FD-5 English
Page 17
Table of contents
How to use this manual 18
Intended use 18
Safety instructions 19
EMC declaration 21
INFORMATION: Speed mode 21
INFORMATION: Configuration variables 21
Operation overview 22
Technical specifications 24
Checking the package contents 24
Required tools and consumables 24
Safe and correct soldering 25
Performing a visual check 25
Mounting the function decoder 26
Programming the function decoder 28
FAQ 29
Manufacturer's note 29
Certification 30
Conditional warranty 30
Connections Diagram (Fig. 1) I
Circuit Diagram (Fig. 2) II
(Pages I and II in the centre of this handbook are removeable.)

English FD-5
Page 18
!
How to use this manual
If you have no specialist technical training, this manual gives step-by-
step instructions for safe and correct fitting of the module, and
operation. Before you start, we advise you to read the whole manual,
particularly the chapter on safety instructions and the FAQ chapter. You
will then know where to take care and how to prevent mistakes which
take a lot of effort to correct.
Keep this manual safely so that you can solve problems in the future. If you
pass the module on to another person, please pass on the manual with it.
Intended use
Caution:
Integrated circuits are very sensitive to static electricity. Do not touch
components without first discharging yourself. Touching a radiator or
other grounded metal part will discharge you.
The module can be used according to the specifications of this manual.
It is designed for a mounting in a model railway locomotive or in a
model railway carriage. It evaluates the DCC format data sent by the
digital control unit to its address. The decoder has 7 outputs for the
connection of optional accessories.
The module is not suitable for children under the age of 14.
Reading, understanding and following the instructions in this manual
are mandatory for the user. Any other use of the module is
inappropriate and invalidates any guarantees.

FD-5 English
Page 19
Safety instructions
Mechanical hazards
Cut wires can have sharp ends and can cause serious injuries. Watch
out for sharp edges when you pick up the PCB.
Visibly damaged parts can cause unpredictable danger. Do not use
damaged parts: recycle and replace them with new ones.
Electrical hazards
§Touching powered, live components,
§touching conducting components which are live due to malfunction,
§short circuits,
§connecting the circuit to a higher voltage than designed,
§impermissibly high humidity,
§condensation of water
can cause serious injury due to electrical shock. Take the following
precautions to prevent this danger:
§Never perform wiring on a powered module.
§Only use low power for this module as described in this manual and
only use certified transformers.
§Connect transformers and soldering stations only in approved mains
sockets installed by an authorised electrician.
§Observe cable diameter requirements.
§After the condensation of water do not start working until after a
minimum of 2 hours of acclimatisation.
§Mounting the module should only be done in closed, clean, dry
rooms. Beware of humidity.
§Use only original spare parts if you have to repair the module.

English FD-5
Page 20
Fire risk
Touching flammable material with a hot soldering iron can cause life-
threatening fire, burns and toxic smoke. Connect your soldering iron or
soldering station only when actually needed. Use the correct soldering
iron or station and never leave a hot soldering iron or station
unattended.
Thermal danger
A hot soldering iron or liquid solder accidentally touching your skin can
cause skin burns. As a precaution:
§use a heat-resistant mat during soldering,
§always put the hot soldering iron in the soldering iron stand,
§point the soldering iron tip carefully when soldering, and
§remove liquid solder with a thick wet rag or wet sponge.
Dangerous environments
A working area that is too small or cramped is unsuitable and can cause
accidents, fires and injury. Prevent this by working in a clean, dry room
with enough freedom of movement.
Other dangers
Children can cause any of the accidents mentioned above because they
are inattentive and not responsible enough. Children under the age of
14 should not be allowed to work with this kit or the ready-built
module.
Little children can swallow small components with sharp edges. Life
threatening! Do not allow components to reach small children.
In schools, training centres, clubs and workshops, assembly must be
supervised by qualified personnel.
In industrial institutions, health and safety regulations applying to
electronic work must be adhered to.

