Surfboard Shelf
PARTS INCLUDED:
A. (1) Surfboard shelf
B. (2) Metal Bracket
C. (2) Assembly Screws (5/8”L)
D. (4) Toggle Anchors
E. (4) Toggle Screws (Flat-tipped 2.25”L)
F. (4) Stud Screws (1.5”L)
G. (1) Fin
TOOLS REQUIRED (NOT INCLUDING)
•Phillips head screwdriver
•Level
•Tape
•Pencil
ASSEMBLY (Figure #1):
1. Attach Brackets (B) to shelf by inserting the Assembly Screws (C) through the hole in each bracket
and into the pre-drilled marks on underside of shelf.
2. Insert the Fin (G) into the hole at the end of shelf; slide the fin towards the end of the board until the
screws are positioned at the narrow slot.
MOUNTING INSTRUCTIONS: Two people are required for mounting.
3. Hold the product (A) at the desired location. NOTE: Use a level to ensure the shelf is not tilting. Using
a pencil, mark on the wall through the two pre-drilled holes on each mounting bracket. These marks
are the insertion points for the mounting hardware. Gently put the shelf aside on a flat surface.
Drywall Mounting (Figure #2):
3. Use a Phillips screwdriver to install the Toggle anchor(s) (D). Do not use a drill to install the toggle
anchors and do not force or “pound” the anchors into the wall. The toggle anchors are designed to
cleanly cut and bore themselves into the wall like a drill bit.
4. Position a toggle anchor over one of your insertion point marks. Slowly turn the anchor clockwise
while applying even pressure until the flange just touches the wall. If the anchor position is close to a
stud (1/2” or less), keep turning clockwise until one of the arrows on the flange is pointing to the 12
o’clock position. Repeat with the other toggle anchors and insertion point marks.
5. Hold the shelf against the wall and align the holes in the brackets to the drywall toggle anchors in the
wall. Using a Phillips head screwdriver, insert a Toggle screw (E) through the bracket’s pre-drilled
holes and into the toggle anchor turning clockwise. At this point, you will feel a slight resistance. This
is the point where the toggle anchor screw is engaging the pivoting portion of the anchor. Continue
turning the screw clockwise until the screw head touches the shelf’s bracket. Continue to tighten the
toggle anchor screw until it becomes difficult to turn. At this point the internal pivot will have engaged
the backside of the drywall. Repeat with the other toggle screws and anchors.
Stud Mounting (Figure #3)
6. Simply hold the shelf against the wall and align the pre-drilled holes in the brackets to the insertion
point marks you made on the wall.
7. Secure the brackets to the wall by installing the Stud Screws (F) through the brackets’ pre-drilled
holes and into the wall studs at insertion point marks on your wall. Do not over tighten.
CARE INSTRUCTIONS:
•Wipe with a soft, dry cloth.
•Avoid cleaners and abrasives as they may damage the finish.
