PARRY PARAGON 1860 User manual

INSTRUCTION REF: IN123
ISSUE No. 3
DATE 17.08.15
Page 1 of 15
www.parry.co.uk
INSTALLATION INSTRUCTIONS
SAFETY INSTRUCTIONS
USER INSTRUCTIONS
PARAGON FRYERS
MODEL: 1860 MODEL: PDF3
MODEL: 1862 MODEL: PDF6
MODEL: 2000 MODEL: PDF9
MODEL: 2001 MODEL: PF6
MODEL: CMF MODEL: PF9
MODEL: CMF2 MODEL: PSF3
MODEL: CMFF2 MODEL: PSF6
MODEL: CMFF MODEL: PSF9
MODEL: PSPF6
MODEL: PSPF9
MODEL: PDPF6
MODEL: PDPF9

INSTRUCTION REF: IN123
ISSUE No. 3
DATE 17.08.15
Page 2 of 15
www.parry.co.uk
PLEASE NOTE INSTALLATION MUST BE CARRIED OUT BY A QUALIFIED
ELECTRICIAN
IMPORTANT
Please read these instructions before you attempt to use the equipment. Keep these
instructions for future reference.
WARNING
To avoid scratching the highly polished exterior surface of this equipment
whilst in transit, the protective film on the exterior surfaces has NOT been
removed.
It is IMPORTANT that this protective film is peeled off before the equipment is
used.
WARNING
1. All electrical appliances/parts must be earthed.
2. No user-serviceable parts.
3. Isolate power supply before carrying out any installation work.

INSTRUCTION REF: IN123
ISSUE No. 3
DATE 17.08.15
Page 3 of 15
www.parry.co.uk
INSTALLATION
1. Choose a suitable site for your machine taking into consideration its, use, and
any heat that may be generated whilst in service.
2. Remove all protect film and packing material, and inspect for any damage
which may effect the machine’s electrical safety.
3. Please find enclosed 4 x shelf adhesive rubber feet. There are 4 dimples on
the base of the unit where each foot must be placed.
4. All appliances with an electrical loading above 3 kilowatts must be connected
to a suitable supply by qualified electrician, who should ensure that
a) Precaution is taken during installation regarding leakage current,
b) The means of isolation has a contact separation of at least 3mm on all
poles, and
c) It is installed in accordance with Health and Safety at Work Act, BS
Codes of Practice, IEE Wiring Regulations and Building and Local
Authority Standards.
PARAGON FRYERS
OIL CAPACITY –PF6 & PF9 - 11 LITRES, ALL OTHER MODELS 6.1 LITRES PER PAN
POWER SUPPLY –PSF3 & PDF3 (X2) ARE FITTED WITH A 13 AMP 3 PIN PLUG
ALL OTHER MODELS MUST BE INSTALLED BY A QUALIFIED ELECTRICIAN.
PSF6, PF6, PSPF6, PDF6 (X2), PDPF6 (X2) –25A 1~ 240V
8.5A 3~ &N 415V
PSF9, PF9, PSPF9, PDF9 (X2), PDPF9 (X2) - 37.5A 1~ 240V
12.5A 3~ &N 415V

INSTRUCTION REF: IN123
ISSUE No. 3
DATE 17.08.15
Page 4 of 15
www.parry.co.uk
NON MODULAR FRYERS
OIL CAPACITY –4.6 LITRES CMF, 2000, CMF2 & 2001 PER PAN
6.1 LITRES CMFF, 1860, CMFF2 & 1862
POWER SUPPLY –ALL MODELS ARE FITTED WITH A 13 AMP 3 PIN PLUG PER
CONTROL UNIT
OPERATING INSTRUCTIONS FOR PARAGON FRYERS
1. Ensure all packaging has been removed and the tank has been cleaned thoroughly
before filling with oil. Check the drain tap is in the fully closed position, and
the batter plate provided is fitted on top of the element.
2. Fill the tank with a good quality cooking oil, animal fat may be used but must be
melted first before pouring into the tank, fill to the level mark indicated on the front of
the heating element. Do not mix oil and fat
3. With the thermostat in the off position turn on the mains supply to the unit, the red
lamp will indicate that the power is on.
4. Turn the thermostat to the desired setting; the green lamp will illuminate showing that
there is power to the element, this will extinguish when the desired temperature is
reached. This procedure will be repeated automatically as the thermostat maintains a
constant temperature.
5. All models are fitted with a mechanical timer. This is used as a guide only, please note
that it will not cut off the power to the element
6. Do not overfill the cooking basket.

