Peco Pro 12 DFS 49621203 User manual

ASSEMBLY OPERATION MAINTENANCE
MANUAL PART#: Q0481 Rev. 3
GRASS
COLLECTION
SYSTEM
P
PECOPECO
PPP P
PECOPECOPECO
OPERATOR’S MANUAL
Boss XL Series
2013 - 2017
Vac Model # 49621203

2
2-2 Lower Main Frame Bracket Installation - - - - - - - 6
2-3 PTO Mount Plate Component Installation- - - - - - 7
2-5 PTO Handle Installation - - - - - - - - - - - - - - - - - 8
2-1 Preparation Of Mower - - - - - - - - - - - - - - - - - - 5
2-14 Boot To Mower Deck Installation - - - - - - - - - - - 14
2-7 Cam Assembly Adjustment - - - - - - - - - - - - - - - 10
2-9 Main Frame Assembly Installation - - - - - - - - - - 11
2-10 Lift Handle Installation - - - - - - - - - - - - - - - - - 12
2-11 Aluminum Grass Container Installation - - - - - - - 13
2-16 Length Of Hose Adjustment - - - - - - - - - - - - - - 15
2-6 Belt Installation And Adjustment - - - - - - - - - - - - 9
2-8 Blower Cone Installation - - - - - - - - - - - - - - - - - 10
2-13 Boot Plate Installation- - - - - - - - - - - - - - - - - - 14
2-4 PTO Assembly Installation - - - - - - - - - - - - - - - 8
2-12 Dump Mechanism Adjustment - - - - - - - - - - - - 13
II INSTALLATION FOR USE - - - - - - - - - - - - - - - - - - - - - 5
SECTION PAGE
Safety - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2
Safety Alert Symbols- - - - - - - - - - - - - - - - - - - - - - 3
Warranty - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4
I INTRODUCTION AND DESCRIPTION - - - - - - - - - - - - 5
1-1 Introduction - - - - - - - - - - - - - - - - - - - - - - - - - 5
1-2 Description - - - - - - - - - - - - - - - - - - - - - - - - - 5
3-3 Disengagement Of The Blower - - - - - - - - - - - 25
III OPERATING INSTRUCTIONS - - - - - - - - - - - - - - - - - 25
3-2 Operation & Tips On Mowing - - - - - - - - - - - - - - 25
2-20 Impeller Blade Removal And Replacement - - - - 16
Torque Specifications - - - - - - - - - - - - - - - - - - - - - 28
2-18 Lower Hose To Blower Cone Installation- - - - - - 15
2-21 Weight Kit Installation- - - - - - - - - - - - - - - - - - 17
2-17 Upper Hose Installation - - - - - - - - - - - - - - - - 15
2-19 Lower Hose To Boot Installation - - - - - - - - - - - 15
Exploded Views and Parts List - - - - - - - - - - - - - 18-24
SECTION PAGE
3-1 General Safety - - - - - - - - - - - - - - - - - - - - - - - 25
4-1 Maintenance Checklist - - - - - - - - - - - - - - - - 25-26
3-4 Unloading The Collection System - - - - - - - - - - - 25
4-2 Lubrication- - - - - - - - - - - - - - - - - - - - - - - - - - 26
IV MAINTENANCE - - - - - - - - - - - - - - - - - - - - - - - - - - - 25
V PARTS AND SERVICE - - - - - - - - - - - - - - - - - - - - - - 26
5-1 Parts And Service Information - - - - - - - - - - - - - 26
Safety Decals - - - - - - - - - - - - - - - - - - - - - - - - - - 27
Troubleshooting Collection System - - - - - - - - - - - - - 29
GRASS COLLECTION SYSTEM
TABLE OF CONTENTS
SAFETY
anyone who is not acquainted with the Safety Instructions to use your attachment.
2. Know the controls and how to stop them quickly. READ THE OPERATOR’S MANUAL!
3. Do not allow children to operate the machine. Do not allow adults to operate it without proper instruction.
1. Read the operator’s manual carefully and familiarize yourself with the proper use of your attachment. Do not allow
4. Be especially watchful of children and pets entering into the area while operating.
13. Wear eye protection to prevent debris from getting into your eyes.
removing clogs, removing or replacing hose, boot, blower cone, or performing any maintenance.
8. Stop machine, shut off deck attachment, set parking brake, shut off engine and remove ignition key before
foreign object.
12. Wear hearing protection.
11. Inspect your lawn and remove any foreign objects before mowing. Never deliberately run the mower across any
6. Do not attempt to operate your machine when not in the driver’s seat.
7. Always shut off blades and engine when emptying the container.
when the container is empty.
5. Keep your eyes and mind on your machine while mowing or operating your attachment. Don’t let others distract
you.
9. Mow across the face of slopes (not more than 10 degrees); never up and down the face.
10. It is recommended that the container be emptied when half full while operating on slopes. Start mowing on slopes
2017 (v1.0)

