Peachtree Audio Deepblue User manual

I I Je
p2ac Ir 1r2 e ~J uc ~ o
Wireless Music System
User Manual
0

I
Congratulations
Congratulation on your purchase. For a better use of your new
device, we recommend you
to read carefully this user manual and
keep
it for record.
Package Content
• Main Unit x 1
• Remote control function
with battery type CR2025
(included) x 1
Features
• Detachable power cord x 1
• 3.Smm AUXIN cable x 1
• Instruction Manual x 1
•
3.5mm AUXIN jack to connect your MP3 player
• Bluetooth® enabled
to wirelessly play your music
• Full function remote control
Safety Precaution
Read, keep and follow these instructions.
Heed all warnings on the product and in th·e instruction manual.
For
your safety, read and follow this manual carefully to ensure
proper
use of the product and avoid any danger or physical damage.
•
Place the unit on aflat surface and ventilated condition. The ventilation
should
not be impeded by covering the ventilation openings with
items, such as newspapers, tablecloths, curtains, etc. to avoid
overheating and malfunction.
GB-1

• No naked flame sources, such
as
lighted candles, should
be
placed
on
the
apparatus.
•
Keep
the appliance away from rain and any moisture.
Do
not
place the
unit
in moist and humid conditions, which could lead
to
malfunction.
• When the
unit
is
suddenly moved from a cold environment
to
a
warm one,
if
moisture forms inside it,
it
may
not
operate properly.
To
correct this problem wait about one hour
for
the moisture
to
evaporate.
• The apparatus shall
not
be
exposed
to
dripping
or
splashing,
no objects filled
with
liquids, such
as
vases,
shall
be
placed on the
apparatus.
•
Do
not
expose the unit under direct sunlight
or
nearby objects
that
radiate heat
to
avoid damaging the unit.
• The apparatus should
be
used in moderate climate.
• The plug
of
the appliance shall remain readily operable.
•
Do
not
pull on the connection cord,
but
rather on the plug,
to
separate
the
appliance from
the
mains.
• The
On
I
Off button does
not
completely isolate the product from
the power supply.
To
disconnect the product from the mains
power supply, you must unplug the power cord.
• Pull
out
the
mains plug
if
the appliance
is
not
to
be
used over a
longer period
of
time.
• Disconnect
the
main plug during thunderstorms.
Servicing-
Do
not
attempt
to
service this product yourself
as
opening
or removing covers may expose you
to
dangerous voltage. Refer all
servicing
to
qualified service personnel.
Damage Requiring Service- Unplug this product from the wall
outlet
and refer servicing
to
qualified service personnel under the following
conditions:
• When the power-supply cord
or
plug
is
damaged.
•
If
liquid
has
been spilled,
or
objects have fallen into the product.
If
the
product
has
been exposed
to
rain
or
water.
GB-2

•
If
the
product does
not
operate normally by following the
operating instructions. Adjust only those controls
that
are covered
by the operating instructions
as
improper adjustment may result
in damage and will often require extensive
work
by a qualified
technician
to
restore the product
to
its normal operation.
•
If
the product
has
been dropped
or
damaged in any
way.
WARNINGS
• Batteries are
to
be
inserted
with
the
correct polarity.
• Never
use
batteries
that
show signs
of
electrolyte leaks
or
cracking.
• Never dispose
of
used batteries in
an
open fire, risk
of
explosion.
•
Keep
batteries
out
of
reach
of
children.
• Never short circuit battery terminals.
• Exhausted batteries are
to
be
removed from the product.
• Remove batteries from the appliance before disposing
of
it
at the
end
of
its service life,
or
during long periods
of
non-use.
•
Do
not
try
to
open the batteries.
• Batteries (battery pack
or
batteries installed) shall
not
be
exposed
to
excessive heat
such
as
sunshine, fire
or
the like.
• Ensure
the
battery compartment panel
is
secure.
• Danger
of
explosion
if
battery
is
incorrectly replaced.
• Replace only
with
the same
or
equivalent type.
•
Do
not
charge non-rechargeable batteries.
IMPORTANT
• When replacing used batteries, please comply
with
applicable
regulation relating
to
their
disposal.
•
Please
return them
to
a suitable collection facility
for
environmentally friendly disposal.
GB-3

