Parkside PDLS 5 B1 User manual

DRUCKLUFT-SET
Bedienungs- und Sicherheitshinweise
Originalbetriebsanleitung
DE AT CH
DRUCKLUFT-SET PDLS 5 B1
DE
IAN 327357_1904
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_cover_LB1.indd 2 05.09.2019 09:04:47
AIR COMPRESSOR SET
KOMPLET NA STISNJEN ZRAK
PNEUMATICKÁ SÚPRAVA DRUCKLUFT-SET
KOMPRESSZOR KÉSZLET
PNEUMATICKÁ SADA
Operation and Safety Notes
Translation of the original instructions
Navodila za upravljanje in varnostna opozorila
Prevod originalnega navodila za uporabo
Návod na obsluhu a bezpečnostné upozornenia
Originálny návod na obsluhu Bedienungs- und Sicherheitshinweise Originalbetriebsanleitung
Kezelési és biztonsági hivatkozások
Az eredeti használati utasítás fordítása
Návod k obsluze a bezpečnostní pokyny
Originální návod k obsluze
GB
SI
SK DE
HU
CZ
AT CH
AIR COMPRESSOR SET PDLS 5 B1
SK
SI
CZ
HU
IAN 327357_1904
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_cover_LB4.indd 2 10.10.19 16:09

GB
Before reading, unfold the page containing the illustrations and familiarise yourself with all
functions of the device.
HU
Olvasás előtt hajtsa ki az ábrát tartalmazó oldalt, és ezután ismerje meg a készülék
mindegyik funkcióját.
SI
Pred branjem odprite stran s slikami in se nato seznanite z vsemi funkcijami naprave.
CZ
Než začnete číst tento návod k obsluze, rozložte stránku s obrázky a seznamte se se všemi
funkcemi zařízení.
SK
Prv než začnete čítať tento návod, rozložte si stranu s obrázkami a potom sa oboznámte so
všetkými funkciami zariadenia.
DE AT CH
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich
anschließend mit allen Funktionen des Gerätes vertraut.
GB Operation and Safety Notes Page 5
HU Kezelési és biztonsági hivatkozások Oldal 21
SI Navodila za upravljanje in varnostna opozorila Stran 39
CZ Návod k obsluze a bezpečnostní pokyny Strana 55
SK Návod na obsluhu a bezpečnostné upozornenia Strana 71
DE/AT/CH
Bedienungs- und Sicherheitshinweise Originalbetriebsanleitung Seite 87
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_cover_LB4.indd 3 10.10.19 16:09

1 2 3
4
6
10
5
8
9
15
12
11
7
14
13
17
16
18
19
23
22
21
20
25 24
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_cover_LB4.indd 4 10.10.19 16:09

5GB
Table of contents
Table of pictograms used ............................................................................... Page 6
Introduction........................................................................................................... Page 6
Intended use ............................................................................................................... Page 6
Package contents......................................................................................................... Page 7
Parts description.......................................................................................................... Page 7
Technical specifications ................................................................................................ Page 8
Residual risk ......................................................................................................... Page 8
Safety instructions for compressed air tools......................................... Page 9
Safety instructions for fine spray systems............................................. Page 12
Using the device.................................................................................................. Page 13
Connect the devices..................................................................................................... Page 13
Operating the compressed air paint spray gun.................................. Page 13
Prepare spraying surface.............................................................................................. Page 13
Switching the compressed air paint spray gun on/off....................................................... Page 14
Set the paint quantity ................................................................................................... Page 14
Set the paint jet ........................................................................................................... Page 14
Replace nozzle............................................................................................................ Page 14
Maintenance............................................................................................................... Page 15
Operating the compressed air spray gun .............................................. Page 15
Prepare spraying surface.............................................................................................. Page 15
Switching the compressed air spray gun on/off .............................................................. Page 15
Set the substance quantity............................................................................................. Page 16
Maintenance............................................................................................................... Page 16
Operating the compressed air tyre inflator........................................... Page 16
Operating the compressed air blow gun................................................ Page 17
Maintenance............................................................................................................... Page 17
Storage.................................................................................................................... Page 17
Information about recycling and disposal............................................. Page 17
EU Declaration of Conformity....................................................................... Page 17
Warranty and service information ............................................................ Page 18
Warranty conditions .................................................................................................... Page 18
Warranty period and statutory claims for defects............................................................. Page 18
Extent of warranty ....................................................................................................... Page 18
Processing of warranty claims ....................................................................................... Page 19
Service....................................................................................................................... Page 19
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_content_LB4.indb 5 10.10.19 16:05

