Paravan PR 40 User manual

User manual
PR 40
PARAVAN WHEELCHAIR SERIES
EN V1.4

Valid for the following model Paravan PR 40
Publisher and Copyright: PARAVAN GmbH
Date of issue: 01/09/2020
Document number: PR40_V1.4 EN

3
Dear customer,
We would like to thank you for choosing our PARAVAN PR 40 standing wheelchair.
These operating instructions contain all the important information and instructions regarding your new
PR 40. We ask that you carefully read the following pages to ensure that your PR 40 will continue to work
without problems for many years to come. Keep these operating instructions "to hand" for future refe-
rence. Our operating instructions contain answers to questions that relate to the equipment, operation
and care of the PR 40. However, if you still have questions or comments regarding the PR 40, please do
not hesitate to contact us.
Your PARAVAN Team