FD-5 English
Page 21
EMC declaration
This product is developed in accordance with the European standards
EN 55014 and EN 50082-1, tested corresponding to the EC - directive
89/336/EWG (EMVG of 09/11/1992, electromagnetic tolerance) and
meets legal requirements.
To guarantee the electromagnetic tolerance you must take the
following precautions:
§Connect the transformer only to an approved mains socket installed
by an authorised electrician.
§Make no changes to the original parts and accurately follow the
instructions, circuit diagram and PCB layout included with this manual.
§Use only original spare parts if you have to repair the module.
Information: Speed mode
Digital control units for DCC format can send 14, 28 or 128 speed levels
depending on the model and the settings. The number of speed levels sent
by the control unit (=speed mode) must be set at the decoder as well.
The speed mode set at the digital control unit for a particular decoder
address must correspond to the speed mode saved in the function
decoder. Otherwise the performance of the decoder may be incorrect.
Information: Configuration variables (CVs)
You can set the so-called configuration variables of the decoder from
the control unit. The programming of the variables allows the
adjustment of the decoder to the individual needs of the user.
The configuration variables are saved in the decoder and are also
preserved if the decoder is switched off. Changing the configuration
variables is possible at any time from the digital control unit.
The configuration variables for the DCC format are standarised. The
variables that can be set depend on the decoder type.

English FD-5
Page 22
Operation overview
The decoder is designed for operation in DCC format and can be
adjusted to one of 127 basic addresses or to one of 10.239 extended
addresses. It switches the accessories connected to the seven outputs
via the functions F0 to F4. Other functions are not available with the
FD-5.
The configuration variables of the FD-5
The following configuration variables (CVs) can be set from the digital
control unit:
§Basic address (CV 1)
§Version (CV#7) – read only
§Manufacturer identification (CV#8) - read only
§Extended address (CV#17 und CV#18)*
§Consist-Address (CV 19)*
§Configuration data (CV 29)
§Utilisation and setting of output X9 and X10 (CV 56)*
*Not possible with central units with register programming!
Function F0 (Light)
The lights can be switched from the digital control unit. You can either set
the lighting according to the direction of travel or a fixed light for both
directions of travel by programming the configuration variable CV 56.
Functions F1 and F3
Each of the functions F1 and F3 allow two accessories connected to the
outputs X4 and X5 resp. X7 and X8, with a max. current consumption of
500 mA, to be switched on or off. Parallel switching of the outputs is also
possible. In this way accessories with a maximum current consumption of
up to 900 mA can be switched. They are available for optional accessories
(e.g. smoke generator, cab lighting, sound module).

FD-5 English
Page 23
Function F2
The function F2 allows an accessory connected to the output X6, with a
maximum current consumption of 500 mA, to be switched on or off.
Function F4
If the configuration variable CV 56 is programmed accordingly, the
function F4 allows an optional accessory, connected to the output X9,
to be switched on or off. If lighting for reverse direction is programmed
for the output X9, the function F4 has no effect on this output.
Point connections
X1 Return conductor for all functions.
X2 und X3 Connections to the rails .
X4 und X5 Two optional accessories with a maximum current
consumption of 500 mA* each or one optional accessory
with a maximum current consumption of 900 mA*.
Switched via F1.
X6 Optional accessory with a maximum current
consumption of 500 mA*. Switched via F2.
X7 und X8 Two optional accessories with a maximum current
consumption of 500 mA* each or one optional accessory
with a maximum current consumption of 900 mA*.
Switched via F3.
X9 Optional accessory with a maximum current
consumption of 500 mA*. Switched via F4 or:
Lighting for reverse direction (switched dependent of the
direction of travel via F0).
X10 Optional accessory or lighting for forward direction with
a maximum current consumption of 500 mA*.
Switched dependent or independent of the direction of
travel via F0).
* Maximum current consumption of all accessories = 1.500 mA

English FD-5
Page 24
Technical specifications
Data format DCC
Supply voltage 12-24 Volt digital voltage
Current consumption
(without connected loads) ca. 10 mA
Max. current per function output 500 mA
Max. total current 1.500 mA
Protected to IP 00
Ambient temperature in use 0 - + 60° C
Ambient temperature in storage -10 - + 80° C
Comparative humidity allowed max. 85 %
Dimensions ca. 12,5 x 27,5 x 3,5 mm
Weight ca. 2 g
Checking the package contents
Check the contents of the package for completeness:
§1 module
§1 manual
Required tools and consumables
Make sure you have the following tools, equipment and materials ready
for use:
§a heat-resistant mat
§a soldering iron stand with tip-cleaning sponge
§a small side cutter and wire stripper
§an electronic soldering iron (max. 30 Watt) with a fine tip
§tin solder (0,5 mm. diameter)
§wire (diameter: >0,08 mm² for all connections)