6GB
AIR COMPRESSOR SET
PDLS 5 B1
• Introduction
Congratulations! You have
purchased one of our high-quality
products. Please read the operating
instructions with care and observe the notes
described. Familiarise yourself with the
device, its proper use and the safety notes
based on these operating instructions. Please
learn about the technical features of this
device. Ensure you hand over all documenta-
tion when passing the product on to anyone
else. Only trained persons may start up this
product.
Keep out of the reach of children!
• Intended use
Compressed air paint spray gun
PDLS 5 B1-1:
The device powered by compressed air
is only intended to be used to apply/
spray lacquer paints containing solvents
and water-soluble lacquer paints, glazes,
primers, clear varnishes, vehicle top coats,
stains, wood preservatives, plant protection
products, oils and disinfectants. The device is
not designed to handle
Emulsion and latex paints, alkalis, acidic
coating substances, spray substances which
are granular and contain solids as well as
non-spray and non-drip substances.
Table of pictograms used / Introduction
• Table of pictograms used
Table of pictograms used
Read the operating instructions! Important note!
Wear hearing protection,
a respirator/dust mask, safety
goggles and protective gloves! Attention! Possible risks!
Compressed air hose Never use hydrogen, oxygen, carbon dioxide or any other
bottled gas as an energy source!
Dispose of packaging properly.
Do not dispose of the appliance
in household waste!
Packaging material –
corrugated paper
Made from recycling material
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_content_LB4.indb 6 10.10.19 16:05

7GB
Introduction
Compressed air spray gun
PDLS 5 B 1-2:
This device is designed for injecting and
spraying on detergents and spray oils, as
well as waxing and sealing. You can process
spraying substances up to a maximum of
80 DIN / sec. using the device.
Compressed air tyre inflator
PDLS 5 B 1-3:
The device is intended to be used to pump
up tyres with a Schrader valve. After the
filling process, the tyre pressure can be read
using the pressure gauge.
NOTE:
The pressure gauge 18 is not trade-
approved. Therefore you must check the tyre
pressure as soon as you can using a suitable
device at a petrol station or car repair shop.
Compressed air blow gun
PDLS 5 B 1-4:
This device is designed cleaning objects and
hard-to-reach areas as well as blow-drying
damp areas. Use the product only as
described and only for the work areas as
stated. Any other use or modification of the
device is considered a misuse and carries
a risk of serious accidents and/or injury.
Damage or injury caused by misuse or
disregarding the above warning is not
covered by the warranty or any liability
on the part of the manufacturer.
Use the product only as described and only
for the work areas as stated. Any other use
or modification of the devices is considered
a misuse and carries a risk of serious
accidents and/or injury. Damage or injury
caused by misuse or disregarding the above
warning is not covered by the warranty or
any liability on the part of the manufacturer.
The devices are intended for use by private
consumers only. Commercial use will void
the guarantee.
• Package contents
1 Compressed air paint spray gun PDLS 5 B1-1
1 Compressed air spray gun PDLS 5 B1-2
1 Compressed air tyre inflator PDLS 5 B1-3
1 Compressed air blow gun PDLS 5 B1-4
1 Aluminium suction pot 1000 ml
1 Suction pot 900 ml
1 Compressed air hose PE 5 m
1 Set of operating instructions
• Parts description
Figure A:
1Nozzle
2Lock nut
3Ventilation opening
4Suction pot
5Compressed air connection for the
compressed air spray gun
6Trigger arm for the compressed air
spray gun
Figure B:
7Paint quantity adjusting screw
8Trigger arm for the compressed air paint
spray gun
9Compressed air connection for the
compressed air paint spray gun
10 Aluminium suction pot
11 Lid
12 Fixing nuts
13 Nozzle head
14 Union nut
15 Control
Figure C:
16 Compressed air connection for the
compressed air blow gun
17 Trigger arm for the compressed air
blow gun
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_content_LB4.indb 7 10.10.19 16:05

