Parkside PBSA 12 D2 User manual

Cordless Drill PBSA 12 D2
Akku-Bohrschrauber
Originalbetriebsanleitung
Cordless Drill
Translation of the original instructions
Επαναφορτιζόμενο
δραπανοκατσάβιδο
Μετάφραση των αυθεντικών οδηγιών λειτουργίας
IAN 309546_1904

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions
of the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit
allen Funktionen des Gerätes vertraut.
GB / IE / NI /CY Translation of the original instructions Page X4GR / CY Μετάφραση των αυθεντικών οδηγιών λειτουργίας Σελίδα 17DE / AT / CH Originalbetriebsanleitung Seite 32

1 2 3 4
12
5
610
13
11
7
8
9
6
11 1
141 2
14
D

4
GB IE NI CY
Content
Introduction .................................4
Intended purpose.........................4
General description......................5
Extent of the delivery ........................5
Overview........................................5
Functional description.......................5
Technical data..............................5
Safety instructions........................ 6
Symbols and icons ...........................6
General Safety Directions for
Power Tools.....................................6
Operation ..................................12
Removing/inserting the Battery ........12
Checking the battery charge level ....12
Choice of gear ..............................12
Set the direction of rotation .............12
Torque setting ................................12
Tool change ..................................13
Keyless drill chuck removal..............13
Using the bitholder.........................13
Switching on/off............................13
Cleaning and maintenance......... 13
Cleaning.......................................14
Maintenance .................................14
Storage...................................... 14
Disposal and protection of the
environment ..............................14
Replacement parts/accessories... 14
Guarantee .................................15
Repair Service............................ 16
Service-Center............................16
Importer .................................... 16
Introduction
Congratulations on the purchase of your
new device. With it, you have chosen a
high quality product.
During production, this equipment has
been checked for quality and subjected to
a nal inspection. The functionality of your
equipment is therefore guaranteed.
The operating instructions constitute
part of this product. They contain
important information on safety,
use and disposal. Before using the
product, familiarise yourself with
all of the operating and safety in-
structions. Use the product only as
described and for the applications
specied.
Keep this manual safely and in the
event that the product is passed on,
hand over all documents to the third
party.
Intended purpose
The device is intended for drilling screws
in and out and for drilling holes in wood,
metal or plastic.
Any other use that is not explicitly ap-
proved in these instructions may result in
damage to the equipment and represent a
serious danger to the user.
The user or operator is responsible for ac-
cidents causing injury to other people or
damage to property.
This equipment is not suitable for commer-
cial use. Commercial use will invalidate the
guarantee.
Translation of the original EC
declaration of conformity ............48
Exploded Drawing ..................... 53

5
GB IE NI CY
General description
The illustrations are on the
front and back fold-out page.
Extent of the delivery
Carefully unpack the appliance and check
that it is complete:
- Cordless Drill
- Storage case
- Instruction Manual
Pictured bit and drill not included.
Overview
1 Keyless drill chuck
2 Chuck ring
3 Torque adjustment ring
4 Battery Indicator
5 Speed selector
6 Direction of rotation switch
7 On/off switch
7 LED working light
9 Drill chuck aperture
10 Battery
11 Battery release button
12 Storage case
13 Charger
14 Bitholder
Functional description
The cordless drill with two-speed gearing
has a 19+1 level torque adjustment, left/
right running, a removable keyless chuck,
a 6-point bitholder and an LED working
light.
Technical data
Cordless Drill................PBSA 12 D2
Motor voltage U.......................... 12 V
Idling speed n0
1st gear.............................0-350 min-1
2nd gear .........................0-1300 min-1
Maximum torque..........................28 Nm
Span-chuck............................ 0.8-10 mm
Weight (without battery charger).....1.0 kg
Drilling capacity
for wood.......................... max. 25 mm
for steel ............................. max. 8 mm
Sound power level
(LpA)................... 70,2 dB(A), KpA= 5 dB
Sound power level
(LWA)................. 81,2 dB(A); KWA= 5 dB
Vibration (ah)
Drilling in metal .................. < 2.5 m/s2
Screwdriving ...................... < 2.5 m/s2
K= 1.5 m/s2
Noise and vibration values have been
determined according to the standards and
regulations mentioned in the declaration of
conformity.
The stated vibration emission value was
measured in accordance with a standard
testing procedure and may be used to com-
pare one power tool to another.
The stated vibration emission value may
also be used for a preliminary exposure
assessment.
Warning: The vibration emission
value may differ during actual use
of the power tool from the stated
value depending on the manner in
which the power tool is used.
Try to keep the exposure to vibra-
tions as low as possible. Examples
of measures to reduce vibration