3
ALERT! YOUR SAFETY IS INVOLVED!”
SAFETY
WARNING! NEVER operate the mower unless the discharge guard and either the deflector assembly or
the vacuum collector adapter are fastened securely in place.
WARNING! Do not work around the mower deck boot or the blower area until you are certain that the mower
blades and the blower impeller have stopped rotating.
WARNING! To avoid serious injury, perform maintenance on the vacuum collector; ONLY AFTER
STOPPING THE MOWER’S ENGINE AND WAITING FOR ALL MOVING PARTS TO COME TO A
COMPLETE STOP. Set the parking brake. Always remove the ignition key before beginning maintenance.
WARNING! For your own personal safety, ALWAYS mow ACROSS the face of slopes and
NEVER UP and DOWN the face. NEVER attempt to mow excessively steep slopes, and use
caution when turning on any slope.
Safety Alert Symbol
This Safety Alert Symbol means: “ATTENTION! BECOME
This symbol is used to call attention to safety precautions that
Should be followed by the operator to avoid accidents. When
you see this symbol, carefully read the message that follows
and heed its advice. Failure to comply with safety precautions
could result in death or serious bodily injury.
Safety Signs
The signal words DANGER, WARNING, and CAUTION are used on the equipment safety signs. These words
are intended to alert the viewer to the existence and the degree of hazard seriousness.
DANGER
!
CAUTION
This signal word indicates a potentially hazardous situation which, if not
avoided, will result in death or serious injury.
This signal word indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
It may also be used to alert against unsafe practices.
This signal word indicates a potentially hazardous situation which, if not
avoided, will result in minor or moderate injury.
It may also be used to alert against unsafe practices.
White letters on RED
Black letters on ORANGE
Black letters on YELLOW
WARNING
!
!
!
2017 (v1.0)

