PAW SC5.14 User manual

*11204656* 11204656
Thank you for buying this product.
Please read this manual carefully to get the best performance from this unit. Please keep this manual carefully.
SC5.14
Manual
en
Mounting
Connection
Operation
Troubleshooting
Application examples
Manual for the
specialised craftsman

en
2
© 20140226_11205239_PAW_SOLEX_SC5.14.monde-en_tagged.indd
Safety advice
Please pay attention to the following safety advice in order to avoid danger and
damage to people and property.
Instructions
Attention must be paid to the valid local standards, regulations and directives!
Information about the product
Proper usage
The solar controller is designed for use in PAW SOLEX systems in compliance
with the technical data specied in this manual.
Improper use excludes all liability claims.
CE-Declaration of conformity
The product complies with the relevant directives and is therefore la-
belled with the CE mark.The Declaration of Conformity is available upon
request, please contact the manufacturer.
Note
Strong electromagnetic elds can impair the function of the controller.
ÎMake sure the controller as well as the system are not exposed
to strong electromagnetic elds.
Subject to technical change. Errors excepted.
Target group
These instructions are exclusively addressed to authorised skilled personnel.
Only qualied electricians should carry out electrical works.
Initial installation must be effected by the system owner or qualied personnel
named by the system owner.
Description of symbols
WARNING! Warnings are indicated with a warning triangle!
ÎThey contain information on how to avoid the danger
described.
Signal words describe the danger that may occur, when it is not avoided.
• WARNING means that injury, possibly life-threatening injury, can occur.
• ATTENTION means that damage to the appliance can occur.
Note
Notes are indicated with an information symbol.
ÎArrows indicate instruction steps that should be carried out.
Disposal
• Dispose of the packaging in an environmentally sound manner.
• Dispose of old appliances in an environmentally sound manner. Upon request
we will take back your old appliances bought from us and guarantee an environ-
mentally sound disposal of the devices.

en
3
SC5.14
Contents
1 Overview ...............................................................................................4
1.1 Optional functions ........................................................................................................5
2 Installation ............................................................................................5
2.1 Mounting .........................................................................................................................5
2.2 Electrical connection ....................................................................................................6
2.3 Data communication / Bus..........................................................................................7
2.4 SD memory card slot...................................................................................................8
3 Step-by-step parameterisation ...........................................................8
4 Operation and function .......................................................................9
4.1 Buttons ............................................................................................................................9
4.2 Selecting menu items and adjusting values ..............................................................9
4.3 Menu structure ........................................................................................................... 12
5 Initial commissioning .........................................................................13
5.1 Pre-congured SOLEX schemes............................................................................. 15
5.2 Basic systems and hydraulic variants...................................................................... 17
5.3 Overview of relay and sensor allocation ................................................................... 18
6 Main menu ..........................................................................................28
7 Status...................................................................................................28
7.1 Solar .............................................................................................................................. 28
7.2 Arrangement ............................................................................................................... 28
7.3 Heating.......................................................................................................................... 29
7.4 Messages....................................................................................................................... 29
7.5 Meas. / Balance values................................................................................................ 30
7.6 Service .......................................................................................................................... 30
8 Solar.....................................................................................................30
8.1 Basic solar settings..................................................................................................... 31
8.2 Solar optional functions............................................................................................ 33
8.3 Function control......................................................................................................... 45
8.4 Solar expert menu ..................................................................................................... 46
9 Arrangement ......................................................................................46
9.1 Optional functions ..................................................................................................... 46
10 Heating................................................................................................56
10.1 Demands ...................................................................................................................... 56
10.2 Heating circuits ........................................................................................................... 56
10.3 Optional functions ..................................................................................................... 59
11 HQM ....................................................................................................63
12 Basic settings ......................................................................................64
13 SD card................................................................................................65
14 Manual mode ......................................................................................66
15 User code ............................................................................................67
16 In- / Outputs........................................................................................67
16.1 Modules ........................................................................................................................ 67
16.2 Inputs............................................................................................................................. 68
16.3 Outputs ........................................................................................................................ 69
16.4 PWM proles .............................................................................................................. 70
17 Troubleshooting..................................................................................71
18 Accessories .........................................................................................74
18.1 Sensors and measuring instruments ...................................................................... 74
18.2 VBus®accessories ...................................................................................................... 74
18.3 Interface adapters....................................................................................................... 76
19 Index ....................................................................................................76