INSTRUCTION REF: IN123
ISSUE No. 3
DATE 17.08.15
Page 5 of 15
www.parry.co.uk
OPERATING INSTRUCTIONS FOR NON MODULAR FRYERS
1. Make sure all packaging has been removed and the pan has been thoroughly cleaned
before filling with oil
2. Ensure the control head is seated correctly –your fryer is fitted with a safety
microswitch and will not operate unless it is fully seated on the body of the fryer
3. Fill the pan with oil to the correct level indicated on the element shroud
4. Plug into mains and turn on supply the red lamp will show to indicate there is power to
the unit- if you have a twin fryer and you are plugging into a double socket please
ensure the socket is suitable for 25 amp supply
5. Turn on the thermostat to the desired temperature, the green lamp will show indicating
power to the element, this will extinguish when the desired temperature is reached,
this procedure will be repeated as the thermostat maintains a constant temperature
6. Do not over fill the basket
GUIDE TO FOOD COOKING TEMPERATURES ALL MACHINES
This is only intended as a guide and best results will be obtained with experience.
CHICKEN AND CHIPS (BLANCHING) - 140ْC - 160ْC
FISH FILLETS, CHOP CUTLETS - 160ْC
FRITTERS, SCAMPI - 180ْC
CHIPS - MAX
DRAINING AND CHANGING THE OIL ON PARAGON FRYERS
The life expectancy of the oil or fat will be lengthened if they are passed through a filter on a
regular basis, and the fryer is turned down or off during periods when it is not in use.
PSPF6, PSPF9, PDPF6 & PDPF9
To drain the oil in the above models
1. Allow oil to cool
2. Ensure the power has been isolated
3. Open the door of the cabinet and place the bucket &strainer provided underneath the
drain spout.
4. Open the drain valve and allow the oil to fill the bucket, do not overfill so that the
bucket becomes unmanageable.

INSTRUCTION REF: IN123
ISSUE No. 3
DATE 17.08.15
Page 6 of 15
www.parry.co.uk
PSF3, PSF6, PSF9, PDF3, PDF6 & PDF9
On all other models the drain tap is situated on the front of the machine & the following
procedure should be adhered to
1. Allow oil to cool
2. Ensure the power has been isolated
3. Remove the finger tight bung from the drain and fix the spout provided to the drain
4. Place a clean suitable receptacle underneath the spout
5. Lift up the safety catch & slide the arm of the drain tap across to allow the oil to flow.
DRAINING AND CHANGING THE OIL ON ALL NON MODULAR
FRYERS
1. Allow oil to cool
2. Ensure power has been isolated
3. Lift out control unit –do not immerse control unit in water wipe down with a suitable
cloth
4. Lift out the pan from the body of the machine taking care not to spill any oil
5. Pour the oil into a suitable receptacle through a strainer if the oil is to be reused
6. Clean the pan in hot soapy water, dry and replace in the body of the fryer.
7. Refer back to operating instructions
CLEANING PARAGON FRYERS
Once the oil has been drained remove the control head from the bowl and wash the bowl and
the drain with hot soapy water, rinse and dry thoroughly.
Close the drain tap & replace the drain bung.
Clean around the element and batter plate, then replace back into the bowl.
The oil can then be poured back into the bowl.
Top up with clean oil as necessary.
All equipment should be kept absolutely clean; under no circumstances must food particles
be allowed to congeal on baskets or elements as this will cause foaming due to the particles
continuously cooking.
Periodically you will need to replace the cooking medium, do this when discolouration, odour,
surging or stray tastes indicate this; again, experience is your best guide, but remember that
more frequent changes will be required when different foods are cooked in the same medium.

INSTRUCTION REF: IN123
ISSUE No. 3
DATE 17.08.15
Page 7 of 15
www.parry.co.uk
DANGER
Old oil has a reduced flash point and is more prone to surge boiling.
Attention is also drawn to the effect of over-wet food and too large a charge on surge boiling.
Treat your fryer with the utmost respect with regard to safety, as hot cooking oil is a very
hazardous substance. Never use the lid while the fryer is switched on or is cooling off. It is
only a dust cover for when the fryer is not in use.
N.B.Incorrect oil level, old oil or allowing the machine to be switched on without any oil,
will cause the override switch to trip.
RESETTING FRYER OVERRIDE SWITCH ON PARAGON RANGE
1. Isolate machine from mains supply
2. Remove the screws on the access panel at rear of the control panel (A)
3. Press the inner button firmly may need to use a pen until a click is heard
4. Replace cover and reconnect to mains.
5. Check oil condition and level, renew or top up as required, and turn on the fryer
thermostat.