6
GB IE NI CY
exposure are limiting the working
hours. For this purpose all parts of
the operating cycle have to be con-
sidered (for example, times when
the electric tool is switched off and
times when it is switched on but
running without any load).
Safety instructions
Ensure that the safety instructions
are observed when operating the
appliance.
Symbols and icons
Symbols on the appliance:
Carefully read these operat-
ing instructions.
This device is part of the
Parkside X12VTEAM
series
Electrical appliances must
not be disposed of with the
domestic waste.
Symbols in the manual
Warning symbols with
information on damage
and injury prevention.
Hazard symbol with
information on the pre-
vention of personal in-
jury caused by electric
shock.
Instruction symbols with infor-
mation on preventing dam-
age.
Help symbols with informa-
tion on improving tool han-
dling.
General Safety Directions
for Power Tools
WARNING! Read all
safety notices, instruc-
tions, illustrations and
technical data that have
been provided with this
power tool. Omissions in
the compliance with safety
directions and instructions
can cause electrical shock,
re and/or severe injuries.
Retain all safety directions
and instructions for future
use.
The term „power tool“ in the warn-
ings refers to your mains-operated
(corded) power tool or battery-
operated (cordless) power tool).

7
GB IE NI CY
c) Do not expose power
tools to rain or wet condi-
tions. Water entering a power
tool will increase the risk of elec-
tric shock.
d) Do not abuse the cord.
Never use the cord for
carrying, pulling or un-
plugging the power tool.
Keep cord away from
heat, oil, sharp edges or
moving parts. Damaged or
entangled cords increase the
risk of electric shock.
e) When operating a power
tool outdoors, use an ex-
tension cord suitable for
outdoor use. Use of a cord
suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool
in a damp location is
unavoidable, use a RCD
(Residual Current Device)
protected supply. Use of an
RCD reduces the risk of electric
shock.
3) PERSONAL SAFETY
a) Stay alert, watch what
you are doing and use
common sense when
operating a power tool.
Do not use a power tool
while you are tired or un-
1) WORK AREA SAFETY
a) Keep work area clean and
well lit. Cluttered or dark ar-
eas invite accidents.
b) Do not operate power
tools in explosive atmos-
pheres, such as in the
presence of ammable
Iiquids, gases or dust.
Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and by-
standers away while op-
erating a power tool. Dis-
tractions can cause you to lose
control.
2) ELECTRICAL SAFETY
a) Power tool plugs must
match the outlet. Never
modify the plug in any
way. Do not use any
adapter plugs with
earthed (grounded) power
tools. Unmodied plugs and
matching outlets will reduce risk
of electric shock.
b) Avoid body contact with
earthed or grounded sur-
faces, such as pipes, ra-
diators, ranges and refrig-
erators. There is an increased
risk of electric shock if your
body is earthed or grounded.

8
GB IE NI CY
der the inuence of drugs,
alcohol or medication. A
moment of inattention white op-
erating power tools may result
in serious personal injury.
b) Use personal protective
equipment. Always wear
eye protection. Protective
equipment such as dust mask,
non-skid safety shoes, hard hat,
or hearing protection used for
appropriate conditions will re-
duce personal injuries.
c) Prevent unintentional
starting. Ensure the switch
is in the off-position be-
fore connecting to power
source and/or battery
pack, picking up or carry-
ing the tool. Carrying power
tools with your nger on the
switch or energising power tools
that have the switch on invites
accidents.
d) Remove any adjusting key
or wrench before turn-
ing the power tool on. A
wrench or a key left attached to
a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep
proper footing and bal-
ance at all times. This ena-
bles better control of the power
tool in unexpected situations.
f) Dress properly. Do not
wear loose clothing or
jewellery. Keep your hair,
clothing and gloves away
from moving parts. Loose
clothes, jewellery or long hair
can be caught in moving parts.
g) If dust extraction and col-
lection devices can be
installed, make sure that
these are connected and
used correctly. Use of dust
collection can reduce dust-relat-
ed hazards.
h) Do not allow yourself to
be lulled into a false sense
of security and do not dis-
regard the safety rules for
power tools, even if you
are familiar with the pow-
er tool after using it many
times. Careless action can
lead to serious injuries within a
fraction of a second.
4) POWER TOOL USE AND
CARE
a) Do not force the power
tool. Use the correct pow-
er tool for your applica-
tion. The correct power tool
will do the job better and safer
at the rate for which it was de-
signed.
b) Do not use the power tool
if the switch does not turn
it on and off. Any power tool
that cannot be controlled with

