Peavey TLS 6X User manual

FFrreeqquueennccyy rraannggee ((--1100 ddBB,, hhaallff ssppaaccee))::
40 Hz to 18 Hz
FFrreeqquueennccyy rreessppoonnssee ((±± 33 ddBB,, hhaallff ssppaaccee))::
58 Hz to 16 Hz
SSeennssiittiivviittyy ((11ww//11mm))::
100 dB
PPoowweerr rraattiinngg ((pprrooggrraamm))::
1,000 Watts
PPeeaa ppoowweerr ccaappaacciittyy ((ppeeaa))::
2,000 Watts
MMaaxxiimmuumm SSPPLL::
132 dB
TTrraannssdduucceerr ccoommpplleemmeenntt::
Two Scorpion®Plus 15" premium
woofers, RX™22 2" titanium
diaphragm dynamic compression
driver on a 90˚ x 40˚ coverage constant
directivity horn
DDrriivveerr pprrootteeccttiioonn::
Sound Guard™III on the compression
driver provides long- and medium-
term overload and overdrive protection
NNoommiinnaall ccoovveerraaggee ppaatttteerrnn::
90˚ x 40˚
EElleeccttrroo--aaccoouussttiicc ccrroossssoovveerr ffrreeqquueennccyy::
300 Hz, 2.2 Hz
NNoommiinnaall iimmppeeddaannccee::
4 Ohms
IInnppuutt ccoonnnneeccttiioonnss::
Two 1/4" phone jac s in parallel
EEnncclloossuurree mmaatteerriiaallss && ffiinniisshh::
Trapezoidal, blac carpet-covered
enclosure with dado-joined 1/2" MDF
(Medium Density Fiberboard) and a
full-length, blac powder-coated steel
grille
DDiimmeennssiioonnss ((HH xx WW xx DD))::
FFrroonntt::
44.75" x 18.25" x 17.563"
113.66 cm x 43.36 cm x 44.61 cm
RReeaarr::
44.75" x 12.25" x 17.563"
113.66 cm x 31.12 cm x 44.61 cm
WWeeiigghhtt::
85 lbs. (38.64 g)
BBuulllleettss::
• Quasi-three-way music playbac
enclosure
• Peavey-exclusive Scorpion Plus
woofers with 2.5" voice coils
• RX 22 titanium diaphragm
compression driver, with 2"
diaphragm
• Sound Guard III tweeter
protection
• 1,000 Watts program/2,000
Watts pea power handling
• Heavy duty crossover networ for
driver protection and EQ
• Rugged, trapezoidal enclosure
• 90˚ x 40˚ coverage constant-
directivity horn for better off-axis
tonality
• High quality, heavy duty carpet
covering
• Steel handles
• Steel corners
• Rugged dado and rabbet
construction for strong-yet-
lightweight joints
• T-Nut spea er mounting
• Heavy duty full-length steel grille
• Two poc et casters on bottom rear
for ease of transport
• Top rear centered handle for use
with the poc et casters
DDeessccrriippttiioonn
The TLS6X is a quasi-three-way
spea er system utilizing two 15"
Scorpion Plus woofers and an RX22
titanium diaphragm, dynamic
compression driver mounted on a 90˚ x
40˚ coverage constant-directivity horn.
The rugged, carpet-covered trapezoidal
enclosure features steel handles, poc et
casters and a top handle to facilitate
portable use for music playbac , live
music or speech sound reinforcement. A
full-length, blac powder-coated steel
grille provides driver protection and a
professional appearance.
The TLS 6X spea er system is
rated at 1,000 Watts program power
handling, and the full crossover networ
includes high voltage film caps and
Sound Guard III tweeter protection for
clear punchy sound and excellent long-
term reliability. Two 1/4" phone jac
input connectors ma e hoo -up a
breeze.
SSPPEECCIIFFIICCAATTIIOONNSS TTLLSS™™66XX

Features and specifications subject to change without notice.
Peavey Electronics Corporation • 711 A Street • Meridian • MS • 39301 [phone] • FAX [phone] • www.peavey.com
©2003 Printed in the U.S.A. 7/03
80304965
20 50 100 200 500 1k 2k 5k 10k 20k
Frequency (Hz)
60
70
80
90
100
110
dB SPL (re 20 Pa)
Amplitude Response (1W 1m On-Axis)
Figure 1
20 50 100 200 500 1k 2k 5k 10k 20k
Frequency (Hz)
30
40
60
80
100
140
180
300
360
Beamwidth (Degrees)
Beamwidth
Vertical
Horizontal
Figure 2
20 50 100 200 500 1k 2k 5k 10k 20k
Frequency (Hz)
1
10
100 Q & Directivity Index
Q
Figure 3
20
10
Di
0
SSPPEECCIIFFIICCAATTIIOONNSS TTLLSS™™66XX
33 ++ 22 YYEEAARR LLIIMMIITTEEDD WWAARRRRAANNTTYY
NNOOTTEE:: For details, refer to the warranty statement. Copies of this statement may be obtained by
contacting Peavey Electronics Corporation, P.O. Box 2898, Meridian, Mississippi 39301-2898.