en
4
1 Overview
• Extra large graphic display
• 5 relay outputs
• 9 (10) inputs for Pt1000, Pt500 or KTY temperature sensors
• 1 input for a FlowRotor
• 1 input for an analogue Grundfos Direct Sensors™ or an electronic
pressure gauge
• 4 PWM outputs for speed control of high-efciency pumps
• Datalogging / rmware updates via SD memory card
• Selectable system schemes for PAW SOLEX
• Pre-programmed optional functions
• Drainback option
• Time-controlled thermostat function
• Thermal disinfection
• Automatic function control according toVDI 2169
• VBus®
• Energy-saving switch-mode power supply
upper fastening point
lower fastening point
170
198
43
Technical data
Housing: plastic, PC-ABS and PMMA
Protection type: IP 20 / EN 60529
Protection class: I
Ambient temp.: 0 … 40 °C
Dimensions: 198 × 170 × 43 mm
Mounting: wall mounting, also suitable for mounting into patch panels
Display:
Full graphic display, control lamp (directional pad) and background illumination
Operation: 7 push buttons at the front of the housing
Functions: DT control, pump speed control, heat quantity measurement, operat-
ing hours counter for the solar pump, tube collector function, antifreeze function,
thermostat function, store loading in layers, weather-compensated heating circuit
control,priority logic, drainback option, booster function, heat dump function, ther-
mal disinfection function, PWM pump control, automatic function control accord-
ing to VDI 2169.
Inputs: 9 (10) inputs for Pt1000, Pt500 or KTY temperature sensors (7 of them
can optionally be used for RTA11-M remote controls), 1 V40 impulse input, input
for 1 analogue Grundfos Direct Sensor™ or 1 electronic pressure gauge 1 CS10
irradiation sensor, 1 FlowRotor
Outputs: 4 semiconductor relays, 1 potential-free relay, 4 PWM outputs (switch-
able to 0-10 V)
Data interfaces: VBus®, SD card slot
Power supply: 100 … 240 V~, 50 … 60 Hz
Switching capacity per relay:
1 (1) A 100 … 240 V~ (semiconductor relay)
4 (2) A 100 … 240 V~ (potential-free relay)
Total switching capacity: 4 A
Standby power consumption: < 1W
Mode of operation: type 1.Y
Degree of pollution: 2
Rated impulse voltage: 2.5 kV
Supply connection: type Y attachment

en
5
1.1 Optional functions
Solar
Bypass
CS-Bypass
External heat exchanger
Tube collector
Target temperature
Frost protection
Afterheating suppression
Parallel relay
Cooling mode
Drainback
Twin pump
Heat dump
Flow rate monitoring
Pressure monitoring
Arrangement
Parallel relay
Mixer
Store loading
Error relay
Heat exchange
Solid fuel boiler
Circulation
Return preheating
Function block
Irradiation switch
Heating
Thermal disinfection
DHW heating
2 Installation
2.1 Mounting
The unit must only be located in dry interior rooms.
The controller must additionally be supplied from a double pole switch with con-
tact gap of at least 3 mm.
Please pay attention to separate routing of sensor cables and mains cables.
In order to mount the device to the wall, carry out the following steps:
ÎUnscrew the cross-head screw from the cover and remove it along with the
cover from the housing.
ÎMark the upper fastening point on the wall. Drill and fasten the enclosed wall
plug and screw leaving the head protruding.
ÎHang the housing from the upper fastening point and mark the lower fastening
points (centres 150 mm).
ÎInsert lower wall plugs.
ÎFasten the housing to the wall with the lower fastening screws and tighten.
ÎCarry out the electrical wiring in accordance with the terminal allocation,
(see page 6).
ÎPut the cover on the housing.
ÎAttach with the fastening screw.
cover
screw
Note
Strong electromagnetic elds can impair the function of the controller.
Make sure the controller as well as the system are not exposed to strong
electromagnetic elds.
WARNING! Electric shock!
Upon opening the housing, live parts are exposed!
ÎAlways disconnect the controller from power supply
before opening the housing!

