FrameSaverSLV 9820 Standalone Unit
Installation Instructions
Document Number 9820-A2-GN10-20
August 1999
Product Documentation on the World Wide Web
We provide complete product documentation online. This lets you search the
documentation for specific topics and print only what you need, reducing the waste of
surplus printing. It also helps us maintain competitive prices for our products.
Complete documentation for this product is available at www.paradyne.com.
Select
Library → Technical Manuals → FrameSaver Frame Relay Devices.
Select the following document:
9820-A2-GB20
FrameSaver SLV 9820 User’s Guide
To request a paper copy of a Paradyne document:
Within the U.S.A., call 1-800-PARADYNE (1-800-727-2396)
Outside the U.S.A., call 1-727-530-8623
FrameSaver SLV 9820 Models
There are two models of the FrameSaver 9820 product:
Model 9820-C – Central site model. Supports up to 120 PVCs.
Model 9820 – Remote site model. Supports up to 16 PVCs.
Package Checklist
Verify that your package contains the following:
FrameSaver SLV 9820 or 9820-C unit
Universal power supply with an attached cable and ferrite choke
Power cord appropriate for the wall-plug standard in your country (depends on
model ordered).

2
COM port-to-PC cable – DB9 connector (14 feet – 4.3m)
Ferrite choke

FrameSaver SLV 9820 Quick Reference (Document No. 9820-A2-GL10)
Additional cables may be ordered. See
Cables You Can Order on page 3 when
ordering cables.
Be sure to register your warranty at www.paradyne.com/warranty.
Before You Begin
If you ordered a wall mounting kit (Feature No. 9001-F1-891) for your FrameSaver unit,
install the wall mounting before you start installing the unit. Follow the same guidelines
below when installing the wall mounting. Contact your sales representative to order this
feature.
Before starting the installation, make sure you have:
A dedicated, grounded power outlet that is protected by a circuit breaker within
6 feet of the FrameSaver unit.
A clean, well-lit, and ventilated site that is free from environmental extremes.
One to two feet of clearance for cable connections.
A physical connection to the frame relay network via an NTU, with either an
EIA-530, V.35 or an X.21 user interface. This connection is made using the
appropriate cable attached to the Network port of the FrameSaver unit.
This cable is not supplied with your FrameSaver unit, and you will need to order
the appropriate cable kit for your application, V.35, X.21, or EIA-530 (see page 3
for the Feature No. you need to order).
An async (asynchronous) terminal or PC (personal computer) to set up the
access unit.
Node IP Addresses and Subnet Masks (see your network administrator).
See the User’s Guide for additional information on:

Troubleshooting
 Technical Specifications
 Cables, Connectors, and Pin Assignments

3
Cables You Can Order
If connecting to . . . Order a . . . Feature
Number Part Number
LAN adapter Adapter DB25
plug-to-8-position
modular receptacle
3100-F1-920 002-0069-0031
COM Port-to-LAN
adapter cable
(14 feet – 4.3 meters)
3100-F2-910 035-0315-1431
Equipment with
X.21 interfaces,
DB15 connectors
X.21 cable kit, which
includes a:
X.21 network cable
(10 feet – 3 meters)
X.21 DTE
adapter cable,
EIA-530A-to-X.21
(1 foot – .3 meters)
9008-F1-521
035-0384-1031
035-0302-0131
Equipment with
V.35 interfaces,
MS34 connectors
V.35 cable kit, which
includes a:
V.35 network cable
(10 feet – 3 meters)
V.35 DTE adapter,
EIA-530A-to-V.35
9008-F1-522
035-0383-1031
002-0095-0031
Equipment with
EIA-530 interfaces,
DB25 connectors
EIA-530 straight-through
cable
(10 feet – 3 meters)
9008-F1-523 035-0385-1031
Contact your sales representative to order cables.
Safety Instructions
Please refer to the Important Safety Instructions beginning on page 17.