8GB
Figure D:
18 Pressure gauge
19 Drain valve
20 Compressed air connection of the
compressed air tyre inflator
21 Trigger arm for the compressed air
tyre inflator
22 Clamp valve
23 Valve lock
Figure E:
24 Compressor connection
25 Quick coupling
• Technical specifications
Compressed air paint spray gun
PDLS 5 B1-1:
Working pressure: max. 5 bar
Nozzle size: Ø 1.5 mm
Suction pot: approx. 1000 ml
Recommended viscosity: 18–23 DIN / Sec.
Compressed air spray gun
PDLS 5 B1-2:
Working pressure: max. 8 bar
Nozzle size: Ø 3 mm
Suction pot: approx. 900 ml
Compressed air tyre inflator
PDLS 5 B1-3
Working pressure: max. 6 bar
Compressed air blow gun
PDLS 5 B1-4:
Working pressure: max. 5 bar
Compressed air hose:
Working pressure: max. 8 bar
Length: 5 m
Noise emission level:
Noise emission level measured according
to EN 14462. The estimated noise level in
the user’s location:
Sound pressure level:
Compressed air
paint spray gun: LpA = 81.7 dB (A)
Compressed air
spray gun: LpA = 85.4 dB (A)
Compressed air
tyre inflator: LpA = 84.4 dB (A)
Compressed air
blow gun: LpA = 86.1 dB (A)
Uncertainty: KpA = 2.5 dB
• Residual risk
Even if you operate the devices as intended,
there will be residual risks. The following
dangers may occur in connection with the
build and design of this air compressor set:
Danger from whipping compressed
air hoses
Danger of falling from compressed
air hoses lying around
Reduce the risk by carefully using the devices
as intended and observing all instructions.
PLEASE NOTE!
fAfter unpacking the product, please
check that all of the package contents
are present and that the devices are in
perfect condition. Do not use devices if
they are defective.
Keep the packaging material out of reach of
young children. There is a risk of suffocation!
Introduction / Residual risk
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_content_LB4.indb 8 10.10.19 16:05

9GB
Safety instructions for
compressed air tools
PLEASE NOTE!
fThe use of the term “compressed air
device” or “device” in the following text
refers to the compressed air devices
named in these operating instructions.
PLEASE READ THROUGH THE
OPERATING INSTRUCTIONS
CAREFULLY BEFORE USE.
THESE FORM PART OF THE
PRODUCT AND MUST BE
AVAILABLE AT ALL TIMES!
When compressed
air tools are used, basic safety
precautions must be taken in
order to avoid the risk of fire,
electric shock or personal injury.
Before first using the product,
please ensure you read and
follow these operating instructions
in full, and keep them in a safe
place. The manufacturer accepts
no liability for losses, damage
or personal injury caused by a
failure to follow these operating
instructions.
The dangers
stated are foreseeable when
using handheld compressed
air devices for general-purpose
work. However, users must
themselves consider the risks that
can occur when using the equip-
ment for a specific application.
The safety instructions must be
read and understood before
configuration, operation, repair,
maintenance, and exchange of
accessories on the devices and
before all work near the devices.
If this is not the case, there may
be grievous injury as a result.
DANGER OF INJURY
Switch off the compressed air
supply before changing tools
and settings or performing
maintenance.
DANGER OF INJURY
Never exceed the working
pressures specified in the
“Technical specifications” section.
Use a pressure regulator to set
the working pressure.
RECOIL HAZARD
High working pressures can
produce powerful recoil forces
that can in some circumstances
create hazards due to continuous
stress and strain.
Safety instructions for compressed air tools
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_content_LB4.indb 9 10.10.19 16:05