4rev1 2/15
PECO LIMITED WARRANTY FOR NEW PRODUCTS
A. WHAT IS UNDER WARRANTY?
PECO extends the following warranties to the original purchaser of each new PECO consumer product subject
to the following limitations.
delivery of the product. The purchaser shall pay any charge for the product to and from Arden, NC.
DATE OF ORIGINAL SALE ONLY.
H. REMEDIED EXCLUSIVE.
defect appears within 12 months from the date of delivery of the product to the original purchaser.
All obligations of New PECO, Inc. under this warranty shall be terminated if products are altered or modified in
ALL DEFECTIVE PARTS MUST BE RETURNED TO PECO FOR INSPECTION TO
returned to New PECO, Inc. 10 Walden Dr., Arden, NC 28704 before any warranty adjustment can be
delivered to the purchaser will be repaired or replaced, as PECO elects, without charge for parts or labor, if the
2. PARTS REPLACED DURING WARRANTY: Any new PECO part which is furnished in performance of this
manufacturer.
D. UNAPPROVED ALTERATION OR MODIFICATION.
1. PRODUCT WARRANTY: Any part of any consumer product, which is defective in material or workmanship as
warranty and is defective in material or workmanship as delivered to the purchaser will be repaired or replaced,
Call PECO for Return Authorization. Damaged or broken parts other than engines or batteries, must be
B. SECURING WARRANTY ADJUSTMENTS.
E. ACCIDENTS AND NORMAL MAINTENANCE.
caused by normal wear, accident, improper use or abuse of products. The cost of normal maintenance and
paid for by the purchaser.
C. ITEMS NOT COVERED BY PECO WARRANTY.
DETERMINE VALIDITY OF WARRANTY CLAIMS. Freight and mailing will be borne by the customer.
as PECO elects, without charge if the defect appears within 90 days from the date of installation of such part or
before the expiration of the original warranty period, whichever is later.
Engines and batteries attached to PECO products are covered under a separate warranty by the respective
F. NO REPRESENTATIONS ADDITIONAL WARRANTIES, DISCLAIMER.
normal replacement of service items such as belts, cutting blades, hoses, etc., which are not defective shall be
Neither New PECO, Inc. nor any company affiliated with it makes any warranties, representations or promises
ways not approved by New PECO, Inc.
The warranty covers only defective material and workmanship. It does not cover depreciation or damage
authorized. At the time of requesting warranty adjustment, the purchaser must present evidence of the date of
as to the quality of performance of its products other than those set forth herein. Except as described above,
New PECO, Inc. makes no other warranties AND SPECIFICALLY DISCLAIMS ANY AND ALL
IMPLIED WARRANTIES OF FITNESS AND MERCHANTABILITY.
G. ANY MACHINE USED FOR RENTAL PURPOSES ARE GUARANTEED FOR 45 DAYS FROM
PECO, Inc. consumer products are set forth above. In no event will PECO be liable for special incidental or
consequential damages.
authority to make any representation or promise on behalf of PECO or to modify the terms of this warranty in
1. NO SERVICE CENTER WARRANTY.
The only remedies the purchaser has in connection with the breach or performance of any warranty on New
The selling Service Center makes no warranty on his own on any item warranted by New PECO, Inc. unless he
delivers to purchaser a separate written warranty certificate specifically warranting the item. The dealer has no
any way.

5
INSTALLATION FOR USE
2-1 Preparation Of Mower
The grass collection system is designed for turf
maintenance where there is a need to collect the grass
clippings as the mower cuts the turf. It is also used for
picking up leaves and in pre-season and post-season
clean-up. The blower, mounted on the right side of the
unit, uses a belt and gearbox system from the engine
PTO shaft. Drive train protection comes through belt
slippage. The blower draws grass clippings from the
discharge area of the cutter deck back to the 12 cubic
foot aluminum box at the rear portion of the mower
frame. The operator can engage the blower with a push
of the over-center linkage on the right side of the unit.
Once the container is full, the operator can easily push
and raise the dump handle, opening the rear door on the
container and pivoting the box to the ground. Once
empty, the operator can easily lower and pull the dump
handle, pivoting the box back into position and closing
the door.
Remove deck drive belt from the clutch pulley (refer to
your Country Clipper operator’s manual). From the
underside of the engine, disconnect the wiring harness
attached to the electric clutch. Remove the bolt and
electric clutch from the mower. Refer to Figure 2-1a.
1-1 Introduction
Section II
Remove the D-drive spacer using an arbor press or
equivalent. On removal, adjacent bearing OUTER race
must be supported or bearing damage may occur. Refer
to Figure 2-1b.
Your grass collection system has been designed to give
you a low maintenance, simple, and effective way to
collect the grass clippings from your mower. This manual
is provided to give you the necessary instructions to
properly mount and operate the collection system on
your mower. Please read this manual thoroughly.
Understand what each control is for and how to use it.
Observe all safety decal precautions on the machine and
noted throughout the manual.
NOTE: all references made to right, left, front, rear, top
or bottom are as viewed from the normal operator’s
position on the mower.
1-2 Description
SECTION I
INTRODUCTION AND DESCRIPTION
The engine pulley assembly must be installed using an
arbor press or equivalent. Upon Installation, opposite
bearing inner race must be supported or bearing
damage may occur. Refer to Figure 2-1c.
Use engine pulley assembly #25 P#(A1200), (1) 7/16”
lock washer P#(K0140), and 7/16”-20 x 4-1/2” hex bolt
P#(K0427).
Kawasaki FX1000V
The added pulley will power the collection system. Note
that the center of the hub that is extended, should be
upward toward the engine (Figure 2-1d). Torque the bolt
to 55 ft./lbs. Please inspect that lock washer is
properly in place when the crankshaft bolt is fully
tightened.
Use engine pulley assembly #24 P#(A1176), (1) 7/16”
lock washer P#(K0140), and 7/16”-20 x 4-1/2” hex bolt
P#(K0427).
Kawasaki FX801V / 27HP Kohler / 29HP Kohler
Electric Clutch
Figure 2-1d
Engine Pulley
Assembly
Hex Bolt Lock Washer
PRESS
Figure 2-1c
Engine Pulley Installation
Engine Pulley
Number Is
Stamped On
The Pulley
Bushing Here
Figure 2-1a
Engine Bushing
PRESS
Figure 2-1b
Support Bearing
Outer Race
D-drive Spacer
D-drive Spacer Removal
Support Bearing
Inner Race
Remove Bolt

