PCE Instruments PCE-LSZ Series User manual

Manual
Laboratory Balances
PCE-LSZ
PCE Americas Inc.
711 Commerce Way
Suite 8
Jupiter
FL-33458
USA
From outside US: +1
Tel: [phone]
Fax: [phone]
[email protected]
www.pce-instruments.com/english
www.pce-instruments.com
PCE Instruments UK Ltd.
Units 12/13
Southpoint Business Park
Ensign way
Hampshire / Southampton
United Kingdom, SO31 4RF
From outside UK: +44
Tel: [phone]
Fax: [phone]
[email protected]

2
Contents:
1. General description................................................................................................3
2. Completeness........................................................................................................3
3. Balance description................................................................................................4
4. Keys and indicators................................................................................................6
5. Technical data........................................................................................................7
6. Security rules .........................................................................................................8
7. Environment protection ..........................................................................................8
8. Working environment .............................................................................................9
9. Preparation – the balance....................................................................................10
10. General rules........................................................................................................11
11. Testing and calibration.........................................................................................12
12. External calibration...............................................................................................12
13. Connecting the balance to a computer or a printer ..............................................13
14. Special functions description................................................................................14
15. Legend.................................................................................................................15
16. Normal weighing ..................................................................................................15
17. Weighing with tare................................................................................................15
18. Paperweight calculation (PAPEr) .........................................................................16
19. Serial port transmission parameters (F..-rS) ........................................................18
20. Maintenance and repairs of small defects............................................................19
Declaration of Conformity...........................................................................................20

3
1.General description
This type of scale PCE-LSZ...C is mainly used in paper production, tissue production,
paper laboratories, textile production companies as well as by material importing
companies ... and in laboratory practice. This scale it's perfect for sales departments
comparing the paper or fabric weight to the competition when visiting customers.
For periodical control of the balance the user should own weight standard of OIML E2
class (weight value stated in Technical Data sheet) – available separately.
All balances are metrologically tested - calibration on demand.
NACE classification: 33.20.31.
2.Completeness
A standard set consist of:
1. Balance
2. Pan elements:
-round pan balances (PCE-LSZ 100C - PCE-LSZ 600C): pan support and pan
-rectangular pan balances (PCE-LSZ 1000C - PCE-LSZ 4000C): pan supports
(4pcs.) and pan
3. Antiblast glass draft shield with lid (PCE-LSZ 100C - PCE-LSZ 500C),
4. Feeder ZN 12V/500mA,
5. User Manual,
6. Guarantee card.

4
3.Balance description
Front view (PCE-LSZ 100C - PCE-LSZ 600C)
1 – pan
2 – pan support
3 – pan ring
4 – LCD display
5 – keys
6 – rotating legs
7 – water level
8 – antiblast shield
Note:
PCE-LSZ 600C does
not have the pan ring
and the antiblast
shield.
Front view (PCE-LSZ 1000C - PCE-LSZ 4000C)
1 – pan
2 – pan supports
4 – LCD display
5 – keys
6 – rotating legs
7 – water level
7
6
1
2
4
5
7
6
1
2
4
3
5
8

5
Rear view:
ON OFF
Przełącznik
adjustacji
RxD (odbiór)
TxD (nadawanie)
masa
obudowa
RS232C
Zasilacz
Zasilacz Drukarka
lub komputer
1
2
3
4
5
6
7
8
9
~230V
Feeder Computer
or printer
Feeder Adjustation
switch
RxD ( receiver )
TxD
(
send
)
Mass
Housing

6
4. Keys and indicators
Basic functions:
→T←-tare (subtract package weight from weighed mass)
→0←-zeroing (balances for direct sale use only),
-data output (print / transmission),
-internal calibration,
Menu -Menu,
I/ -switch-on/switch-off (standby),
indicator -result stabilisation,
bar indicator -load indicator 0 ÷ 100%,
indicator OFF -stand-by mode,
Max, Min, d, e, I -metrologic parameters and accuracy class.
When entering numeric values use the keys as described below:
- change digit value
- decimal point,
→ T ← - move to the next position
MENU - end.
Max Min e d
II