9
GB IE NI CY
the switch is dangerous and
must be repaired.
c) Remove the plug from
the wall socket and/or
remove the rechargeable
battery before you change
the device’s settings,
change accessory parts or
put away the power tool.
Such preventive safety measures
reduce the risk of starting the
power tool accidentaIly.
d) Store idle power tools out
of the reach of children
and do not allow persons
unfamiliar with the power
tool or these instructions
to operate the power tool.
Power tools are dangerous in
the hands of untrained users.
e) Look after the power tool
and application tool care-
fully. Check for misalign-
ment or binding of moving
parts, breakage of parts
and any other condition
that may affect the power
tool’s operation. If dam-
aged, have the power tool
repaired before use. Many
accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp
and clean. Properly main-
tained cutting tools with sharp
cutting edges are less Iikely to
bind and are easier to control.
g) Use the power tool, ac-
cessories and tool bits etc.
in accordance with these
instructions, taking into
account the working con-
ditions and the work to be
performed. Use of the power
tool for operations different from
those intended could result in a
hazardous situation.
h) Keep handles and grip
surfaces dry, clean and
free from oil and grease.
Slippery handles and grip sur-
faces do not permit safe opera-
tion and control over the power
tool in unexpected situations.
5) CAREFUL HANDLING AND
USE OF BATTERY DEVICES
a) Charge the batteries only
in chargers that are rec-
ommended by the manu-
facturer. Risk of re if a
charger that is suitable for a
specic type of battery is used
with other batteries.
b) In the power tools, use
only the batteries de-
signed for the purpose. The
use of other batteries may result
in injuries and risk of re.
c) Keep the unused battery
away from paper clips,
coins, keys, nails, screws
and other small metal ob-

10
GB IE NI CY
jects, which could cause
bridging of the contacts. A
short circuit between the battery
contacts may cause burns or
re.
d) If used incorrectly, liquid
may leak from the bat-
tery. Avoid contact with
this. In the event of ac-
cidental contact, rinse off
with water. If the liquid gets
into eyes, seek medical assis-
tance. Leaking battery uid may
cause skin irritations or burns.
e) Do not use damaged or
altered batteries. Damaged
or altered batteries can be un-
predictable and lead to re,
explosion or risk of injury.
f) Do not expose batteries to
re or elevated tempera-
tures. Fire or temperatures over
130°C can cause an explo-
sion.
g) Follow all instructions
for charging and never
charge the battery or the
battery-powered tool
outside the temperature
range stated in the oper-
ating instructions. Incorrect
charging or charging outside
the permitted temperature range
may destroy the battery and in-
crease the risk of re.
6) SERVICE
a) Have your power tool ser-
viced by a qualied repair
person using only identi-
cal replacement parts. This
will ensure that the safety of the
power tool is maintained.
b) Never repair damaged
batteries. All battery repairs
should be carried out by the
manufacturer or authorised cus-
tomer service centres only.
7) ADDITIONAL SAFETY
INSTRUCTIONS
a) Hold the appliance by the
insulated gripping surfac-
es when performing work
in which the tool may
come into contact with
hidden wiring. Contact with
a live wire can also cause a
charge in metal parts of the ap-
pliance and result in an electric
shock.
b) Hold the device by the in-
sulated gripping surfaces
when performing work in
which the cutting tool may
come into contact with
hidden wiring or its own
cord. If the screw were to come
into contact with a live electrical
cable, metal parts of the appli-

