PCE-MSR 340 Magnetic Stirrer
User Manual
User manuals in various languages (français,
italiano, español, português, nederlands, türk, polski,
русский, 中文) can be found by using our
product search on: www.pce-instruments.com
Last change: 18 November 2020
v1.0
English

© PCE Instruments
Contents
1Safety notes........................................................................................... 1
2Technical specifications ...................................................................... 3
3Delivery scope.......................................................................................3
4Preparation ............................................................................................ 3
5Operation ............................................................................................... 4
5.1 Power on.......................................................................................................................... 4
5.2 Start / stop stirring process............................................................................................... 4
5.3 Temperature adjustment .................................................................................................. 4
5.4 RPM setting ..................................................................................................................... 5
5.5 Stirring time setting .......................................................................................................... 5
6Warranty.................................................................................................6
7Disposal ................................................................................................. 6

© PCE Instruments
1
1 Safety notes
Please read this manual carefully and completely before you use the device for the first time. The
device may only be used by qualified personnel and repaired by PCE Instruments personnel.
Damage or injuries caused by non-observance of the manual are excluded from our liability and
not covered by our warranty.
•The device must only be used as described inthis instruction manual.If used otherwise,
this can cause dangerous situations for the user and damage to the meter.
•The instrument may only be used if the environmental conditions (temperature, relative
humidity, …) are within the ranges stated in the technical specifications. Do not expose
the device to extreme temperatures, direct sunlight, extreme humidity or moisture.
•Do not expose the device to shocks or strong vibrations.
•The case should only be opened by qualified PCE Instruments personnel.
•Never use the instrument when your hands are wet.
•You must not make any technical changes to the device.
•Keep the surface clean and free from damage. Clean it only with protective gloves. The
device should only be cleaned with a soft cloth.
•The device must only be used with accessories from PCE Instruments or equivalent.
•Before each use, inspect the case for visible damage. If any damage is visible, do not
use the device.
•The device must not be used in a potentially explosive atmosphere, must not come into
contact with hazardous substances or be submerged.
•Place the magnetic stirrer on a flat, stable, clean, non-slip and fireproof surface.
•Make sure that only authorised persons who have previously familiarised themselves
with the operating instructions use the magnetic stirrer.
•Note that magnetic fields can affect pacemakers and cause data loss.
•Do not touch the heating plate when it has reached atemperature above 50°C to avoid
injury / burns. Please note that there is still residual heat even after switching off.
•Do not place any objects on the stirring plate that are not temperature-resistant.
•Hold the instruments firmly in both hands when moving or connecting it. The unit should
not be moved until it has reached room temperature.
•Make sure that the power cable and temperature sensor do not come into contact with
the heating plate.
•Do not place any steel or magnetic parts on the magnetic stirrer. The recommended
magnetic stirring bar may only be placed on the device if it is in a beaker or flask.
•Depending on the medium, you should wear appropriate protective equipment. With
some media, there is a risk of splashing or the release of toxic or flammable gases, for
example.
•Damaged cups, flasks, stirring bars or other parts should not be used anymore.
•Reduce the speed if the medium splashes out of the container due to excessive speed,
if the device runs unsteadily or if the container moves back and forth on the plate.
•Do not move the instrument during operation or when it is connected to the power
supply.
•Do not use the appliance for hazardous or reactive solutions.
•Special care should be taken when working with flammable materials, especially if they
have a low vapour pressure. Overfilling should also be avoided in any case. The
container should be the right size and stand firmly on the plate. Broken glass can also
be a hazard.
•Contamination and chemical reactions must be expected.
•The temperature sensor must always be immersed at least 30 mm deep in the medium.
•Please observe the specified operating voltage.

