Parker Research Corp DA1500DR User manual

OPERATING INSTRUCTIONS Bulletin
MODEL DA1500DR 262-1500-2-DR
MAGNETIC INSPECTION UNIT July 2015
THE CONTENTS OF THIS MANUAL MUST BE READ AND FULLY UNDERSTOOD
BEFORE INSTALLATION, OPERATION OR MAINTENANCE OF THIS EQUIPMENT.
FAILURE TO DO SO MAY RESULT IN INJURY.
INTRODUCTION
The DA1500DR Magnetic Inspection Unit is a portable power pack designed to furnish high
amperage, low voltage AC current and Half-Wave rectified (DC) current for Magnetic Particle
inspection. It features infinitely variable magnetizing and demagnetizing current.
THE FOLLOWING SHOULD BE READ AND FULLY UNDERSTOOD.
SAFETY PRECAUTIONS PAGE 2
GENERAL DESCRIPTION PAGE 2
ELECTRICAL FEATURES PAGE 3
CONNECTION PAGE 3
CONTROLS-ELECTRICAL PAGE 4
OPERATION PAGE 5
SERVICE DATA & WARRANTY PAGE 6
SCHEMATIC DIAGRAM PAGE 7-8
Parker Research Corporation assumes no liability from any claims arising from the use of this
equipment.
CAUTION: For the correct and safe use of this equipment, proper training of operating
personnel to required inspection techniques, specifications and safety requirements is
necessary and is the obligation of the user.

2
SAFETY PRECAUTIONS
The following safety precautions must be fully understood and applied during the installation,
operation and maintenance of this equipment. These safety precautions appear throughout
the text and are covered here for emphasis.
A. "DANGER" Ground this equipment before operating. Failure to ground this unit properly
may result in electrical shock hazard.
B. "CAUTION" Use safety glasses when operating this equipment.
C. "DANGER" Line current must be disconnected before equipment panels are removed for
any reason. Only qualified electrical personnel should attempt service.
D. "CAUTION" When performing prod inspection with this unit, use very firm contact pressure
to minimize chances of arcing.
E. "WARNING" This equipment produces a strong electromagnetic field which can be harmful
to people with Cardiac Pacemakers and implanted medical devices. Personnel with such
devices should not operate this machine and must stay a safe distance away from this
machine and cable output area. Contact the manufacturer of your medical device for
additional precautions and warnings.
GENERAL DESCRIPTION
The DA1500DR is an extremely rugged and compact Magnetic Inspection unit.
All operating controls and output terminals are located on the front panel. Two carrying
handles are provided. One on the rear of the unit; the other is a swivel handle located at the
front of the unit. This handle may also be positioned to raise the front of the unit for ease of
meter reading and operation.
Current output is approximately 1500 amperes low voltage A.C. and approximately 1500
amperes half-wave D.C. The current output is based on the use of 30 feet (two 15') cables as
a load. Current levels will vary dependent on cable length.
Optional magnetizing cables can be equipped with prods for circular magnetization. The
cables can also be wrapped around parts to form a "coil" for longitudinal magnetization.
Demagnetization is accomplished in a similar manner.
ELECTRICAL FEATURES

3
The DA1500DR unit is built to operate from either 230VAC or 460VAC (not interchangeably),
50/60 Hz., single phase current. Line current at rated output is approximately 45 amperes at
230 volts and 23 amperes at 460 volts. Check "Data Nameplate" on the unit for correct
operating voltage.
The DA1500DR is sold without a power cord plug. Only locally approved plugs with the
proper rating should be used and installed by certified personnel.
The DA1500DR is wired at the factory for either 230VAC or 460VAC operating voltage.
Change over from one voltage to another can not be done in the field. Unit must be returned
to the factory for modification.
A manual circuit breaker is provided to prevent overheating and damage to electrical
components.
The current control potentiometer in conjunction with internal electrical circuit, provide
infinitely variable magnetizing and demagnetizing current control.
The power transformer operating in conjunction with an SCR module, transforms the high
voltage line input to low voltage, high amperage AC or Half-Wave DC output. While these
components are fan cooled, they are designed for intermittent service at 1500 amperes
output. To avoid overheating and possible damage, a maximum duty cycle of 10% must be
adhered to.
CAUTION: Attaching less than 30' of 4/O cable (two 15' cables) may cause excessive line
current draw and possible overheating of parts.
CONNECTION
1. With the current control in the "Off" position, connect the line cord to the properly fused and
grounded disconnect switch of proper rating. Consult "Data Nameplate" on the back of the
unit for correct operating voltage.
2. Turn the current control so that the unit powers "On". A red pilot light will glow indicating
that there is power to the unit and that it is "On". The digital ammeter display will also light
showing a calibration countdown. This process takes approximately 15 seconds. Do not
attempt to power the instrument until the meter has completed its auto calibration sequence.
3. Plug in and twist clockwise two 15' 4/O magnetizing cables into the output connectors at
the front of the unit. Note: One cable must be connected to the "Common" connector. The
other cable must be connected to either the A.C. or HWDC cable connector. Connect the two
eitherend connectors or two lug connectors at the opposite end of the cables to form a "loop".
Plug in the control cable and activate to check operation for both AC and DC output.
For maximum output on either AC or half-wave DC, it is necessary to reduce the inductive
loop of the external cables as much as possible; that is, the spacing between the external
4/O cables must be kept at a minimum. If possible, the first ten feet of cable may be bound or
taped together for optimum current output. NOTE: When cables are used as a coil with AC
current, ammeter readings will be lower due to coil/part inductance.
CONTROLS –ELECTRICAL

