Patton SmartNode 10200 Series User manual

SmartNode™ 10200 Series
TDM+VoIP Smart Media Gateway
Quick Start Guide
Important —This is a Class A device and is not intended for use in a residential environment.
Part Number: 07MSN10200-QS, Rev. D
Revised: May 7, 2012
Sales Office: [phone]
Technical Support: [phone]
E-mail: [e-mail]
www.patton.com

2SmartNode 10200 Series Quick Start Guide
• Do not open the device when the power cord is connected. For sys-
tems without a power switch and without an external power
adapter, line voltages are present within the device when the power
cord is connected.
• For devices with an external power adapter, the power adapter shall
be a listed Limited Power Source The mains outlet that is utilized to
power the device shall be within 10 feet (3 meters) of the device,
shall be easily accessible, and protected by a circuit breaker in compli-
ance with local regulatory requirements.
• For AC powered devices, ensure that the power cable used meets all
applicable standards for the country in which it is to be installed.
• For AC powered devices which have 3 conductor power plugs (L1, L2
& GND or Hot, Neutral & Safety/Protective Ground), the wall outlet
(or socket) must have an earth ground.
• For DC powered devices, ensure that the interconnecting cables are
rated for proper voltage, current, anticipated temperature, flammabil-
ity, and mechanical serviceability.
• WAN, LAN & PSTN ports (connections) may have hazardous voltages
present regardless of whether the device is powered ON or OFF.
PSTN relates to interfaces such as telephone lines, FXS, FXO, DSL,
xDSL, T1, E1, ISDN, Voice, etc. These are known as “hazardous net-
work voltages” and to avoid electric shock use caution when working
near these ports. When disconnecting cables for these ports, detach
the far end connection first.
• Do not work on the device or connect or disconnect cables during peri-
ods of lightning activity.
• This device contains no user serviceable parts. This device can only be
repaired by qualified service personnel.
• If one has reason to open the chassis or case, then the precautions
mentioned above shall be followed. This includes both the warnings
relating to disconnection of the input power, and the warnings relat-
ing to the disconnection of WAN, LAN & PSTN ports.
In accordance with the requirements of council directive 2002/96/EC on
Waste of Electrical and Electronic Equipment (WEEE), ensure that at end-
of-life you separate this product from other waste and scrap and deliver
to the WEEE collection system in your country for recycling.
This device is NOT intended nor approved for connection to the PSTN.
It is intended only for connection to customer premise equipment.
WARNING
WARNING

SmartNode 10200 Series Quick Start Guide 3
1.0 Before you begin
In the box, you will find:
• One SmartNode 10200
• One set of mounting brackets with screws
• One DB-9 to RJ-45 adapter SCSI Cables and Patch Panels, if applicable
• Three RJ45 Ethernet Straight Cables (male-male)
• One warranty sheet
• One packing slip
• One SmartNode 10200 Series Quick Start Guide
• One SmartNode 10200 Important Notice sheet with unique information for your specific unit
To install the SN10200, you will need (not included):
• Two AC power cords
• 19” equipment rack
2.0 Installing the rack hardware
1. Install rack-mounting hardware on to the SN10200 and install the unit on the equipment rack.
2. Connect the Ethernet port to your management network.
Figure 1. Installing the SN10200
SmartNode
™
Console
Ethernet
Power
TDM+VoIPSmartMediaGateway
Management
Ethernet
Management Port
Serial Console
Management Port
Power LED

4SmartNode 10200 Series Quick Start Guide
3.0 Connecting to the VoIP Network
1. Connect the VoIP Ports 0/1 and 0/1 to your network.
Note Ethernet ports (ETH 0/0 & 0/1), and SMS ports (SMS-0/0 & 0/1) are not used when connecting VoIP.
Figure 2. Connecting the VoIP ports
4.0 Connecting to the PSTN Network
1. Connect the SN10200 to the PSTN, using one of the following options:
– SCSI Interface (T1/E1), (patch panel provided)
– Dual BNC (DS3)
– Optical Interface (OC3/STM-1)
ETH VoIP SMP
0/0 0/1 0/0 0/1 0/0 0/1
VoIP Ports
1–2
49-64
33-48
17-32
1-16

