Park Safe SW004SD User manual

1
4CH SD Card
Mobile DVR Operation manual
Content
DVR instruction
Power connection--------------------------------------------------------------------------------------4
Remote controller instruction----------------------------------------------------------------------6
DVR operation
Login and password---------------------------------------------------------------------------------8
Language set up---------------------------------------------------------------------------------------9
Alarm I/O set up---------------------------------------------------------------------------------------11
Password set up--------------------------------------------------------------------------------------12
Record setting
Record base set up----------------------------------------------------------------------------------13
Motion detection-------------------------------------------------------------------------------------16
Network
Server---------------------------------------------------------------------------------------------------19
Tools
Format---------------------------------------------------------------------------------------------------21
Config----------------------------------------------------------------------------------------------------22
Upgrade-------------------------------------------------------------------------------------------------22
Video
Search recorded video-----------------------------------------------------------------------------23
Playback-------------------------------------------------------------------------------------------------24
Info-----------------------------------------------------------------------------------------------------------25
DVR parameter-------------------------------------------------------------------------------------------26

2
F.A.Q.:
1. Why DVR can not start?
A.: when you connect DVR with a stable power source, please connect red and yellow power wire
together with +12V, and then connect black wire with GND. And please lock on the DVR front
panel.
When you install the DVR on car, please make sure, the power wires connect correct. Red connect
with battery +12V, yellow connect with CARACC, black wire connect with battery GND.
2. Why my SD/HDD can not working after formatted by DVR.
A.: when you first time insert SD card/HDD into DVR, please wait DVR to format it automatically.
DVR will detect SD first, and then it will start formatting automatically after 15s. and then, DVR will
reboot. (do not format sd/hdd manually when first time use)
3. When playback recorded files on player, the video is chopping, or slower, or faster, or has
no sound.
A: Please contact supplier for the latest version of player. Or you need to change another
computer with higher process. Because of the high quality video file cost a lot of computer CPU
when playing back file.
4. When playback recorded files on TV/MONITOR, there has no sound.
A.: yes, recorded file playback on TV/MONITOR without sound. If you want to hear the sound,
please playback on computer.
5. After set up “schedule”, DVR can not working after reboot.
A.: yes, you have to wait till reached starting time you set in DVR. (See page 15)

3
1. About DVR
It is an inexpensive type SD card CAR DVR designed for taxies, buses, mini vans, trucks and
ships surveillance. This DVR used high-speed processor, an embedded Linux platform. Video
processes such as H.264 Video Compression/Decompression. SD MDVR enables CIF, HD1 and
D1 video formats. All video and GPS information will save in SD card.
1.1 Front panel instruction
Interface
Name
Instruction
LED
PWR
LED light on as power normal
RUN
working station indicator
3G
3G module working status
GPS
GPS exist or not
REC
Recording LED light on as recording
SD
SD card recording LED light on as SD exist.
WIFI
Wifi net work (unavailable now)
IR receiver
IR
IR Receiver, Receive remote control signal
Electronic Lock
LOCK
DVR will not working if it unlock
SD slot
SD
Support 1pcs Max. 128GB sd card
Sim slot
Sim
When DVR works with 3G module, this slot for 3G sim card

4
1.2 Rear panel
Interface
Name
Instruction
Power
POWER
Power input interface, support DC 8-36V
AVOUT
Audio and Video out
Always connect with monitor or TV
A/V input
AV1,AV2,AV3,AV4
Connect with Camera
3G/4G antenna
3G
Connect with 3G/4G antenna (optional)
GPS antenna
GPS
Connect with GPS antenna (optional)
I/O
Alarm input
High/low signal input to trigger recording or
full screen
Sweet tips:
Please use original type SD card, we recommend you use brand Kinstone, class 10, high
speed, max. support 128GB