10 GB
EXPLOSION HAZARD
Never use petrol or other
flammable liquids to clean the
compressed air device! Residual
fumes in the compressed air
device could be ignited by sparks
and cause the compressed air
device to explode. Do not work
with the devices in explosion
hazard areas where combustible
liquids, gases or dusts are
present. Never work on materials
which are or could potentially
be highly flammable or explosive.
Always use the devices for
the specific applications
for which they have been
designed!
Never use hydrogen, oxygen,
carbon dioxide or any other
bottled gas as the source of
energy for this tool, since this
may cause an explosion and
lead to serious injury.
The devices must not be
altered. Alterations may com-
promise the effectiveness of the
safety measures and increase
the risks for the operating
personnel.
Do not point the devices at
people and/or animals.
Do not create any sparks or
light an open fire.
Detach the hose from the
compressed air supply first,
before you remove the supply
hose from the devices.
This will prevent a situation
where the supply hose whips
around uncontrollably or
recoils.
Wear personal protective
equipment and safety goggles
at all times. Depending on the
type of compressed air tool
and how it is used, wearing
personal protective equipment
such as a dust mask, non-slip
safety shoes, safety goggles,
a hard hat and hearing
protection can lessen the risk
of injuries.
Stay focused while working!
Unexpected movements of the
devices can be hazardous.
When not in use, keep com-
pressed air devices out of the
reach of children. Do not let
anyone use the devices if they
are not familiar with their
use or have not read these
instructions. Compressed air
devices are dangerous when
they are used by inexperi-
enced persons.
Disconnect the device from
the compressed air supply
before carrying out repair
and servicing work as well
Safety instructions for compressed air tools
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_content_LB4.indb 10 10.10.19 16:05

11GB
as work stoppages or
transporting the device.
When undoing the hose
coupling, keep a firm grip
of the hose in order to avoid
injuries caused by a hose
flicking back.
Look out for damage. Before
setup or first use, check the
devices for any damage.
Should the devices exhibit any
defects, then they should not be
used under any circumstances.
Ensure hoses cannot become
kinked or crushed, and keep
them away from solvents and
sharp edges. Also keep
hoses away from heat,
oil and rotating parts.
Please also follow the safety
instructions from the spraying
substance manufacturer.
Do not use the devices if you
are tired or under the influence
of drugs, alcohol or medicines.
A brief moment of carelessness
when using the devices can
result in serious injuries.
Do not remove the rating
plates, they are safety-related
elements of the devices.
Only qualified and trained
operators should set up, adjust
or use the devices.
Only use accessories and
additional devices which are
specified in the operating
instructions. Use of accessories
other than those recommended
in the operating instructions
can mean there is a risk of
injury to you.
The devices must not be
altered. Modifications can
reduce the effectiveness
of safety precautions and
increase the level of risk for the
operator.
Keep hands and other parts of
the body away from rotating
parts Otherwise there is a risk
of injury.
Check all connections and
supply lines. The specifications
of maintenance units, cou-
plings and hoses must match
the rated values for the device
in terms of pressure and air-
flow rate. The devices will not
work properly if the pressure
is too low, while excessive
pressure can cause damage
and injuries.
Safety instructions for compressed air tools
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_content_LB4.indb 11 10.10.19 16:05

12 GB
Safety instructions for
fine spray systems
Keep your work area clean,
well-lit and free of paint or
solvent containers, cloths and
other flammable substances.
Possible risk of spontaneous
combustion. Keep fully-
functional fire extinguishers/
extinguishers available at all
times.
Make sure there is good
ventilation in the spraying
area and that there is sufficient
fresh air in the entire room.
Vaporised flammable solvents
create an explosive
environment.
Do not spray or clean with
substances which have a
flashpoint below 21°C.
Use water-based substances,
non-volatile hydrocarbons or
similar substances. Volatile
vaporised solvents create an
explosive environment.
Do not spray near sources of
ignition such as static electrical
sparks, naked flames, pilot
lights, hot objects, motors, ciga-
rettes and sparks from plugging
power cables in and out or
use of switches. These types of
sources of sparks can lead to
ignition of the environment.
Do not spray any substances
where it is not known
whether they represent a risk.
Unknown substances can
create hazardous conditions.
Wear additional personal
protective equipment such as
appropriate protective gloves
and protective or breathing
masks when spraying or
handling chemicals.
Wearing protective equipment
appropriate for the conditions
reduces the exposure to
hazardous substances.
Never spray yourself,
other people or animals.
Keep your hands and other
parts of the body away from
the spray jet. If the spray
jet penetrates the skin seek
medical attention immediately.
The substance to be sprayed
can even penetrate through
a glove into the skin and be
injected into your body.
Do not treat an injury from
a jet as a harmless cut.
A high-pressure jet can ‘inject’
poisons into the body, which
can result in serious injuries.
Accordingly, seek immediate
medical attention for any skin
injury caused by a jet.
Pay close to any possible
dangers of the substance to be
Safety instructions for fine spray systems
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_content_LB4.indb 12 10.10.19 16:05

