Pawleys Island Durawood Essentials User manual

Congratulations on purchasing this Durawood Essentials
or Sunrise Dining Chair! You’re going to love the quality,
durability and simple assembly —plus the full Residential
Lifetime Warranty. QUESTIONS REGARDING THIS PRODUCT?
Call our customer-service line toll-free at [phone].
HARDWARE PACK
Before beginning assembly, make sure you have all parts. Note that
not all parts pictured are to scale.
10 - 1.5" Barrel Bolts
REQUIRED TOOL (NOT PROVIDED)
•Standard Phillips Head Screwdriver
USING BARREL BOLTS
EXTREMELY
IMPORTANT:
Use ONLY
a Standard
Phillips Head
Screwdriver to
tighten Barrel
Bolt Assemblies;
using a drill can
strip the Barrel
Bolt head,
marring the
appearance of
your chair.
then
To correctly thread Barrel Bolts to Bolt Fasteners:
Fit the Fastener over the bottom of the Bolt,
turning the Fastener at rst counterclockwise,
until you hear a slight click, then begin
tightening clockwise as you normally would.
ASSEMBLY INSTRUCTIONS on back of page; Residential Lifetime Warranty, back of page
Durawood
Essentials
& Sunrise
Dining Chair
essentials
chair back sunrise chair back
sunriseessentials
right
leg
CHAIR
PARTS
left
leg
PEG
HOLE
FACING
UP
PEG
HOLE
FACING
UP bottom
chair frame
chair seat
Your Durawood Furniture comes with several
pegs to increase sturdiness. Wherever you
nd a peg hole, insert peg. You may need to
use a small mallet to tap the plug into place.
x6 x1x10 x4
Assemblies
4 - 1 5/8" screws
6 - Pegs
1 - Allen Wrench
1 - #2 Square Bit
Hardawre pack
weight 7.88oz

#6019 / 060315F
STEP 4. Align bottom
chair frame with rear legs,
making sure peg and
peg holes align. (Figure
4) Take apart one Barrel
Bolt Assembly, inserting
the Barrel Bolt into a set
of lined-up holes, if the
Barrel Bolt doesn't go in
easily, push it all the way
in using the Allen Wrench.
Fit Bolt Fastener over the
bottom of the Barrel Bolt
and tighten using the Allen
Wrench and a Standard
Phillips Head Screwdriver.
Do not over tighten.
Repeat for opposite side.
RESIDENTIAL WARRANTY | This quality product includes a FULL LIFETIME WARRANTY for RESIDENTIAL CUSTOMERS. If damage
occurs due to any splintering, rotting, cracking or peeling, within normal or acceptable use, The Hammock Source will replace
this furniture, at no charge to you. Note that an original sales receipt must accompany any returned product, along with a Return
Authorization Number from Hammock Source customer service; call toll-free at [phone].
CONTRACTOR WARRANTY | CONTRACTORS receive a FULL 7-YEAR WARRANTY. Follow the same steps outlined above.
FIGURE 4
PEG
PEG
STEP 7. Tighten all Barrel Bolt Assemblies securely.
peg
STEP 1. Align chair back
holes with chair seat holes.
(FIGURE 1).
STEP 3. Insert screw as
shown (Figure 3) and
secure into place using drill.
Turn chair over and repeat
for opposite side.
ASSEMBLY STEP 2. Take apart one
Barrel Bolt Assembly,
inserting the Barrel Bolt into
the lined-up holes (FIGURE 2),
if the Barrel Bolt doesn't go in
easily, push it all the way in
using the Allen Wrench.
Line up the other set of holes,
repeating this step with a
second Barrel Bolt Assembly.
HOLES
HOLES
FIGURE 1
FIGURE 3
FIGURE 2
STEP 5. Turn chair with right side facing up. Align both peg holes in
the arm/leg assembly with pegs on side of chair. (You may need
to wiggle the chair seat to allow for proper seeding.) Attach barrel
bolt assembly as previously instructed for each of the 3 holes on
the side of the chair. Do not over tighten. Flip chair over to left side
and repeat with left leg.
STEP 6. Insert screw as
shown (Figure 6) and
secure into place using drill.
Turn chair over and repeat
for opposite side.
FIGURE 5
FIGURE 6
