Patton electronics SmartNode 4650 User manual

The SmartNode 4650 series is the CPE
of choice for business broadband
access providers that want to gener-
ate new revenue and acquire new customers
through voice-over-IP. Part of the
proven market-leading SmartNode VoIP
product family, the SmartNode 4650 Series
features a 3 or 5 BRI/So port configuration
to fit the requirements of small and medium
enterprises.
In one single box, it combines broadband
access and voice-over-IP, and thanks to IGMP
v2/v3 proxy functionality it also delivers
video. Throughput ranges up to 24 Mbps
downstream are made possible with ADSL2+
Annex A/M & B support, and interoperability
covers all major ADSL2+ COs. This is triple-
play at your fingertips!
The extra BRI port solves many VoIP network
integration problems encountered in real-
world installations. The port can synchronize
the gateway, and it can be used as a local
PSTN breakout port for survivability. It can
also be used to shorten the time of number
portability—accepting incoming calls through
the breakout port while making outgoing calls
on the cost-saving VoIP network. With the life-
line relay, the port even
enables integration of an
ISDN emergency termi-
nal powered from the
public ISDN.
Like every SmartNode,
the 4650 Series models
are state-of-the-art VoIP gateways with out-
standing interoperability for fax (T.38 and
G.711 fallback) and voice. SmartNode prod-
ucts provide seamless network integration,
continuous trouble-free operation and cost
effective deployment to protect your invest-
ments for the future.
Visit www.patton.com for more information.
The SmartNode 4650, with up to 5 BRI ports and 8 simultaneous voice channels, is the best way to connect ISDN networks to
the world of voice over IP. Using integrated ADSL2+ broadband access, it delivers converged voice and data services that
exceed ISDN standards.
Multiport ISDN VoIP IAD
with ADSL2+ Interface
SmartNode 4650
VoIP
Special Rates Available
Call for Details
Management & Provisioning
Web-based management, SNMP, command line
interface, and auto-provisioning for automated
configuration and software upgrades.
Full VoIP Protocol Support
SIPv2, H.323v4, MGCP/IUA, ISDN, DSS1, QSIG*,
T.38, fax and modem bypass, DTMF relay.
Full Telephony Features
SessionRouter™allows flexible call routing and
numbering plan adaptations, CLIP/CLIR, hold,
AOC transfer, and much more.
ADSL2+ Broadband Access
Complete access router with integrated ADSL2+
WAN interface. Up to 24 Mbps downstream
throughput, supporting ATM QoS. Multiple PVC,
VLAN, and DSLAM interoperability.
3/5 Ports BRI ISDN VoIP
3 or 5 ISDN BRI So ports, 4 or 8 low bandwidth
voice or T.38 fax calls. Advanced adaptive traffic
management and shaping for maximum voice
quality. Voice prioritization and DownStreamQoS™.
Outstanding Interoperability
Interoperable for voice and T.38 fax with leading
SIP service providers, softswitch vendors, and
Asterisk™IP-PBX.
EIA-232
console port
3 or 5 ISDN BRI So ports with
integrated lifeline failover relay
and terminal power
Front panel indicators
show system status
at-a-glance
Proven
Patton design,
Patton supported
10/100
Ethernet port
24 Mbps broad-
band access

07MSN4650ADSL-DS4
Patton is a registered trademark and the
termsSmartNode, DownStreamQoS,and
SessionRouter are trademarks of Patton
Electronics Company in the United States and
other countries.
* Specifications subject to change without notice. ** Requires optional license.
SN4654/3BISAA/EUI: Smartnode 3 BRI VoIP ADSL2+ IAD—1 Fast Ethernet, 4 VoIP
Call; Passthrough Relay; ADSL2+ Annex A interface, H.323 and SIP, External 100–250
VAC 50/60Hz Power.
SN4654/3BISAB/EUI: Smartnode 3 BRI VoIP ADSL2+ IAD—1 Fast Ethernet, 4 VoIP
Call; Passthrough Relay; ADSL2+ Annex B interface, H.323 and SIP, External 100–250
VAC 50/60Hz Power.