5
1.3 Power connection
Red: POSITIVE
Black: NEGATIVE.
Yellow: FIREWIRE(ACC).
Tips: For testing in with a stable power source, RED+YELLOW connect with positive, and
BLACK connect with negative will start DVR.
NOTES：
1）Please verify battery voltage before connecting with battery. DVR support 8V-36V power input.
DVR will be damaged if power input over 36V.
2）After connecting the cables, ensure that power cables are insulated to prevent short circuiting
and burning out the battery.
3）The Yellow cable must be connected to the vehicle ignition cable, otherwise the device will not
be able to execute the delayed shutdown and the final moment of the video will be lost.
4）Note: Connection to the vehicle's engine must be connected directly to the positive anode of
the battery. Do Not Use bond strap for grounding as it will produce negative pulses that would
interfere the device's normal operation. The negative pole of the power code must be Φ1.5mm and
above.

6
1.4 Packing list
Packing list:
4CH MDVR: 1pcs
IR remote controller: 1pcs
Video input cable: 4pcs (the other side is naked wires only)
Video output cable: 1pcs
Key: 2pcs
1.5 Video cable: pins instruction
1
12V
2
GND
3
Audio
4
Video

7
1.6 SD memory installation
Please use original SD card, Recommend brand Kinstone, class 10, high speed, max.
support 128GB
1.7DVR lock and keys
DVR will not working properly if DVR unlock.
When you testing or using DVR, please make sure the LOCK is on, otherwise DVR will reboot or
power off automatically.
1.8 Remote control instruction
Keys
Function
Startup/power off
Power off/on DVR
LOGIN
Login into main menu
0-9 number keys
Type numbers into system, menu or login password
and
Digit keys1,2,3,4
Switch between 1-channel and 4-channel version.
Press it, show 4-channel. Press digit key 1,2,3,4,
can separately switch to CH1,CH2,CH3,CH4
“＋”and “－”key
Adjust digit when plus or deduct
INFO
Check all DVR status and dvr info
, , ,
Direction key, move up,down,left and right
“ENTER”
Choose and save settings
RETURN
Return to last menu or previous steps
Cancel
Delete or cancel the data you typed into MENU.
PREV
REW for playback recording, 4 grades: 2X，4X，
8X,16X
（PLAY/Pause）
Start playback video
Press it one time to pause the video playback
durning playing back video.
NEXT
FAST FORWARD for playback recording, 4 grades:
2X，4X，8X，16X
Record ●
Start manual recording key
Stop ■
Stop playing

8
2. DVR operation
2.1 Login
In preview mode, press “LOGIN”key, type password “111111”, and then, press OK to login.
Note: Default password is 111111, please remember if you set up a new password. If you lost it,
please contact your supplier for a reset password file.
After login, below is main menu

9
2.2 System set up
2.2.1 Basic set up
Instruction：
1. Press direction key to move to the item you want to set up, and type in correct data.
2. Press “cancel”key to delete the wrong data
3. DEV ID is used for 3G/4G function. If you have your own server, you can set up this ID by
yourself, otherwise, please contact your supplier for this number.
4. After set up the data, press “SAVE”to save and exit.
Note: after you set up another language, you need to reboot DVR after you save the setting.

10
2.2.2 Power Setting
Instruction：
1. Power Mode: ACC/Timing. Press “Enter” to switch
2. Power off Delay: ACC/close selectable. Press “Enter” to switch.
If choose ACC, the user could set the delay time. Press “Cancel” and number keys to input the
number. (Note: Time range usually is 3-240min).After set up this, the MDVR will continue working
after the vehicle ignition turned off till the time you set.
3. On time/Off time: When you set power mode in “Timing”, you need to set up DVR power on/off
time here. After setting this, the MDVR will auto power on/off by the time you set up.

