Parker Hurricane Plus HT0805H Guide

Model:
HT0805H
HT0806B
Hurricane Plus Blowers
OPERATION SERVICE PARTS CARE

IMPORTANT SAFETY INSTRUCTIONS READ ALL
INSTRUCTIONS BEFORE USING
WARNING
 To prevent personal injury or property damage, do not attempt to start engine until all assembly steps are
complete and you have read and understand the safety and operating instructions in this manual.
 Under California law, and under laws of several other states, you are not permitted to operation internal
combustion's engine using hydrocarbon fuels on any forest covered, brush covered, or grass covered
land, or on land with grain, hay, or other flammable agricultural crop, without an engine spark arrester in
continuous effective working order. The engine on your power equipment, like most outdoor power
equipment, is an internal combustion engine that burns gasoline, a hydrocarbon fuel. Therefore, your
power equipment must be quipped with a spark arrester muffler in continuous effective working order. The
spark arrester must be attached to the engine exhaust system in such a manner that flames or heat from
the system will not ignite flammable material. Failure of the owner/operator of the equipment to comply
with this regulation is a misdemeanor under California law, and may also be a violation of other state
and/or federal regulations, laws, ordinances, or codes. Contact your local fire marshal or forest service for
specific information about what regulations apply in your area.
 Wear approved safety glasses when operating this equipment. The operation of any powered
machine can result in foreign objects being thrown by high-speed rotating parts.
 Wear work gloves, sturdy footwear, and hearing protection when operating this equipment.
 Remove hearing protection and watch for traffic when operating near, or when crossing roadways.
 Before inspecting or servicing any part of equipment, shut off engine, disconnect spark plug wire from
spark plug, and make sure that all moving parts have come to a complete stop. Be aware that rotating
blades slow down gradually after engine is shut off.
 Exercise extreme caution on slopes and avoid excessively steep slopes.
 Never leave equipment unattended when engine is running. Shut off engine and disconnect spark plug
wire from spark plug before leaving equipment. Turn off fuel shut-off if equipped.
 Do not vacuum any burning or smoldering materials such as cigars, cigarettes, ashes, or cinders.
 Do not vacuum areas that have been recently treated with fertilizers, pesticides, or herbicides.
Follow chemical manufacturer's safety instructions regarding contact with treated areas.
 Do not vacuum flammable liquids such as gasoline, kerosene, diesel fuel, paint thinner, etc.
 Do not operate this equipment on a paved, gravel, or hard surface unless the collection bag is
installed. Discharged material may bounce from a hard surface.
 Never pick up or carry equipment while the engine is running.
 Walk, never run.
 Never allow children or untrained adults to operate this equipment.
 Keep the area of operation clear of all persons, particularly small children, and pets. Keep bystanders at
least 25 feet away from the area of operation.

 Do not run engine in an enclosed area. Engine exhaust contains carbon monoxide gas, a deadly
poison that is odorless, colorless, and tasteless.
 Do not operate this equipment near buildings, windows, or air conditioners.
 Do not allow hands or any other part of the body or clothing inside the vacuum inlet.
 Do not start engine or operate this equipment with any safety guards or housing removed.
 Operate machine in daylight or good artificial light.
 Do not change the engine governor settings or overspeed the engine.
DANGER
Gasoline is highly flammable and its vapors are explosive. To prevent personal injury or
property damage:
 Do not add fuel if engine is running or still hot from recent operation. Allow engine to cool for at
least three minutes.
 Do not fill fuel tank indoors. After filling, wipe up any spills and move away from gasoline fumes
before starting engine.
 Do not allow open flame, matches, or smoking in area.
 Fill fuel tank with fresh, clean unleaded regular automotive gasoline, (leaded regular and
unleaded or leaded premium grades of gasoline are acceptable substitutes).
 Do not mix oil with gasoline.
 Clean the area around the fuel fill cap and remove the cap from the fuel tank. Insert a clean
funnel
into the fuel tank.
 Fill the tank to 1/2 inch below the bottom of the filter neck to provide space for any fuel
expansion.
 Reinstall the fuel fill cap securely and wipe up any spilled gasoline.
 Store fuel in containers specifically designed for these purposes.
 Replace faulty silencers or mufflers and muffler guards.
 Before using, visually inspect to see that the blade and blade bolts are not worn or damaged
and, if needed, replace in sets.
 Do not start the engine when standing in front of the discharge chute.
 Drain fuel outdoors.
SAVE THESE INSTRUCTIONS