The lightning flash WARNING:
TO
symbol
within
an
REDUCE
THE
RISK
OF
equilateral triangle
is
ELECTRIC
SHOCK
DO
intended
to
alert
the
NOT
REMOVE
COVER
user
to
the
presence
(OR
BACK),
NO
USER
of
un-insulated
SERVICEABLE
PARTS
"dangerous voltage"
within
the
product's
enclosure
that
may
be
of
sufficient
magnitude
to
constitute a risk
of
electric shock
to
persons.
0
For
indoor
use only.
INSIDE
REFER
SERVICING
TO
QUALIFIED
SERVICE
PERSONNEL.
The exclamation
point
within
an
equilateral triangle
is
intended
to
alert
the
user
to
the
presence
of
important
operating and
maintenance
(servicing)
instructions in
the
literature
accompanying
the
appliance.
@]This
is
CLASS
II
apparatus
with
double insulation, and no protective
earth provided.
Technical Specifications
• Power supply:
AC
100-240V,
50/60Hz
• Battery
for
remote control (provided) :
3V
=
(1
x
CR2025)
• Power consumption:
140W
•
Output
power:
200W
max.
• Standby mode consumption:
0.45W
• Bluetooth®effective distance: 10 meters open air
• AUXIN jack:
3.5mm
• Bluetooth version: V2.1
+EDR
GB-4

Installation and Maintenance
TOP
PANEL
1--71"------~
2-~._...,__..
____
•
·---~+----3
FRONT
PA
4
REAR
PAN
6
7
NEL
EL
@ ®
®
®
®
===
@
===
===
===
===
===
===
===
===
===
===
===
===
===
©
===
===
V"""''
===
===
===
===
a
@)
~
1.
<!>Power
I
Pairing/Function
2.
-1):1
(Volume down)
3.
a::J+
(Volume up)
00
5
I
® ® @
@)
===
®
D
=~~
==c::::;;;a
=<=2:::)~
=c;;;;:ll;)c:;:z;;;ll
=c:::IO=
=CZ)~
=CZ)~
=c:::;lC;)~
=c:::IO~
=c:::IO~
=
&:::10
~
=c;;;;:ll;)~
=c:::l:)~
=<=2:::)~
=c:::;lC;)~
=c:::IOc::::>
=c:::IOc:::::>
=CZ)~
=c;;;;:ll;)~
J&-~J
=<=2:::)~
----=--
®
@)
4.
AUX
(Green)"
I Bluetooth® (Blue) I
Standby(R~d)
indicator
5. Remote sensor
6. AUX
IN
jack
7.
AC
Socket
GB-5

REMOTE CONTROL
8.
(!)Power
8
14
9. Bluetooth®switch
10.
~ Mute
9 15 11.
~ Previous
10
16
12. Bass+
11
17
13. Bass-
12
18
14. PAIRING
15. AUX switch
13
19 16
. .,.II Play/Pause
17.
~Next
peachtree audio
18. VOL+ (Volume up)
19. VOL- (Volume
down)
REMOTE CONTROL BATTERY
•
1. Slide and hold the battery release tab in the direction of the arrow.
2. Pull out the battery holder and remove the old battery.
3. Replace with a new battery (CR2025).
4. Insert the battery holder back into the remote control.
GB-6

Operation
To power the player ON:
1. Plug ACcord into AC jack, and plug hto a live AC wall outlet.
2. Press the [<!>PowerI Pairing/ Function] button on the top panel
or the [ <!> Power] button on the remote control to switch the
player to ON mode.
3. Press and hold the[<!>PowerI Pairing/ Function] button on the
top panel for 1 to 5 seconds or press the [<!>Power] button on the
remote control
to switch the player to Standby mode.
Note:
To save power, the player will switch to economic standby mode
when the speaker
is idle for 12 hours.
Using Bluetooth®Function: Paring Your Device
Before your start:
Your Bluetooth device (cellphon
e, MP3 payer, computer, etc.)
must support the
A2DP Bluetooth®profile (Commonly known as
stereo audio profile) to work with the player. Many of the latest
mobile phones and
PCs with built-in Bluetooth®functionality will
support this profile.
For accurate information about your product,
please refer
to your Bluetooth®device's user manual for details on
the Bluetooth®profiles
it s.upports and on how to set the device5
Bluetooth pairing /searching /setup mode.
Pairing
your Bluetooth®device with the player
1. Press and hold the[<!>PowerI Pairing/ Function] button on the
top panel for 5 seconds or the [PAIRING] button on the remote
control
for 2 seconds at ON mode until blue light flashes slowly to
begin pairing operation.
Please Note: Maximum broadcast distance for Bluetooth in open
space
is typically 33 feet. Walls and other obstructions may reduce
this distance significantly
GB-7