SN4658/5BISAA/EUI: Smartnode 5 BRI VoIP ADSL2+ IAD—1 Fast Ethernet, 8 VoIP
Call; Passthrough Relay; ADSL2+ Annex A interface, H.323 and SIP, External 100–250
VAC 50/60Hz Power.
SN4658/5BISAB/EUI: Smartnode 5 BRI VoIP ADSL2+ IAD—1 Fast Ethernet, 8 VoIP
Call; Passthrough Relay; ADSL2+ Annex B interface, H.323 and SIP, External 100–250
VAC 50/60Hz Power.
Ordering Information
Network Integration
Specifications*
Voice Signaling
SIPv2 • H.323v4 • SIP call transfer, redi-
rect • Overlap or en-bloc dialing • DTMF
in-band, out-of-band • Configurable tones
Broadband Access
ADSL2+ ITU-T G.992.5, Annex A/M, B •
Up to 24 Mbps • PPPoE • 8 PVCs, each
UBR, CBR or VBR-rt selectable • I.610
OAM F4/F5 support • G.994.1 (G.hs)
Call Routing & Services
Regular expression number matching •
Regular expression number manipulation
• Least Cost Routing • Number blocking •
Short-Dialing • Digit collection •
Distribution- and Hunt- Groups
ISDN
3/5 BRI So ports, RJ-45 • NT/TE config-
urable per port • Built-in line power on
each port (total 4W) • DSS1, Q.921,
Q.931. NTT-64 • Point-point and point-
multipoint • Lifeline Bypass Relay •
Optional QSIG support**
Voice Processing
G.711m/A-law • G.723.1 (6.4 kbps) •
G.729, 729a, 729ab (8 kbps) • G.726 (16
,24, 32, 40 kbps) • G.168 echo cancella-
tion (25 ms) • 4/8 simultaneous low-
bandwidth voice or T.38 fax calls •
Transparent ISDN data • Silence suppres-
sion and comfort noise • Adaptive and
configurable dejitter buffer • Configurable
packet length
IP Quality of Service
Voice priority, DownStreamQoS™ • Traffic
Management, shaping policing • IEEE
802.1p, IEEE 802.1Q, 4096 VLANs (Tag
insertion/deletion), TOS, DiffServ Labeling
Connectivity
One 10/100Base-T Ethernet port • Auto-
MDIX • DHCP Client • PPPoE Client
(multi-session) • IP Multi-Netting, VLAN,
Secondary IP • IPv4, RIPv2, ICMP •
Dynamic and static NAT and NAPT • ACL
Firewall • DNS, DynDNS • DHCP Server •
SNTP Client • Optional IPsec VPN (DES,
3DES, AES)
Management
Web-based GUI • Fully Documented CLI •
Telnet and HTTP access • TFTP configu-
ration up- and download • TFTP firmware
upgrade • SNMPv1 agent (MIB II and pri-
vate MIB) • Built-in diagnostic tools •
Secure Auto-Provisioning
Power & Packaging
Desktop metal chassis
Dimensions: 11.0W x 1.5H x 6.2D in.
(28W x 3.9H x 15.7D cm)
Weight: < 21 oz (600 g)
Power Consumption < 10 W
Operating Environment
Operating temperature: 32–104°F
(0–40°C)
Operating humidity: up to 90%,
non-condensing
Compliance
FCC Part 15 Class A (US EMC)
CE per RTTE 99/5/EC (EMC and LVD)
Safety—EN60950
TBR-3 (ISDN BRI/So)
LAN Ethernet
PBX
24 Mbps broadband access
Local breakout & life-line
Up to 8 VoIP calls
LAN to WAN QoS Routing and Security
Up to 5 BRI So for ISDN
terminals and/or PBX
ISDN
Network
Internet Data
Voice
SmartNode 4650
Note: Please indicate country specific power cord at time of ordering
