Parker 590 series User manual

590 Series
DC Digital
Converter
Product Manual
HA467078 Issue 7
©Copyright 2007 Parker SSD Drives, a division of Parker Hannifin Ltd.
All rights strictly reserved. No part of this document may be stored in a retrieval system, or transmitted in any
form or by any means to persons not employed by a Parker SSD Drives company without written permission
from Parker SSD Drives, a division of Parker Hannifin Ltd . Although every effort has been taken to ensure the
accuracy of this document it may be necessary, without notice, to make amendments or correct omissions.
Parker SSD Drives cannot accept responsibility for damage, injury, or expenses resulting therefrom.
Compatible with Version 4.x Software

Cont.2
WARRANTY
Parker SSD Drives warrants the goods against defects in design, materials and workmanship for the period of 12 months from the date of delivery on the
terms detailed in Parker SSD Drives Standard Conditions of Sale IA058393C.
Parker SSD Drives reserves the right to change the content and product specification without notice.

Cont.3
Requirements
IMPORTANT: Please read this information BEFORE installing the equipment.
Intended Users
This manual is to be made available to all persons who are required to install, configure or
service equipment described herein, or any other associated operation.
The information given is intended to highlight safety issues, EMC considerations, and to enable
the user to obtain maximum benefit from the equipment.
Complete the following table for future reference detailing how the unit is to be installed and
used.
INSTALLATION DETAILS
Serial Number
(see product label)
Where installed
(for your own
information)
Unit used as a:
(refer to Certification
for the Inverter)
RComponent RRelevant Apparatus
Unit fitted: RWall-mounted REnclosure
Application Area
The equipment described is intended for industrial motor speed control utilising AC induction or
AC synchronous machines.
Personnel
Installation, operation and maintenance of the equipment should be carried out by qualified
personnel. A qualified person is someone who is technically competent and familiar with all
safety information and established safety practices; with the installation process, operation and
maintenance of this equipment; and with all the hazards involved.
Product Warnings
Caution
Risk of electric
shock
Caution
Refer to
documentation
Earth/Ground
Protective
Conductor
Terminal

Cont.4
Hazards
DANGER! - Ignoring the following may result in injury
1. This equipment can endanger life by exposure to
rotating machinery and high voltages.
2. The equipment must be permanently earthed due to
the high earth leakage current, and the drive motor
must be connected to an appropriate safety earth.
3. Ensure all incoming supplies are isolated before
working on the equipment. Be aware that there may
be more than one supply connection to the drive.
4. There may still be dangerous voltages present at
power terminals (motor output, supply input phases,
DC bus and the brake, where fitted) when the motor
is at standstill or is stopped.
5. For measurements use only a meter to IEC 61010 (CAT
III or higher). Always begin using the highest range.
CAT I and CAT II meters must not be used on this
product.
6. Allow at least 5 minutes for the drive's capacitors to
discharge to safe voltage levels (<50V). Use the
specified meter capable of measuring up to 1000V dc &
ac rms to confirm that less than 50V is present between
all power terminals and earth.
7. Unless otherwise stated, this product must NOT be
dismantled. In the event of a fault the drive must be
returned. Refer to "Routine Maintenance and Repair".
WARNING! - Ignoring the following may result in injury or damage to equipment
SAFETY
Where there is conflict between EMC and Safety requirements, personnel safety shall always take precedence.
•Never perform high voltage resistance checks on the
wiring without first disconnecting the drive from the
circuit being tested.
•Whilst ensuring ventilation is sufficient, provide
guarding and /or additional safety systems to
prevent injury or damage to equipment.
•When replacing a drive in an application and before
returning to use, it is essential that all user defined
parameters for the product’s operation are correctly
installed.
•All control and signal terminals are SELV, i.e. protected
by double insulation. Ensure all external wiring is rated
for the highest system voltage.
•Thermal sensors contained within the motor must have
at least basic insulation.
•All exposed metalwork in the Inverter is protected by
basic insulation and bonded to a safety earth.
•RCDs are not recommended for use with this product
but, where their use is mandatory, only Type B RCDs
should be used.
EMC
•In a domestic environment this product may cause
radio interference in which case the user may be
required to take adequate counter-measures.
•This equipment contains electrostatic discharge
(ESD) sensitive parts. Observe static control
precautions when handling, installing and servicing
this product.
•This is a product of the restricted sales distribution class
according to IEC 61800-3. It is designated as
“professional equipment” as defined in EN61000-3-2.
Permission of the supply authority shall be obtained
before connection to the low voltage supply.
CAUTION!
APPLICATION RISK
•The specifications, processes and circuitry described herein are for guidance only and may need to be adapted to the
user’s specific application. We can not guarantee the suitability of the equipment described in this Manual for
individual applications.
RISK ASSESSMENT
Under fault conditions, power loss or unintended operating conditions, the drive may not operate as intended.
In particular:
•Stored energy might not discharge to safe levels
as quickly as suggested, and can still be present
even though the drive appears to be switched off
•The motor's direction of rotation might not be controlled
•The motor speed might not be controlled
•The motor might be energised
A drive is a component within a drive system that may influence its operation or effects under a fault condition.
Consideration must be given to:
•Stored energy •Supply disconnects •Sequencing logic •Unintended operation