HT0805H HT0806B
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1
3
60510
Blower Hsng Assy. 5/6 Hp
1
2
360509
Hsng. Chute Assy. 5/6 Hp
1
3
360500
-
1
Frame Weld Assy.
1
4
360104
WheelBracket
1
5
360133
Wheel 8x2 w.5 Bore
-
Front
1
6
360118 N/A
Axel Rear Part of Item 3
_
-
7
360140
Wheel Pneu. ¾
Bore
2
8
360100
Blower Chute Flap
1
9
360020
Blower Door
1
10
170051
Spring
1
11
360109PTD
Handle Blower
1
12
360035
Engine Honda 5hp
1
12A
360036
Engine Briggs 6.0
1
13
360112
Weld Tube
2
14
360513
Safety Guard 5 & 6 Hp
2
1
5
350139
Knob 5/16 Thread
1
16
360108
Sleve Handle
1
17
360129
Rubber Shims
2
18
64
-
134
-
A
Spacer .75 X 1.43 X .25
1
19
711512
Wshr. Flat .75 X1.37 X .08
5
20
360512
Fan Assy 5/6 Hp
1
21
60
-
516
-
24
Blt
-
HH 5/16
-
24 X 1.5 #5
1
22
713030
Blt
-
HH 5/16
-
18 x 1 3/4 #5
8
23
711506
Wshr Flat 5/16
24
24
711374
Nut Nyloc 5/16
-
18
24
25
831889
Pin Clevis 5/16 X ½ Zinc
1
26
711808
Pin Hair Pin Cotter #13
1
27
710232
Screw 10
-
32 X .75
2
28
711350
Nut Nyloc 10
-
32
2
29
75
-
89
-
A
Nut Speed 1/4
4
30
67
-
521
-
A
Pin Roll 3/16 X 1.0
2
31
711809
Pin Cotter 1/8
2
32
713026
Blt
-
HH5/16
-
18 x ¾ #5
3
33
712122
Blt Shldr.Sckt.1/2 x 2 1/2
1
34
711592
Wshr Flt..940x.506x.064 Nyl
2
35
711515
Wshr Flt .406 x.812
x.0625
1
36
711380
Nut Nyloc 3/8
-
16
1
37
712102
Bolt Carriage 5/16 x 3/4
5
38
713031
Blt
-
HH5/16
-
18 x 2 #5
4
39
713001
Blt
-
HH ¼
-
20 x .62
3
40
711505
Wshr. Flat 1/4
2
41
711373
Nut Nyloc 1/4
-
20
3
42
60
-
51
6
-
20
Blt
-
HH 5/16
-
24 x 1.25
4
43
350320
Engine Spacer
1
44
711545
Washer Helical 5/16
5
45
82
-
138
-
B
-
Washer Special
1
47
46
SA-1070-B Fan Cover Assy. 5/6 Hp 1
1

LIMITED WARRANTY
The Parker Sweeper Company warrants to the original purchaser/user that this product is free from defects in
workmanship and materials under normal use and service for a period of two years from date of purchase. In
addition, Parker Sweeper Company will, at its option, honor labor warranty claims for the first 12 months from date of
sale, provided such claims are submitted through and approved by factory authorized repair stations. Parker Sweeper
Company will, at its option, repair or replace without charge, except for transportation costs, parts that fail under
normal use and service when operated and maintained in accordance with the applicable operation and instruction
manuals.
This warranty does not apply to normal wear, or to items whose life is dependent on their use and care, such as belts,
cords, switches, hoses, rubber parts, electrical motor components or adjustments. Parts not manufactured by Parker
Sweeper Company such as engines, batteries, battery chargers, hydraulic pumps, and tires are covered by and
subject to the warranties and/or guarantees of their manufacturers. Please contact Parker Sweeper Company for
procedures in warranty claims against these manufacturers.
Special warning to purchaser - Use of replacement filters and/or prefilters not manufactured by Parker Sweeper
Company or its designated licensees, will void all warranties expressed or implied.
A potential health hazard exists without exact original equipment replacement.
All warranteed items become the sole property of Parker Sweeper Company or its original manufacturer, whichever
the case may be.
Parker Sweeper Company disclaims any implied warranty, including the warranty of merchantability and the warranty
of fitness for a particular purpose. Parker Sweeper Company assumes no responsibility for any special, incidental or
consequential damages.
This limited warranty is applicable only in the U.S.A. and Canada, and is extended only to the original user/purchaser
of this product. Customers outside the U.S.A. and Canada should contact their local distributor for export warranty
policies. Parker Sweeper Company is not responsible for costs or repairs performed by persons other than those
specifically authorized by Parker Sweeper Company. This warranty does not apply to damage from transportation,
alterations by unauthorized persons, misuse or abuse of the equipment, use of non-compatible chemicals, or damage
to property, or loss of income due to malfunctions of the product.
If a difficulty develops with this machine, you should contact the dealer from whom it was purchased.
This warranty gives you specific legal rights, and you may have other rights which vary from state to state. Some
states do not allow the exclusion or limitation of special, incidental or consequential damages, or limitations on how
long an implied warranty lasts, so the above exclusions and limitations may not apply to you.
Division of Kwik Products Inc.
3700 East Anne Street Phoenix, AZ 85040
Tel: 602 453·3950 Fax: [phone]·3929
988401
Revised 0209