13GB
sprayed. Observe the mark-
ings on the container or the
manufacturer’s information for
the substance to be sprayed,
including the requirement
to use personal protective
equipment. The manufacturer’s
instructions must be followed,
in order to reduce the risk of
fire as well as injuries caused
by poisons, carcinogens, etc.
Never spray without the
nozzle head fitted. The use of
a special nozzle insert with
the matching nozzle head
reduces the probability that a
high-pressure jet penetrates the
skin and injects poisons into
the body.
• Using the device
• Connect the devices
The product must be used exclusively
with compressed air that is clean,
moisture-free and oil-free and must not
exceed the maximum working pressure to
the devices as specified in the “Technical
specifications” section.
To be able to control the air pressure, the
compressed air supply must be equipped
with a (filter) pressure regulator.
To operate these devices you need a flexible
compressed air hose with quick coupling
and an appropriate compressed air supply.
Follow the operating and safety instructions
for the compressed air supply and special
instructions for paint application.
PLEASE NOTE!
fMake sure you are using the correct
working pressure. Working pressure that
is too high leads to powerful fine disper-
sion and means that the liquid vaporises
too quickly. The surfaces become rough
and poor adhesion properties develop.
If the working pressure is too low, the
paint substance will not be sufficiently
atomised. The consequences are wavy
surfaces and formation of droplets.
Connect the compressed air hose with
the quick coupling 25 to the compressed
air connector 5, 9, 16 or 20 of the
relevant device. The plug locks into place
automatically.
Connect the compressor connector 24 to
the compressed air supply.
Set the working pressure as specified
in the “Technical specifications” section
using the filter pressure regulator of the
compressed air supply.
• Operating the compressed
air paint spray gun
• Prepare spraying surface
Cover a large area around the spraying
surface carefully. Otherwise any
surfaces which are not covered could
be contaminated.
Make sure that the spraying surface is
clean, dry and free of grease.
Roughen up smooth surfaces and then
remove any sanding dust.
... / Using the device / Operating the compressed air paint spray gun
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_content_LB4.indb 13 10.10.19 16:05

14 GB
• Switching the compressed
air paint spray gun on/off
Tips for use:
When thinning, make sure that the
substance to be sprayed and the thinner
are compatible. If the wrong thinner is
used, lumps may form and as a result of
this, the compressed air paint spray gun
can get clogged.
Unscrew the lid 11 of the aluminium
suction pot 10.
Fill the aluminium suction pot 10 with the
substance to be sprayed.
Screw the lid 11 back onto the aluminium
suction pot 10.
Using the fixing nuts 12, screw the
aluminium suction pot 10 tightly onto the
compressed air paint spray gun in an
anti-clockwise direction.
Always hold the compressed air paint
spray gun at the same distance from the
object. The ideal spraying distance is
approx. 15 cm.
Identify the appropriate settings in each
case by carrying out a test.
Do not switch the device on/off above
the spraying surface, start and finish the
spraying process approx. 10 cm away
from the spraying surface.
Switching on:
Press to switch on the trigger arm of the
compressed air paint spray gun 8and
keep it pressed.
Switching off:
To stop operation, release the trigger arm
of the compressed air paint spray gun 8
again.
• Set the paint quantity
You can control the paint quantity to be
sprayed using the paint quantity adjusting
screw 7.
Identify the appropriate settings in each
case by carrying out a test.
• Set the paint jet
The device has settings for round jet and
broad jet.
Round jet Broad jet
For example, use the round jet for small
surfaces, corners and edges.
Use the broad jet vertically and
horizontally on larger surfaces.
Rotate the control 15, until you have set
the type of jet you require.
Identify the appropriate settings in each
case by carrying out a test.
• Replace nozzle
Rotate the paint quantity adjusting
screw 7in an anti-clockwise direction.
Take the nozzle needle out.
Twist off the union nut 14 with the nozzle
head 13.
You can now undo the nozzle with a
hexagon key.
You can reassemble the device following
the instructions in reverse order.
Operating the compressed air paint spray gun
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_content_LB4.indb 14 10.10.19 16:05

