P356 Cradle Deployment and Operation Guide
Step 1: Install P356 Crawler into P356 Cradle
Place P356 Crawler (3) in P356 Cradle (1). Choose whether the Deploy Bracket (5) is to face forwards or
backwards, set by whether the camera is to point upwards or downwards during deployment.
Push P356 Crawler to the opposite side of P356 Cradle from Lobe screw (4) and fully engage drives on that
side. Tighten Lobe screw until hand tight. The spring-loaded drive shafts of P356 Cradle engage
automatically when P356 Cradle Assembly is driven.
Step 2: Deploy P356 Cradle Assembly
Using a rope through Deploy Bracket, lower the P356 Assembly into position using P350 Cable (2) to guide
the Assembly if required. When it is in position, remove the rope. Set the wheel size to 170mm in the P350
‘Setup Equipment’ menu and begin your survey.
Step 3: After the survey
Lift P356 Cradle Assembly using a rope through Deploy Bracket. Again, P350 Cable may be used to guide
its position. Loosen Lobe screw to remove P356 Crawler from P356 Cradle, if required.
Specifications
Notes
Dimensions (H x W x L)
369 x 534 x 712mm / 14.5 x 21.0 x 28.1"
P356 Cradle only
Weight
22kg / 48.5lb
Dimensions (H)
524mm / 20.6"
Min height of Assembly, incl. P356 Crawler, Powered
Elevator (lowered), PTZ Camera and Lighthead
Weight
50kg / 110lb
Ordering information
Description
Sales Part Number
P356 Cradle
10/P356-CRADLE
P356 Crawler and other parts available separately
Wheel for P356 Cradle
10/P356-CRADLE-WHEEL
Single spare wheel 13"/325mm
P350 Cable (2)
Can be used to guide
the P356 Cradle during
deployment
Lobe screw (4)
To fix the P356 Crawler
in place in the Cradle
P356 Crawler (3)
With Powered Elevator,
PTZ camera, and
Lighthead
Deploy Bracket (5)
For rope, to deploy
the P356 Cradle
assembly
P356 Cradle (1)
Elevator Hook (6)
Do not use to
deploy P356 Cradle
Assembly
Heavy object: care must be taken when lifting

P356 Compact Cradle Deployment and Operation Guide
Step 1: Install P356 Crawler into P356 Compact Cradle
Place P356 Crawler (3) in P356 Compact Cradle (1). Choose whether the Deploy Bracket (5) is to face
forwards or backwards, set by whether the camera is to point upwards or downwards during deployment.
Push P356 Crawler to the opposite side of P356 Compact Cradle from Lobe screw (4) and fully engage
drives on that side. Tighten Lobe screw until hand tight. The spring-loaded drive shafts of P356 Compact
Cradle engage automatically when P356 Compact Cradle Assembly is driven.
Step 2: Deploy P356 Compact Cradle Assembly
Using a rope through Deploy Bracket, lower the P356 Assembly into position using P350 Cable (2) to guide
the Assembly if required. When it is in position, remove the rope. Set the wheel size to 110mm in the P350
‘Setup Equipment’ menu and begin your survey.
Step 3: After the survey
Lift P356 Compact Cradle Assembly using a rope through Deploy Bracket. Again, P350 Cable may be used
to guide its position. Loosen Lobe screw to remove P356 Crawler from P356 Compact Cradle, if required.
Specifications
Notes
Dimensions (H x W x L)
320 x 419 x 617mm/12.6 x 16.5 x 24.3"
P356 Compact Cradle only
Weight
15kg / 33.1lb
Dimensions (H)
442mm / 17.4 "
Min height of Assembly, incl. P356 Crawler, Powered
Elevator (lowered), PTZ Camera and Lighthead
Weight
43kg / 94.8lb
Ordering information
Description
Sales Part Number
P356 Compact Cradle
10/P356-CRADLE-COMP
P356 Crawler and other parts available separately
Wheel for P356 Comp. Cradle
10/P356-CRADLE-WHEEL-COMP
Single spare wheel 9"/225mm
Copyright © 2018 Radiodetection Ltd. All rights reserved. Radiodetection is a subsidiary of SPX Corporation. Pearpoint, P350 and P356 are trademarks of
Radiodetection in the United States and/or other countries. Due to a policy of continued development, we reserve the right to alter or amend any published
specification without notice. This document may not be copied, reproduced, transmitted,modified or used, in whole or in part, without the prior written consent
of Radiodetection Ltd.
90/P356CRADLE-DEPLOY-EN/02
P350 Cable (2)
Can be used to guide
the P356 Compact Cradle
during deployment
Lobe screw (4)
To fix the P356 Crawler
in place in the Cradle
P356 Crawler (3)
With Powered Elevator,
PTZ camera, and
Lighthead
Deploy Bracket (5)
For rope, to deploy
the P356 Compact
Cradle assembly
P356 Compact Cradle (1)
Heavy object: care must be taken when lifting