11
GB IE NI CY
ance could also become live
and cause an electric shock.
8) SAFETY INFORMATION
FOR USING LONG DRILLS
a) Do not work at a speed
higher than the maximum
permissible speed for the
drill. Higher speeds can cause
the drill to bend slightly when
rotating freely without contact
with the workpiece and can
also cause injury.
b) Always begin drilling at
a low speed and when
the drill is in contact with
the workpiece. Higher
speeds can cause the drill to
bend slightly when rotating
freely without contact with the
workpiece and can also cause
injury.
c) Do not apply excessive
pressure to the drill. Only
apply pressure lengthwise
along the drill. Drills can
bend and break or cause a loss
in control, thus resulting in inju-
ries.
The device is part of the
Parkside X 12 V TEAM
series and can be oper-
ated using X 12 V TEAM
series batteries. The
batteries may only be
charged using charg-
ers from the Parkside
X12VTEAM series.
Attention! Observe the
safety information and
notes on charging and
proper use as shown in
the instruction manual
for your battery and
charger from the Park-
side X 12 V Team se-
ries.
9) RESIDUAL RISKS
Even if properly operating and
handling this electric tool, some
residual risks will remain. Due to its
construction and build, this electric
tool may present the following haz-
ards:
a) Cuts
b) Ear damage if working without
ear protection.
c) Damage to your health caused
by swinging your hands and
arms when operating the appli-
ance for longer periods of time
or if the unit is not held or main-
tained properly.
Warning! During operation,
this electric tool generates an
electromagnetic eld which,

12
GB IE NI CY
under certain circumstances,
may impair the functionality
of active or passive medical
implants. To reduce the risk of
serious or lethal injuries, we
recommend that persons with
medical implants consult their
doctor and the manufacturer
of their medical implant be-
fore operating the machine.
Operation
Removing/inserting the
Battery
1. To remove the battery (10) from the ap-
pliance, press the release button (11)
on the battery and pull out the battery.
2. To insert the battery (10), place it on
the guide track and push it into the ap-
pliance. It will audibly snap in.
Checking the battery charge
level
The battery’s ( 10) charge level is indi-
cated by the charge state indicator ( 4).
The LEDs indicate the battery’s charge
level, when the device is in operation.
Press and hold the power button ( 7).
red-yellow-green => Battery fully charged
red and yellow => Battery half charged
red => Battery needs
to be charged
Choice of gear
Slide the gear selector (5) to 1or 2,
corresponding to a low or high torque
selection.
A gear change may only be per-
formed in standstill mode!
Set the direction of
rotation
You can select the direction of rotation with
the direction switch (clockwise and anti-
clockwise direction) and secure the device
against accidental start up.
1. Wait for the device to shut-down.
2. Clockwise direction: Press
direction switch (6) to the right.
3. Anticlockwise direction: Press
direction switch (6)
to the left.
4. Switch lock: Bring direction switch to
neutral position.
The direction changed may only be
performed in standstill mode.
Torque setting
You can preset the maximum torque by ro-
tating the torque adjustment ring (3).
19+1 torque levels are provided.
1. Turn the adjusting ring (3) to select the
desired torque:
Step 1 --> lowest torque,
Step --> highest torque.
Screws: Steps 1 - 19
Drilling: Step .
2. Start with a lower torque step and in-
crease according to requirement.

13
GB IE NI CY
Torque adjustment should only be
performed in standstill mode.
Reaching the preset torque limit pro-
duces a noticeable rasping sound.
This sound is caused by the slip
clutch.
Tool change
1. Rotate the keyless chuck (1) towards
RELEASE
until the drill chuck aperture
(11) is large enough to accommodate
the tool.
2. Push the tool as far as possible into the
keyless chuck (1).
3. Turn the keyless chuck towards
GRIP
in
order to clamp the tool.
4. To remove the tool again, rotate the
keyless chuck (1) and pull out the tool.
Keyless drill chuck
removal
To use the bitholder (14), you must remove
the keyless chuck (1).
1. Hold the keyless chuck (1) tightly from
the front. Pull or push the drill chuck
ring (2) in the direction of the keyless
chuck (1).
2. This unlocks the keyless chuck (1) and it
can be pulled off from the front.
3. In order to put the keyless chuck (1)
back in position, pull the drill chuck
ring (2) in the direction of the keyless
chuck. Push the keyless chuck (1) on as
far as it will go.
If the keyless chuck (1) does not
engage automatically, turn the drill
chuck ring (2).
Using the bitholder
After removing the keyless chuck (1) you
can use the bitholder (14).
1. Insert a suitable 6-point bit in the
bitholder (14). Because of the 6-point
bit holder, it may be that you need to
rotate the bit slightly.
2. Slide the bit right into the bitholder
(14). The bit is held rmly by the duct
and the magnetic bitholder.
3. To remove the bit, simply remove the bit
from the bitholder (14).
Switching on/off
By using the on/off switch (9) you can
progressively control the speed. The longer
you push the on-off button, the higher the
speed.
1. Press the on/off switch (9) to start the
device. The LED work light (10) lights
up during operation.
2. To turn it off, release the on/off switch
(9). When you move the direction
switch (6) to the middle position,
the device is secured against being
switched on.
Cleaning and
maintenance
Contact our Service Centre about
repairs and servicing not described
in this manual. Only use OEM
parts. Risk of injury!
Turn off the appliance and, before
doing any servicing, remove the
battery.