Contents
Contents Page
Cont.5
Chapter 1 GETTING STARTED
Introduction ..................................................................................................1-1
Equipment Inspection and Storage ..............................................................1-2
Packaging and Lifting Details ...................................................................... 1-2
About this Manual ........................................................................................1-2
Initial Steps .............................................................................................................1-2
How the Manual is Organised .................................................................................1-3
Chapter 2 AN OVERVIEW OF THE CONVERTER
How it Works................................................................................................. 2-1
Component Identification .............................................................................2-2
Control Features ........................................................................................... 2-3
Understanding the Product Code .................................................................2-4
Chapter 3 INSTALLING THE CONVERTER
Mechanical Installation ................................................................................3-1
Mounting the Converter...........................................................................................3-2
•Ventilation and Cooling Requirements ...................................................3-2
•AC Line Choke .....................................................................................3-2
Electrical Installation ....................................................................................3-3
Minimum Connection Requirements.........................................................................3-4
•Protective Earth Connections (PE) ...........................................................3-6
•Power Wiring Connections ....................................................................3-7
•Control Wiring Connections ................................................................3-10
Motor Field Connections........................................................................................3-14
•Internal/External Supply ......................................................................3-14
•Power Board - PCB Reference 385851.................................................3-14
•Power Board - PCB Reference 385621.................................................3-15
•Power Board - PCB Reference 385128.................................................3-16
DC Contactor - External VA Sensing.......................................................................3-16
•Power Board - PCB Reference 385851.................................................3-16
•Power Board - PCB Reference 385621.................................................3-17
External AC Supply EMC Filter Installation ..............................................................3-17
Earth Fault Monitoring Systems ..............................................................................3-19
Installation Drawings .................................................................................3-20
Converter Installation Drawings .............................................................................3-20
External Stack Installation Drawings .......................................................................3-30
Filter Installation Drawings.....................................................................................3-33
AC Line Choke Installation Drawing.......................................................................3-40
590 Capacitor Box................................................................................................3-41

Contents
Contents Page
Cont.6
Chapter 4 OPERATING THE CONVERTER
Pre-Operation Checks ..................................................................................4-1
Setting-up the Converter ..............................................................................4-2
Calibration .............................................................................................................4-2
Switchable Calibration Panel .......................................................................4-2
Analog Tacho Calibration Option Board ......................................................4-3
Microtach/Encoder Feedback Option Board .................................................4-3
Selecting Speed Feedback .......................................................................................4-4
Initial Start-up Routine ................................................................................. 4-5
Performance Adjustment........................................................................................4-11
Current Loop - The Autotune Feature .........................................................4-11
Speed Loop ..............................................................................................4-11
Starting and Stopping Methods..................................................................4-12
Stopping Methods .................................................................................................4-12
Normal Stop (C3) .....................................................................................4-13
Program Stop (B8) ....................................................................................4-15
Coast Stop (B9).........................................................................................4-16
Standstill...................................................................................................4-16
The Trip Condition ....................................................................................4-16
Normal Starting Method........................................................................................4-17
Advanced Starting Methods ...................................................................................4-17
Starting Several Converters Simultaneously.................................................4-17
Jog ..........................................................................................................4-17
Crawl.......................................................................................................4-17
Chapter 5 THE MAN-MACHINE INTERFACE (MMI)
Introducing the MMI ..................................................................................... 5-1
Welcome Screen .........................................................................................5-1
Using the MMI ..............................................................................................5-1
Control Keys ...........................................................................................................5-1
Keys for Programming the Converter ...........................................................5-1
LED Indications .......................................................................................................5-2
The Menu System..........................................................................................5-3
Navigating the Menu System....................................................................................5-3
The Menu System Map ............................................................................................5-4
Changing a Parameter Value...................................................................................5-5
Alarm Message Displays..........................................................................................5-5
Quick Diagnostics ...................................................................................................5-5
Special Key Combinations .......................................................................................5-5
Special Menu Features..................................................................................5-5

