PCE Instruments PCE-TT 4 User manual

© PCE Instruments
PCE-TT 4 Digital Multimeter
User Manual
User manuals in various languages (français,
italiano, español, português, nederlands, türk, polski,
русский, 中文) can be found by using our
product search on: www.pce-instruments.com
Last change: 16 July 2020
v1.0
English

© PCE Instruments
Contents
1Safety notes........................................................................................... 1
2Delivery contents ..................................................................................2
3Technical specifications ...................................................................... 2
4Device description ................................................................................3
4.1 Keyboard description........................................................................................................ 4
4.2 Display description........................................................................................................... 4
5Switching on / switching off ................................................................ 5
6Hold function.........................................................................................5
7Backlight................................................................................................5
8Toggle subfunctions.............................................................................5
9Measurement.........................................................................................5
9.1 Voltage measurement...................................................................................................... 5
9.2 Current measurement ...................................................................................................... 6
9.3 Resistance measurement, diode test, continuity test, capacitance measurement............. 6
9.4 NCV measurement........................................................................................................... 8
9.5 Temperature measurement.............................................................................................. 8
9.6 Phase recognition ............................................................................................................ 9
10 Battery replacement.............................................................................. 9
11 Warranty.................................................................................................9
12 Disposal ................................................................................................. 9

© PCE Instruments
1
1 Safety notes
Please read this manual carefully and completely before you use the device for the first time. The
device may only be used by qualified personnel and repaired by PCE Instruments personnel.
Damage or injuries caused by non-observance of the manual are excluded from our liability and
not covered by our warranty.
•The device must only be used as described inthis instruction manual.If used otherwise,
this can cause dangerous situations for the user and damage to the meter.
•The instrument may only be used if the environmental conditions (temperature, relative
humidity, …) are within the ranges stated in the technical specifications. Do not expose
the device to extreme temperatures, direct sunlight, extreme humidity or moisture.
•Do not expose the device to shocks or strong vibrations.
•The case should only be opened by qualified PCE Instruments personnel.
•Never use the instrument when your hands are wet.
•You must not make any technical changes to the device.
•The appliance should only be cleaned with a damp cloth. Use only pH-neutral cleaner,
no abrasives or solvents.
•The device must only be used with accessories from PCE Instruments or equivalent.
•Before each use, inspect the case for visible damage. If any damage is visible, do not
use the device.
•Do not use the instrument in explosive atmospheres.
•The measurement range as stated in the specifications must not be exceeded under
any circumstances.
•Non-observance of the safety notes can cause damage to the device and injuries to
the user.
•Never touch live components when measuring. There is danger to life.
•Never touch the bare measuring tips as this may result in electric shock.
•Before each measurement, make sure that the correct measurement range is set and
that the test leads are connected correctly.
•Resistance, capacitance and temperature measurements as well as diode tests may
only be carried out in a voltage-free state.
•Before replacing the batteries or the fuses, all test leads must be removed from the
measuring instrument.
We do not assume liability for printing errors or any other mistakes in this manual.
We expressly point to our general guarantee terms which can be found in our general terms of
business.
If you have any questions please contact PCE Instruments. The contact details can be found at
the end of this manual.

© PCE Instruments
2
2 Delivery contents
1 x digital multimeter PCE-TT 4
1 x pair of test leads
1 x K-type thermocouple
1 x transport bag
2 x 1.5 V AAA battery
1 x user manual
3 Technical specifications
Measurement
function
Measurement
range
Resolution
Accuracy
Voltage
measurement
DC
6 V
1 mV
±(0.5 % ±3 dgt.)
60 V
10 mV
±(0.5 % ±3 dgt.)
600 V
100 mV
±(0.5 % ±3 dgt.)
1000 V
1 V
±(0.5 % ±3 dgt.)
Input resistance: 10 MΩ
Maximum input voltage: 1000 V DC, 750 V AC RMS
Voltage
measurement AC
6 V
1 mV
±(0.8 % ±3 dgt.)
60 V
10 mV
±(0.8 % ±3 dgt.)
600 V
100 mV
±(0.8 % ±10 dgt.)
1000 V
1 V
±(0.8 % ±10 dgt.)
Input resistance: 10 MΩ
Maximum input voltage: 1000 V DC, 750 V AC RMS
True RMS frequency range: 45 ... 1000 Hz
Resistance
600 Ω
0,1 Ω
±(0.8 % ±3 dgt.)
6 kΩ
1 Ω
±(0.8 % ±3 dgt.)
60 kΩ
10 Ω
±(0.8 % ±3 dgt.)
600 kΩ
100 Ω
±(0.8 % ±3 dgt.)
6 MΩ
1 kΩ
±(0.8 % ±3 dgt.)
60 MΩ
10 kΩ
±(1.2 % ±30 dgt.)
Overvoltage protection: 600 V AC/DC
Diodes
0 ... 3.3 V
0.001 V
Shows the diode
forward voltage
Overvoltage protection: 600 V AC/DC
Continuity check
50 Ω
0.1 Ω
Signal tone at <50 Ω
Overvoltage protection: 600 V AC/DC
Capacity
6 nF
0.001 nF
±(4 % ±10 dgt.)
60 nF
0.01 nF
±(4 % ±5 dgt.)
600 nF
0.1 nF
±(4 % ±5 dgt.)
6 µF
1 nF
±(4 % ±5 dgt.)
60 µF
10 nF
±(4 % ±5 dgt.)
600 µF
100 nF
±(4 % ±5 dgt.)
6 mF
1 µF
±(4 % ±5 dgt.)
Overvoltage protection: 600 V AC/DC
Current
measurement DC
60 mA
0.01 mA
±(0.8 % ±3 dgt.)
200 mA
0.1 mA
±(0.8 % ±3 dgt.)
Maximum input current: 200 mA AC/DC RMS