6
2-2 Lower Main Frame Bracket
Installation
First, remove (2) existing top bolts 3/8”-16 x 1” FHCS
and (2) 3/8”-16 nyloc nuts that secure the top rear
engine guard bar. Also, remove the (2) existing 1/2”-13 x
2” FHCS and (2) 1/2”-13 nyloc nuts from the right side of
the top and bottom rear engine guard bars. Next,
remove the (1) existing 1/2”-13 x 2” FHCS and (1) 1/2”-
13 nyloc nut from the left side of the top rear engine
guard bar. Secure the Lower Main Frame Bracket
P#(B0873) to the top engine guard bar using (2) 3/8”-16
x 1-1/4” HHCS P#(K1192) and (2) 3/8”-16 Ny-Flange
locknuts P#(K2038). Refer to Figure 2-2a.
See Page 7, Figure 2-2c for completed assembly image.
Secure the Left PTO Mount Plate P#(B0852) and Lower
Main Frame Bracket to the top and bottom rear engine
guard bars using (2) 1/2”-13 x 2-1/2” HHCS P#(K1235)
and (2) 1/2”-13 Ny-Flange locknuts P#(K2012). Secure
the left side of the main frame bracket to the top rear
engine guard bar and
battery mount box, using (1) 1/2”-13 x 2-1/2” HHCS
P#(K1235) and (1) 1/2”-13 Ny-Flange locknuts
P#(K2012) as shown in Figure 2-2b.
(2) 3/8”-16 x 1-1/4”
Hex Bolts
(2) 3/8”-16
Locknuts
Lower Main
Frame Bracket
(2) 1/2”-13
Locknuts
(2) 1/2”-13 x 2-1/2”
Hex Bolts
(1) 1/2”-13 x 2-1/2”
Hex Bolt
Left PTO
Mount Plate
1/2”-13
Locknut
Lower Main
Frame Bracket
(1) 1/2”-13 x 2-1/2”
Hex Bolt
(1) 1/2”-13
Locknut
Battery
Mount Box
Figure 2-2a
Figure 2-2b
Top Rear Engine
Guard Bar
Bottom Rear Engine
Guard Bar

7
Secure the right PTO mount plate P#(B0854) to the left
PTO mount plate, using (2) 3/8”-16 x 1” HHCS
P#(K1191) and (2) 3/8”-16 nylon flange locknuts
P#(K2038). Do not tighten the hardware completely.
Insert the PTO stop plate P#(B0736) between the left
and right PTO mount plates and secure using (4) 1/4”-20
x 3/4” HHCS P#(K1222) and (4) 1/4”-20 nylon flange
locknuts P#(K2014). Tighten all PTO component
hardware at this time. Refer to Figure 2-3b.
2-3 PTO Mount Plate Components
Installation
Figure 2-3b
PTO Stop
Plate
Right PTO
Mount Plate
(2) 1/4”-20 x 3/4”
Hex Bolts
(4) 1/4”-20
Locknuts
Left PTO
Mount Plate
(2) 3/8”-16
Locknuts
(1) 3/8”-16 x 1”
Hex Bolts
(2) 1/4”-20 x 3/4”
Hex Bolts
(1) 3/8”-16 x 1”
Hex Bolts
Figure 2-2c