4
Installing the Power Supply and Cord
1. Insert the power supply’s 4-prong plug into the POWER jack.
When inserting the plug at the rear of the FrameSaver unit, align the plug with the
notch above the POWER jack. Make sure the locking tab snaps securely into the
jack.
98-16197
Power Cord /
Transformer
(FrameSaver 9820
Shown)
OK ALM
Locking
Tab Grounded
Power
Outlet
2. Insert the socket end of the power cord into the power supply’s receptacle.
3. Plug the power cord into the grounded power outlet.
Verification Check:
Did any LEDs light?
– If yes, the FrameSaver unit has power.
– If no, refer to
Troubleshooting in the User’s Guide.

5
Connecting the COM Port to an Async Terminal or PC
The FrameSaver unit must first be directly connected to a PC or asynchronous terminal
(providing VT100 terminal emulation) to set up access and management of the unit.
1. Configure the VT100-compatible terminal or PC to be compatible with the
access unit:
– Baud Rate set to 19.2 kbps.
– Character length set to 8 data bits.
– Parity set to none.
– Stop bit set to 1.
– Flow Control set to None.
2. Insert the DB25 end of the EIA-232 cable into the FrameSaver unit’s COM port.
99-16198-01
To Connect to a PC
or Async Terminal
COM
Port
(FrameSaver 9820
Shown)
3. Insert the other end of the cable into the PC or VT100-compatible terminal.
4. Tighten the screws on each side of the connector to secure them.
5. Install the ferrite choke as close to the COM port connector as possible, making
sure the choke snaps shut around the cable.
6. Press Enter (or Return, depending on your keyboard) to display the Main Menu.
Verification Check:
Did the Main Menu appear?
– If yes, continue with the installation.
– If no, recheck terminal and FrameSaver unit compatibility (see settings in
Step 1), or press the Enter key.
Refer to
Troubleshooting in the User’s Guide for other possible explanations.

6
A Quick Guide to Configuration
The FrameSaver unit should operate using the default (factory-set) configuration
options, with exception to the changes specified in these installation instructions. Refer
to the following table for help in navigating through the menus.
Press the . . . To . . .
Esc key Go back one screen or menu level. To see a visual
representation of the menu levels, see Menu Hierarchy in
the
FrameSaver 9820 Quick Reference .
Tab key, or
Up (↑), Down (↓),
Left (←) and Right (→)
arrow keys
Move the cursor from one menu item to the next.
Enter or Return key Complete the menu or option selection.
Spacebar Display the next available setting when changing a
configuration option. All the available settings for an
option appears at the bottom of the screen.
As an example, follow these steps to go to the Configuration Edit/Display menu so you
can start setting up the unit. To load a configuration for editing:
1. From the Main Menu, press the down arrow key twice so the cursor is on
Configuration.
2. Press Enter to display the Configuration menu. The Load Configuration From
menu appears.
3. Press Enter to select Current Configuration (the cursor is already on this
selection). The Configuration Edit/Display menu appears.
This sequence of steps would be shown as the menu selection sequence:
Main Menu → Configuration
To save a configuration option change:
1. Press Ctrl-a to switch to the function keys area at the bottom of the screen.
2. Type sor S(Save) and press Enter. The Save Configuration To menu appears.
3. Press Enter again to save your changes to the Current Configuration.
4. Press Esc until the Configuration Edit/Display menu reappears to continue
configuring the unit.
Press Ctrl-a, type m(MainMenu), and press Enter to return to the Main Menu.
In the sections that follow, only the minimum option changes required are included so
you will have a quick and trouble-free installation. See the configuration option tables in
the User’s Guide for more information about configuration options.