INSTRUCTION REF: IN123
ISSUE No. 3
DATE 17.08.15
Page 8 of 15
www.parry.co.uk
RESETTING FRYER ON NON MODULAR RANGE
1. Isolate machine from mains supply
2. On CMF, CMF2, CMFF & CMFF2 remove the bung at the rear of the control panel to
gain direct access to the reset button, press and replace the bung
3. On 2000, 2001 1860 & 1862 using a pen press the button until a click is heard
4. Check oil condition and level, renew or top up as required, and turn on the fryer
thermostat

INSTRUCTION REF: IN123
ISSUE No. 3
DATE 17.08.15
Page 9 of 15
www.parry.co.uk
SYMPTOM
FAULT
REMEDY
Oil Smoking
Overheating
Check Accuracy of thermometer.
Fry at recommended temperatures
and reduce temperature when idle.
Oil Smoking
Frying oil contamination
Skim surface and filter or strain oil
regularly to remove food particles.
Oil Smoking
Break down of frying oil
Drain, clean down fryer and refill
with fresh oil.
Oil Smoking
Constant frying of wet food
Remove excess moisture from food
before frying.
Oil Smoking
Long periods of exposure
To air and light
Always keep oil covered particularly
when turnover of oil is low.
Oil Foaming
Overheating
Check accuracy of thermostat with
a thermometer. Fry at
recommended temperatures and
reduce temperature when idle.
Oil Foaming
Low oil level
Ensure that oil is topped up to
manufacturers load line daily.
Oil Foaming
Break down of frying oil
Drain fryer, clean down and refill
with fresh oil.
Oil Foaming
Continuous overloading
of fryer
Do not exceed food to oil ratio of 1
to 6 refer to manufacturers
instructions.
COOKING OILS

INSTRUCTION REF: IN123
ISSUE No. 3
DATE 17.08.15
Page 10 of 15
www.parry.co.uk
Oil Foaming
Frying of food with excess
moisture
Remove excess moisture from food
before frying.
Oil Foaming
Heating oil too rapidly
Heat oil slowly
Oil Foaming
Detergent present after
cleaning
Fryer should be thoroughly rinsed
and dried before refilling
Oil Foaming
Brass or copper utensils
used
Contact between frying oil and
copper or brass should be avoided.
Oil Darkening
Low turnover of frying oil
Increase throughput of friend food
by examining menu.
Oil Darkening
High level of starch or sugar
in food
Particularly avoid potatoes high in
starch or sugar.
Oil Darkening
Frying oil contamination
Skim surface and filter or strain oil
regularly to remove food particles.
Oil Darkening
Frying of salted foods
Salt food after frying
Oil Darkening
Break down of frying oil
Drain fryer, clean down and refill
with fresh oil.
Oil Darkening
Overheating
Check accuracy of thermostat with
a thermometer. Fry as
recommended temps, reduce
temperature when idle.
Food absorbing
excess oil
Excess butter or
breadcrumbs on fried food
Avoid excessive use of butter or
breadcrumbs.
Food absorbing
excess oil
Continuous overloading of
fryer
Do not exceed food to oil ratio of 1
to 6 or refer to fryer manufacturers
instructions.
Food absorbing
Excess oil
Frying at too low a
temperature
Check accuracy of thermostat with
thermometer. Fry at recommended
temperatures.
Food absorbing
Excess oil
Breakdown of frying oil
Drain fryer, clean down and refill
with fresh oil.

INSTRUCTION REF: IN123
ISSUE No. 3
DATE 17.08.15
Page 11 of 15
www.parry.co.uk
MAINTENANCE INSTRUCTIONS
Servicing
This appliance should be routinely serviced to prolong its lifetime. Parry
recommends that the appliance is serviced every 12 months by a Parry
authorised engineer. Failure to service your product within the initial 12 month
warranty period will cause the 24 month warranty to become void.
MAINTENANCE AND SERVICE MUST ONLY BE UNDERTAKEN BY A QUALIFIED
ELECTRICIAN.
WARRANTY INFORMATION
Warranty Policy
The manufacturer’s warranty is only valid in the UK mainland. Northern Ireland,
Western Isles, Inner Hebrides and Islands are parts only warranty.
All service calls will be carried out between the hours of 8.00am –5.00pm
Monday to Friday only.
We accept no responsibility for delays in replacing or repairing the equipment
due to circumstances beyond our control.
Your warranty can be immediately invalid if the installation of the equipment
has not been carried out in accordance with the manufacturer’s instructions.
(See installation details). Also the misuse, alteration or unauthorised repairs of
the equipment will invalidate the warranty.
During the warranty period it is at Parry’s discretion to repair or replace the
equipment.
Warranty only applies if the equipment has been used in a professional
manner following the manufacturer’s instructions and maintenance guide lines.