8
Note: Remove the gearbox pulley guard in preparation
for the belt installation. Refer to Figure 2-4a.
2-4 PTO Assembly Installation
To mount the PTO assembly, insert the pivot rod on the
PTO assembly P#(A1950) into the mounting slots
located on the left & right PTO mount plates (Figure 2-
4a). Tilt the PTO assembly upward and insert the PTO
mount pin P#(B0274) through the hole in the top of the
right PTO mount plate assembly. Secure the PTO mount
pin using 1/8” x 2-3/8” hair pin clip P#(K0086) as shown
in Figure 2-4b.
Attach the PTO handle P#(A1142) to the PTO assembly
using (3) 1/4”-20 x 3/4” HHCS P#(K1222) and (3) 1/4”-
20 nylon flange locknuts P#(K2014). Attach the handle
grip P#(J0522) to the PTO handle. Refer to Figure 2-5.
2-5 PTO Handle Installation
NOTE: The PTO Handle can be adjusted after
performing Step 2-8 to achieve proper belt adjustment.
To adjust the handle, remove (3) 1/4”-20 x 3/4” HHCS
P#(K1222) and (3) 1/4”-20 nylon flange locknuts
P#(K2014), rotate handle until positioned in the desired
location (while aligning holes) and reattach. The bolts
should be kept approximately 120 degrees apart to
ensure proper fastening.
Figure 2-4b
PTO
Mount Pin
Hair Pin
Clip
Install PTO
Handle Here
Figure 2-4a
Figure 2-5
Mounting
Slot
PTO
Assembly
Pivot
Rod PTO Handle
Handle Grip
(3) 1/4”-20 x 3/4” HHCS
(3) 1/4”-20 Nylon
Flange Locknut
Remove
Gear Box
Pulley Guard

9
2-6 Belt Installation and Adjustment
Loosen the (4) bolts P#(K1191), (2) on each side, that
secure the gear box assembly to the PTO assembly
P#(A1950) (Figure 2-6a and 2-6b).
Loosen the adjustment bolt P#(K0348) until the gear box
assembly is at its far left adjustment (the gear box is
moved toward the mower’s engine pulley). Refer to
Figure 2-6c.
Once the correct tension of the belt is achieved, tighten
the (4) bolts that secure the gear box assembly. Refer to
Figures 2-6f and 2-6g. Replace the belt guard and
hardware that was removed in Section 4.2-
Connect the belt A57K P#(M0256) from the engine
pulley to the lower gear box pulley (Figure 2-6d).
To tension the drive belt, turn the adjustment bolt
clockwise (Figure 2-6e) until there is 1” of deflection, with
10-11 lbs. of pressure, at the center of the belt between
the engine pulley and the gear box pulley.
Loosen Bolts
Figure 2-6a
Figure 2-6b
Loosen Bolts
Figure 2-6c
Loosen The
Adjustment Bolt
Slide Gear Box
Towards The
Engine Pulley
Connect Belt
To Both Pulleys
Figure 2-6d
Figure 2-6e
Figure 2-6f
Figure 2-6g
Tighten Bolts
Tighten Bolts
Tighten The Adjustment
Bolt To Tension The Belt