15GB
• Maintenance
WARNING!
DANGER OF INJURY!
Disconnect the device from the
compressed air supply prior to
maintenance work.
Clean the device after each use.
ATTENTION DAMAGE
TO PROPERTY
fDo not immerse the device fully into the
detergent, as this could cause damage
to the seals.
fDo not use any halogen solvents
which contain hydrocarbons such as
trichloromethyl, ethyl chloride etc.,
as they cause chemical reactions with
some substances from the compressed
air paint spray gun. This can lead to
hazardous reactions.
Flush the compressed air paint spray gun
through at low pressure with a container
filled with a suitable detergent.
Catch the liquid in a container and dis-
pose of the liquid in an environmentally
friendly manner.
Oil the moving parts of the trigger arm of
the compressed air paint spray gun 8.
If you remove the nozzle when cleaning,
you must grease it afterwards.
When doing this, do not use lubricants
which contain silicone.
• Operating the compressed
air spray gun
• Prepare spraying surface
Cover a large area around the spraying
surface carefully. Otherwise any
surfaces which are not covered could
be contaminated.
Make sure that the spraying surface is
clean, dry and free of grease.
Roughen up smooth surfaces and then
remove any sanding dust.
• Switching the compressed
air spray gun on/off
Tips for use:
When thinning, make sure that the
substance to be sprayed and the thinner
are compatible. If the wrong thinner is
used, lumps may form and as a result of
this, the compressed air spray gun can
get clogged.
Fill the suction pot 4with the substance
to be sprayed.
Screw the suction pot 4in an anti-
clockwise direction firmly onto the
compressed air spray gun.
Always hold the compressed air spray
gun at the same distance from the object.
The ideal spraying distance is approx.
15 cm.
Identify the appropriate settings in each
case by carrying out a test.
Do not switch the device on/off above
the spraying surface, start and finish the
spraying process approx. 10 cm away
from the spraying surface.
... / Operating the compressed air spray gun
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_content_LB4.indb 15 10.10.19 16:05

16 GB
Switching on:
WARNING!
fThe ventilation opening 3on the
suction pot bracket must always be
unobstructed. Stop work immediately
if compressed air or spray substance
comes out of the ventilation opening
3. Correct the problem before
continuing to work.
fIf you need to spray in a position
where the suction pot 4is at a steep
angle, just fill it half full. In this way,
the spray substance will not come out
of the ventilation opening 3.
Press to switch on the trigger arm of the
compressed air spray gun 6and keep it
pressed.
Switching off:
To stop operation, release the trigger
arm of the compressed air spray gun 6
again.
• Set the substance quantity
You can control the quantity of the substance
to be sprayed.
Undo the lock nut 2.
Rotate the nozzle 1to the required
position.
Fix the nozzle 1with the lock nut 2.
• Maintenance
DANGER OF INJURY!
Disconnect the device from the
compressed air supply prior to
maintenance work.
Clean the device after each use.
ATTENTION DAMAGE
TO PROPERTY
fDo not immerse the device fully into the
detergent, as this could cause damage
to the seals.
Flush the compressed air spray gun
through at low pressure with a container
filled with a suitable detergent.
Catch the liquid in a container and dis-
pose of the liquid in an environmentally
friendly manner.
Oil the moving parts of the trigger arm of
the compressed air spray gun 6.
• Operating the compressed
air tyre inflator
Keep the valve lock 23 pressed and plug
the clamp valve 22 onto the valve of
the tyre to be inflated. Release the valve
lock 23.
To inflate the tyre press the trigger arm
of the compressed air tyre inflator 21.
Release the trigger arm of the com-
pressed air tyre inflator 21, in order to
check the tyre pressure on the pressure
gauge 18.
Press the drain valve 19, if the tyre
pressure is too high. Doing this will
release air from the tyres.
PLEASE NOTE!
fThe pressure gauge 18 is not trade-
approved. Therefore you must check the
tyre pressure as soon as you can using a
suitable device at a petrol station or car
repair shop.
... / Operating the compressed air tyre inflator
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_content_LB4.indb 16 10.10.19 16:05