4
CURRENT CONTROL/RED PILOT LIGHT
This is the main switch, located next to the ammeter on the front panel. With the current
control in any position other than "Off", the red pilot light will glow indicating that the unit is
ready for operation. Current values will be indicated by the digital ammeter reading when the
external magnetizing circuit (loop) is complete.
CIRCUIT BREAKER
This control is located on the back of the unit. It will interrupt the current to the unit whenever
the rated amperage of the circuit breaker is exceeded.
AMMETER
The digital ammeter, located on the front panel, registers the current flowing in the
magnetizing circuits. An automatic switching circuit allows a single meter to provide accurate
current readings for both AC and half-wave DC magnetizing currents.
OUTPUT CONNECTORS
Half-wave DC current is obtained by connecting the magnetizing cables to the "Common" and
"Half-Wave" connectors. A.C. current is obtained by connecting to the "Common" and "AC"
connectors. Always insert and then twist cable connectors clockwise to lock in position.
CONTROL CABLE RECEPTACLE
This receptacle is located below the current control. Twist and lock the control cable in the
receptacle.
PROD CONTROL SWITCH
Various optional prod assemblies have a control switch built into the handle. It is connected
through a 20' cable and three prong twist lock plug to the control cable receptacle. It controls
the magnetizing current through the prods.
REMOTE CONTROL CABLE SWITCH
The optional remote control switch is attached to a 20' cable and activates the unit with a
push button switch. This switch is required when using cables as
a coil.
CONTROL CIRCUIT FUSE
This fuse is located on the rear panel. Replacement can be accomplished from the outside.
After power has been turned off, unscrew the head of the fuse holder. Remove the fuse from
the holder by pulling out the fuse. Replace with a new fuse of proper rating and place back
into holder. Replace fuse holder head. This fuse will interrupt the 115 volt control circuit in the
event of an overload.

5
OPERATION
COIL MAGNETIZATION
1. Attach (2) 15' lengths of 4/O cable to the appropriate connectors of the front panel.
2. Wrap three turns of a 15 foot cable around or through the part to be inspected. Connect in
series with the two other cables to form a 30 foot closed circuit.
3. Plug remote control cable into "Control Cable" receptacle. Use switch to control
magnetizing current.
4. Turn current control to position that provides desired current level.
5. Apply magnetic inspection powder or bath to the surface to be inspected while current is
on. Inspect for lines of magnetic particle build-up indicating circular defects.
PROD MAGNETIZATION
1. Attach two 15' lengths of 4/O cables to appropriate connectors on front panel.
2. Plug prod control cable into "Control Cable Receptacle".
3. Turn current control to position that gives desired current level.
4. Make prod contacts with clean surface of part. Place prod tips approximately six inches
apart on either side of the line of suspected defect. Press prod handle switch to initiate
current flow. Use very firm contact pressure to minimize chances of arcing and burning.
Ammeter will indicate magnetizing current.
5. Apply magnetic powder to the surface while magnetizing current is on.
6. Release prod handle switch to stop current flow. Remove prods from parts.
DEMAGNETIZATION
Connect a formed coil to the AC and common output terminals. Set the current control to
desired current level. Depending upon the size, the part is either passed through the coil, or
the coil is passed completely over the part and slowly withdrawn while current is on. As the
part or coil is withdrawn, the diminishing intensity of the AC field completes the
demagnetization.

6
SERVICE DATA
Each DA1500DR is thoroughly tested and adjusted before shipping from the factory.
However, while operators and maintenance department personnel should be familiar with the
function of the electrical circuits all units should be returned to the factory for repairs.
WARRANTY
The DA1500DR is warranted against malfunction due to defective material and workmanship.
The warranty shall cover repair or replacement of the DA1500 at no charge (less incoming
freight charges) for a period of one (1) year from the date of purchase. Warranty will not apply
to units that have been altered or to those units that have been used improperly.
In the event of malfunction, return the unit (prepaid) to the factory. Repair or replacement of
the defective unit will be made at the discretion of Parker Research Corporation. The
repaired or replacement unit will be returned to the original purchaser prepaid. Note: Do not
return cables or prods with defective unit.
SHIP TO:
PARKER RESEARCH CORPORATION
2642 ENTERPRISE ROAD WEST
CLEARWATER, FLORIDA 33763
ATTENTION: REPAIR DEPT.