10
2-7 Cam Assembly Adjustment
The cam assembly P#(A0422), which controls the
blower belt tension, comes from the factory pre-adjusted.
If the belt is too tight or becomes too loose, remove the
hair pin clip P#(K0130) from the belt tension rod
P#(K0326) and pull the “L” end of the rod out of it’s hole
in the cam assembly.
The tension rod may then be screwed out to tighten the
belt or screwed in to loosen the belt. Replace the “L” end
into the top hole in the cam and replace the hair pin clip.
Adjust the cam stop bolt P#(K1159) to allow the cam to
rotate slightly over center when the blower is engaged
(Figure 2-7).
Thread (1) 5/16”-18 jam nut P#(K0120) onto each end of
(2) 5/16”-18 x 2-1/2” HHCS P#(K0125) as shown in
Figure 2-8a.
2-8 Blower Cone Installation
Now partially thread (1) bolt into each of the two
threaded bosses located on the blower housing. Place
blower cone so the two tabs line up with the bolts and
tighten completely as shown in Figure 2-8b.
Once the (2) bolts are tight, tighten the jam nuts against
the threaded boss as shown in Figure 2-8c.
Refer to Figure 2-8d for proper blower cone installation
reference.
Figure 2-7
Cam
Assembly
Cam Stop
Bolt
Tension
Rod
Figure 2-8a
Thread (1) Jam Nut
Onto Each 5/16”-18 Bolt
Figure 2-8b
Threaded
Boss
Blower
Cone Tab
Figure 2-8c (1st) Tighten
Bolt
(2nd) Tighten
Jam Nut
Figure 2-8d
Blower
Cone

11
2-9 Main Frame Assembly Installation
Secure the main frame assembly P#(A0601) to the lower
main frame bracket P#(B0873) using (4) 3/8”-16 x 1”
HHCS P#(K1191) and (4) 3/8”-16 nylon flange locknuts
P#(K2038). Refer to Figure 2-9.
Main Frame
Assembly
Lower Main
Frame Bracket
(2) 3/8”-16 x 1”
Hex Bolts
(4) 3/8”-16
Locknuts
(2) 3/8”-16 x 1”
Hex Bolts
Figure 2-9

12
2-10 Lift Handle Installation
NOTE: Before continuing the lift handle installation,
have someone assist you in turning the grass container
upside down. Insert (1) 3/8”-16 x 2” HHCS P#(K1208)
into the lift handle P#(A0273), and secure with (1) 3/8”-
16 flange nut P#(K1215). Thread the flange nut onto the
bolt upside down, as shown in Figure 2-10a. Do not
tighten the nut fully at this time.
Slide the lift handle through the slot on the handle mount
bracket. Insert the lift handle into the box frame as
shown in Figure 2-10b, and secure using (1) 3/8”-16
flange nut P#(K1215) on the inside of the container as
shown in Figure 2-10c. Now test the movement of the
handle. It should have full-range of movement in the slot.
If the handle does not have full-range of movement,
adjust the 3/8”-16 flange nut from step 2-10a. Once
achieved, tighten the fasteners.
Fasten the ball joint P#(K1442) to the end of the latch
rod P#(A0620). Tighten the ball joint to approximately
half way down the threads on the latch rod. Attach the
ball joint to the latch hook as shown in Figure 2-10d,
using (1) 5/16”-24 hex nut P#(K1444) and (1) 5/16” lock
washer P#(K0043).
Attach the other end of the latch rod to the lift handle, as
shown in Figure 2-10e. Attach one end of the spring
P#(J0176) to the lift handle and the other end of the
spring to the handle mount bracket as shown in Figure
2-10f. Adjust the ball joint up or down on the latch rod
threads until the latch hook closes completely. After
adjusting the latch hook, secure the latch rod to the lift
handle using (1) cotter pin P#(K0094).
Insert (1) 3/8”-16 x 2”
HHCS Into The Lift Handle
Secure With
(1) 3/8”-16 Flange Nut
Figure 2-10a
Slide Lift Handle Through
Handle Mount Bracket And
Fasten To Box Frame
Use (1) 3/8”-16 Flange Nut
On The Inside Of The
Grass Container
Figure 2-10b
Figure 2-10c
Ball Joint
Latch Rod
Latch Hook (1) 5/16”-24 Hex Nut
(1) 5/16” Lock Washer
Figure 2-10d
Attach Latch Rod
To Lift handle
Secure With
(1) Cotter Pin
Attach Spring To
Lift Handle And To
Handle Mount Bracket
Figure 2-10e
Figure 2-10f