7
5. Technical data
Type PCE-LSZ100C PCE-LSZ 200C PCE-LSZ 300C PCE-LSZ 500C
Capacity (Max) 100g 200g 300g 500g
Min load (Min) 0,02g 0,02g 0,02g 0,02g
Reading unit (d) 0,001g 0,001g 0,001g 0,001g
Verification unit (e) 0,01g 0,01g 0,01g 0,01g
Tare range -100g -200g -300g -500g
Accuracy class II
Working temperature +18 ÷+33°C
Weighing time
<5s
Pan dimension φ115mm
Balance base dim.
(including legs) 215(235)x345x90mm
Balance weight 5kg
Power ~230V 50Hz 9VA / =12V 300mA
Calibration weight
(OIML) F2 100g F2 200g F2 200g F1 500g
Type PCE-LSZ 600C PCE-LSZ 1000C
PCE-LSZ 2000C PCE-LSZ 3000C PCE-LSZ 4000C
Capacity (Max) 600g 1000g 2000g 3000g 4000
Min load (Min) 0,5g 0,5g 0,5g 0,5g 0,5g
Reading unit (d) 0,01g 0,01g 0,01g 0,01g 0,01g
Verification unit
(e) 0,1g 0,1g 0,1g 0,1g 0,1g
Tare range
-600g -1000g -2000g -3000g -4000g
A
ccuracy class
II
Working
temperature +18 ÷+33°C
Weighing time
<5s
Pan dimension
φ150mm 165x165mm
Balance base
dim.
(including legs)
215(235)x345x90mm
Balance weight 5kg
Power ~230V 50Hz 9VA / =12V 300mA
Calibration
weight (OIML)
F2 500g F2 1000g F2 2000g

6. Security rules
To avoid electrical shock or damage of the balance or
connected peripheral devices, it is necessary to follow the
security rules below.
•For power supply use only a socket with a ground contact.
•All repairs and necessary regulations can be made by authorised
personnel only.
•To avoid fire risk use a feeder of an appropriate type (supplied with the
balance). Pay attention that supply voltage is compatible with specified
technical data.
•Do not use the balance when its cover is opened.
•Do not use the balance in explosive conditions.
•Do not use the balance in high humidity.
•If the balance seems not to operate properly, unplug it from the mains and
do not use until checked by authorised service.
7. Environment protection
According to legal regulations it if forbidden to dispose
electronic equipment in waste containers.
(WEEE-Reg.-Nr. DE64249495).
•Please return wasted balance to the point of purchase or other company
specialised in recycling of wasted electronic components.

9
8.Working environment
+18°C
+33°C
When choosing a location to set up the balance, remember the following rules to
ensure proper working conditions and user-friendly operating:
-setup the balance on an even, flat surface leaving necessary room for easy access,
-maintain proper working temperature,
-avoid strong air drafts, vibrations, dust, big temperature changes and humidity over
90%,
-avoid locations with extreme heat radiation and electromagnetic or magnetic fields.

10
9.Preparation – the balance
1. Take the balance and all supplied accessories (a feeder, pan elements) out of the
box.
2. Place the balance on a stable ground not affected by mechanical vibrations and
airflows.
3. Level the balance with rotating rear legs 6 so that the air bubble in water level 7 at
the back of the balance is in the middle.
4. ( PCE-LSZ 100C - PCE-LSZ 600C only) Gently place the pan support 2 into the
socket in the balance mechanism through the pan ring 3 and put the pan 1 on the
pan support (PCE-LSZ 600C balances are equipped with a pan integrated with the
pan support).
5. ( PCE-LSZ 1000C - PCE-LSZ 4000C only) Place the pan supports 2 on the
mandrels at the corners of the casing. Place the pan 1 on the pan supports.
7
6
123
7
6
1
2