en
6
2.2 Electrical connection
Note:
Connecting the device to the power supply must always be the last step
of the installation!
The controller is equipped with 5 relays in total to which loads such as pumps,
valves, etc. can be connected:
Relays 1 ... 4 are semiconductor relays, designed for pump speed control.
Conductor R1... R4
Neutral conductor N (common terminal block)
Protective earth conductor PE ⏚(common terminal block)
Relay 5 is a potential-free relay:
Connections to the R5 terminals can be made with either polarity.
WARNING! ESD damage!
Electrostatic discharge can lead to damage to electronic com-
ponents!
ÎTake care to discharge properly before touching
the inside of the device!To do so, touch a grounded
surface such as a radiator or tap!
Note:
The pump speed must be set to 100% when non-speed-controlled devices
such as valves are connected.
WARNING! Electric shock!
Upon opening the housing, live parts are exposed!
ÎAlways disconnect the controller from power supply
before opening the housing!
Note
For more details about the initial commissioning procedure see page 13.
Depending on the product version, mains cables and sensor cables are already
connected to the device. If that is not the case, please proceed as follows:
Temperature sensors (S1 to S9) have to be connected to the terminals S1... S9 and
GND (either polarity).
Potential-free relay
Protective conductor
common terminal block (PE)
Neutral conductor
common terminal block
VBus®
PWM / 0-10V terminal
Opening lever
Connection terminal
Connection for analogue Grundfos
Direct Sensor™ or electronic pressure
gauge respectively
Connection
terminal
S1
12345678910 11 12 13 14 15 16
S2 S3 S4 S5 S6 S7 S8
R4 R5
IP20
R5
N
R1-R4
100 ... 240 V~
50-60 Hz
T4A
1 (1) A (100 ... 240) V~
4 (1) A 240 V~
4 (1) A 24V
R5
R3 R2 R1
L' L
Temp. Sensor
FlowRotor
N
Isolate mains before removing cover!
Vor Öffnen Gerät spannungslos schalten!
Use ground common terminal block
Masse-Sammelklemme benutzen
Use neutral conductor common terminal block
Neutralleiter-Sammelklemme benutzen!
Use PE Common terminal block
Schutzleiter-Sammelklemme benutzen
RPS
S10
V40
PWM1
0-10V PWM2 0-10V PWM3 0-10V PWM4 0-10V
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
CS10
+VBus-
S9
Connection for
FlowRotor