© PCE Instruments
2
•Pathogenic substances should always be processed in a closed container and using a
suitable extraction hood.
•Only use media that you know will not react dangerously to the additional energy
generated during processing. Additional energy can also be generated by light
irradiation, a certain ambient temperature or other factors.
•Under certain circumstances, abrasion debris from dispersion and stirring devices can
get into the medium to be processed.
•For dissolved alkali metals or alkaline earth metals and at temperatures above 250 °C,
only glass-coated magnetic stirring bars should be used.
•Do not cover the appliance either partially or completely with metal plates or sheets as
this can cause overheating. Always keep the mounting plate clean.
•Make sure that the socket is earthed (protective contact).
•Do not use the instrument if theceramic surface is damaged, i. e. if it has, for example,
scratches, rust or splinters.
•Non-observance of the safety notes can cause damage to the device and injuries to
the user.
We do not assume liability for printing errors or any other mistakes in this manual.
We expressly point to our general guarantee terms which can be found in our general terms of
business.
If you have any questions please contact PCE Instruments. The contact details can be found at
the end of this manual.

© PCE Instruments
3
2 Technical specifications
Specification
Explanation
Drive of the stirring point
Brushless motor
Stirring volume
1 ... 10 l
Adjustable speed
60 ... 2200 rpm
Heating range
(ambient temperature + 5 °C / 9 °F) ... 400 °C / 752 °F
Stirring surface
180 x 140 mm / 7.1 x 5.5 in
Timer
0 ... 9999 minutes
Material stirring plate
Ceramics
Heat output
max. 500 W
Stirring output
40 W
Power supply
220 V / 50 Hz
Dimensions
195 x 255 x 155 mm / 7.7 x 10 x 6.1 in
Weight
4.45 kg / 9.8 lbs
3 Delivery scope
1 x magnetic stirrer PCE-MSR 340
1 x device connection cable
1 x temperature sensor
1 x holder
1 x instruction manual
4 Preparation
•Keep the original packaging in case the magnetic stirrer needs to be returned to us.
•Carefully remove the appliance from the packaging and place it on a firm, level
surface. This should be non-slip and not prone to vibration. All four feet should stand
firmly on the surface. The supplied accessories should also be carefully unpacked
and removed.
•The ambient temperature should ideally be 25 °C and direct sunlight should be
avoided.
•Keep a distance of at least 20 cm from other objects all around to ensure optimum
cooling efficiency.
•Keep the instrument away from heated solutions to avoid effects on the sample
temperature.
•Do not place the magnetic stirrer in places that are difficult to access.
•Screw the support rod as far as it will go into the thread provided on the back of the
unit.
•Attach the sensor holder to the support rod using the cross clamp.
•Connect the power cable to the socket on the back of the unit and to your power
supply.
•Make sure that the input voltage is correct.
•Align the sensor holder so that the tip of the temperature sensor is immersed at least
30 mm deep in your stirring medium. Then connect the temperature sensor to the
green socket on the back of the instrument.

© PCE Instruments
4
5 Operation
5.1 Power on
Switch on the magnetic stirrer via the main switch which is located at the back of the device, on
the left-hand side.
Attention!
The stirring platform heats up when the temperature sensor is inserted and the temperature is
set.
5.2 Start / stop stirring process
Press the Start / Stop key to start or stop the stirring process.
The Start / Stop key has no effect on the heating function.
5.3 Temperature adjustment
Temperature range (ambient temperature + 5 °C / 9 °F) ... 400 °C / 752 °F
The temperature can be set by using the lower row of keys on the control panel.
The lower display shows you the temperature currently measured with the temperature sensor in
°C.
Set the temperature of the stirring medium with the Up, Down and <AT keys.
Up key
Each time you press the key, the temperature increases by 0.1 °C.
Down key
Each time you press the key, the temperature is reduced by 0.1°C.
Press and hold the Up or Down keys to increase or decrease the temperature setting more
quickly.
<AT key
This function allows you to change the individual digits of the temperature setting.
Press and hold the <AT key until "AT" appears on the temperature display alternately with the
temperature display.
You can change the decimal place with the Up or Down keys.
After another brief press of the <AT key, you can change the units digit.
After another short press on <AT, the tens digit can be changed.
After another short press on <AT the hundreds digit can be changed.
The SET key is intended for maintenance purposes only and has no function innormal operation.
LED indications
ALM upper LED red
The temperature of the stirring medium is at least 2 °C above the temperature specified.
OFF middle LED red
The stirring platform has reached the specified temperature.
OUT lower LED green
Stirring platform heats up.

