Paxar Monarch Pathfinder Ultra Platinum 6039 Service manual

PRINTER WALL REFERENCE
PathfinderUltraSilver (6032) Printer PathfinderUltraGold (6037) Printer PathfinderUltraPlatinum (6039) Printer
See the Equipment Manua
l
for more information.
Loading Supplies in Peel Mode
Turn on the printer and put Press the latch buttons Open the spring-loaded Insert the supply roll so it
it into load mode. and open the supply cover. supply holder. feeds from the bottom.
6032: Press the Load Key.
6037: Press Function and Supply Cover
0 (zero.)
6039: Select the supply loading
option from the displa
y
screen.
Or, ask your System Latch Buttons
Administrator.
Peel four inches of labels Pull the Label Deflector down. Feed all four inches of the backing paper
unde
r
the applicator roller,
from the backing paper.
ove
r
the peel bar, and unde
r
the label deflector.
Applicator Roller
Peel Bar
Label Label Deflector
Deflector
Push the Label Deflector Pull the backing paper
up until it snaps into place.
ove
r
the Guide Roller,
down to the Pinch and Close the
Partiall
y
close the cover Feed Rollers. cover and
to the first position. Press the trigger. press ESC or
return to the
Guide Roller previous menu.
(behind supply)
Pinch and
Feed Rollers
Cleaning Your Printer NOTE: Always turn off the printer before cleaning.
Platen Roller Pinch and Feed Rollers Printhead Printer Flex Cable
Adhesive
Buildup
Cable
Use a dry, soft-bristle brush. Use a dry, lint-free cloth. Use a cleaning pen or a Use a soft cloth, lightly
soft cloth, lightly moistened moistened with
with 91% Isopropyl Alcohol. 91% Isopropyl Alcohol.
Platinu
m
Display Screen On-Demand Sensor Scanner Windo
w
Black Mark Sensor
Display
Screen On-Demand
Sensor
Pull the
Label Deflector
down.
Use a soft cloth, lightly Use a dry cotton swab. Use a soft cloth, lightly Use a dry cotton swab.
moistened with water. moistened with water.
2
13 4
5 6 7
8
9
11
10
TC603XWC Rev. AC 6/05 2003 Paxar Americas, Inc. All Rights Reserved.

PRINTER WALL REFERENCE
PathfinderUltraSilver (6032) Printer PathfinderUltraGold (6037) Printer PathfinderUltraPlatinum (6039) Printer
See the Equipment Manua
l
for more information.
Loading Supplies in Non-Peel Mode
Turn on the printer and put Press the latch buttons and open Open the spring-loaded supply holder.
it into load mode. the supply cover.
6032: Press the Load Key.
6037: Press Function and
0 (zero.)
6039: Select the supply loading
option from the displa
y
screen.
Or, ask your System Supply Cover
Administrator.
Latch Buttons
Insert the supply roll so it Feed the supply out the front of the printer,
unde
r
Close the supply cover and press ESC
feeds from the bottom. the Applicator Roller and
abov
e
the Label Deflector. or return to the previous menu.
Applicator Roller
Label Deflector
Cleaning Your Printer NOTE: Always turn off the printer before cleaning.
Platen Roller Pinch and Feed Rollers Printhead Printer Flex Cable
Adhesive
Buildup
Cable
Use a dry, soft-bristle brush. Use a dry, lint-free cloth. Use a cleaning pen or a Use a soft cloth, lightly
soft cloth, lightly moistened moistened with
with 91% Isopropyl Alcohol. 91% Isopropyl Alcohol.
Platinu
m
Display Screen On-Demand Sensor Scanner Windo
w
Black Mark Sensor
Display
Screen On-Demand
Sensor
Pull the
Label Deflector
down.
Use a soft cloth, lightly Use a dry cotton swab. Use a soft cloth, lightly
moistened with water. moistened with water. Use a dry cotton swab.
2 3
5 64
1
TC603XWC Rev. AC 6/05 2003 Paxar Americas, Inc. All Rights Reserved.