en
7
The S10 terminal is an impulse input for a V40 owmeter or an FS08 ow switch.
A V40 owmeter can be connected to the terminals S1 / V40 and GND (either
polarity).
S1
1234567 8910 11 12 13 14 15 16
S2 S3 S4 S5 S6 S7 S8
R4 R5
IP20
R5
N
R1-R4
100 ... 240 V~
50-60 Hz
T4A
1 (1) A (100 ... 240) V~
4 (1) A 240V~
4 (1) A 24V
R5
R3 R2 R1
L' L
Temp. Sensor
FlowRotor
N
Isolate mains before removing cover!
Vor Öffnen Gerät spannungslos schalten!
Use ground common terminal block
Masse-Sammelklemme benutzen
Use neutral conductor common terminal block
Neutralleiter-Sammelklemme benutzen!
Use PE Common terminal block
Schutzleiter-Sammelklemme benutzen
RPS
S10
V40
PWM1
0-10V PWM2 0-10V PWM3 0-10V PWM4 0-10V
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
CS10
+VBus-
S9
Connect the irradiation sensor CS10 to the terminals CS10 and GND with cor-
rect polarity. To do so, connect the cable marked GND to the GND common
terminal block, the cable marked CS to the terminal marked CS10.
The terminals marked PWM1…4 contain the 2 PWM-/ 0-10-V speed control sig-
nal outputs for high-efciency pumps.
Note:
If a relay is to be allocated to a PWM / 0-10 V output, carry out the fol-
lowing adjustment in the In- / Outputs menu:
1. PWM / 0-10 V output: selection output = PWM1
2. PWM / 0-10 V output: selection output = PWM2
3. PWM / 0-10 V output: selection output = PWM3
4. PWM / 0-10 V output: selection output = PWM4
Connect the FlowRotor to the input marked FlowRotor. Connect analogue
Grundfos Direct SensorTM or the electronic pressure gauge to the input
marked RPS.
Note:
When Grundfos Direct SensorsTM are used, the sensor ground common
terminal block must be connected to PE.
The controller is supplied with power via a mains cable.The power supply of the device
must be 100…240V~ (50…60 Hz).
S1
12345678910 11 12 13 14 15 16
S2 S3 S4 S5 S6 S7 S8
R4 R5
IP20
R5
N
R1-R4
100 ... 240 V~
50-60 Hz
T4A
1 (1) A (100 ... 240)V~
4 (1) A 240V~
4 (1) A 24V
R5
R3 R2 R1
L' L
Temp. Sensor
FlowRotor
N
Isolate mains before removing cover!
Vor Öffnen Gerät spannungslos schalten!
Use ground common terminal block
Masse-Sammelklemme benutzen
Use neutral conductor common terminal block
Neutralleiter-Sammelklemme benutzen!
Use PE Common terminal block
Schutzleiter-Sammelklemme benutzen
RPS
S10
V40
PWM1
0-10V PWM2 0-10V PWM3 0-10V PWM4 0-10V
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
CS10
+VBus-
S9
The mains connection is at the terminals:
Neutral conductor N
Conductor L
Conductor L’ (L’ is not connected with the mains cable. L’ is a fused contact perma-
nently carrying voltage.)
Protective earth conductor PE ⏚(common terminal block)
2.3 Data communication / Bus
The controller is equipped with aVBus® or data transfer with and energy supply to
external modules.The connection is to be carried out at the two terminals marked
VBus and GND (any polarity). One or more VBus®modules can be connected via
this data bus, such as:
• GA3 Large Display module / SD3 Smart Display
• AM1 Alarm Module
• DL2 Datalogger
• EM Extension module
Furthermore, the controller can be connected to a PC via the VBus®/USB or
VBus®/LAN interface adapter (not included). With the ServiceCenter Software,
measured values can be read, processed and visualised.The software allows an easy
function control of the system.
Parameterising the controller via the ServiceCenter software is not possible at
the moment.This feature will be made available in a later version of the RPT con-
guration tool.
Note:
More accessories on page 74.
WARNING! Electric shock!
L’ is a fused contact permanently carrying voltage.)
ÎAlways disconnect the controller from power supply
before opening the housing!

