Pawleys Island dt96 User manual

STEP 1. Use (12) 3” screws to attach fascia plates and spreaders to leg
assemblies.
(4) LEG ASSEMBLIES
(4) FASCIA PLATES
(4) SPREADER BARS
(1) TABLE TOP
• ADJUSTABLE WRENCH
• DRILL
Hardware Pack Weight: 11.4 oz.
HARDWARE PACK
TABLE PARTS
SUGGESTED TOOLS
ASSEMBLY
(8) 2.5” BARREL BOLTS
(24) 3” SCREWS
(8) LOCK NUTS
(16) WASHERS(1) ALLEN WRENCH
(1) SQUARE-HEAD BIT
96” & 120” DINING TABLE
INSTRUCTIONS
96” Dining Table pictured.
FASCIAFASCIA
PLATEPLATE
SPREADER BARSPREADER BAR
3”3”
SCREWSCREW
LEGLEG
ASSEMBLYASSEMBLY

Congratulations on purchasing this Durawood 96” or 120” Dining Table. QUESTIONS REGARDING THIS PRODUCT? Call our customer service team, 252-758-0641.
RESIDENTIAL WARRANTY - This quality product includes a LIMITED LIFETIME WARRANTY for RESIDENTIAL CUSTOMERS. In the unlikely event any splintering, rotting, cracking,
peeling, or chipping should ever occur, The Hammock Source will supply replacement parts or replace the furniture, at no charge to you. This does not include negligence, improper use,
animal damage or damage caused by natural disasters. When using around fire, keep furniture at a minimum distance of 30 inches from the heat source. Prevent prolonged exposure to
chlorinated water. Note that an original sales receipt must accompany any returned product, along with a Return Authorization Number from Hammock Source customer service; call toll-
free at 252-758-0641.
CONTRACTOR WARRANTY - CONTRACTORS receive a LIMITED 7-YEAR WARRANTY. Follow the same steps outlined above.
MAINTENANCE - Thoroughly inspect product before each use. Periodically check bolts after assembly and re-tighten when necessary.
STEP 2. Use (8) 2.5” bolts, (16) washers and (8) lock nuts to attach leg structure to table top.
Make sure to use two washers per bolt, one for the bolt head and one for the locknut.
Refer to detailed image for hardware order.
NOTE: Parts hidden for visibility
2.5” BOLT2.5” BOLT
WASHERWASHER LOCKLOCK
NUTNUT
TABLE TOPTABLE TOP
2.5” BOLT2.5” BOLT
WASHERWASHER
LOCKLOCK
NUTNUT
#5215*5215*