© PCE Instruments
3
Current
measurement AC
60 mA
0.01 mA
±(1 % ±3 dgt.)
200 mA
0.1 mA
±(1 % ±3 dgt.)
Maximum input current: 200 mA AC/DC RMS
Current measurement in a frequency range between 40 ... 1 kHz True RMS
Temperature
measurement
-20 ... 500 °C
1 °C
±(2 % ±2 dgt.)
-4 ... 932 °F
2 °F
±(2 % ±2 dgt.)
Overvoltage protection: 600 V AC/DC
Further specifications
Power supply
2 x 1.5 V AA battery
Operating conditions
0 … 40 °C
Storage conditions
-10 ... 50°C, <75 % RH
Dimensions
140 x 50 x 30 mm
Weight
approx. 119 g
4 Device description
No.
Description
1
NCV sensor
2
Signal lamp lights up as soon as the NCV sensor detects a voltage
3
Display
4
Keyboard
5
Rotary measuring switch
6
Connections for test leads
7.1
Test lead holder - first possibility
7.2
Test lead holder - second possibility

© PCE Instruments
4
4.1 Keyboard description
SEL
Switch measurement function
Hold /
Hold function (freeze measured value), switch on backlight
Hz
Activate frequency measurement for ACV and AC mA
V / Alert
Switch between measurement function and NCV measurement
4.2 Display description
Symbol
Description
Automatic power-off is active
Battery discharged
Danger of electric shock
AC voltage
DC voltage
Continuity test function
Diode test function
Hold function - the measured value has been frozen
NCV
"Not Connected Voltage" measuring function for checking an applied
voltage
mV，V
Voltage units
μA，mA，A
Current units
Ω，KΩ，MΩ
Resistance units
Hz，kHz
Frequency units
F, μF, nF
Farat units
°C, °F
Temperature units

© PCE Instruments
5
5 Switching on / switching off
To turn on the meter, turn the rotary measuring switch to the desired measuring function. To turn
off the meter, turn the rotary measuring switch back to "OFF". After switching on, the following
functions are available for the individual measuring functions:
6 Hold function
With the Hold function, you can freeze the displayed reading by pressing and releasing the "Hold"
key once. Pressing it again resumes the measurement.
7 Backlight
To turn the backlight on and off, press and hold the key for two seconds.
8 Toggle subfunctions
After you have set your desired measuring function, you can also set a sub-function. To do this,
press the "SEL" key until you get the desired function.
9 Measurement
The meter has different electronic measuring methods. These can be used as follows.
9.1 Voltage measurement
To perform a voltage measurement, first set the rotary measuring switch to . Then connect the
test leads to the meter. Use the "SEL" key to select DC or AC voltage. Now touch your sample
with the test tips. The measured value will then be displayed.
Note: With the smaller measurement ranges, a measured value can be displayed even if the
measuring cable is not connected. This is due to the sensitivity of the measuring instrument. As
soon as the measuring instrument is connected to the test sample, the correct measured value
is displayed.

© PCE Instruments
6
9.1.1 Frequency measurement with a parallel connection
To make a frequency measurement with the current parallel connection now, press the "Hz" key.
The current reading is displayed directly. Thisfunction is only availableif thecurrent measurement
is set to alternating current. To return to the original measuring mode, press the "Hz" key again.
9.2 Current measurement
To make a current measurement, first turn the rotary measuring switch to .
Then plug the test leads into the meter. Use the "SEL" key to select DC or AC voltage. Now touch
your sample with the test tips. The measured value will then be displayed.
9.2.1 Frequency measurement with a series connection
To make a frequency measurement with the current series connection now, press the "Hz" key.
The current measured value is displayed directly. This function is only available if the current
measurement is set to alternating current. To return to the original measuring mode, press the
"Hz" key again.
9.3 Resistance measurement, diode test, continuity test, capacitance measurement
To perform a resistance measurement, diode test, continuity test or capacitance measurement,
set the rotary measuring switch to . Then plug the test leads into the meter. Now select the
appropriate measurement function with the "SEL" key. Then connect the test lead to your test
object to perform a measurement. The measured value is shown directly on the display.
The following measurement ranges are available for the resistance measurement: 600 Ω, 6 Ω,
60 Ω, 600 kΩ, 6 Ω, 60 MΩ

© PCE Instruments
7
For the diode test, the falling voltage at the diode is indicated. Please pay attention to the
polarity.
When measuring larger capacitors, it may take some time to charge the capacitor to determine
its capacity. Pay attention to the polarity when measuring. After a measurement, the measured
capacitors are charged. There is a risk of electric shock.
During the continuity test, an acoustic signal is triggered as soon as the measured resistance is
<50 Ω.