en
8
2.4 SD memory card slot
The controller is equipped with an SD card slot.
With an SD card, the following functions can be carried out:
• Store measurement and balance values onto the SD
card.After the transfer to a computer, the values can be
opened and visualised, e. g. in a spreadsheet.
• Prepare adjustments and parameterisations on a computer
and transfer them via the SD card.
• Store adjustments and parameterisations on the SD card
and, if necessary, retrieve them from there.
• Download  rmware updates from the Internet and install
them on the controller.
For more information about using an SD card, see page 65.
3 Step-by-step parameterisation
The SC5.14 controller is a controller that offers a broad variety of functions to the
user. At the same time, the user has a lot of freedom in con guring them. Therefore,
to set up a complex system, careful planning is required.We recommend drawing
a sketch of the system  rst.
If planning, hydraulic execution and electrical connection have all been carried out
successfully, proceed as follows:
1. Running the commissioning menu
The commissioning menu is run after the  rst connection and after every reset. It
will request the following basic adjustments:
• Menu language
• Temperature unit
• Volume unit
• Pressure unit
• Energy unit
• Time
• Date
• Solar system
• Hydraulic variant
At the end of the commissioning menu, a safety enquiry follows. If the safety en-
quiry is con rmed, the adjustments will be saved.
For further information about the commissioning menu see page 13.
With an SD card, the following functions can be carried out:
Prepare adjustments and parameterisations on a computer
2. Registering sensors
If  owmeters,  ow switches, Grundfos Direct Sensors™ and/or external extension
modules are connected, these have to be registered in the In-/Outputs menu.
For further information about the registration of modules and sensors see page 67.
3. Activating solar optional functions
The basic solar system has been adjusted during commissioning. Now, optional
functions can be selected, activated and adjusted.
Free relays can be allocated to optional functions which require a relay.The con-
troller always suggests the numerically smallest free relay.
Sensors can be allocated to more than one function.
For further information about the optional arrangement functions see page 33.
4. Activating optional arrangement functions
Now, optional functions for the non-solar part of the arrangement can be selected,
activated and adjusted.
Free relays can be allocated to optional functions which require a relay.The con-
troller always suggests the numerically smallest free relay.
Sensors can be allocated to more than one function.
For further information about the optional arrangement functions see page 46.
5. Adjusting heating circuits and activating optional heating functions
Now, heating circuits can be activated and adjusted.
For the heating part of the arrangement, optional functions can be selected, acti-
vated and adjusted.
To heating circuits and optional functions which require one or more relays, the
corresponding number of free relays can be allocated. The controller always sug-
gests the numerically smallest free relay.
Sensors can be allocated to more than one function.
For further information about heating circuits and optional heating functions see
page 56.

en
9
4 Operation and function
4.1 Buttons
The controller is operated via the 7 buttons next to the display. They have the
following functions:
button ❶- scrolling upwards
button ❸- scrolling downwards
button ❷- increasing adjustment values
button ❹- reducing adjustment values
button ➄ - con rming
button ➅- entering the status menu / chimney sweeper mode
(system-dependent)
button ➆- escape button for changing into the previous menu
1
2
4
63
5
7
4.2 Selecting menu items and adjusting values
During normal operation of the controller, the display is in the main menu. If no
button is pressed for a few seconds, the display illumination goes out.
Press any key to reactivate the display illumination.
ÎIn order to scroll though a menu or to adjust a value, press either buttons ❶
and ❸or buttons ❷and ❹.
ÎTo open a sub-menu or to con rm a value, press button ➄.
ÎTo enter the status menu, press button ➅ – uncon rmed adjustments will
not be saved.
ÎTo switch to the previous menu level, press button ➆ – uncon rmed adjust-
ments will not be saved.
If no button has been pressed within a couple of minutes, the adjustment is can-
celled and the previous value is retained.
If the symbol »is shown behind a menu item, pressing button ➄will open a new
sub-menu.
If the symbol ➕is shown in front of a menu item, pressing button ➄will open a
new sub-menu. If it is already opened, a ➕is shown instead of the ➖.

en
10
current value savedminimum value maximum value
adjusted value
(not yet con rmed)
adjustment channel
Values and adjustments can be changed in different ways:
Numeric values can be adjusted by means of a slide bar.The minimum value is indi-
cated to the left, the maximum value to the right.The large number above the slide
bar indicates the current adjustment. By pressing buttons ❷and ❹the upper
slide bar can be moved to the left or to the right.
Only after the adjustment has been con rmed by pressing button ➄will the num-
ber below the slide bar indicate the new value.The new value will be saved if it is
con rmed by pressing button ➄again.
active area inactive area
When two values are locked against each other, they will display a reduced adjust-
ment range depending on the adjustment of the respective other value.
In this case, the active area of the slide bar is shortened, the inactive area is indicat-
ed as a dotted line.The indication of the minimum and maximum values will adapt
to the reduction.
If only one item of several can be selected, they will be indicated with “radio but-
tons”. When one item has been selected, the radio button in front of it is  lled.
If more than one item of several can be selected, they will be indicated with check-
boxes.When an item has been selected, an xappears inside the checkbox.