LED
Status:
1 Flashing
quickly-
No device paired
1
Flashing
Slowly-
Device pairing
1
Steady
ON-
Device paired
*Once the device
is
paired the blue light will turn
off
after 15 seconds
2.
Activate
Bluetooth®on
your
device
according
to
the
device's
user
manual
to
link
to
the
player. Typically, Bluetooth®controls are
found on
the
device's tools
or
settings menu. Turn on Bluetooth®
connectivity and make you device "discoverable".
3.
Search
the
device name "Peachtree BT" on your Bluetooth®device
listed and select
it
as
your audio speaker.
4. Once paired
with
a device,
the
Blue light will stop flashing and
glow steadily. A beep sound will also indicate
that
the connection
is
established.
5.
Pairing remains intact even when the player
or
the Bluetooth®
device
is
powered
off
or
is
taken
out
of
link range. The player will
auto link
with
the last linked device when
that
device
is
in range.
Note: Connecting
to
a Bluetooth®device may take up
to
5 minutes.
If
the
pairing
is
unsuccessful, re-pair your Bluetooth® device
with
the
player and repeat the above steps.
Pairing
your
other
Bluetooth® device
Previously Paired Devices:
To
restart the current connection from player
for
select
the
other
Bluetooth® cevice, press and hold the [·<!>Power
I
Pairing/
Function]
button on
the
top
panel
for
5 seconds
or
the [PAIRING] button on
the remote control
for
2 seconds and repeat the above steps
for
pairing your
other
Bluetooth®.
GB-8

Phone Calls During Bluetooth®Connection
1. If you are using a smartphone as your source the audio playing will be
interrupted when there is an incoming call or when the user makes
a call.
2. The audio will continue to play where it stopped once the call is
finished.
Playing Bluetooth® Music
1. Once your device and the player are linked you can start to play
Bluetooth®music through the player.
2. Turn on the player and press the [<!>PowerI Pairing/ Function]
button on the top panel or the [Biuetooth®] button on the remote
control
to select the Bluetooth®mode, Blue light indicates for
Bluetooth®mode.
3. Press the [_...II] button on the remote control to play your
Bluetooth®-enable device.
NOTE: Depending on the Bluetooth® device you are using, you may
need
to manually go into media player mode on your device to control
all the functions.
4. Press the [ ~] button on the remote control to skip the next track.
5. Press the [ ~] button on the remote control to skip back to
the beginning of the track currently play. Press the button again
immediately
to skip the previous track.
6. Press the [_...II] button on the remote control again to pause play;
Press again to resume it.
7. Press the [-CD/ E(J+] button on the top panel or [-CD/ ECI+ 1on
remote control
to adjust the system volume.
Note:
Please remember to turn off Bluetooth® device manually.
GB-9

