is inserted.
MODE BUTTON [M]
RECHARGING
When the battery is discharged, there will be a voice beep. Please
charge the Bluetooth speaker in time.
Connect this Bluetooth speaker to the USB port of your computer
via provided USB charging cable for recharging, or recharge it with
Papa Protect ReCharge USB Wall Charger.
 Recharging: red indicator lights on
 Fully charged: red indicator lights o
6

POWER ON/OFF
Note:
 Slide the Power button to ON state to power it on, LED indicator
lights will blink and you will hear a voice beep.
 Slide the Power button to O state to turn it o and you will hear
a voice beep.
In order to save power, the device will auto power o if no
devices are connected within 5 minutes.
In order to save power, the device will auto power o if not
operated for 10 minutes.
7

LED INDICATOR
LED COLOR
Flashing Blue
Steady Blue
Steady Green
Flashing Red
Steady Red
No Color
STATUS
: Bluetooth Pairing mode
: Device Paired / MicroSD
: Aux-in mode
: Low battery power
: Charging
: Switched O/Charged
8

Note:
CONNECT AND PAIR
Step 1: Slide the Power button to ON state to power on the speaker,
blue indicator quickly flashes to automatically enter pairing
process with voice prompt.
Step 2: Activate your Bluetooth device and search for other
Bluetooth devices.
Step 3: Select “Papa Qube” from the list of Bluetooth devices
shown for connection (if needed, input password 0000).
 After successful pairing, the speaker will make a prompt sound
and Blue LED indicator light will stop flashing.
 It will automatically connect with the mobile phone or other
devices that were already paired last time when you turn it on.
 The Bluetooth speaker will automatically power off if no
devices are connected within 5 minutes.
9

Press the M button (depending what mode your speaker is
currently in, you may have to press it twice) until the indicator light
is a solid Green.
Connect your speaker to the media player using
an AUX cable (included).
You can use the - / + buttons to adjust speaker volume and the
button to play/mute.
AUX MODE
10

MICRO SD SLOT
To play media from a Micro SD card, insert the card and then press
the M button until the light is solid Blue. Use - / + to navigate
through the tracks on the card by pressing them normally. Press
and hold the - / + buttons to adjust speaker volume.
To remove your card, push it farther in to the slot to activate the
release mechanism.
MICRO SD SLOT
11

Note:
POWER BANK
 Devices with USB charging support only.
 Devices that require 5V / 1A power only.
 Recommended for smartphones.
Simply insert the USB charging cable in the (here put the USB line
art) output provided, to charge your devices on the go.
12

FUNCTION OPERATION
Music Play / Pause
Volume Decrease / Increase
Previous / Next track
Answer / Hang up a Call
: Short press button
: Long press button to
decrease / increase volume
: Short press button to toggle
previous / next song(invalid in
Aux-in mode)
: Short press button once
13

1. Qube cannot be turned on?
Make sure Qube speaker has enough battery capacity.
2. What should be done if Qube speaker cannot pair with
Bluetooth device?
 Make sure it is in pairing mode.
 Make sure your Bluetooth device supports A2DP.
 The Bluetooth device may be out of range, move it closer and
try again.
FAQS AND SOLUTIONS
14

3.What should be done if there is no audio out from Qube
speaker?
 Make sure it is not muted or very low.
 Make sure the Bluetooth device is playing audio files and
increase the volume.
 Your Bluetooth device may be out of range, move it closer and
try again.
4.What should be done if there is proof sound quality?
 The Bluetooth device may be out of range, move it closer and
try again.
 Keep your Bluetooth device and Qube speaker away from any
device that generates electro magnetic interference, such as
another Bluetooth device, cordless phone, microwave oven or
wireless router.
 Make sure the music file is of good quality.
15

5.What Should be done if there is no audio from AUX source?
 Make sure the aux cable is correctly inserted.
 Make sure the connected device is on and playing.
 Increase the volume on the Bluetooth device and the speaker.
16

CONNECT WITH US
[e-mail]
@papaprotect
Papa Protect
@papaprotect
@papaprotect
Papa Protect
17

This Papa Protect Qube Bluetooth Speaker has a 6-month
limited warranty against manufacturing defects starting
from the purchase date.
For more details and to register your product for warranty,
please visit on our website www.papaprotect.com