11
2.2.3 Alarm I/O set up
Instruction:
1. Name: There are 5 different condition, such as turning left, turning right, brake, key alarm.
2. Trigger DVR by High/Low level
High level: signal higher than 4V.
Low level: signal lower than 4V.
3. Record open/close: DVR recording video or not by sensor triggered.
4. Action: set DVR action after it be triggered by alarm input.
5. Preview: DVR switch to full screen by the alarm channel
Sensor wire with video channels
Red wire to channel 1 White wire to channel 3
Black wire to channel 2 Yellow wire channel 4

12
2.2.4 Password Setting
Instruction：
PSW Enable: Press “Enter” to switch on/off.
User’s PSW and Admin PSW could only be revised by admin.Press “Cancel” to pop up the number
keyboard and revise the new PSW.
3. Record Setting

13
3.1 Base Setting
Instruction：
1．Video mode: Press “Enter “to select PAL/NTSC
2．Record Mode: Press “Enter “to choose select Power/ Alarm/Timed
3．Bitrate: it is a fixed item, you can not set it here.
4．Camera type: DVR support 4 camera input type.
A. all AHD: 4 channels works with AHD cameras
B. AHD+Analog: channel 1 and 2 works with AHD camera, channel 3 and 4 works with analog
C. Analog+AHD: channel 1 and 2 works with analog camera, channel 3 and 4 works with AHD
D. All Analog: 4 channels works with Analog cameras
5. ALM prerecord time: DVR will pre-recording if DVR triggered by alarm signal. (time range 0S--
10S);
6. ALM REC DELAY(S): DVR will keep recording after alarm signal gone. (delay range 1-900s).
7. Normal protect time:
8. Video overlay GPS: set up GPS data show on video or not
Note: After set up the data, press Save to save it and exit.

14
3.2 Channel Setting
Instruction:
1. Set up video and working details for each channel.
2. Function
Item
Function
Enable
Set up each channel working or not
Resolve
Set up video resolution in 720P/D1/CIF
Bitrate
Higher bitrate makes video better,but it will cost more memory
Audio
Set up each channel audio recording or not
Frame
Lower rate cost lower memory, but video quality lower too

15
3.3 Schedule setting
Instruction
1. Press direction key to move into the item you want to set.
2. Type in numbers or use “+”and ”-”keys to adjust the time
3. Press Save to save the setting and exit
Warning:
1. If you set up DVR start and stop time here, when you power off DVR
manually, you can not power on DVR again till DVR reached the start time.
2. If you set up start and stop time same, DVR will not power on again after you
power off the DVR.
Solution for point 2: open DVR housing, take out the PCB board, you ca
n find a small battery on PCB board, take off it, wait 10 minutes, and th
en power on DVR without battery. at this moment, all data reset.
Power off DVR, and then install battery on PCB again. DVR works.

16
3.4 CAM MD
Instruction:
1. Set up motion detection for each channel.
2. Function
Item
Function
Enable
Set up motion detection for each channel working or not
Sensity
The higher sensitive will trigger DVR recording easier
Area
Set up detection area for each channel
How to set up motion detection working
A. Set “enable” Open. (you can set motion function on/off with the channel you need) No matter
which channel was triggered by motion, all 4 channel will start recording video. And then click
set up to set the motion detection area

17
B. Motion detection area decided by 2 points. 1st is left upon corner, please press “+”to set this
point (see below picture)
C. And then, click the direction key to move the icon

18
D. Press “-“key to set up the right down corner. After this, the final detection area had been set.
E. Power off DVR, and reboot it.

19
4.Network
4.1 Server
Set up 3G data into DVR MENU. Please contact your local SIM card supplier about these data.
1. The “phone”port, it is “center number”, normally, it is *99#
2. The “access”port, it is “APN”, please ask SIM supplier for that.
3. “User name”and “Password”should confirmed with SIM supplier too. If there has no data, just
leave it blank.
4. If you test DVR with our server, you have to keep “Server”and “Port”data same as in DVR
menu. (the IP may different as above picture, you just keep it same as in your DVR)
4.2eam
Instruction: Set up transmit data when DVR works with 3G network.

20
4.3 Other (Unavailable for now)
5. Tools