7
Installing and Setting Up the 9820 FrameSaver Unit
The following sections guide you through installation and setup of a FrameSaver unit.
It is assumed that the FrameSaver unit is configured for factory default settings at the
start of installation.
For correct operation of the unit’s Hardware Bypass feature, both the network and user
port interface types need to be the same, and the combined length of their cables
should not exceed the maximum length limitation for the interface type (EIA-530A, V.35,
or X.21). In addition, both the source and primary destination DLCI numbers need to be
the same.
See the following illustration for an example of a network that includes FrameSaver
units at the central site (e.g., the company’s headquarters in Munich) and the remote
sites (e.g., branch offices in London and Singapore). User data PVCs provide
LAN-to-LAN connectivity between the central site and the remote sites.
Frame
Relay
Router Central Site
FrameSaver
Unit
NMS
Munich
Headquarters
Port NET
NTUNTUNTU NET Port
Frame
Relay
Router
Remote Site
FrameSaver
Unit
London Office
DLCI/EDLCIs:
100/0 User Data
100/2 Management Data
NTUNTUNTU
London OfficeLondon Office
NTUNTUNTU NET Port
Frame
Relay
Router
Remote Site
FrameSaver
Unit
Singapore Office
DLCI/EDLCIs:
200/0 User Data
200/2 Management Data
Frame
Relay
Network
100
200
DLCI/EDLCIs:
100/0 User Data for London
200/0 User Data for Singapore
100/2 Management Data for London
200/2 Management Data for Singapore
98-15989-01
NTU
From a network management perspective, the central site FrameSaver unit should be
configured for management from a Network Management System (NMS), through
either the attached router as shown in the above figure, or through the Network
Operations Center (NOC) router (for management by the Network Service Provider).
Multiple management PVCs then connect the central site unit to the remote site units
using Paradyne’s proprietary PVC multiplexing method (embedded DLCIs).

8
Verifying that Self-Test Passed
1. Follow this menu selection sequence from the Main Menu and press Enter after
each selection:
Main Menu → Status → System and Test Status
2. Check the Self-Test Results column (in the center of the System and Test Status
screen).
– If Passed appears, the FrameSaver unit successfully completed the self-test.
– If any failure messages appear in this column, reset the unit by disconnecting,
then reconnecting the power cord. The unit will perform the self-test again. If the
failure reappears, call your service representative for assistance.
Setting the System Clock
To set up the system clock:
1. Select System Information.
Main Menu → Control → System Information
2. Move the cursor to the Date, then the Time field to enter:
– Date in the mm/dd/yyyy format (month/day/year)
– Time in the hh:mm format (hours:minutes)
3. Save the settings.
Assigning the Node IP Address
1. Set up the node.
Main Menu → Configuration → Management and Communication → Node IP
2. Minimally, enter the following options:
– Node IP Address
– Node Subnet Mask
3. Save the configuration.

9
Configuring Physical Interfaces
The network and data port interfaces support three different port types: EIA-530, V.35
and X.21. If your application does not use V.35 interfaces, then the port type needs to
be changed. If the Hardware Bypass feature will be used, both the network and user
port interfaces should use the same type of interface. The port type is specified in the
physical configuration options.
To configure the physical interfaces:
1. Select the Network physical configuration options.
Main Menu → Configuration → Network → Physical
2. Select the appropriate Port Type.
3. Press Ctrl-a and Save your change(s).
4. Return to the Configuration Edit/Display menu.
5. Repeat Steps 2–4 for the data port.
Main Menu → Configuration → Data Ports → Physical
6. Return to the Configuration Edit/Display menu.
Setting Up Management
1. Select General SNMP Management.
Configuration → Management and Communication →
General SNMP Management
2. Minimally, set Name 1 Access to Read/Write.
3. Save the configuration.