14
GB IE NI CY
The following cleaning and servicing
should be done regularly. This will ensure
a long and reliable service life.
Cleaning
Do not spray the appliance
with water and do not im-
merse it in water. Electric
shock hazard!
• Keep clean the ventilation slots, motor
housing and handles of the appliance.
Use a damp cloth or a brush.
Do not use cleaning agents or solvents.
You may otherwise irreparably dam-
age the appliance.
Maintenance
The appliance cleaner is maintenance free.
Storage
• Store the equipment in a dry place well
out of reach of children.
Disposal and protection
of the environment
Remove the battery from the device and
take the device, battery, accessories and
packaging for environmentally friendly
recycling.
Machines do not belong with do-
mestic waste.
• Remove the rechargeable battery be-
fore disposing of the appliance!
• Return the unit to a recycling centre.
The plastics and metals in the unit can
be sorted and appropriately recycled.
Ask our Service Centre for details.
• Defective units returned to us will be
disposed of for free.
Replacement parts/
accessories
Spare parts and accessories can be
obtained at
www.grizzly-service.eu
If you have issues ordering, please use the
contact form.
If you have any other questions, contact
the ”Service-Center” (see page 16).
Keyless drill chuck ( 1)........ 91103354

15
GB IE NI CY
Guarantee
Dear Customer,
This equipment is provided with a 3-year
guarantee from the date of purchase.
In case of defects, you have statutory rights
against the seller of the product. These
statutory rights are not restricted by our
guarantee presented below.
Terms of Guarantee
The term of the guarantee begins on the
date of purchase. Please retain the original
receipt. This document is required as proof
of purchase.
If a material or manufacturing defect
occurs within three years of the date of
purchase of this product, we will repair or
replace – at our choice – the product for
you free of charge. This guarantee requires
the defective equipment and proof of pur-
chase to be presented within the three-year
period with a brief written description of
what constitutes the defect and when it oc-
curred.
If the defect is covered by our guarantee,
you will receive either the repaired product
or a new product. No new guarantee pe-
riod begins on repair or replacement of the
product.
Guarantee Period and Statutory
Claims for Defects
The guarantee period is not extended by
the guarantee service. This also applies for
replaced or repaired parts. Any damages
and defects already present at the time of
purchase must be reported immediately af-
ter unpacking. Repairs arising after expiry
of the guarantee period are chargeable.
Guarantee Cover
The equipment has been carefully pro-
duced in accordance with strict quality
guidelines and conscientiously checked
prior to delivery.
The guarantee applies for all material and
manufacturing defects. This guarantee
does not extend to cover product parts that
are subject to normal wear and may there-
fore be considered as wearing parts (e.g.
keyless drill chuck) or to cover damage to
breakable parts (e.g. switches).
This guarantee shall be invalid if the prod-
uct has been damaged, used incorrectly or
not maintained. Precise adherence to all of
the instructions specied in the operating
manual is required for proper use of the
product. Intended uses and actions against
which the operating manual advises or
warns must be categorically avoided.
The product is designed only for private
and not commercial use. The guarantee
will be invalidated in case of misuse or
improper handling, use of force, or inter-
ventions not undertaken by our authorised
service branch.
Processing in Case of Guarantee
To ensure efcient handling of your query,
please follow the directions below:
• Please have the receipt and item num-
ber (IAN 309546_1904) ready as
proof of purchase for all enquiries.
• Please nd the item number on the rat-
ing plate.
• Should functional errors or other de-
fects occur, please initially contact the
service department specied below by
telephone or by e-mail. You will then
receive further information on the pro-
cessing of your complaint.