17GB
• Operating the compressed
air blow gun
Switching on:
Press to switch on the trigger arm of the
compressed air blow gun 17 and keep it
pressed.
Switching off:
To stop operation, release the trigger
arm of the compressed air blow gun 17
again.
• Maintenance
Clean the device with a damp cloth if
necessary.
Do not use any chemical detergents.
Do not allow any liquids to get into the
compressed air feed of the tools and
do not immerse them in water. Water
in the compressed air supply can cause
damage to the device.
• Storage
Only store compressed air devices in a
dry area which is protected from dust
and dirt.
• Information about recycling
and disposal
Please return this device, accessories
and packaging to your local
recycling depot.
You can obtain information about the
disposal options for the device when it is
worn out, from your local or city council.
• EU Declaration of Conformity
We,
C.M.C. GmbH
Responsible for documentation:
Dr Christian Weyler
Katharina-Loth-Str. 15
66386 St. Ingbert
Germany
hereby take sole responsibility for declaring
that the product
Air compressor set
IAN: 327357_1904
Year of manufacture: 03 / 2020
Art. no.: 2246
Model: PDLS 5 B1
meets the basic safety requirements as
specified in the European Directives
Machinery Directive
EC Directive 2006/42/EU
and the amendments to these Directives.
This conformity assessment is based on the
following harmonised standards:
EN 1953:2013
EN ISO 12100:2010
EN 4414:2010
St. Ingbert, 29/08/2019
pp Dr Christian Weyler
– Quality Assurance –
Operating ... / Storage / Information ... / EU Declaration of Conformity
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_content_LB4.indb 17 10.10.19 16:05

18 GB
• Warranty and service
information
Warranty from Creative Marketing &
Consulting GmbH
Dear Customer,
The warranty for this equipment is 3 years
from the date of purchase. In the event
of product defects, you have legal rights
against the retailer of this product. Your
statutory rights are not affected in any way
by our warranty conditions, which are
described below.
• Warranty conditions
The warranty period begins on the date of
purchase. Please retain the original sales
receipt. This document is required as your
proof of purchase.
Should this product show any defect in
materials or manufacture within 3 years
from the date of purchase, we will repair
or replace it – at our discretion – free of
charge.
This warranty service requires that you retain
proof of purchase (sales receipt) for the
defective device for the three year period
and that you briefly explain in writing what
the fault entails and when it occurred.
If the defect is covered by our warranty, we
will repair and return your product or send
you a replacement. The original warranty
period is not extended when a device is
repair or replaced.
• Warranty period and
statutory claims for defects
The warranty period is not extended by the
guarantee. This also applies to replaced
and repaired parts. Any damages or defects
detected at the time of purchase must be
reported immediately after unpacking.
Any incidental repairs after the warranty
period are subject to a fee.
• Extent of warranty
This device has been manufactured
according to strict quality guidelines and
carefully inspected before delivery.
The warranty applies to material and
manufacturing defects only. This warranty
does not extend to product parts, which are
subject to normal wear and tear and can
thus be regarded as consumable parts, or
for damages to fragile parts, e.g. switches,
rechargeable batteries or parts made
from glass.
This warranty is voided if the product
becomes damaged or is improperly used or
maintained. For proper use of the product,
all of the instructions given in the operating
instructions must be followed precisely. If the
operating instructions advise you or warn
you against certain uses or actions, these
must be avoided in all circumstances.
The product is for consumer use only and is
not intended for commercial or trade use.
The warranty becomes void in the event of
misuse and improper use, use of force, and
any work on the device that has not been
carried out by our authorised service branch.
Warranty and service information
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_content_LB4.indb 18 10.10.19 16:05