10
Setting Up Local Management at the Central Site
1. Create a DLCI for the data port.
Configuration → Data Ports → DLCI Records
2. Save the configuration.
3. Create a Management PVC using the data port DLCI just created.
Configuration → Management and Communication → Management PVC
Minimally, enter the following options:
– Name for the management PVC
– Interface IP Address and Subnet Mask, if different from the Node’s
– Primary Link for this Management PVC (the user data port)
– Primary DLCI (i.e., the data port DLCI)
4. Save the configuration.
Automatic Configuration
The FrameSaver unit provides several automatic configuration features. Frame Relay
Discovery and configuration is one of these features.
Main Menu → Auto-Configuration
The default discovery mode is 1MPort. In this mode, for each DLCI discovered on the
network, a multiplexed network DLCI and a standard data port DLCI will be configured
and connected, and a Management PVC will be embedded in the network DLCI.
NOTE:
When auto-configuration creates a multiplexed DLCI, but a standard DLCI is
needed, change the DLCI to standard from the network DLCI Records screen:
Configuration → Network → DLCI Records
Other modes can be selected. See Setting Up Automatic Configuration in Setup of the
User’s Guide for information about other modes and how the Frame Relay Discovery
Mode can be changed.
No automatic configuration occurs until the network cable is connected. If you do not
want management links configured or automatic configuration, change the default
setting for the Frame Relay Discovery feature.

11
Connecting to the Network
Now that the FrameSaver unit is set up, the unit can be connected to the network.
1. Insert the DB25 connector of the network cable into the network data port.
2. Insert the other end of the cable into the NTU (EIA-530, V.35 or X.21).
98-16199
NTU
NOTE:
After connecting the network cable, wait about a minute to allow
Auto-Configuration a chance to discover DLCIs.
3. Check that the Network (NET OK) LED is on. If yes, the network interface is set up
correctly and it is operational. If not, make sure both ends of the network cable are
properly seated and secured.
4. Verify that the network physical options are configured correctly.
Main Menu → Configuration → Network → Physical
5. Check Health and Status messages in the left column of the System and Test
Status screen to see the LMI status and verify that LMI is up.
Main Menu → Status → System and Test Status
If LMI Down, Net1-FR1 appears for more than three minutes, or any other
network-related status message appears, refer to the status information in
Operation and Maintenance of the User’s Guide for possible reasons.

12
Setting Up Service Provider Connectivity
at the Central Site
When management needs to be set up between a service provider’s customer and its
network operations center (NOC), a non-multiplexed DLCI must be configured to carry
management data between the customer’s central site and the NOC console. This
requires that a frame relay discovered DLCI needs to be modified. This is because all
auto-configured network DLCIs are configured as multiplexed DLCIs.
To set up NOC management:
1. Select DLCI Records on the network interface:
Configuration → Network → DLCI Records
2. Select Modify. The Modify DLCI Record for DLCI Number? prompt
appears.
3. Select the DLCI that will be used by pressing the spacebar until the correct DLCI
number appears, then select it.
4. Change the DLCI Type from Multiplexed to Standard.
The DLCI in connections. Update DLCI usage as follows: prompt
appears.
5. Select the Delete EDLCI Connections and Make a Mgmt Only PVC
option.
PVC connections for the selected DLCI are broken, the Port-1 DLCI mapped to
this network DLCI and the embedded management DLCI (EDLCI) are deleted, and
the selected DLCI will be reconfigured as a management PVC using the Node IP
Address.

13
Configuring SNMP Trap Managers and Traps
Once the FrameSaver unit is connected to the network, SNMP trap managers and
SNMP traps can be configured.
To enter SNMP managers and configure traps:
1. Select SNMP Traps.
Main Menu → Configuration → Management and Communication →
SNMP Traps
2. Configure the following:
– Enable SNMP Traps.
– Identify the total Number of Trap Managers.
– Specify the IP address of the NMS(s) to which traps will be sent.
– Specify the network Destination for the Trap Manager(s).
– Select desired trap categories.
3. Save the configuration.
4. Return to the Main Menu.
Verifying the End-to-End Path
After installation of a remote site unit, run an IP Ping test to Ping the NMS at the central
site and verify that the entire path from the remote unit to the NMS is functioning. To run
the IP Ping test, NMS trap managers must have been configured for the remote unit.
One of those trap managers must be the central site NMS.
1. Select the IP Ping test.
Main Menu → Test → IP Ping
2. Enter the IP Address of the device being Pinged, then select Start.
NOTE:
When running tests, the cursor is positioned over the Start command. Press
Enter to start the test. Stop is displayed while the test is running. Press Enter
again to issue the Stop command.
– While the test is running, In Progress... is displayed in the Status field.
– When the test is finished, Alive. Latency =
nn ms should appear as the
Status (
nn being the amount of time the test took in milliseconds).
If any other message is displayed, additional testing will be required.
See
Device Messages in Operation and Maintenance of the User’s Guide for
information about IP Ping-related messages.