Contents
Contents Page
Cont.7
Menu Viewing Levels ...............................................................................................5-5
Selecting the Display Language................................................................................5-5
Password Protection ................................................................................................5-6
To Activate Password Protection ...................................................................5-6
To Deactivate Password Protection ...............................................................5-6
To Reactivate Password Protection................................................................5-6
How to Save, Restore and Copy your Settings.............................................. 5-7
Saving Your Application ..........................................................................................5-7
Restoring Saved Settings ..........................................................................................5-7
Copying an Application ...........................................................................................5-7
Chapter 6 PROGRAMMING YOUR APPLICATION
Programming with Block Diagrams ............................................................. 6-1
Modifying a Block Diagram .....................................................................................6-1
Configuration and Parameterisation Modes..................................................6-1
Making and Breaking Links in Configuration Mode.......................................6-1
Programming Rules.....................................................................................6-1
Saving Your Modifications ...........................................................................6-2
Understanding the Function Block Description ..........................................................6-2
MMI Menu Maps.........................................................................................6-2
Hexadecimal Representation of Trips........................................................................6-3
Function Block Descriptions.......................................................................... 6-4
ANALOG INPUTS .......................................................................................6-5
ANALOG OUTPUTS....................................................................................6-7
AUX I/O .....................................................................................................6-8
AUX PORT P2 ...........................................................................................6-10
CALIBRATION...........................................................................................6-11
CURRENT LOOP.......................................................................................6-14
CURRENT PROFILE....................................................................................6-17
DIAGNOSTICS .........................................................................................6-18
DIAMETER CALC.......................................................................................6-22
DIGITAL INPUTS .......................................................................................6-24
DIGITAL OUTPUTS ...................................................................................6-26
FIELD CONTROL ......................................................................................6-27
INHIBIT ALARMS .......................................................................................6-30
JOG/SLACK .............................................................................................6-32
LINK 11 & LINK 12 ...................................................................................6-34
MAIN PORT P1 .........................................................................................6-36
MENUS ....................................................................................................6-37
miniLINK ..................................................................................................6-38

Contents
Contents Page
Cont.8
PID ..........................................................................................................6-39
RAISE/LOWER...........................................................................................6-42
RAMPS .....................................................................................................6-44
SETPOINT SUM 1 .....................................................................................6-48
SETPOINT SUM 2 .....................................................................................6-49
SPEED LOOP ............................................................................................6-51
ADVANCED..............................................................................................6-55
STANDSTILL .............................................................................................6-56
STOP RATES .............................................................................................6-57
SYSTEM PORT P3......................................................................................6-59
TAPER CALC.............................................................................................6-60
TENS+COMP CALC. ................................................................................6-61
TORQUE CALC. .......................................................................................6-63
USER FILTER .............................................................................................6-64
Chapter 7 TRIPS AND FAULT FINDING
Trips ..............................................................................................................7-1
What Happens when a Trip Occurs..........................................................................7-1
MMI Indications ..........................................................................................7-1
Resetting a Trip Condition........................................................................................7-1
Alarm Messages......................................................................................................7-1
LAST ALARM ...............................................................................................7-2
HEALTH WORD ..........................................................................................7-2
HEALTH STORE...........................................................................................7-2
Using the MMI to Manage Trips ...............................................................................7-2
Trip Messages.............................................................................................7-2
Symbolic Alarm Messages ...........................................................................7-4
Self Test Alarms ..........................................................................................7-5
Setting Trip Conditions ................................................................................7-5
Viewing Trip Conditions ..............................................................................7-5
Inhibiting Alarms.........................................................................................7-5
Fault Finding................................................................................................. 7-6
Test Points...............................................................................................................7-6