19GB
Warranty and service information
• Processing of warranty
claims
To ensure prompt processing of your claim,
please follow the instructions given below.
Please retain proof of purchase and the
article number (e.g. IAN) for all inquiries.
The product number can be found on the
type plate, an engraving, the cover page of
your instructions (bottom left), or the sticker
on the back or underside of the device.
In the event of malfunctions or other defects,
please first contact our service department
below by phone or email. If your product
is found to be defective, you can then send
your product with proof of purchase (till
receipt) and a statement describing what the
fault involves and when it occurred free of
charge to the service address given.
Note:
On www.lidl-service.com you can
download this and several other man-
uals, product videos and software.
With this QR code you can gain
immediate access to the Lidl Service page
(www.lidl-service.com) and you can open
your operating instructions by entering the
article number (IAN) 327357_1904.
• Service
How to contact us:
GB
Name: C. M. C. GmbH
Website: www.cmc-creative.de
E-mail:
ser[email protected]
Phone: [phone]
Registered office: Germany
IAN 327357_1904
Please note that the following address is not
a service address. Please first contact the
service point given above.
C.M.C. GmbH
Katharina-Loth-Str. 15
66386 St. Ingbert
GERMANY
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_content_LB4.indb 19 10.10.19 16:05

20 GB
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_content_LB4.indb 20 10.10.19 16:05

21HU
Tartalomjegyzék
A használt piktogramok táblázata .......................................................... Oldal 22
Bevezetés............................................................................................................... Oldal 22
Rendeltetésszerű használat .......................................................................................... Oldal 22
Szállítási terjedelem.................................................................................................... Oldal 23
Az alkatrészek leírása................................................................................................. Oldal 23
Műszaki adatok ......................................................................................................... Oldal 24
Fennmaradó kockázat.................................................................................... Oldal 24
Biztonsági tudnivalók sűrített levegővel működő
szerszámokhoz................................................................................................... Oldal 25
Biztonsági tudnivalók finom szórórendszerekhez............................ Oldal 28
Üzembe helyezés............................................................................................... Oldal 29
A készülékek csatlakoztatása ....................................................................................... Oldal 29
A sűrített levegős festékszóró pisztoly kezelése................................ Oldal 30
A beszórandó felület előkészítése ................................................................................. Oldal 30
A sűrített levegős festékszóró pisztoly be- és kikapcsolása................................................ Oldal 30
A festék mennyiségének beállítása................................................................................ Oldal 30
A festéksugár beállítása............................................................................................... Oldal 30
A fúvóka cseréje......................................................................................................... Oldal 31
Karbantartás.............................................................................................................. Oldal 31
A sűrített levegős szórópisztoly kezelése.............................................. Oldal 31
A beszórandó felület előkészítése ................................................................................. Oldal 31
A sűrített levegős szórópisztoly be- és kikapcsolása ........................................................ Oldal 32
Az anyag mennyiségének beállítása............................................................................. Oldal 32
Karbantartás.............................................................................................................. Oldal 32
A sűrített levegős abroncsfeltöltő kezelése.......................................... Oldal 33
A sűrített levegős kifúvó pisztoly kezelése .......................................... Oldal 33
Karbantartás.............................................................................................................. Oldal 33
Tárolás .................................................................................................................... Oldal 33
Környezettel kapcsolatos tudnivalók és ártalmatlanítási adatok .. Oldal 33
EU-megfelelőségi nyilatkozat...................................................................... Oldal 34
Garanciával és szervizeléssel kapcsolatos tudnivalók................... Oldal 34
Garanciális feltételek................................................................................................... Oldal 34
Jótállási idő és törvényben előírt kellékszavatossági igények............................................ Oldal 35
A garancia terjedelme................................................................................................. Oldal 35
Garanciális eset kezelése ............................................................................................ Oldal 35
Szerviz...................................................................................................................... Oldal 36
Hu jótállási tájékoztató................................................................................................ Oldal 37
327357_1904_Druckluft-Set_5tlg_PDLS_5_B1_content_LB4.indb 21 10.10.19 16:05
