PARKIT360 CARRIER 13K Installation instructions

READ CAREFULLY
BEFORE OPERATION
IMPROPER USE OF THIS DOLLY CAN
CAUSE DAMAGE TO YOUR TRAILER,
PERSONAL INJURY OR EVEN DEATH. DANGERDANGER
BALL MOUNT INSTRUCTIONS
VERSION 1.0
CARRIER 13K
1

CONNECTING TO YOUR TRAILER:
BALL MOUNT ADAPTER
HITCH BALL
Thread desired Hitch Ball into the
Ball Mount. Apply a generous portion
of All-Purpose Grease along the top
surface of the Ball Mount Collar.
The shoulder of the Hitch Ball should
rest slightly above the top of the collar.
BALL MOUNT ASSEMBLY
2

WELD SPOTS
Insert the assembled Ball Mount
into the Hitch and lock as normal.
Make sure the Weld Spots on
the Hitch Ball are pointed towards
the rear left side of your trailer
at about 10 o’clock.
HITCH BALL
PLACEMENT
FLUSH,
TIGHT,
NO GAP
HITCH CONNECTION
Turn the Ball Mount Counterclockwise
until the gap between the Ball Mount
Collar and Trailer Tongue closes
tightly, with no gap.
TIGHTENING BAR
Once the Ball Mount is secure,
use the Tightening Bar to ensure
the connection is as tight as possible!
This will take a few rotations.
TIGHTEN THE
BALL MOUNT
Have a Gap or Step Down Hitch
preventing a ush connection?
See Page 3
3

STEP DOWN HITCH?
THRUST WASHER with PUZZLE PIECE
Space between the Ball Mount and Coupler?
Install the Thrust Washer on top of the Ball Mount
with the Puzzle Piece facing the Transformer.
Tighten Ball Mount as normal.
CONNECTION GAP?
THRUST WASHER
Have an obstruction preventing a at connection?
Place the Thrust Washer on top of the Ball Mount
with the open section facing the trailer.
While tightening, hold the Thrust Washer
in place to prevent it from spinning.
DANGER
OPERATING WITH A LOOSE OR UNEVEN
CONNECTION CAN CAUSE DAMAGE TO
YOUR TRAILER OR PERSONAL INJURY.
4

FREEWHEEL KNOBS
Ensure the Dolly is in parking
position and ready to connect to
the Hitch, then Engage both Motors.
(See page 8)
LEFT
ENGAGE MOTORS
INTO DRIVE
RIGHT
TURN ON THE DOLLY
Pull out the Battery Power Button
then Press and Hold the Power Button
to turn on the Dolly. Connect the
Trailer’s 7 Pin Brake Cable to the
Smart Brake Plug.
5

Ensure that the Trailer is Level and the Dolly is in
the Drive Position. Use the Trailer Jack Stand to
fully lower the Ball Mount into the Receiver Tube.
INSERT ADAPTER
Using the Wireless Remote, Drive the Dolly
underneath the hitch. Align the Adapter with the top
of the Dolly’s Receiver Tube.
ALIGN THE DOLLY
6

RE-TIGHTEN BALL MOUNT
Using the Wireless Remote, move the Dolly
back & forth slightly. Re-tighten Ball Mount.
Repeat 2-3 times until you can’t tighten anymore.
ENSURE BALL MOUNT IS AS TIGHT AS
POSSIBLE BEFORE OPERATING!
READY!
PARKIT360 INC.
130 Industrial Ave, Unit 600
Carleton Place, ON K7C 3T2 Canada
1-888-926-5517 or PARKIT360.com
7