en
11
Adjusting the timer
When the Timer option is activated, a timer is in-
dicated in which time frames for the function can be
adjusted.
First of all, an overview of the current adjustments is
displayed. For each day of the week there is an overview
display. The display can be switched back and forth be-
tween the different days by pressing buttons ❷and ❹.
In order to adjust the timer, press button ➄.
First the individual days of the week or all days of the
week can be selected.
The last menu item after the list of days is Continue.
If Continue is selected, the Edit timer menu opens, in
which the time frames can be adjusted.
Adding a time frame:
The time frames can be adjusted in steps of 15 min.
In order to add an active time frame, proceed as follows:
ÎMove the cursor to the desired starting point of
the time frame by pressing buttons ❷and ❹.
Conrm the starting point of the time frame by
pressing button ❶.
ÎMove the cursor to the desired ending point of
the time frame by pressing buttons ❷and ❹.
ÎThe end of a time frame can be determined by
pressing button ➄.
ÎIn order to add another time frame, repeat the
last three steps.
ÎPress button ➄again to get back to the overview
of current adjustments.
Removing a time frame:
In order to remove an active time frame, proceed as
follows:
ÎDetermine the point from which on the time
frame is to be removed by pressing button ❸.
ÎMove the cursor to the desired ending point of
the time frame by pressing buttons ❷and ❹.
ÎIn order to conclude removing the time frame,
press button ➄upon reaching the desired ending
point.
ÎPress button ➄again to get back to the overview
of current adjustments.

en
12
4.3 Menu structure
Main menu
Status
Solar
Arrangement
Heating
HQM
Basic settings
SD card
Manual mode
User code
In- / Outputs
Expert
Solar
Basic setting
Optional functions
Function control
Expert
Arrangement
Optional functions
Basic setting
System
Collector
Store
Loading logic
Optional functions
Parallel relay
Mixer
Store loading
Error relay
…
Heating
Demands
Heating circuits
Optional functions
Parallel relay
Relay
Reference relay
Overrun
Delay
Inverted
…
The menu items and adjustment values selectable are variable depending on adjust-
ments already made. The gure only shows an exemplary excerpt of the complete
menu in order to visualise the menu structure.
Basic settings
Language
Auto DST
Date
Time
Temp. unit
Vol. unit
…
In- / Outputs
Modules
Inputs
Outputs

en
13
5 Initial commissioning
When the hydraulic system is  lled and ready for operation, connect the controller
to the mains.
The controller runs an initialisation phase in which the directional pad  ashes red.
When the controller is commissioned for the  rst time or when it is reset, it will
run a commissioning menu after the initialisation phase.The commissioning menu
leads the user through the most important adjustment channels needed for oper-
ating the system.
Commissioning menu
The commissioning menu consists of the channels described in the following.In or-
der to make an adjustment,push button ➄.Adjust the value by pressing buttons ❷
and ❹, then push button ➄ to con rm. The next channel will appear in the display.
5
5
Adjustment mode
button navigation
changing a value
con rming a value
next parameter appears
automatically
2
4
1. Language:
ÎAdjust the desired menu language.
2. Scheme:
ÎAdjust the scheme number according to page 15.
3. Units:
ÎAdjust the desired temperature unit.
ÎAdjust the desired volume unit.
ÎAdjust the desired pressure unit.
ÎAdjust the desired energy unit.
4. Daylight savings time adjustment:
ÎActivate or deactivate the automatical daylight
savings time adjustment.