INSTRUCTION REF: IN123
ISSUE No. 3
DATE 17.08.15
Page 12 of 15
www.parry.co.uk
The warranty covers defects in the material and component failure only. We
are not liable for trading loss, loss of perishable items, water damage, loss due
to injury or fire damage.
Please be aware that the warranty starts from the date of purchase from Parry
and not the sale or installation date of the equipment.
Warranty Request
Please ensure you have referred to the manufacturers’ instructions before
placing a warranty call. Or contact our warranty department on 01757 213909
for technical assistance, ensure you obtain the model number before calling.
Please ensure you have read the section not covered under warranty to avoid
any unnecessary warranty charges.
It is vital that all warranty requests be submitted to Parry via email to
[email protected]
It is at the discretion of PARRY whether to honour a service call which is out of
the warranty period.

INSTRUCTION REF: IN123
ISSUE No. 3
DATE 17.08.15
Page 13 of 15
www.parry.co.uk
Not Covered Under Warranty
• Fault due to poor maintenance.
• Resetting of equipment or circuit breakers.
• Abuse of the equipment
• Foil should never be used on racks
• Blockages e.g., drains, condensers, pumps etc.
• Lime scale related issues
• Installed incorrectly
• Access arranged for service call and engineer refused access or customer not
there.
• No faults with the machine.
• Setting up of equipment e.g., dishwasher detergents, levelling and setting up of
doors on a 6 burner cooker.
• Excessive carbon build up on griddle plates.
• Over use of lava rock on the chargrills. Parry recommends maximum of 2kg.
• Faulty electrics – e.g., customers plug socket, plug, wiring, junction box fault, wrong
fuse.
• Any damages caused by the customer.
• Lamps, glass, door gaskets, Perspex, baskets, knobs all perishable items are not
covered.
This appliance should be routinely serviced to prolong its lifetime. Parry recommends
that the appliance is serviced every 12 months by a Parry authorised engineer.
Failure to service your product within the initial 12 month warranty period will cause
the 24 month warranty to become void.

INSTRUCTION REF: IN123
ISSUE No. 3
DATE 17.08.15
Page 14 of 15
www.parry.co.uk
Disposal Information
This appliance is marked according to the European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health which could otherwise
be caused by inappropriate waste handling of this product.
A symbol on the product, or on the documents accompanying the product, indicates
that this appliance may not be treated as household waste. Instead it should be
handed over to the applicable collection point for the recycling of electrical and
electronic equipment.
Disposal must be carried out in accordance with local environmental regulations for
waste disposal.
For more detailed information about treatment, recovery and recycling of this product,
please contact your local city office, your household waste disposal service or the
shop where you purchased the product.
Parry Catering recognises our obligations to the EU DIRECTIVE covering the waste
disposal of electrical and electronic equipment (WEEE) Parry Catering are committed
to this policy in order to help conserve the environment.
At the end of this units life you MUST dispose of it in an approved manner. You
MUST not discard the unit or place it in the refuse bin.

INSTRUCTION REF: IN123
ISSUE No. 3
DATE 17.08.15
Page 15 of 15
www.parry.co.uk
You have several options:
a) Take the unit to an approved WEEE scheme company, there will be one in your
area.
b) Take the unit to an approved waste disposal site; many sites are managed by your
local authority.
Contact the units manufacturer, importer or their agent; the contact details will be on
the unit.
There will probably be a charge for this service which will depend on the physical size
and location of the unit. You will be given a collection price for a curb side collection
based on commercial rates prevailing at the time.
It should be noted that the unit to be collected should be suitably packed and sealed
to prevent dangerous gases and fluids from escaping. The condition of the unit must
also be clean to comply with health and safety regulations.
Parry Group Ltd,
Town End Road,
Draycott,
Derby,
England,
DE72 3PT
