PathRight Medical RestoreX User manual

Quick Start
Video
at
restorex.com
INSTRUCTIONS FOR USE
Your path to restored health
Next Generation Penile Traction
Therapy Device
To correct or prevent lost penile length
resulting from urological surgeries and
treatments or chronic disease
Developed in Cooperation with Mayo Clinic

Indication for Use
RestoreX®is intended for use to correct the deformity (lost length) resulting
from urological surgeries and treatments or chronic disease.
Read these instructions in their entirety before using the RestoreX device.
Use only as directed.
If you have questions about the use of the RestoreX device,
please call or email customer service at:
1-877-228-5147
[e-mail].
9 a.m. to 5 p.m. (CST), Mon-Fri
RestoreX is a registered trademark of PathRight Medical, Inc.

Contents
Overview....................................................................................................................................................4
Setting up the RestoreX Device
Part 1 - Selecting Extension Rod Length .................................................................................6
Part 2 - Adjusting Clamp Height.................................................................................................9
Using the RestoreX Device
Step 1 - Secure the Penis in the Clamp ................................................................ 12
Step 2 - Extend and Add Tension......................................................................... 14
Removing RestoreX ................................................................................................... 17
Recommended Treatment Times .............................................................................. 18
Warnings and Precautions......................................................................................... 19
Contraindications ...................................................................................................... 20
Troubleshooting ........................................................................................................ 21
Care........................................................................................................................... 23

41-877-228-5147
Instructions for Use
Overview
Please review the image to become familiar with the primary components of RestoreX.
EXTENSION ROD
SCREWS
EXTENSION
RELEASE
ROTATION
BUTTONS
EXTENSION RODS
TENSION RODS CLAMP HEIGHT
ADJUSTMENT
CLAMP LOCK
CLAMP ARMS
CLAMP
HOUSING
CLAMP RELEASE
TAB
PELVIC RING
PELVIC RING
BACK VIEW
Note: RestoreX for lengthening will not
utilize the rotation feature or adjustment
of the clamp housing on the clamp arms.

1-877-228-5147
Instructions for Use
5
RestoreX accommodates stretched penile lengths greater than 3.75 inches.
Follow these one-time setup instructions to customize RestoreX for your
length and girth.
To customize, you will need the following:
•Your RestoreX device
•A ruler (not supplied)
•A Phillips-head screwdriver (not supplied)
Setting up the RestoreX Device

61-877-228-5147
Instructions for Use
Note: RestoreX cannot accommodate a stretched penile length less than 3.75 inches (10
centimeters). If less than 3.75 inches, please remeasure as detailed above being sure to push the
ruler into any fat pad which may exist near the base of the penis to get an accurate measurement.
Note: RestoreX may not provide sufficient traction for men with a stretched penile length
greater than 9 inches (23 centimeters).
Part 1 – Selecting Extension Rod Length
To begin setting up RestoreX, complete the following measurement:
Stretched Penile Length
- Hold the tip of the flaccid penis and pull it outward
from the body until maximally stretched.
- With a ruler, measure from the tip of the penis to
the base of the penis in the flaccid state.
Important: If you have a fat pad at the base of the penis
(very common), push the ruler into this pad to properly
measure the full penile length.
Compare your recorded stretched penile length to the following table:
Inches Centimeters
3.75 to 6.25 10 to 16
Recorded Stretched Length Recommended
Extension Rod Length
Standard rod length - Your device is currently
set-up with the correct rod length. Please
proceed to Part 2 (pg. 9).
Longer than
6.25
Longer than
16
Extended rod length* - Please see the
instructions to exchange the rods.
*The extended rods are located in the RestoreX box

1-877-228-5147
Instructions for Use
7
RESTOREX MAIN BODY
EXTENSION
RELEASE
Part 1 – Selecting Extension Rod Length (Cont.)
Changing Extension Rods (if necessary) and Adjusting Rod Location
If your stretched penile length is less than 6.25 inches and you are using the
standard extension rod length, proceed to Part 2 (pg. 9). Otherwise, you will need
to change the rod length.
Removing the rods:
•First, slide the extension release and hold to disengage the extension rods.
•Second, slide the main body of the device off the rods and away from the pelvic
ring until it is fully removed.
•Next, unscrew the extension rods and detach from the pelvic ring using a
Phillips-head screw driver (not supplied). See page 4 for location of screws.
•Gently pull each extension rod until they come free from the pelvic ring.

81-877-228-5147
Instructions for Use
RESTOREX MAIN BODY
EXTENSION
RELEASE
EXTENSION RODS
PELVIC RING
Align flat side
of extension
rod with flat
portion of
“key” hole in
pelvic ring
With the extension rods in
place, re-connect the main
body of the RestoreX device:
•Slide and hold the extension
release while sliding the body
onto the rods, as shown.
Re-attaching the extension rods:
•Place the extension rod into the pelvic ring by aligning the flat side of the
extension rod with the flat portion of the “key” hole in the pelvic ring, as
depicted.
•Attach the screw to the extension rod
through the hole in the pelvic ring
and tighten. Do not overtighten.
Overtightening may damage your
RestoreX device.
•Attach the second rod using
the same process.

1-877-228-5147
Instructions for Use
9
Part 2 – Adjusting Clamp Height
In some cases, the clamp height may need to be adjusted to improve comfort
during the treatment. To determine if an adjustment is necessary, remove the clamp
from the clamp housing.
Remove the clamp from the clamp housing:
Return the clamp lock to the locked position and place the head of the flaccid penis
into the clamp. Gently begin closing the clamp. Continue to close to tighten—
listening to the number of “clicks” required—until reaching a setting where you
could comfortably wear the clamp without discomfort for at least 30 minutes.
Press on the release tab near
the bottom of the clamp housing
Next, press the
clamp lock and
open the clamp

10 1-877-228-5147
Instructions for Use
Part 2 – Adjusting Clamp Height (Cont.)
If you are unable to close the clamp or only able to lock it in the highest position (one
click), you will need to adjust the clamp height. Otherwise, proceed to the next page.
Adjusting the clamp height:
•Remove the clamp from the clamp housing.
•Identify the two screws on the
inside, bottom portion of the
clamp, as shown at right.
•Loosen and remove the screws
using a Phillips-head screw driver.
•Once the screws are removed, gently separate the two pieces by
pulling apart.
•Reposition the clamp at the higher location, as shown above.
•Replace the screws and gently tighten. Completely tighten but do not
overtighten the screws. Overtightening may damage your RestoreX device.
•Replace the clamp into the clamp housing.
Your RestoreX device is now customized for your use!