16
GB IE NI CY
• After consultation with our customer
service, a product recorded as defec-
tive can be sent postage paid to the
service address communicated to you,
with the proof of purchase (receipt) and
specication of what constitutes the
defect and when it occurred. In order
to avoid acceptance problems and
additional costs, please be sure to use
only the address communicated to you.
Ensure that the consignment is not sent
carriage forward or by bulky goods,
express or other special freight. Please
send the equipment inc. all accessories
supplied at the time of purchase and
ensure adequate, safe transport pack-
aging.
Repair Service
For a charge, repairs not covered by
the guarantee can be carried out by
our service branch, which will be happy to
issue a cost estimate for you.
We can handle only equipment that has
been sent with adequate packaging and
postage.
Attention: Please send your equipment to
our service branch in clean condition and
with an indication of the defect.
Equipment sent carriage forward or by
bulky goods, express or other special
freight will not be accepted.
We will dispose of your defective devices
free of charge when you send them to us.
Service-Center
GB Service Great Britain
Tel.: [phone]
E-Mail: [email protected]
IAN 309546_1904
IE
NI
Service Ireland
Service Northern Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: [email protected]
IAN 309546_1904
CY Service Cyprus
Tel.: [phone]
E-Mail: [email protected]
IAN 309546_1904
Importer
Please note that the following address is
not a service address. Please initially con-
tact the service centre specied above.
Grizzly Tools GmbH & Co. KG
Stockstädter Straße 20
D-63762 Großostheim
GERMANY
www.grizzly-service.eu

17
CY
GR
Περιεχόμενα
 ............................................ 17
................................... 17
............................... 18
Παραδοτέαυλικά............................... 18
Επισκόπηση...................................... 18
Περιγραφήλειτουργίας...................... 18
.................................. 18
........................ 19
Σύμβολακαιεικονοσύμβολα............ 19
Γενικέςυποδείξειςασφαλείαςγια
ηλεκτρικάεργαλεία............................ 19
 ............................................ 26
τοποθέτηση/Αφαίρεσητης
μπαταρίας......................................... 26
Έλεγχοςτηςκατάστασηςφόρτισης
τηςμπαταρίας................................... 26
Επιλογήταχύτητας............................ 27
Διακόπτηςκατεύθυνσης
περιστροφής..................................... 27
Ρύθμισηροπήςστρέψης................... 27
Αλλαγήεργαλείου.............................. 27
Απομάκρυνσηταχυτσόκ.................... 28
Χρήσηυποδοχήςμυτών.................... 28
Ενεργοποίηση/απενεργοποίηση....... 28
 .................... 28
Καθαρισμός....................................... 29
Συντήρηση........................................ 29
 ....................................... 29

.................................... 29
 .................... 29
 .............................................. 30
................................ 31
Service-Center .................................... 31
......................................... 31
Εισαγωγή
Συγχαρητήριαγιατηναγοράτηςνέαςσυ-
σκευήςσας.Προτιμήσατενααγοράσετε
έναπροϊόνανώτερηςποιότητας.
Ηποιότητααυτήςτηςσυσκευήςελέγχθη-
κεκατάτηδιάρκειατηςπαραγωγής,αλλά
καισετελικόέλεγχο.Μετοντρόποαυτό
εξασφαλίστηκεηλειτουργικότητατηςσυ-
σκευήςσας.
 Οιοδηγίεςχρήσηςαποτελούν
αναπόσπαστοτμήμααυτούτου
προϊόντος.Περιέχουνσημαντικές
υποδείξειςγιατηνασφάλεια,τη
χρήσηκαιδιάθεσητηςσυσκευής.
Πριντηχρήσητουπροϊόντοςνα
εξοικειωθείτεμεόλεςτιςοδηγίες
χειρισμούςκαιτιςυποδείξειςασφα-
λείας.Ναχρησιμοποιείτετοπροϊόν
μόνοόπωςπεριγράφεταικαιμόνο
γιατοναναφερόμενοσκοπό.Να
φυλάξετεκαλάτιςοδηγίεςκαινα
τιςπαραδώσετεσετρίτουςμαζίμε
τοπροϊόν.
Σκοπός χρήσης
Ησυσκευήπροορίζεταιγιατοβίδωμακαι
τολύσιμοβιδών,καθώςκαιγιαδιάτρηση
ξύλου,μετάλλουήπλαστικού.Οποιαδή-
ποτεάλληχρήση,ηοποίαδενεγκρίνεται
ρητάμέσααπότιςοδηγίεςαυτές,μπορεί
ναπροκαλέσειζημιέςστησυσκευήκαινα
αποτελέσεισοβαρόκίνδυνογιατοχρή-
στη.
Οκατασκευαστήςδενευθύνεταιγιαζημιές
πουπροκλήθηκανλόγωμηενδεδειγμένης
χρήσηςήλόγωεσφαλμένουχειρισμού.
Αυτήησυσκευήδενείναικατάλληληγια
επαγγελματικήχρήση.
Σεπερίπτωσηεπαγγελματικήςχρήσης
παύειναισχύειηεγγύηση.