Line in connection
1. Connect a sound source with a Line or headphone analogue output
to play through your player as below hookup diagram shown.
2. Press the [<!>PowerI Pairing/Function] button on the top panel
or press the [AUX] button on the remote control to select the
AUX mode. Green light indicates AUX Mode also.
3. Set your personal audio playerI computer to PLAY.
Headphone socket @ @ @ I @ @ @
3.5mm jack cable @
~55
® D
@)
~~~,1
@
===
c::::::::) c::::::::l c::::;;;J;
===
~~a:::::a:::)~
(included)
§§§
§:55~1
=== gg~~l
===
===
§~~~
===
===
=(:::::1:::3=!
========-:::::::::- '------
===
2~21
===
...--.. ~=----
--1@
§~~~
~~=~
·~
=c::::;E;>=I
§~§
§:55~
===
2~21
===
===
i;~,-h\:1
c:::::::) c:z::::) c:::::.}
@
~
@
1w ••• ill
@
~
1-~--.::.. @)
""~~~"'
• iPhone /iPad/iPod models
• MP3 players
•
CD walkman players
• Tape walkman players
• Personal computers
or laptops
Note: Due to the different audio sources, the input level may vary
at maximum volume
output level. Therefore, if the unit randomly
stops playing
the music or becomes distorted, move the volume level
to minimum and wait for a while. The user can try to move up the
volume level again and the unit will play at normal operation again.
GB-10

Iraubladaa'tiol
,
',
~'0;~,::;_,'
14'~
'
,;
p ,
,:,,,",JJ&,\\~,
,:,k\
ti~J;',;:"'"
',
,,
';'~,
,/~#L!rtJt>;L\'·zf
,,,£"'
,"
'
»,
,:,;ik(G~~>,;ftlv~
' , ,'
Ensure
that
the
Power Switch
of
wall socket
is
There
is
no
power
physically set
to
the
ON
position.
to
the
player Ensure
that
the
AC
plug
is
securely
connected
to
the
player and
proper
wall
outlet.
Trouble
pairing
deviceI
computer
with
the
player
Make sure you have
the
latest
firmware
for
your
iPhon
e®
/iPad®/iPod®.
Make sure
your
device
is
working
properly.
Check
your
device's manual
for
details on
Bluetooth
pairing and lin king.
Make sure
your
device supports
the
A2DP
and
AVRCP
Bluetooth®profiles before
linking
/pairing.
The pi ayer defaults
to
the
last linked device,
so
a
new
device may
need
to
be linked by press and hold
the
[(!)Power
I Pairing/Function]
button
for
pairing
other
device.
iPod®,
iPhone®,
and
iPad®
are
trademarks ofApple
Inc.,
registered
in
the
U.S.
and
other
countries.
GB-11

Recycling
This product bears
the
selective sorting symbol
for
Waste electrical
and electronic equipment
{WEEE).
This
means
that
this·
product must
-
be
handled pursuant
to
European directive 2002/96/EC in
order
to
be
recycled or dismantled
to
minimize its impacton
the
environment. ·
User
has
the
choice
to
give his product
to
a competent recycling
organization
or
to
the
retailer when he buys a new electrical
or
electronic equipment. .
For
further information, please contact your local
or
regional authorities.
Net weight: 6.3kg
WARRANTY: 1 year parts and
labor.
Please contact Signal Path
International Service
at
704-391-9337
or
email
[email protected]
GB-12

Additional Information
This
equipment
has
been tested and found
to
comply
with
the
limitsfor .
a
Class
Bdigital device, pursuant
to
Part
15
of
the
FCC
rules. These limits
are
designed
to
provide reasonable protection against harmful interference
in a residential installation.This
equipment
generates,
uses,
and can
radiate radio
frequency
energy
and,
if
not
installed and used in
accordance
with
the
instructions, may cause harmful interference
to
radio communications. However, this
is
no guarantee
that
interference
will
not
occur in a particular installation.
If
this equipment does
cause
harmful interference
to
radio
or
television
reception, which
can
be
determined by turning the equipment
off
and
on,
the user
is
encouraged
to
try
to
correct the interference by one
or
more
of
the following measures:
• Reorient
or
relocate the receiving antenna;
• Increase the separation between the equipment and the receiver;
• Connect the equipment into
an
outlet
on a circuit different from
that
to
which the receiver
is
connected;
• Consult the dealer
or
an
experienced radio/TV technician
for
additional suggestions.
Any changes
or
modifications
not
expressly approved by the party
responsible
for
compliance could void the user's authority
to
operate
the equipment. Where shielded interface cables have been provided
with
the product
or
specified additional components
or
accessories
elsewhere defined
to
be
used
with
the installation
of
the product, they
must
be
used
in
order
to
ensure compliance
with
FCC
regulation.
This
Class
B digital apparatus complies
with
Canadian ICES-003.
Signal Path
I Peachtree Audio
2405 120th Avenue
NE
Bellevue,
WA
98005
704.391.9337
www.peachtreeaudio.com
Service: 704.391.9337
FCC
ID:
VWPKW-B25BT
The
Bluetooth• word mark
and
logos
are
registered
trademarks owned by Bluetooth
SIG,
Inc.,
and
any
use
of
such
marks
by
Signal
Path
International
is
under
license.
GB-13
:tt
CE

651-KN22180GOOOO