Contents
Contents Page
Cont.9
Chapter 8 ROUTINE MAINTENANCE AND REPAIR
Routine Maintenance....................................................................................8-1
Repair ...........................................................................................................8-1
Saving Your Application Data ..................................................................................8-1
Returning the Unit to Parker SSD Drives....................................................................8-1
Technical Support Checks........................................................................................8-2
Chapter 9 CONTROL LOOPS
Principle of Operation .................................................................................. 9-1
Current Loop ..........................................................................................................9-1
•Manual Tuning .....................................................................................9-2
Speed Loop ............................................................................................................9-4
Field Control...........................................................................................................9-4
•Set-up Notes.........................................................................................9-4
•Current Control ....................................................................................9-5
•Voltage Control ....................................................................................9-5
•Field Weakening...................................................................................9-5
•Standby Field........................................................................................9-5
Chapter 10 PARAMETER SPECIFICATION TABLE
Specification Table: Tag Number Order..................................................... 10-2
Chapter 11 TECHNICAL SPECIFICATIONS
Environmental Details............................................................................................11-1
EMC Compliance..................................................................................................11-1
External AC Supply (RFI) Filters and Line Choke ......................................................11-2
Cabling Requirements for EMC Compliance ...........................................................11-2
Internal Fuses........................................................................................................11-3
External Fuses (European)......................................................................................11-3
Earthing/Safety Details ..........................................................................................11-3
Electrical Ratings - Power Circuit ............................................................................11-4
3-Phase Power Supply Details ................................................................................11-4
Electrical Ratings - Output......................................................................................11-5
Auxiliary Power Supply Details................................................................................11-5
Terminal Definitions (Digital/Analog Inputs & Outputs)............................................11-6
Printed Circuit Board Types....................................................................................11-7
Power Terminals....................................................................................................11-7
Terminal Information (Power Board).......................................................................11-8
Terminal Information (Control Board)...................................................................11-10

Contents
Contents Page
Cont.10
Terminal Information (Option Boards)..................................................................11-14
Termination Tightening Torque ............................................................................11-15
Mechanical Details..............................................................................................11-15
Cooling ..............................................................................................................11-16
Chapter 12 CERTIFICATION FOR THE CONVERTER
Requirements for EMC Compliance.............................................................12-1
Minimising Radiated Emissions ..............................................................................12-1
Earthing Requirements...........................................................................................12-1
Protective Earth (PE) Connections ...............................................................12-1
EMC Earth Connections ............................................................................12-2
Cabling Requirements ...........................................................................................12-2
Planning Cable Runs.................................................................................12-2
Increasing Motor Cable Length..................................................................12-2
EMC Installation Options.......................................................................................12-3
Screening & Earthing (cubicle mounted, Class B) ........................................12-3
Star Point Earthing ....................................................................................12-4
Sensitive Equipment ..................................................................................12-5
Requirements for UL Compliance ...............................................................12-6
Motor Overload Protection ........................................................................12-6
Branch Circuit/Short Circuit Protection Requirements...................................12-6
Short Circuit Ratings..................................................................................12-6
Field Wiring Temperature Rating................................................................12-7
Operating Ambient Temperature ...............................................................12-7
Field Wiring Terminal Markings .................................................................12-7
Terminal Tightening Torque.......................................................................12-7
Field Grounding Terminals........................................................................12-7
Field Terminal Kits ....................................................................................12-7
Fuse Replacement Information...................................................................12-7
European Directives and the CE Mark........................................................ 12-8
CE Marking for Low Voltage Directive ....................................................................12-8
CE Marking for EMC - Who is Responsible?............................................................12-8
Legal Requirements for CE Marking ...........................................................12-9
Applying for CE Marking for EMC..............................................................12-9
Which Standards Apply?......................................................................................12-10
Basic and Generic Standards...................................................................12-10
Certificates..........................................................................................................12-12