............. 49
............. 53

18
CY
GR
Γενική περιγραφή
 Τηναπεικόνισητωνσημαντικότε-
ρωνεξαρτημάτωνλειτουργίαςθα
βρείτεστησελίδα-φάκελλο.
Παραδοτέα υλικά
Βγάλτετησυσκευήαπότησυσκευασία
καιελέγξτε,ανείναιπλήρης:
- Επαναφορτιζόμενοδραπανοκατσάβιδο
- Βαλιτσάκι
- Οδηγιώνχρήσης
Οιμύτεςμπιτκαιτρυπάνιαπουαπεικο-
νίζονται,δεσυμπεριλαμβάνονταιστησυ-
σκευασίαπαράδοσης.
Επισκόπηση
 1 Ταχυτσόκ
 2 Δακτύλιοςτσοκ
 3 Δακτύλιοςρύθμισηςροπής
στρέψης
 4 Ένδειξηφόρτισηςμπαταρίας
 5 Διακόπτηςεπιλογήςταχυτήτων
 6 Διακόπτηςκατεύθυνσηςπερι-
στροφής
 7 Διακόπτηςενεργοποίησης/απε-
νεργοποίησης
 8 ΛυχνίαLEDλειτουργίας
 9 Ανοιγματουτσοκ
 10 Μπαταρία
 11 Πλήκτροαπομανδάλωσηςμπα-
ταρίας
 12 Βαλιτσάκι
 13 Φορτιστής
14 Υποδοχήμυτών
Περιγραφή λειτουργίας
Τοεπαναφορτιζόμενοδραπανοκατσάβιδο
δύοταχυτήτωνδιαθέτειρύθμισηροπής
στρέψης19+1βαθμίδων,φοράκίνησης
προςταδεξιάκαιπροςτααριστερά,ένα
αποσπώμενοταχυτσόκ,μιαυποδοχή
6γωνωνμυτώνκαιμιαλυχνίαLEDλει-
τουργίας.
Τεχνικά στοιχεία

 ............ PBSA 12 D2
ΤάσηκινητήραU............................ 12V 
Αριθμόςστροφώνρελαντίn0
1ηταχύτηήτα........................0-350min-1
2ηταχύτηήτα......................0-1300min-1
Μέγιστηροπήστρέψης.................. 28Nm
Διάστασητσοκ..........................0,8-10mm
Βάρος(χωρίςΦορτιστής)................1,0kg
Διάμετροςδιάτρησηςγιαξύλομέγ.25mm
Διάμετροςδιάτρησης
γιαχάλυβα................................ μέγ.8mm
Στάθμηηχητικήςπίεσης
(LpA)..................... 70,2dB(A);KpA=5dB
Επιτρεπόμενηστάθμηθορύβου
(LWA).................... 81,2dB(A);KWA=5dB
Δόνηση(ah)................................................
Διάτρησημετάλλου.................<2,5m/s2
Βίδωμα...................................<2,5m/s2
K=1,5m/s2
Οιτιμέςθορύβουκαιδονήσεωνεξα-
κρι-βώνονταισύμφωναμετουςκανόνες
καιτουςκανονισμούςπουαναφέρονται
στηδήλωσησυμμόρφωσης.
Hαφερόμενητιμήμετάδοσηςδόνησης
μετρήθηκεβάσειτυποποιημένηςμεθόδου
δοκιμήςκαιμπορείναχρησιμοποιηθείγια
τησύγκρισημίαςηλεκτρικήςσυσκευήςμε
μίαάλλη.Ηαναφερόμενητιμήμετάδοσης