11
6. Plug a feeder to the power socket at the back of the balance.
7. Leave the pan empty and plug the feeder to the mains (230V). At the end of self-
tests, the balance displays zero indication and is now ready to work.
10.General rules
1. Weighed sample should be placed in the centre of the pan.
2. In balances with active → 0 ← key and with d=e, before placing a load on the pan
make sure that zero indicator is displayed. If not, press → 0 ← key and wait until
zero indication and zero indicator appears. In other balances the key does not
operate.
3. The balance is equipped with tare equal to its range. To tare the balance press
→ T ← key (left or right). Storing tare value does not extend measuring range, but
only subtracts it from a load placed on the pan. To make weight control easier and
to avoid range overdrawing, the balance is equipped with the load indicator
(graduated in percentages).
4. Weighing result should be read when the indicator " " lights, which signalises
stabilisation of a result.
5. When the balance is not used but it is necessary to be ready to work immediately, it
can be switched off by pressing I/key. The balance reading system is then
switched off to "standby" mode (signalled by the indicator "OFF"). To switch the
balance on press I/key. The balance is immediately ready to operate maximum
accuracy (after self tests).
6. The mechanism of the balance is a precise device, sensitive to mechanical strokes
and shocks.
7. The balance should not be used to weigh ferromagnetic materials due to accuracy
decrease.
Moisture in the air may condense on the surface of the balance when
transferred to the warmer environment. In this case leave the balance for at
least 4 hours unplugged from the mains for conditioning to avoid wrong
operating or damage of the balance.
Do not overload the balance more then 20% of maximum load
(Max). Do not press the pan with a hand.
Before transportation take off the pan (move it slightly and lift it up)
and the pan base and preserve from any damages.

12
11.Testing and calibration
To ensure reliable results it is advised to check balance accuracy with an object of
precisely known weight before and after each measuring session.
In case permissible error is exceeded calibrate the balance with an external weight
standard or contact an authorised service.
12.External calibration
Calibration with external weight standard should be performed in case balance
indications exceed permissible error. To calibrate the balance a service centre should
use calibration weight as stated in Technical Data table (or of better accuracy) with
valid calibration certificate.
Operation sequence:
Press key.
Press key several times to choose
calibration weight value.
To accept press → T ← button.
Wait until calibration process is finished.
When LOAD communicate put a calibration
weight on the pan and press → T ← key.
Wait until internal calibration is finished.
The display should indicate the weight
standard value.
T
0.000g
m
m
m
m
CAL
m
--------
LO AD
CC
1
2
...

13
13.Connecting the balance to a computer or a printer
The balance may send data to a computer or a printer through RS232C port.
When cooperating with the balance, a
computer should be equipped with a
program, which enables processing data from
the balance.
PCE Group offers computer programs
cooperating with balances. Demo versions
and program descriptions are available on
the website: .
There is also a freeware program for testing a
serial port of the balance.
We also offer:
•Computer wires
•Thermal printers
•Label printers
The balance sends weighing result after initialising signal from a computer or after
pressing key.
Data transmission protocol description (Long protocol)
Computer →Balance: initialising signal S I CR LF (53h, 49h, 0Dh, 0Ah)
Balance →Computer: balance indication in the following format (16 Bytes)
Byte 1 - sign or space
Byte 2, 11 and 14 - space
Byte 3÷4 - digit or space
Byte 5÷9 - digit, decimal point or space
Byte 10 - digit
Byte 12 - k, l, c, p or space
Byte 13 - g, b, t, c or %
Byte 15 - CR (0Dh)
Byte 16 - LF (0Ah)

14
It is possible to use transmission protocol other then LonG on customer’s demand,
e.g. Farb protocol used for cooperation with automatic paint mixer: continuous
transmission (Send option), transmission speed 2400bps, additional “+” sign in first
byte.
Connection cable WK-1 (balance – computer / 9-pin):
Connection cable WD-1 (balance - PCE-BP1 printer):
PCE-BP1 printer internal switches set-up:
SW-1 SW-2 SW-3 SW-4 SW-5 SW-6 SW-7 SW-8
on off on off off on off off
14.Special functions description
All balances, beside basic functions like weighing and tare, are equipped with the set
of additional functions: calibration, pieces counting, autozeroing and serial port
working mode setting. Other functions: recipe ingredients summing, density
calculation and other special functions can be enabled as an option on customer
request (described in additional brochure when ordered).
To display all available function, enter Function Menu with F key. Functions are
displayed with successive numbers: F1-LIC, F2-AUt, etc. When special functions are
displayed, “MODE” indicator is displayed.
To make clear how to manage with each function, in further part of instruction
descriptions are replaced with pictures.
Balance Com
p
ute
r
Balance Printer PCE-BP1

