PARRY PPGS Installation instructions

INSTRUCTION REF: IN130
ISSUE No. 1
DATE 05.03.07
Page 1 of 4
www.parry.co.uk
INSTALLATION INSTRUCTIONS
SAFETY INSTRUCTIONS
USER INSTRUCTIONS
CONTACT/PANNINI GRILLS
MODEL PPGS/PPGL/PCGS/PCGL/PCGT/PPCGL/
PPGT/PPCGT

INSTRUCTION REF: IN130
ISSUE No. 1
DATE 05.03.07
Page 2 of 4
www.parry.co.uk
WARNING
To avoid scratching the highly polished exterior surface of this equipment whilst
in transit, the protective film on the exterior surfaces has NOT been removed.
It is IMPORTANT that this protective film is peeled off before the equipment is
used.
IMPORTANT
PLEASE READ INSTRUCTIONS FULLY BEFORE USE
MODELS PPGS/PPGL/PCGS/PCGL/PCGT.PPCGL/PPGT/PPCGT
CONTACT/PANNINI GRILLS
INSTRUCTIONS MANUAL
1. Choose a dry suitable place for the grill.
a) The grill should not be installed close to inflammable or heat deformation products. If this is
not possible, the grill working place has to be isolated with a good thermic non-inflammable
material.
b) Choose the least wet place possible to place the grill.
2. INSTALLATION
The machine must be placed in an aired zone. If in contact with a wall take care of its resistance against
heat. Preferably the machine should be spaced out about 5cm from the wall, or some insulating board
inserted.
Before using, remove the protective film, and allow the machine to heat up for 20/30 minutes.

INSTRUCTION REF: IN130
ISSUE No. 1
DATE 05.03.07
Page 3 of 4
www.parry.co.uk
ELECTRIC WIRING
All appliances with an electrical loading of 3 kilowatts or below are supplied with a BS1363 13 amp plug
and should be connected to an earthed mains socket. All appliances with an electrical loading above 3
kilowatts must be connected to a suitable electrical supply by a qualified electrician, who should ensure
that
a) precaution is taken during installation regarding leakage current.
b) The means of isolation has a contact separation of at least 3mm on all poles, and
c) It is installed in accordance with Health and Safety at Work Act, BS Codes of Practice, IEE Wiring
Regulations and Building and Local Authority Standards.
3.
Turn the thermostat(s) to the required temperature up to a maximum of 250°C (482°F). The thermostat(s)
LED lights up, and turns off when the set temperature is reached.
4. While the set is working do not touch the metallic parts once they are very hot.
5. CLEANING
NEVER USE WATER DIRECTLY ON THE MACHINE.
After using your Griddle for a short time you will see a build up of carbon forming on the Griddle
surface, this is normal, after each session this carbon must be removed, to do this keep the griddle on
a low temperature approximately 80°C and scrape with a suitable scraper or griddle stone.
If the carbon is allowed to build up, it will dry out and start cracking or flaking, this is not a fault with
your griddle surface.
If this happens then this surface must be removed and normal scraping will not suffice, a wire brush or
griddle stone will be required.
6. If by accident water is spilled over the grill, it should be immediately disconnected
from the power supply and it should be properly dried, before it is used again.
7. It is possible to regulate the tension of the upper plate by turning the screw on the
upper-back part of the grill, by using the hole key supplied with the grill.
8. If the power cable needs to be replaced, a cable type H05RN-F 3G 1mm2 for the
single plate grills, and a cable type H07RN-F 3G 1.5MM2 for the double plate grills,
must be used.
N.B. for the United States of America and Canada, the cable should be of the type
SJTO –14 AWG PVC 105°C.

INSTRUCTION REF: IN130
ISSUE No. 1
DATE 05.03.07
Page 4 of 4
www.parry.co.uk
Parry Catering recognises our obligations to the EU DIRECTIVE covering the waste disposal of
electrical and electronic equipment (WEEE), Parry Catering are committed to this policy in order to
help conserve the environment.
At the end of this unit’s life you MUST dispose of it in an approved manner. You MUST not discard the
unit or place it in the refuse bin.
You have several options:
a) Take the unit to an approved WEEE scheme company, there will be one in your area.
b) Take the unit to an approved waste disposal site; many sites are
managed by your local authority.
c) Contact the unit’s manufacturer, importer or their agent the contact
details will be on the unit.
There will probably be a charge for this service which will depend on the physical location of the unit
and size you will be given a collection price for a curb side collection based on commercial rates
prevailing at the time.
It should be noted that the unit to be collected should be suitably packed and sealed to prevent
dangerous gases and fluids from escaping. The condition of the unit must also be clean to comply with
health and safety regulations.
Parry Group Ltd
Town End Road
Draycott
Derby
England
DE72 3PT