SmartNode 10200 Series Quick Start Guide 5
4.1 SCSI (T1/E1)
Figure 3. Connecting to the PSTN via SCSI
4.2 Dual BNC (DS3)
Figure 4. Connecting to the PSTN via Dual BNC connectors
4.3 Optical Interface (OC3/STM-1)
Figure 5. Connecting to the PSTN via the optical interface
ETH VoIP SMP
0/0 0/1 0/0 0/1 0/0 0/1
T1/E1
SCSI connectors
49-64
33-48
17-32
1-16
ETH VoIP SMP
0/0 0/1 0/0 0/1 0/0 0/1
DS3
Dual BNC connectors
RxTx
BIT1
BIT2
RxTxRxTx
321
ETH VoIP SMP
0/0 0/1 0/0 0/1 0/0 0/1
OC3/STM-1
BIT1
BIT2
APS MAIN

6SmartNode 10200 Series Quick Start Guide
5.0 Connecting to the power source
1. Connect to two independent power sources (if only one power source is used, press the green button at
the rear of the unit to disable the audible alarm).
2. Verify that the Power LED on the front panel is a Solid Green.
Figure 6. Connecting the power source
6.0 Connecting to the Control host
1. Connect to the Control host through the console serial port (see 6.1 “Connecting the console serial
port” on page 7) OR the Ethernet management interface (see 6.2 “Connecting the Ethernet man-
agement interface” on page 7).
The IP address of the management port is 192.168.200.10/24. If it is not possible to connect to the
management port via IP, use the serial cable to connect to the SmartNode Control host for the first time.
2. Default HOSTNAME is the Control host serial number, which can be found in the “Important Notice” sheet
included with your shipment.
3. Refer to the "Important Notice" sheet for the username and password to log onto the Control host. Navi-
gate to: HTTP://HOSTNAME:12358, to configure the SmartNode unit. (username/password: root/root)
ETH VoIP SMP
0/0 0/1 0/0 0/1 0/0 0/1
Audible
alarm button
Power switch
Power socket
49-64
33-48
17-32
1-16

SmartNode 10200 Series Quick Start Guide 7
6.1 Connecting the console serial port
1. Connect a CAT5 RJ-45 (male-male) cable (supplied with unit) between the COM port of your computer
and the serial port (labeled 1010) of the SN10200.
2. If your computer’s serial port features a DB9 connector, use the DB9 to RJ-45 adapter supplied with your
SN10200. If your computer's serial port features a USB connector, you will need to provide a USB to DB9
adapter.
Figure 7. Connecting the console serial port
6.2 Connecting the Ethernet management interface
1. Connect the supplied CAT5 Ethernet cable to the management port labeled Ethernet on the front of the
SmartNode 10200.
2. Log into the SmartNode using the specific credentials included on the “Important Notice” sheet that
shipped with your unit. The management port is configured with a static Class C IP address by default.
Figure 8. Connecting the management interface
7.0 Configuring the SmartNode
You may access the SmartNode through the console management port, or through the Ethernet management
port. Refer to the following sections for more information:
• 7.1 “Accessing the SmartNode via the Console Management port” on page 8
• 7.2 “Accessing the SmartNode via the Ethernet Management port” on page 8
SmartNode
™
Console
Ethernet
Power
TDM+VoIPSmartMediaGateway
Management
Serial Console
Management Port
Serial Terminal (PC)
Note A Patton Model 16F-561 RJ45 to DB-9 adapter is included with
each SmartNode 10200 Series device
SmartNode™
Console
Ethernet
Power
TDM+VoIP Smart Media Gateway
Management
Ethernet
Management Port