en
14
5. Time:
ÎAdjust the clock time. First of all adjust the hours,
then the minutes.
6. Date:
ÎAdjust the date. First of all adjust the year, then
the month and then the day.
8. Completing the commissioning menu:
After the system has been selected, a safety enquiry
appears. If the safety enquiry is con rmed, the adjust-
ments will be saved.
ÎIn order to con rm the safety enquiry, press but-
ton ➄.
ÎIn order to reenter the commissioning menu
channels, press button ➆. If the safety enquiry
has been con rmed, the controller is ready for
operation and should enable an optimum system
operation.
All adjustments made during commissioning can, if
necessary, be changed later on in the Basic settings
menu.
7. Selection of the solar system:
ÎAdjust the desired solar system (number of collec-
tors and stores, hydraulic variants).
Note:
This step will be skipped when a scheme number has been entered.

en
15
5.1 Pre-congured SOLEX schemes
SOLEX 1 = Scheme 881
(In order to select this scheme, enter scheme number 881)
S2
S3
P1 (R1)
(PWM1)
S1
P2 (R3)
(PWM2)
S9
dV
S1
12345678910 11 12 13 14 15 16
S2 S3 S4 S5 S6 S7 S8
R4 R5
IP20
R5
N
R1-R4
100 ... 240 V~
50-60 Hz
T4A
1 (1) A (100 ... 240)V~
4 (1) A 240 V~
4 (1) A 24V
R5
R3 R2 R1
L' L
Temp. Sensor
FlowRotor
N
Isolate mains before removing cover!
Vor Öffnen Gerät spannungslos schalten!
Use ground common terminal block
Masse-Sammelklemme benutzen
Use neutral conductor common terminal block
Neutralleiter-Sammelklemme benutzen!
Use PE Common terminal block
Schutzleiter-Sammelklemme benutzen
RPS
S10
V40
PWM1
0-10V PWM2 0-10V PWM3 0-10V PWM4 0-10V
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
CS10
+VBus-
S9
Relay / sensor allocation
Connection
terminal Description Indication
PWM1 Primary pump Speed control signal Primary pump
PWM2 Secondary pump Speed control
signal Sec.ExtHX 1
S1 Collector sensor Collector / Flow HQM 1
S2 Store sensor Store 1
S3 Heat exchanger sensor ExtHX: Primary 1
S9 Return sensor Return HQM 1
FlowRotor Flow rate sensor FlowRotor
R1 Primary pump Power supply
R3 Secondary pump Power supply
FlowRotor
Functions
Function
Factory setting
Sensors
External heat exchanger, solar yes S3
Flow rate monitoring yes FlowRotor
Heat quantity measurement yes S3, S9, FlowRotor
Heat transfer uid Tyfocor LS

en
16
S4
S2
V1
(R2)
S3
P1 (R1)
(PWM1)
S1
P2 (R3)
(
PWM2
)
S9
dV
S1
12345678910 11 12 13 14 15 16
S2 S3 S4 S5 S6 S7 S8
R4 R5
IP20
R5
N
R1-R4
100 ... 240 V~
50-60 Hz
T4A
1 (1) A (100 ... 240)V~
4 (1) A 240 V~
4 (1) A 24V
R5
R3 R2 R1
L' L
Temp. Sensor
FlowRotor
N
Isolate mains before removing cover!
Vor Öffnen Gerät spannungslos schalten!
Use ground common terminal block
Masse-Sammelklemme benutzen
Use neutral conductor common terminal block
Neutralleiter-Sammelklemme benutzen!
Use PE Common terminal block
Schutzleiter-Sammelklemme benutzen
RPS
S10
V40
PWM1
0-10V PWM2 0-10V PWM3 0-10V PWM4 0-10V
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
CS10
+VBus-
S9
SOLEX 2 = Scheme 882
(In order to select this scheme, enter scheme number 882) Relay / sensor allocation
Connection
terminal Description Indication
PWM1 Primary pump Speed control signal Primary pump
PWM2 Secondary pump Speed control signal Sec.ExtHX 1
S1 Collector sensor Collector / Flow HQM 1
S2 Store sensor Store 1
S4 Store sensor 2 Store 2
S3 Heat exchanger sensor ExtHX: Primary 1
S9 Return sensor Return HQM 1
FlowRotor Flow rate sensor FlowRotor
R1 Primary pump Power supply
R2 3-port changeover valve 3PV store 2
R3 Secondary pump Power supply
FlowRotor
Functions
Function
Factory setting
Sensors
External heat exchanger, solar yes S3
Flow rate monitoring yes FlowRotor
Heat quantity measurement yes S3, S9, FlowRotor
Heat transfer uid Tyfocor LS