15
15. Legend
-press a key
-balance indication
-forced change
-automatic change
16.Normal weighing
When the pan is empty and indication
is different than zero press → T ←
key.
Note: In balances for direct trade
settlements (option) to zero a balance
use → 0 ← key. → T ← key operates
as Tare only when the pan is loaded.
Weighing result should be read when
the indicator " "lights.
17.Weighing with tare
The balance is equipped with tare
equal to its range.
123.4 g
0.0 g
123.4 g
12.3 g
0.0 g
123.4 g
T
T

16
18.Paperweight calculation (PAPEr)
The paper scale is a high precision / resolution device for the determination of the
basis weight (in relation to a square meter of materials). This is the most accurate way
to determine basis paper / tissue weight. The scale displays the basis weight of paper,
tissue, fabrics ... directly in g/m² with 0.1 g/m² (0.001 g) resolution. This function
enables to calculate paperweight of 1m2of paper basing on samples of known area.
Weighing in g/m ²
By the pressing of the key one changes for the conventionally weighing between
the paper balancing function in g/m ² and in [g]. The paper balancing mode [g/m ²] by
the indication ▲in the left display corner suggested without that the unit [g/m ²] at the
display is indicated.
Weighing in g
Switch with the help of the key from the paper balancing mode into the
conventional balancing mode in [g]. Present them the sample on the weighing platform
of the balance. The weight of the sample is indicated to the balance at the display.
19. Serial port transmission parameters (F..-rS)
The function enables to set the following
transmission parameters (standard
parameters underlined):
-transmission speed (bAud: 1200, 4800,
9600),
-the number of bits in a byte (bit: 7, 8),
-parity control (PArItY: 0, 1; Odd: 0, 1),
-Continuous transmission – without using
, key, approx. 10 results per second
(SEnd: 0, 1).
To set desired transmission parameters
activate “F.._rS” function, choose
appropriate parameter and press → T ← key
to accept needed parameter value. The
example at the left presents how to set
transmission speed value to 9600bps.
To leave the function, choose “out” option.
0.000g
F.. -rS
F.. -1
F.. -0
baud
-9600
-4800
bIt
out
Odd
PA r I t Y
Se n d
MENU
T
T
T
T
T
T
T
T
T

17
20. Maintenance and repairs of small defects
1. The balance should be kept clean.
2. Take care that no dirt gets between the casing and the pan. If found any, remove
the pan (lift it up), remove dirt and then replace the pan.
3. In case of improper operation caused by short-lasting power supply decay, unplug
the balance from the mains and then plug it again after few seconds.
4. To calibrate the balance contact nearest service.
5. It is forbidden to make any repairs by unauthorised persons.
6. To repair the balance, please contact our nearest service.
Error communicates:
Communicate Possible cause Remedy
C-1 ... 6
(over 1 min.) selftests failed if displayed more than 1 minute,
contact an authorised service
L pan missing put the pan on
mechanical damage contact an authorised service
H overloading remove the load from the pan
mechanical damage contact an authorised service
Err H the pan is not empty remove a load from the pan
unstable ground
vibrations
air flows
place the balance on a stable
ground not affected by mechanical
vibrations and airflows
indicator does
not appear balance damage contact an authorised service
------taring in progress as above

18
Declaration of Conformity
Konformitätserklärung
Declaration of conformity for apparatus with CE mark
Konformitätserklärung für Geräte mit CE-Zeichen
Déclaration de conformité pour appareils portant la marque CE
Declaración de conformidad para aparatos con disitintivo CE
Dichiarazione di coformitá per apparecchi contrassegnati con la marcatura CE
PCE-LSZ…C
1. EN 55022 standard Limits and methods of measurement of radio disturbance
characteristics of information technology equipment and IEC 61000-4-3
Electromagnetic compatibility (EMC) - Part 4-3: Testing and measurement
techniques - Radiated, radio-frequency, electromagnetic field immunity test
harmonized with the Council Directive 89/336/EEC (Electromagnetic compatibility
directive).
Additional information:
Conformity evaluation for the Council Directive 89/336/EEC was carried out
by Research Laboratory of Electrotechnology Institute.