© PCE Instruments
8
9.4 NCV measurement
With the NCV "Not Connected Voltage" measurement, you can measure inductively whether a
voltage is present on a line. This function is always active in addition to all other measuring
functions as soon as the measuring instrument is switched on. To do this, target the conductor to
be measured with the sensor. The meter will emit an acoustic as well as a visual pulse signal.
The interval changes depending on the intensity.
Via the "V / Alert" key, the intensity is additionally indicated on the display by means of lines.
Press this key again to return to normal measuring mode.
Note: Even if no voltage is signalled, voltage may still be present on a line. This function can also
issue a warning when measuring current or voltage directly. Motors or flashlights can also be the
reason why something is displayed.
9.5 Temperature measurement
In order to carry out a temperature measurement, turn the rotary measuring switch to " ". Now
connect a K-type thermocouple. The current measured value is displayed directly. To select one
of the units degrees Fahrenheit or degrees Celsius, press the "SEL" key.

© PCE Instruments
9
9.6 Phase recognition
With this meter, it is possible to distinguish the N conductor from the L conductor. To do this, set
the rotary measuring switch to "Live". Then plug a test lead into the "Input" connection. Now carry
out measurements with the measuring tip. As soon as you have found the L-wire, the display
shows "LIVE".
10 Battery replacement
As soon as the battery symbol appears, the batteries must be replaced to ensure proper function.
To replace the batteries, first remove all test leads from the meter. Then turn off the meter. Now
open the battery compartment. Now can you replace the batteries. After you have replaced the
batteries and closed the battery compartment, you can use the meter again.
11 Warranty
You can read our warranty terms in our General Business Terms which you can find here:
https://www.pce-instruments.com/english/terms.
12 Disposal
For the disposal of batteries in the EU, the 2006/66/EC directive of the European Parliament
applies. Due to the contained pollutants, batteries must not be disposed of as household waste.
They must be given to collection points designed for that purpose.
In order to comply with the EU directive 2012/19/EU we take our devices back. We either re-use
them or give them to a recycling company which disposes of the devices in line with law.
For countries outside the EU, batteries and devices should be disposed of in accordance with
your local waste regulations.
If you have any questions, please contact PCE Instruments.

© PCE Instruments
10
PCE Instruments contact information
Germany France Spain
PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L.
Im Langel 4 23, rue de Strasbourg Calle Mayor, 53
D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete)
Deutschland France España
Tel.: [phone] Téléphone: [phone] Tel. : [phone]
Fax: [phone] Numéro de fax: [phone] Fax: [phone]
[email protected] [email protected] [email protected]
www.pce-instruments.com/deutsch www.pce-instruments.com/french www.pce-instruments.com/espanol
United Kingdom Italy Turkey
PCE Instruments UK Ltd PCE Italia s.r.l. PCE Teknik Cihazları Ltd.Şti.
Unit 11 Southpoint Business Park Via Pesciatina 878 / B-Interno 6 Halkalı Merkez Mah.
Ensign Way, Southampton 55010 Loc. Gragnano Pehlivan Sok. No.6/C
Hampshire Capannori (Lucca) 34303 Küçükçekmece - İstanbul
United Kingdom, SO31 4RF Italia Türkiye
Tel: [phone] Telefono: [phone] Tel: [phone]
Fax: [phone] Fax: [phone] Faks: 0212 705 53 93
[email protected] [e-mail] in[email protected]
www.pce-instruments.com/english www.pce-instruments.com/italiano www.pce-instruments.com/turkish
The Netherlands China Hong Kong
PCE Brookhuis B.V. PCE (Beijing) Technology Co., Limited PCE Instruments HK Ltd.
Institutenweg 15 1519 Room, 6 Building Unit J, 21/F., COS Centre
7521 PH Enschede Zhong Ang Times Plaza 56 Tsun Yip Street
Nederland No. 9 Mentougou Road, Tou Gou District Kwun Tong
Telefoon: [phone] 102300 Beijing, China Kowloon, Hong Kong
[email protected] Tel: [phone] Tel: [phone]
www.pce-instruments.com/dutch [email protected] [email protected]
www.pce-instruments.cn www.pce-instruments.cn
United States of America
PCE Americas Inc.
711 Commerce Way suite 8
Jupiter / Palm Beach
33458 FL
USA
Tel: [phone]
Fax: [phone]
[email protected]
www.pce-instruments.com/us