en
17
5.2 Basic systems and hydraulic variants
System
In addition to the pre-con gured schemes 881 and 882, the controller is pre-pro-
grammed for 7 basic solar systems.The selection depends on the number of heat
sources (collector  elds) and heat sinks (stores, pool). Factory setting is system 1.
The selection of the basic solar system is one of the most important adjustments
and is thus requested already in the commissioning menu.
First, the basic system is adjusted by means of the number of stores and collectors
 elds, then the hydraulic variant.
The selected system is visualised by the corresponding number of store and collec-
tor symbols. The  gure to the left shows system 6 which consists of 3 stores and 2
collector  elds (“east- / west collectors”).
A solar system with store charging in layers is
implemented as a 2-store system (store top =
store 1; store bottom = store 2).
System 0: no solar system
System 1: 1 collector  eld - 1 store
System 2: east- / west collectors - 1 store
System 3: 1 collector  eld - 2 stores
System 4: east- / west collectors - 2 stores
System 5: 1 collector  eld - 3 stores
System 6: east- / west collectors - 3 stores
System 7: 1 collector  eld - 4 stores
Variant
The hydraulic variant refers to the different actuators that are to be controlled.
They are visualised on the display by means of symbols, when the variant is select-
ed. The upper symbol indicates the actuator belonging to the collector  elds, the
lower one the actuators belonging to the stores.
The exemplary  gure shows the display indicated when system 6, variant 2 has
been selected. In this case, each collector  eld has a 2-port valve, the stores are
loaded by means of pump logic.
For each variant, the controller allocates the corresponding relays and sensors.The
allocations of all combinations are shown in chap. 5.3.

en
18
5.3 Overview of relay and sensor allocation
System 1
R1
S1
S2
Relay / sensor allocation
123456789
Relay Solar pump Optional
function
Optional
function
Optional
function
Optional
function
Sensor Collector 1 Store base Free Free Free Free Free Free Free
System 2 variant 1 S1 S6
R1 R2
S2
Relay / sensor allocation
123456789
Relay Pump coll. 1 Pump coll. 2 Optional
function
Optional
function
Optional
function
Sensor Collector 1 Store base Free Free Free Collector 2 Free Free Free

en
19
S1 S6
R1 R2
S2
R3
System 2 variant 2
Relay / sensor allocation
123456789
Relay 2PV coll. 1 2PV coll. 2 Solar pump Optional
function
Optional
function
Sensor Collector 1 Store base Free Free Free Collector 2 Free Free Free
System 3 variant 1
S1
R2
R1 S2 S4
Relay / sensor allocation
123456789
Relay Solar pump 3PV
Store 2
Optional
function
Optional
function
Optional
function
Sensor Collector Store 1 base Free Store 2 base Free Free Free Free Free

en
20
System 3 variant 2
S1
R1 R2
S4
S2
R1 R2
Relay / sensor allocation
123456789
Relay Solar pump
Store 1
Solar pump
Store 2
Optional
function
Optional
function
Optional
function
Sensor Collector Store 1 base Free Store 2 base Free Free Free Free Free
System 3 variant 3
R1
R2 R3
S2
S4
S1
Relay / sensor allocation
123456789
Relay Solar pump 2PV
Store 1
2PV
Store 2
Optional
function
Optional
function
Sensor Collector Store 1 base Free Store 2 base Free Free Free Free Free