Contents
Contents Page
Cont.11
Chapter 13 STANDARD AND OPTIONAL EQUIPMENT
Standard Equipment...................................................................................13-1
Power Board Circuit Descriptions ...........................................................................13-1
590/591 (AH385851U002, U003, U004, U005).......................................13-1
590/591 (AH385621U001) ......................................................................13-5
598/599 Power Board (AH385128U009) ................................................13-10
Heatsink Cooling Fan Connections ......................................................................13-10
Contactor Supply ................................................................................................13-10
Optional Equipment .................................................................................13-11
Speed Feedback Option Boards...........................................................................13-11
Microtach Option Board..........................................................................13-12
Wire-Ended Encoder Option Board..........................................................13-12
Tacho Calibration Option Board..............................................................13-12
Combined Tacho and Encoder Feedback.................................................13-13
Communications Option Boards ..........................................................................13-13
Comms Option Board (P1) ......................................................................13-13
Remote 5721 Operator Station ............................................................................13-13
Chapter 14 SERIAL COMMUNICATIONS
Main Serial Port (P1) ..................................................................................14-1
Aux Serial Port (P2).....................................................................................14-1
5721 Operator Station ..........................................................................................14-1
System Port (P3).......................................................................................... 14-2
ConfigEd Lite ........................................................................................................14-2
UDP Support.........................................................................................................14-2
UDP Menu Structure..................................................................................14-3
UDP Transfer Procedure ............................................................................14-3
MMI Dump...............................................................................................14-4
5703 Support .......................................................................................................14-8
Commissioning the 5703/1.......................................................................14-9
Error Codes ............................................................................................... 14-10
ERROR REPORT (EE) ............................................................................................14-10
Chapter 15 THE DEFAULT APPLICATION
Block Diagrams ..........................................................................................15-1
Programming Block Diagram - Sheet 1 ..................................................................15-3
Programming Block Diagram - Sheet 2 ..................................................................15-4
Main Block Diagram .............................................................................................15-5
Field Control Block Diagram..................................................................................15-6
Start/Healthy Logic Block Diagram.........................................................................15-7
Functional Block Diagram......................................................................................15-8

605 FrequencyInverter/HA389591/Issue1
Contents
Contents Page
Cont.12

Getting Started 1-1
590 Series Digital Converter
1GETTING STARTED
Introduction
System Design
The 590 Series Converter is designed for use in a suitable enclosure, with associated control
equipment. The unit accepts standard three-phase ac supply voltages in the range 110V to 660V,
depending upon the model, and is suitable for the powering of DC shunt field and permanent
magnet motors, providing controlled dc output voltage and current for armature and field.
All units are designed for simple and economical panel mounting using keyhole slots. Plug-in
control connectors simplify the fitting and removal of the unit to the panel.
Where possible, standard parts are used throughout the range thereby reducing the variety of
spare parts required to maintain a multi-drive system. For example, the same basic control
boards are used in all types of three-phase armature controller regardless of horsepower or
bridge configuration.
The control circuit is totally isolated from the power circuit thus simplifying the interconnection
of controllers within a system and improving operator safety. The coding circuitry adjusts
automatically to accept supply frequencies between 45-65Hz and possesses high immunity to
supply-borne interference. The armature controllers are phase rotation insensitive.
Control and Communications
The Converter is controlled by a 16 bit Microcontroller providing advanced features such as:
•Complex control algorithms which are not achievable by simple analog techniques.
•Software-configurable control circuitry built around standard software blocks.
•Serial link communications with other drives or a PC for advanced process systems.
The integral Man-Machine Interface (MMI), with a two-line 16 character display, is a powerful
diagnostic tool. It provides access to all alarms, inputs and principal software blocks in the
controller, whilst the front panel LED indicators give an immediate status display of the drive,
key inputs and outputs.
Regenerative and Non-Regenerative Models
The motor armature controllers include both regenerative and non-regenerative models:
•Regenerative controllers consist of two fully-controlled thyristor bridges and a field bridge
with full transient and overload protection, together with sophisticated electronic control of
acceleration and deceleration, speed and torque in both directions of rotation.
•Non-regenerative controllers consist of one fully-controlled thyristor bridge and a field
bridge with full transient and overload protection, together with its associated electronic
control circuitry, and provide accurate speed and/or torque control in one selected direction
of rotation.
Field Regulator
A field regulator is fitted as standard. The regulator consists of a full-wave half controlled single
phase thyristor bridge with transient and overload protection. It provides either a fixed voltage
or fixed current source, depending upon the selected mode of operation for constant torque
applications. The field current mode of operation can be further enhanced to provide field
weakening for drive control motors which require extended speed or constant horsepower
control.