13
2-11 Aluminum Grass Container
Installation
NOTE: It is recommended that (2) people assist in
mounting the container. Lower the container onto the
frame while inserting the pivot pins P#(K0172) through
the holes. Insert the pins from the outside to the inside.
Secure with (1) 5/8” washer P#(K0058) and (1) 5/32” x
2-5/8” hair pin clip P#(K0088) per pivot pin (Figure 2-
11b). Reattach the bottom ends of the door opening
linkages to the main frame by using (1) Rue-Ring cotter
pin P#(K1437) per side. To test the functionality of the
dump mechanism, pull the lift handle away from the unit,
and lift upward. The door of the container should open
and the box should pivot clockwise towards the ground.
The linkage may be adjusted in two places, at the
adjusting screw P#(K1435) and the latch assembly
items. See page 18 for visual clarification. To change the
door closure tightness, thread the adjusting screw
(Figure 2-12) in or out. To adjust the latch, change the
length of the latch rod by threading the latch adjusting
ball joint in or out. The latch hook pivot should be in the
middle of the slot in the latch hook pivot plate. Slide the
pivot back or forth and then re-tighten.
2-12 Dump Mechanism Adjustment
Rue-Ring
Cotter Pin
Adjustment
Screw
Figure 2-12
Attach
Here
Figure 2-11a Box Assembly
Figure 2-11b
Washer
Hair Pin
Clip
Pivot
Pin

14
Secure the boot plate P#(B0820) to the aluminum boot
P#(E1902) using (2) 3/8”-16 x 1” carriage bolts
P#(K1182) and (2) 3/8”-16 nylon flange locknuts
P#(K2038). Insert the carriage bolts from the inside of
the boot so the threads are on the top of the boot. This
will prevent grass clippings from collecting on the
threads. Leave the hardware loose until the boot plate
has been attached to the mower deck. Refer to Figure 2
-13a and 2-13b for reference.
2-13 Boot Plate Installation
Remove the hardware from the grass deflector and
insert (1) boot rod P#(B4331) into the grass deflector
mounting holes as shown in Figure 2-13a. Secure the
boot rod using (1) hair pin clip P#(K0099). With the
carriage bolts from Section 2-13a still loose, adjust the
position of the boot so that there is no gap between the
mower deck and the boot. Tighten the hardware at this
time.
2-14 Boot To Mower Deck Installation
Boot Rod
(2) 3/8”-16 x 1”
Carriage Bolts
(2) 3/8”-16
Locknuts
Boot Plate
Aluminum
Boot
Hair Pin
Clip
Figure 2-13a
Figure 2-13b
Boss XL
Mounting Holes

15
2-18 Lower Hose To Blower Cone
the lower hose. Then proceed to slide the lower hose
Installation
Slide a hose clamp P#(J0080) over both ends of
2-19 Lower Hose To Boot Installation
(away from yourself) approximately 1” to aid in retaining
boot to mower deck.
clamp to secure the hose to the boot (Figure 2-19). Tip:
Before securing clamp rotate hose counter-clockwise
Note: For maximum collection system performance,
adjust the hose lengths (Step 2-19) to achieve the
smoothest transition between components. Avoid any
sharp bends in the upper and lower hoses.
over the circular end of the boot. Use the lower hose
onto the blower cone. Tighten the hose clamp. Refer to
Figure 2-19.
Take the unattached end of the lower hose and slide it
Slide a pre-assembled hose clamp P#(J0060) onto both
The hoses in steps 2-17 and 2-18 must be cut to fit your
Remember that the hoses need to be long enough to
ends of the 6” upper hose (Figure 2-19). Slide one
2-16 Length Of Hose Adjustment
machine. Follow steps 2-17 and 2-18. Do not cut the
hoses until you have tried to fit them on your machine.
allow for the opening and closing of the collection
system, PTO blower housing engagement, as well as
allowing ample clamping surface between each
component.
2-17 Upper Hose Installation
end of the 6” hose onto the plastic inlet P#(V1054).
Make sure there is about a two-inch overlap between the
hose end and the hose ring. Proceed to slide the
opposite end of the 6” hose onto the outlet of the blower
assembly. See (Figure 2-19) for details. Make sure both
ends of the hose are clearly attached to the inlet and the
blower assembly inlet. Tighten the hose clamps.
Blower
Cone
Blower
Outlet
Upper
Hose
Lower
Hose
Inlet
Hose
Clamp
Hose
Clamp
Boot
Figure 2-19