19
CY
GR
δόνησηςμπορείεπίσηςναχρησιμοποιη-
θείκαιγιααρχικήεκτίμησητηςέκθεσης.
 
 Ητιμήμετάδοσηςτηςδόνησης
μπορείναδιαφέρεικατάτηνπραγ-
ματικήχρήσητηςηλεκτρικήςσυ-
σκευήςαπότηναναφερόμενητιμή,
ανάλογαμετοντρόποχρήσηςτης.
Προσπαθείτεναδιατηρείτετην
επιβάρυνσηλόγωκραδασμώνόσο
μικρότερηγίνεται.Παραδείγματα
μέτρουγιατημείωσητουφορτίου
κραδασμώνείναιηοριοθέτηση
τουχρόνουεργασίας.Εδώπρέπει
ναληφθούνυπόψινόλαταστάδια
λειτουργίας(γιαπαράδειγμαοχρό-
νοςκατάτονοποίοτοηλεκτρικό
εργαλείοείναιαπενεργοποιημένο
καιοχρόνοςκατάτονοποίοτο
ηλεκτρικόεργαλείοείναιμενενερ-
γοποιημένο,αλλάλειτουργείχωρίς
επιβάρυνση).
Υποδείξεις ασφάλειας
Στοκεφάλαιοαυτόθαβρείτετις
βασικέςπροδιαγραφέςασφαλείας
πουαφορούντηνεργασίαμετη
συσκευή.
Σύμβολα και εικονοσύμβολα

 Διαβάστεπροσεκτικάολό-
κληρητηνοδηγίαχειρισμού!
 Ησυσκευήείναιτμήμα
τηςσειράςParkside
X12VTEAM
 Μηνπετάτετιςηλεκτρικές
συσκευέςστασκουπίδια.

 



 
-


 Σύμβολουποχρέωσηςμε
στοιχείαγιατηνπρόληψη
ζημιών.
 Σύμβολουπόδειξηςμεπλη-
ροφορίεςγιατονκαλύτερο
χειρισμότηςσυσκευής.
Γενικές υποδείξεις ασφαλεί-
ας για ηλεκτρικά εργαλεία
-



-

Παραλείψειςστην
τήρησητωνυποδείξεων
ασφαλείαςκαιτωνοδηγιών
μπορούνναοδηγήσουνσε

20
CY
GR
Εάνδενείστεκαλά
συγκεντρωμένοι,δεναποκλεί-
εταιναχάσετετονέλεγχοεπί
τηςσυσκευής.

-


-



Ότανδενέχουν
αλλαχτείταβύσματακαιόταν
χρησιμοποιείτεκατάλληλες
πρίζες,μειώνεταιοκίνδυνος
ηλεκτροπληξίας.
-

-


.Υπάρχειιδιαίτερος
κίνδυνοςηλεκτροπληξίας,όταν
το΄΄ωμασαςείναιγειωμένο.

-
Ηδιείσδυσηνερούσε
ηλεκτρικήσυσκευήαυξάνειτον
κίνδυνοηλεκτροπληξίας.




ηλεκτροπληξία,πυρκαγιά
και/ήβαρείςτραυματισμούς.



Ηέννοια„ηλεκτρικάεργαλεία“,
πουχρησιμοποιείταιστιςυποδεί-
ξειςασφαλείας,αναφέρεταισε
ηλεκτρικάεργαλείαπουλειτουρ-
γούνταιμετοηλεκτρικόδίκτυο(με
καλώδιορεύματος)καισεηλεκτρι-
κάεργαλείαπουλειτουργούνται
μεσυσσωρευτή(δίχωςκαλώδιο
ρεύματος).


-

Σεόχιτακτικούςή
όχικαλάφωτισμένουςχώρους
εργασίαςδημιουργούνταιατυ-
χήματα.
-
-
-

Ταηλεκτρικάεργαλεία
παράγουνσπινθήρεςπουμπο-
ρούννααναφλέξουντησκόνη
καιτουςατμούς.


-