1-2 Getting Started
590 Series Digital Converter
Equipment Inspection and Storage
•Check for signs of transit damage
•Check the product code on the rating label conforms to your requirement.
If the unit is not being installed immediately, store the unit in a well-ventilated place away from
high temperatures, humidity, dust, or metal particles.
Refer to Chapter 2: “An Overview of the Converter” to check the rating label/product code.
Refer to Chapter 8: “Routine Maintenance and Repair” for information on returning damaged
goods.
Refer to Chapter 11: “Technical Specifications” - Environmental Details for the storage
temperature.
Packaging and Lifting Details
Caution
The packaging is combustible and, if disposed of in this manner incorrectly, may lead to
the generation of lethal toxic fumes.
Save the packaging in case of return. Improper packaging can result in transit damage.
Use a safe and suitable lifting procedure when moving the drive. Never lift the drive by its
terminal connections. The larger drives are fitted with lifting points.
Prepare a clear, flat surface to receive the drive before attempting to move it. Do not damage
any terminal connections when putting the drive down.
Refer to Chapter 11: “Technical Specifications” - Mechanical Details for unit weights.
About this Manual
This manual is intended for use by the installer, user and programmer of the 590 Converter. It
assumes a reasonable level of understanding in these three disciplines.
Note: Please read all Safety Information before proceeding with the installation and operation
of this unit.
Enter the “Model No” from the rating label into the table at the front of this manual. There is
also a column for you to record your application’s parameter settings in the table in Chapter 10.
It is important that you pass this manual on to any new user of this unit.
This manual is for the following models from the 590 Converter Series:
•Three phase, regenerative, four quadrant armature controllers:
590 - for currents up to 720A
598 - external stack option for currents exceeding 720A
•Three phase non-regenerative, two quadrant armature controllers:
591 - for currents up to 720A
599 - external stack option for currents exceeding 720A
•590H and 591H (further detail is provided in the separate Addendum manual)
Initial Steps
Use the manual to help you plan the following:
Installation
Know your requirements:
•certification requirements, CE/UL/c-UL conformance
•conformance with local installation requirements
•supply and cabling requirements
Programming (MMI or suitable PC programming tool only)

Getting Started 1-3
590 Series Digital Converter
Know your application:
•plan your “block diagram programming”
•enter a password to guard against illicit or accidental changes
•learn how to back-up your application data
How the Manual is Organised
The manual is divided into chapters and paragraphs. Page numbering restarts with every
chapter, i.e. 5-3 is Chapter 5, page 3.
Application Block Diagram
You will find this at the rear of the manual. The pages unfold to show a complete block
diagram, this will become your programming tool as you become more familiar with the
software.

1-4 Getting Started
590 Series Digital Converter

2-1
12AN OVERVIEW OF THE CONVERTER
How it Works
Note: Refer to Chapter 9: “Control Loops” for a more detailed explanation.
In very simple terms, the Converter controls the dc motor with the use of Control Loops - an
inner Current Loop and an outer Speed Loop. These control loops can be seen in the Application
Block Diagram. The block diagram shows all the Converter’s software connections.
Using the Man-Machine Interface (MMI), you can select the control loops to be used by the
Converter to provide either:
•Current Control
•Speed Control (default)
It is usual to supply a Current or Speed Feedback signal to the appropriate loop for more
effective control of the Converter. Current Feedback sensors are built-in, whereas Speed
Feedback is provided directly from the armature sensing circuit (default), or by tachogenerator,
encoder or Microtach connection to the relevant option board.
When in Speed Control,
you can modify the
performance of the
Converter further by
controlling the motor
field, i.e. Field Control.
By weakening the field
current, you can obtain
an increase in motor
speed beyond that
normally achievable for
the rated Armature
Voltage of the dc motor.
The Converter is controlled remotely using digital/analog inputs and outputs. It cannot be
directly stopped or started using the MMI.
A remote 5721 Operator Station can also be connected. This allows you to read and write to
many of the drive’s parameters from outside the cubicle if required.
By plugging in a COMMS Option Board, the Converter can be linked into a network and
controlled by a PLC/SCADA or other intelligent device.
Field Current 5.7A
Voltage 200V
Speed
speed increase
due to field
weakening
armature voltage
remains constant
field current
reduced
base
speed
Armature
REMOTE START/STOP
REMOTE
SPEED CONTROL
SPEED SETPOINT
REMOTE START/STOP
REMOTE
SPEED CONTROL
SPEED SETPOINT 5721
Operator
Station
Analog/Digital Inputs and Outputs Analog/Digital Inputs and Outputs
5721 Operator Station and
MMI