FD-5 English
Page 25
!
Safe and correct soldering
Caution:
Incorrect soldering can cause fires (through excessive heat). Avoid this
dager by reading the chapter Safety instructions again and following
the directions given.
If you have had training in soldering you can skip this chapter.
§When soldering electronic circuits never use soldering-water or
soldering grease. They contain acids that can corrode components
and copper tracks.
§Only use tin solder with flux.
§Use a small soldering iron with max. 30 Watt. Keep the soldering tip
clean so the heat of the soldering iron is applied to the solder point
effectively.
§Solder fast: long soldering can destroy components and copper
tracks, and damages through plated holes.
§Apply the soldering tip to the soldering spot in such a way that the part
and the soldering spot are heated at the same time. Simultaneously
add solder (not too much). As soon as the solder becomes liquid take it
away. Hold the soldering tip at the spot for a few seconds so that the
tin solder finds its way, then remove the soldering iron.
§Do not move the component for about 5 seconds after soldering.
§To make a good soldering joint you must use a clean and
unoxidised soldering tip. Clean the soldering tip with a damp piece
of cloth, a damp sponge or a piece of silicon cloth.
Performing a visual check
Damaged materials can cause injury. Parts damaged during transit can
also be dangerous. Check the module for damage, missing parts or
poor soldering. If you find damage, return the module for exchange.

English FD-5
Page 26
!
Mounting the function decoder
Open the locomotive or the carriage housing. Locate the position for
the decoder.
Follow the connections diagrams (fig. 1a and 1b)! Solder the
connections to the rails at points X2 and X3.
Connecting the lighting and other accessories
Follow the connections diagrams (fig. 1a and 1b)!
Disconnect any existing diodes in the leads to the lamps. Connect the
lamps for forward motion to X10 and - if desired - the lamps for reverse
motion to point X9. If the lamps are already connected with one side to
ground, you must solder in a diode between the decoder and the lamp
(see fig. 1a) Otherwise you must connect the second side of the lamps
according to fig. 1b to the return conductor (point X1).
Connect other accessories (e.g. smoke generator, noise module), which
are switched by the functions F1 to F4, to the points X4 to X8. Connect
the accessory which is switched via the function F2 to the point X6. The
accessories connected to the points X4 and X5 resp. the points X7 and
X8 are switched jointly on and off via the functions F1 resp. F3. If you
want to connect an accessory with a current consumption of more than
500 mA you must connect the two outputs in parallel (fig. 1a and 1 b,
connection to X4 and X5). You can connect a further accessory to point
X9 which can be switched via the function F4 instead of the lighting for
reverse direction.
Caution:
The current consumption of all connected accessories may not exceed
1.500 mA!
You can connect the second side of the accessories either to the return
conductor (point X1) or to ground. If connecting the accessory to
ground you must solder in a diode.

FD-5 English
Page 27
!
!
!
Caution:
The return conductor for all functions (point X1) must under no
circumstances be connected to locomotive resp. carriage ground.
Possible short circuit! The decoder will be damaged in operation.
Caution:
If you connect the loads to the return conductor for all functions (point
X1), the loads must be insulated. The loads must not make contact with
metal parts of the locomotive or the carriage. Possible short circuit! The
decoder will be damaged in operation.
Connecting the LEDs
The function outputs of the decoder switch against decoder ground. For
that reason you must connect the cathode (-) of the LED to the output
of the relevant function.
Caution:
If you use light-emitting diodes (LEDs) you must always operate them
via a series resistor.
LEDs are available in many different models. There are LEDs with 2-5
mA, but also LEDs with 15-30 mA power consumption. The series
resistor limits the current flow of the LED and will need to be calculated
for each model. Ask for the max current rating when buying your LEDs.
You can connect several LEDs in parallel to each output. In this case every
LED must have a series resistor of its own. If you connect several LEDs to
one output in series, only one series resistor is needed. The number of
LEDs connected in series to one output depends on the digital voltage.
You can determine the number of the LEDs that can be connected in
series to one output from the following formula:
(number of LEDs + 2) x 1,5 < digital voltage
Fixing the decoder
After completing all connections fix the decoder with double-sided
adhesive tape, for example.