14
Connecting to the DTE (Router or FRAD)
1. Connect the appropriate cable to the Port connector.
– If the DTE interface type is EIA-530A, the DTE can be directly connected to the
Port connector.
– If the DTE interface type is V.35 or X.21, a V.35 or X.21 adapter cable is
required.
2. Plug the other end of the cable into the DTE.
3. Tighten the screws on each side of the connector to secure them.
98-16200
NTU
DTE
Verification Check:
Is the Port OK LED on?
– If yes, the port is set up correctly and is operational.
– If no, check that both ends of the cable are properly seated and secured.
Check Health and Status messages in the left column of the System and Test
Status screen for messages.
Main Menu → Status → System and Test Status
– If System Operational appears, the Port interface is set up correctly and
is operational.
– If System Operational does not appear, refer to the status information in
Displaying System Information of the User’s Guide.
NOTE:
When any error conditions are detected, a status message appears along the
bottom right corner of the screen.

15
Check that Data is Being Received
1. Return to the Main Menu.
2. Select Performance Statistics,and select an interface’s frame relay statistics
(e.g., Network Frame Relay).
Main Menu → Status → Performance Statistics → Network Frame Relay
3. Verify that the Frames Received and Characters Received counts under the
Frame Relay Link statistics are incrementing, and there are no errors under the
Frame Relay LMI statistics.
– If count increments occur after refreshing the screen, the unit is receiving data.
– If data is not being received, recheck the cable connections, and replace or
repair a damaged cable. Recheck LMI status; you may need to contact your
service provider. Next, check the DLCI’s status.
Check PVC Connections
Check PVC connections to verify that all PVCs, including management PVCs, are
configured, and to see whether the PVC is active or not.
1. Return to the Status menu.
2. Select PVC Connection Status.
The PVC Connection Status screen shows all PVC connections; the interface
source and DLCI number of the incoming data linked to the interface and DLCI
number for the outgoing data. You can also see whether the PVC is active.
3. Verify that each PVC is active.
– If active, the FrameSaver unit should be passing data.
– If not active, no data traffic can be carried by the PVC. If the PVC is configured
correctly, the circuit may be down.
The FrameSaver installation is complete.
In the User’s Guide, see
Displaying System Information for additional status
information, and
Troubleshooting for additional troubleshooting information.

16
FrameSaver 9820 Rear Panel
98-16189
FrameSaver 9820 Front Panel
98-16201
OK
OK
ALM
TST
OK
9820
PORT
FrameSaver
TM
SLV
FrameSaver
TM
SLV
NETWORK

17
!Important Safety Instructions
1. Read and follow all warning notices and instructions marked on the product or
included in the manual.
2. All installation and service must be performed by qualified service personnel, as
opening or removing covers may expose you to dangerous high voltage points or
other risks.
3. The power supply to be used with this product is intended to be used with a 3-wire
grounding type plug – a plug which has a grounding pin. This is a safety feature.
Equipment grounding is vital to ensure safe operation. Do not defeat the purpose
of the grounding type plug by modifying the plug or using an adapter.
Prior to installation, use an outlet tester or a voltmeter to check the ac receptacle
for the presence of earth ground. If the receptacle is not properly grounded, the
installation must not continue until a qualified electrician has corrected the
problem.
If a 3-wire grounding type power source is not available, consult a qualified
electrician to determine another method of grounding the equipment.
4. Input power to this product must be provided by a power supply with a Safety Extra
Low Voltage (SELV) output less than 240 VA available, certified for use in the
country of installation.
Paradyne power supply part number 327-0107-0031 is recommended. This power
supply includes a special mating connector for connection to this equipment.
5. Slots and openings in the cabinet are provided for ventilation. To ensure reliable
operation of the product and to protect it from overheating, these slots and
openings must not be blocked or covered.
6. Do not allow anything to rest on the power cord and do not locate the product
where persons will walk on the power cord.
7. Special cables, which may be required by the regulatory inspection authority for
the installation site, are the responsibility of the customer.
8. When installed in the final configuration, the product must comply with the
applicable Safety Standards and regulatory requirements of the country in which it
is installed. If necessary, consult with the appropriate regulatory agencies and
inspection authorities to ensure compliance.
9. A rare phenomenon can create a voltage potential between the earth grounds of
two or more buildings. If products installed in separate buildings are
interconnected, the voltage potential may cause a hazardous condition. Consult a
qualified electrical consultant to determine whether or not this phenomenon exists
and, if necessary, implement corrective action prior to interconnecting the products.