2-2
Component Identification
M
E
DC DIGITAL DRIVE
ISSUE 4.X
Health
Run
Start Contactor
Program Stop
Overcurrent Trip
Coast Stop
A+ A- L1 L2 L3
4
8
3
9
7
11
6
12 10 13
15
14
16
1
2
18 17
5
Figure 2-1 View of Component Parts (110A model illustrated)
1 Main converter assembly 10 Calibration panel
2 Converter door assembly 11 Busbars - main power input
3 Hinged MMI cover 12 System Port (P3)
4 Hinged terminal cover 13 Auxiliary Serial Port (P2)
5 Field wiring terminals 14 Man-Machine Interface (MMI) keypad
6 Control terminals 15 Status LEDs
7 Control board 16 MMI display
8 Tacho/Encoder/Microtach option board 17 IP20 Top Cover
9 Main Serial Port COMMS option module (P1) 18 IP20 Fan Housing (where fitted)

2-3
Control Features
Control Control Circuits Fully isolated from power circuit (SELV)
Output Control •Fully controlled 3-phase thyristor bridge
•Microprocessor implemented phase control extended
firing range
•For use on 50 or 60Hz supplies with a frequency
compliance range of 45 to 65Hz
•Phase control circuits are phase rotation insensitive
Control Action •Fully digital
•Advanced PI with fully adaptive current loops for
optimum dynamic performance
•Self Tuning Current Loop utilising "Autotune"
algorithm
•Adjustable speed PI with integral defeat
Speed Control •By Armature Voltage feedback with IR compensation
•By Encoder feedback or analog tachogenerator
Speed Range 100 to 1 typical with tachogenerator feedback
Steady State
Accuracy
•0.01 % Encoder Feedback with Digital setpoint
(serial link or P3)
•0.1 % Analog Tach Feedback
•2 % Voltage Feedback
•Absolute (0.0% error) using QUADRALOC Mk II
digital controller
Note: Long term analog accuracy is subject to
tachogenerator temperature stability.
Adjustments All adjustments in software can be altered by on-board
pushbuttons or via serial communications. An LCD
display provides monitoring of adjustment parameters
and levels, in addition to diagnostic facilities.
Protection •High energy MOVs
•Overcurrent (instantaneous)
•Overcurrent (inverse time)
•Field failure
•Speed feedback failure
•Motor overtemperature
•Thyristor Stack overtemperature (Force ventilated
units)
•Thyristor "Trigger" failure
•Thyristor Snubber Network
•Zero-speed detection
•Standstill logic
•Stall protection
Diagnostics •Fully computerised with first fault latch and
automatic display
•Digital LCD monitoring
•Full diagnostic information available on
RS422/RS485
•LED circuit state indication
Table 2-1 Control Features

2-4
Understanding the Product Code
The unit is fully identified using an alphanumeric code which records how the Converter was
calibrated, and its various settings when despatched from the factory.
The Product Code appears as the “Model No.”. Each block of the Product Code is identified as
below:
Block
No. Variable Description
1 XXXX Generic product
590C : 3 phase 4 quadrant (regenerative) converter up to 720A
591C : 3 phase 2 quadrant (non-regenerative) converter up to 720A
2 XXXX Four identifying the maximum dc output current rating that may be
calibrated for each size of product:
0350 = 35A
0700 = 70A
1100 = 110A
1500 = 150A
1800 = 180A
2700 = 270A
3600 = 360A
4500 = 450A
7200 = 720A
3 X 1 digit identifying the nominal 3 phase ac power, supply voltage;
0 = 110V
1 = 115V
2 = 208V
3 = 220V
4 = 240V
5 = 380V
6 = 415V
7 = 440V
8 = 460V
9 = 480V
A = 500V
4 X 1 digit identifying the auxiliary ac control supply voltage:
0 = 110V
1 = 115V
3 = 220V
4 = 240V
5 X One digit specifying the user interface language.
0 = English
1 = (reserved)
2 = French
3 = German (refer to Customer Services)
4 = Italian (refer to Customer Services)
5 = Spanish (refer to Customer Services)
6 X One character specifying any feedback option installed over and above the
standard features of the product:
0 = Armature Voltage
1 = DC Tacho
2 = 5701 Plastic Fibre Microtach
3 = Wire-ended Encoder
4 = 5901 Glass Fibre Microtach
7 X One character specifying the communications protocol and its hardware
implementation method:
0 = No serial link
1 = Fitted RS485 serial link
2 = PROFIBUS (Version 1) - compatible with existing products
3 = PROFIBUS (Version 2) - preferred version