English FD-5
Page 28
Programming the function decoder
The function decoder is programmed from the digtial control unit. See
chapter in the manual of your digital control unit where the
programming of configuration variables (CVs) is explained.
You can programm the following function decoder variables:
CV-name CV-
no. Input value / (State of
delivery)
Remarks
Basic address 11 ... 127 (3)
Version 7--- Read only!
Manufacturer 8--- Read only!
Reset 80 ... 255 Any value restores the settings
in state of delivery.
Extended
address 17 18 1 ... 10239 (-)
Consist-addr. 19 1 ... 127 (0) = 2nd address
Numerical value
direction "standard" 0
invert direction 1
14 speed levels 0
28 speed levels 2
Basic adress 0
Configuration
data 29 0, 1, 2, 3, 32, 33, 34, 35 (2)
This data is set by
entering the sum
of the numerical
values.Extended adress 32
Numerical value
X9 switched independent of
direction of travel via F4 0
X9 switched via F0 2
X10 and resp. X9 switched
independent of direction via F0 0
Utilization
and setting of
output X9
and X10
56 0, 1, 2, 3 (3)
This data is set by
entering the sum
of the numerical
values.X10 and resp. X9 switched
dependent of direction via F0 1

FD-5 English
Page 29
!
FAQ
§Parts are getting too hot and/or start to smoke.
Disconnect the module from the mains immediately!
Possible cause: Short circuit. The decoder is connected to
locomotive or carriage ground.
àCheck the connections. A short circuit can result in irreparable
damage.
§The lighting does not correspond to the direction of travel.
Possible cause: The configuration data (CV29) of the locomotive
decoder in the train vary from the configuration data programmed
in the function decoder.
àChange the programming or the function or the locomotive
decoder.
§The lighting for forward direction cannot be switched via F0.
Possible cause: The speed mode of the decoder and the digital
control unit do not correspond. Example: The control unit is set to
the mode 28 speed levels, but the decoder to the mode 14 speed
levels.
àChange the speed mode at the control unit and / or at the
decoder.
If you cannot find the problem, please return the decoder for repair
(address on the cover page).
Manufacturer's note
According to DIN VDE 0869, the person who builds this kit or brings the
circuit into operation is the manufacturer of the product. If he sells the
product to another person he is responsible for passing on all the
relevant papers. Domestic appliances assembled from a kit are deemed
industrial products and must comply with health and safety regulations.

English FD-5
Page 30
Certification
This product conforms with the EC- directive 89/336/EWG on
electromagnetic radiation and is therefore CE certified.
Conditional warranty
This product is guaranteed for two years. The warranty includes free
repair if the problem is due to material failure or incorrect assembly of
the module by us. We guarantee the quality of the components.
Other claims are excluded. By law, we are not responsible for damages
or secondary damages in connection with this product. We retain the
right to repair, make improvements, supply spare parts or return the
purchase price.
The following invalidate the warranty:
§using an unsuitable soldering iron, solder containing liquid acids or
similar,
§if damage is caused by not following the instructions in this manual
or the circuit diagram,
§if the circuit has been altered and repair attempts have failed,
§if arbitrary changes in the circuit are made,
§if parts are stored incorrectly and if the wires to the switches, the
power resistors, etc. are made incorrectly,
§if the copper tracks or soldering points are damaged,
§if damage occurs due to an overload of the circuit,
§if the wrong power or current is connected,
§if damaged by other persons,
§if damaged by the wrong use or abuse of the circuit,
§if parts are damaged due to static because they were touched
before a discharge is performed.

FD-5 FD-5
Seite - Page - Page - Pagina I Seite - Page - Page - Pagina I
Anschlußplan - Connections diagram - Schema de connexion - Aansluit plan
nnnFig. 1

FD-5 FD-5
Seite - Page - Page - Pagina II Seite - Page - Page - Pagina II
Schaltplan - Circuit diagram - Schéma de commutation - Schakelplan
nnnFig. 2
Ausgänge
Outputs
Sorties
Uitgangen

n
n
n
Aktuelle Informationen und Tipps:
Information and tips: n
Informations et conseils:
Actuele informatie en tips: n
http://www.tams-online.de n
n
n
n
Garantie und Service:
Warranty and service: n
Garantie et service:
Garantie en service: n
n
Tams Elektronik GmbH n
Rupsteinstraße 10
D-30625 Hannover n
fon: +49 (0)511 / 55 60 60
fax: +49 (0)511 / 55 61 61 n
e-mail: [email protected] n