18
10. In addition, if the equipment is to be used with telecommunications circuits, take
the following precautions:
— Never install telephone wiring during a lightning storm.
— Never install telephone jacks in wet locations unless the jack is specifically
designed for wet locations.
— Never touch uninsulated telephone wires or terminals unless the telephone
line has been disconnected at the network interface.
— Use caution when installing or modifying telephone lines.
— Avoid using a telephone (other than a cordless type) during an electrical
storm. There may be a remote risk of electric shock from lightning.
— Do not use the telephone to report a gas leak in the vicinity of the leak.
EMI Warnings
!WARNING:
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference, in which case, the
user will be required to correct the interference at his own expense.
The authority to operate this equipment is conditioned by the requirements
that no modifications will be made to the equipment unless the changes or
modifications are expressly approved by Paradyne.
!WARNING:
To Users of Digital Apparatus in Canada:
This Class A digital apparatus meets all requirements of the Canadian
interference-causing equipment regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du
règlement sur le matériel brouilleur du Canada.

19
CE Marking
When the product is marked with the CE mark, this demonstrates full compliance with
the following European Directives:
Directive 73/23/EEC – Council Directive of 19 February 1973 on the
harmonization of the laws of the member states relating to electrical equipment
designed for use within certain voltage limits, as amended by Directive 93/68/EEC.
Directive 89/336/EEC – Council Directive of 3 May 1989 on the approximation of
the laws of the member states relating to Electro-Magnetic Compatibility (EMC), as
amended by Directive 93/68/EEC.
Directive 91/263/EEC – Council Directive of 29 April 1991 on the approximation of
the laws of the member states concerning telecommunication terminal equipment,
including mutual recognition of their conformity, as amended by Directive
93/68/EEC.The application of this directive is in relation only to X.21 and V.35
network interfaces as specified in CTR 1 and CTR 2.
Japan
Class A ITE
CAUTION Translation:
This is a Class A product based on the standard of the Voluntary Control
Council for Interference by Information Technology Equipment (VCCI). If this
equipment is used in a domestic environment, radio disturbance may arise.
When such trouble occurs, the user may be required to take corrective
actions.

20
Warranty, Sales, Service, and Training Information
Contact your local sales representative, service representative, or distributor directly for
any help needed. For additional information concerning warranty, sales, service, repair,
installation, documentation, training, distributor locations, or Paradyne worldwide office
locations, use one of the following methods:
Internet: Visit the Paradyne World Wide Web site at www.paradyne.com.
(Be sure to register your warranty at www.paradyne.com/warranty.)
Telephone: Call our automated system to receive current information by fax or to
speak with a company representative.
— Within the U.S.A., call 1-800-870-2221
— Outside the U.S.A., call 1-727-530-2340
Document Feedback
We welcome your comments and suggestions about this document. Please mail them
to Technical Publications, Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773,
or send e-mail to [email protected]. Include the number and title of this
document in your correspondence. Please include your name and phone number if you
are willing to provide additional clarification.
Trademarks
All products and services mentioned herein are the trademarks, service marks,
registered trademarks or registered service marks of their respective owners.

*9820–A2–GN10–20*
Copyright 1999 Paradyne Corporation