16
3
2
4
5
1
3
5
6
7
8
9
10
12
13
11
14
9Taper-Lock Bushing
Enlarged View
1 - Try carefully hitting the base of the impeller blade
(#1), between each vein (#12), with a rubber mallet to
loosen the taper-lock bushing hold.
To Replace: First, place the impeller blade (#1) over the
drive shaft (#13). Next, slide the taper-lock bushing (#9)
on to the drive shaft and into the impeller blade, aligning
the non-threaded holes (#14) of the taper-lock bushing
to the threaded holes of the impeller blade. Then, fasten
by using two 1/4”-20 x 1” HHCS (#10), one spacer
bushing (#8) one taper lock bushing washer (#7), and
one 3/8”-16 x 1-1/2” HHCS (#6). Torque all bolts to the
specifications located in the chart towards the back of
this manual. Last, rotate the impeller blade to ensure
that the blade is clear of contact on all sides of the
blower housing.
Tips on removing impeller blade;
2 - Spray break-free lubricant into the surrounding areas
of the taper-lock bushing (#9) and repeat Tip 1.
To Remove: First, remove one 3/8”-16 x 1-1/2” HHCS
P#(K1211) (#6), one taper-lock bushing washer
P#(K0278) (#7) and one spacer bushing P#(S3242) (#8)
from the taper-lock bushing (#9). See Figure 2-20. Next,
remove two 1/4”-20 x 1” HHCS (#10) and place them
into the threaded holes (#11) of the taper-lock bushing
P#(S4302). Last, gradually thread each bolt evenly into
the taper-lock bushing, forcing the blade to break-away
from the taper-lock bushing.
To gain impeller blade (#1) access, first remove the
blower cone (#2) from the blower housing, located on
the PTO assembly P#(A1821), by removing two blower
cone bolts and nuts (#3). Next, remove the blower
housing front (#4) by removing seven bolts and nuts (#5)
around the outer housing edge. Refer to Figure 2-20.
2-20 Impeller Blade
Removal/Replacement
Figure 2-20

17
Before installing Weight Kit, remove the front step and
mounting hardware from the front caster assembly.
Reference your Country Clipper owner’s manual and
Figure 2-21a. Fasten the Weight Brackets P#(B0418)
and the Weight Bracket Clamps P#(B0834) to the front
casters using (4) 3/8”-16 x 1” Carriage Bolts P#(K1182)
and (4) 3/8”-16 Ny-Flange Locknuts P#(K2038). Tighten
bolts only finger tight at this point. Insert (3) Weight
Assemblies P#(A0852) into the Weight Mount Brackets.
Secure the Weight Assemblies using (2) 3/8” x 6-1/8”
Clevis Pins P#(K1624) and (2) hair pin clips P#(K0086).
Last, tighten the nuts on the Weight Bracket Clamps.
See Figure 2-21b for reference.
2-21 Front Weight Installation
Remove
Front Step
Caster
Assembly
Figure 2-21b
Weight
Assembly
Front
Caster
(1) Hair Pin Clip
(1) Clevis Pin
(2) 3/8”-16 x 1”
Carriage Bolts
(2) 3/8”-16 Locknuts
PER BRACKET
Weight
Bracket
Figure 2-21a
Weight Bracket
Clamp

18
A0794
ALUMINUM GRASS
CONTAINER
EXPLODED VIEW

19
A1841_01 PTO Arm Assembly

20
A1941_01 PTO Base Assembly Exploded Parts View