8SmartNode 10200 Series Quick Start Guide
7.1 Accessing the SmartNode via the Console Management port
Logging into the SmartNode Console
1. To physically connect the console serial port, follow the instructions in 6.1 “Connecting the console
serial port” on page 7.
2. To communicate with the SN10200 through the console port, you must first configure a terminal emula-
tor or console application (such as HyperTerminal or Putty) in order to configure initial settings. Configure
the terminal emulator with the following settings:
3. Log into the console using the specific credentials included on the 'Important Notice' that shipped with
your unit. (If you do not have the “Important Notice” sheet, contact [e-mail]).
7.2 Accessing the SmartNode via the Ethernet Management port
Logging into the SmartNode via SSH
1. To physically connect the Ethernet management port, follow the instructions in 6.2 “Connecting the
Ethernet management interface” on page 7.
2. To access the SN10200, you must use an SSH connection. The password is set at the factory and is indi-
cated on the “Important Notice” sheet included with your unit. (If you do not have the “Important
Notice” sheet, contact [e-mail]).
3. The factory default configuration for the Management Ethernet Interface is a Static IP address of
192.168.200.10/24.
Preparing for Web Management
After logging into the SN10200 via the console port or SSH, a control menu displays. This menu allows you to
complete simple tasks like setting the time zone and configuring the management IP Address, and more compli-
cated tasks like advanced debugging.
For debugging assistance, contact Patton’s Support team at [e-mail]. Once your IP Address and
Time Zone are set, there are no more configuration steps in the CLI and you may proceed to the web manage-
ment page.
Baud rate Data rate Parity Stop bits Flow control
9600 8 bits None 1None

SmartNode 10200 Series Quick Start Guide 9
8.0 Logging into the Web Interface
This section describes how to login and navigate the SmartNode 10200 Web Portal.
The first step involved in initially configuring any Smart Media system involves logging on to the Web Portal. This
can be divided into two distinct tasks: connecting to the 10200 via IP and logging on to the Web Portal. For
establishing IP connectivity refer to 7.2 “Accessing the SmartNode via the Ethernet Management
port” on page 8.
8.1 Connecting to the web server
Using a web browser, connect to the Web Portal by typing the following in your address bar:
– http://[DEVICE HOST NAME]:12358
or, alternately,
– http://[DEVICE IP ADDRESS]:12358
8.2 Logging on to the Web Portal
In order to log on to the Web Portal configuration tool, enter the root user ID and password. The default values
for these parameters are:
– User ID: root
– Default password: root
9.0 Additional Information
Refer to the following manuals–available online at www.patton.com/manuals–for detailed information
about installing, configuring, and operating the SN10200 models, along with warranty, trademark, and compli-
ance information.
• SmartNode 10200 Series User Manual –www.patton.com/manuals/SN10200.pdf
• Smart Media System Software Configuration Guide –www.patton.com/manuals/SmartMedia-scg.pdf

10 SmartNode 10200 Series Quick Start Guide
A.0 Compliance Information
A.1 Compliance
EMC:
• FCC Part 15, Class A
• EN55022, Class A
• EN ETSI 300 386 V1.3.3
Low-Voltage Directive (Safety):
• UL 60950-1/CSA C22.2 No. 60950-1
• IEC/EN60950-1
A.2 Radio and TV Interference (FCC Part 15)
This device generates and uses radio frequency energy, and if not installed and used properly—that is, in strict
accordance with the manufacturer's instructions—may cause interference to radio and television reception. This
equipment has been tested and found to comply with the limits for a Class A computing device in accordance with
the specifications in Subpart B of Part 15 of FCC rules, which are designed to provide reasonable protection from
such interference in a commercial installation. However, there is no guarantee that interference will not occur in
a particular installation. If the equipment causes interference to radio or television reception, which can be
determined by disconnecting the cables, try to correct the interference by one or more of the following mea-
sures: moving the computing equipment away from the receiver, re-orienting the receiving antenna, and/or
plugging the receiving equipment into a different AC outlet (such that the computing equipment and receiver are
on different branches).
A.3 CE Declaration of Conformity
Patton Electronics, Inc declares that this device is in compliance with the essential requirements and other rele-
vant provisions of Directive 1999/5/EC. The Declaration of Conformity may be obtained from Patton Electron-
ics, Inc at www.patton.com/certifications.
The safety advice in the documentation accompanying this device shall be obeyed. The conformity to the above
directive is indicated by CE mark on the device.
A.4 Authorized European Representative
D R M Green
European Compliance Services Limited.
Avalon House, Marcham Road
Abingdon,
Oxon OX14 1UD, UK