© PCE Instruments
5
Attention! Warning!
Always reset the temperature setting to 000.0 °C after completion of the stirring process.
The temperature sensor is also used as a reference sensor for temperature control of the
stirring platform.
If the temperature sensor is not in the stirring medium on the stirring platform when the
magnetic stirrer is switched on and the temperature measured by the temperature sensor
is below the specified temperature, the stirring platform is directly heated up to the
maximum temperature. !!Danger of burns!!
5.4 RPM setting
Speed range 60 ... 2200 rpm
You can set the speed with the upper row of keys on the control panel.
The upper display shows you the current speed in revolutions per minute.
You can change the speed with the Up and Down keys.
By pressing one of the two keys, the display changes from the current speed to the set speed.
Pressing and holding the Up or Down key makes the speed setting increase or decrease more
quickly.
5.5 Stirring time setting
Timer setting 1 ... 9999 minutes or continuous operation
The stirring time can be set via the middle row of keys on the control panel.
The central display shows you the currently remaining stirring time.
Use the Up and Down keys to change the stirring time in minute steps.
When you press one of the two keys, the display changes from the remaining stirring time to the
set stirring time.
Press and hold the Up or Down key to increase or decrease the stirring time setting more quickly.
After the specified stirring time has elapsed, the stirring process is finished.
Continuous operation isset by choosing 0000 as stirring time. Thestirring processmust be started
and ended with the Start / Stop key.

© PCE Instruments
6
6 Warranty
You can read our warranty terms in our General Business Terms which you can find here:
https://www.pce-instruments.com/english/terms.
7 Disposal
For the disposal of batteries in the EU, the 2006/66/EC directive of the European Parliament
applies. Due to the contained pollutants, batteries must not be disposed of as household waste.
They must be given to collection points designed for that purpose.
In order to comply with the EU directive 2012/19/EU we take our devices back. We either re-use
them or give them to a recycling company which disposes of the devices in line with law.
For countries outside the EU, batteries and devices should be disposed of in accordance with
your local waste regulations.
If you have any questions, please contact PCE Instruments.

© PCE Instruments
7
PCE Instruments contact information
Germany France Spain
PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L.
Im Langel 4 23, rue de Strasbourg Calle Mayor, 53
D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete)
Deutschland France España
Tel.: [phone] Téléphone: [phone] Tel. : [phone]
Fax: [phone] Numéro de fax: [phone] Fax: [phone]
[email protected] [email protected] [email protected]
www.pce-instruments.com/deutsch www.pce-instruments.com/french www.pce-instruments.com/espanol
United Kingdom Italy Turkey
PCE Instruments UK Ltd PCE Italia s.r.l. PCE Teknik Cihazları Ltd.Şti.
Unit 11 Southpoint Business Park Via Pesciatina 878 / B-Interno 6 Halkalı Merkez Mah.
Ensign Way, Southampton 55010 Loc. Gragnano Pehlivan Sok. No.6/C
Hampshire Capannori (Lucca) 34303 Küçükçekmece - İstanbul
United Kingdom, SO31 4RF Italia Türkiye
Tel: [phone] Telefono: [phone] Tel: [phone]
Fax: [phone] Fax: [phone] Faks: 0212 705 53 93
[email protected] [e-mail] in[email protected]
www.pce-instruments.com/english www.pce-instruments.com/italiano www.pce-instruments.com/turkish
The Netherlands China Hong Kong
PCE Brookhuis B.V. PCE (Beijing) Technology Co., Limited PCE Instruments HK Ltd.
Institutenweg 15 1519 Room, 6 Building Unit J, 21/F., COS Centre
7521 PH Enschede Zhong Ang Times Plaza 56 Tsun Yip Street
Nederland No. 9 Mentougou Road, Tou Gou District Kwun Tong
Telefoon: [phone] 102300 Beijing, China Kowloon, Hong Kong
[email protected] Tel: [phone] Tel: [phone]
www.pce-instruments.com/dutch [email protected] [email protected]
www.pce-instruments.cn www.pce-instruments.cn
United States of America
PCE Americas Inc.
1201 Jupiter Park Drive, Suite 8
Jupiter / Palm Beach
33458 FL
USA
Tel: [phone]
Fax: [phone]
[email protected]
www.pce-instruments.com/us
