pellenc C45 User manual

PRUNING SHEARS
C45
Operating instructions 163529-A
01/2022
ENG
Translation of the original op-
erating instructions manual
READ THE USER GUIDE CAREFULLY BEFORE USE
.

PRUNING SHEARS C45
163529-A
TABLE OF CONTENTS
1. INTRODUCTION ..................................................................................................................... 5
2. SAFETY ................................................................................................................................... 6
2.1. INTENDED USAGE .......................................................................................................................... 6
2.2. GENERAL POWER TOOL SAFETY WARNINGS .......................................................................... 6
2.2.1. WORK AREA SAFETY ...................................................................................................................... 6
2.2.2. ELECTRICAL SAFETY ....................................................................................................................... 6
2.2.3. PERSONAL SAFETY ......................................................................................................................... 7
2.2.4. POWER TOOL USE AND CARE ........................................................................................................ 7
2.2.5. BATTERY TOOL USE AND CARE ..................................................................................................... 7
2.2.6. SERVICING ....................................................................................................................................... 8
2.2.7. MANAGEMENT OF THE RECYCLING AND RECOVERY OF WASTE FROM YOUR TOOL ................... 8
2.3. SAFETY MEASURES RELATED TO THE USE OF THE BATTERY AND THE CHARGER "PEL-
LENC" ...................................................................................................................................................... 8
2.4. SAFETY WARNINGS FOR BATTERY-POWERED SHEARS ........................................................ 9
2.5. SAFETY SIGNAGE .......................................................................................................................... 9
2.6. PERSONAL PROTECTION EQUIPMENT ..................................................................................... 10
3. DESCRIPTION AND TECHNICAL FEATURES ................................................................... 10
3.1. DESCRIPTION OF THE TOOL ...................................................................................................... 10
3.2. TECHNICAL FEATURES OF THE PRUNING SHEARS C45 ....................................................... 11
4. COMMISSIONING ................................................................................................................. 12
4.1. CONNECTING THE TOOL TO THE BATTERY ............................................................................ 12
4.2. TURNING ON THE TOOL WITH ACTIVSECURITY ACTIVATED (FACTORY SETTING) ........... 12
4.3. TURNING ON THE TOOL WITH ACTIVSECURITY DISABLED .................................................. 13
5. USAGE .................................................................................................................................. 13
5.1. USAGE TIPS .................................................................................................................................. 13
5.2. TOOL SAFETY ............................................................................................................................... 13
5.2.1. DEACTIVATION OF ACTIVSECURITY ............................................................................................. 13
5.2.2. ACTIVATION OF ACTIVSECURITY .................................................................................................. 14
5.2.3. CHECKING THE ACTIVSECURITY SYSTEM .................................................................................... 15
5.3. OPTICAL TRIGGER - HALF OPENING ........................................................................................ 16
5.4. USAGE MODES ............................................................................................................................. 17
5.4.1. CHANGING USAGE MODE ............................................................................................................. 17
5.4.2. PRESENTATION OF USAGE MODES .............................................................................................. 17
5.5. "FUNCTIONAL" SETTINGS MODES ............................................................................................ 19
5.5.1. CHANGING THE "FUNCTIONAL" SETTINGS MODE ........................................................................ 19
5.5.2. PRESENTATION OF "FUNCTIONAL" SETTINGS MODES ................................................................ 20
5.6. AUTHORISATION MODES ............................................................................................................ 20
5.6.1. CHANGE OF AUTHORISATION MODE ............................................................................................ 20
5.6.2. PRESENTATION OF AUTHORISATION MODES .............................................................................. 20
5.6.3. COMPATIBILITY: BATTERY MODE AND MODEL ............................................................................. 21
3

PRUNING SHEARS C45
163529-A
5.7. STANDBY ....................................................................................................................................... 21
5.7.1. AUTOMATIC STANDBY MODE ........................................................................................................ 21
5.7.2. MANUAL STANDBY MODE ............................................................................................................. 21
5.8. STANDBY EXIT ............................................................................................................................. 22
6. MAINTENANCE .................................................................................................................... 22
6.1. MAINTENANCE ADVICE ............................................................................................................... 22
6.2. MAINTENANCE TABLE ................................................................................................................ 23
6.3. SHARPENING THE BLADE .......................................................................................................... 23
6.4. CHECK THE TIGHTENING OF THE BLADE ............................................................................... 24
6.5. CLEANING THE TOOL .................................................................................................................. 24
6.6. CHECKING THE CROSSING OVER OF THE HOOK AND THE BLADE .................................... 25
6.7. GREASING THE BLADE ............................................................................................................... 25
6.8. CHANGING BLADE OR PINS ...................................................................................................... 25
6.8.1. REMOVAL OF THE BLADE AND ITS PIN ........................................................................................ 25
6.8.2. FITTING OF THE BLADE AND ITS PINS ......................................................................................... 26
7. INCIDENTS AND TROUBLESHOOTING ............................................................................. 28
7.1. SUMMARY OF "ACTIVSECURITY" LED CODES AND AUDIBLE SIGNALS ............................. 28
7.2. SUMMARY OF BATTERY LED CODES ON PRUNING SHEARS C45 ....................................... 28
7.3. TROUBLESHOOTING .................................................................................................................... 28
8. TRANSPORT / STORAGE ................................................................................................... 29
8.1. STORAGE ...................................................................................................................................... 29
9. ACCESSORIES AND CONSUMABLES .............................................................................. 29
9.1. ACCESSORIES .............................................................................................................................. 29
9.2. CONSUMABLES ............................................................................................................................ 30
10. WARRANTIES .................................................................................................................... 31
10.1. GENERAL WARRANTIES ........................................................................................................... 31
10.1.1. STATUTORY WARRANTY ............................................................................................................. 31
10.1.2. COMMERCIAL WARRANTYPELLENC ............................................................................................ 31
10.1.3. PAID AFTER-SALES SERVICE ...................................................................................................... 32
10.2. SPECIFIC WARRANTIES ............................................................................................................ 33
11. STATEMENTS OF COMPLIANCE ..................................................................................... 34
11.1. STATEMENT OF COMPLIANCE: C45 ................................................................................ 34
11.2. UK DECLARATION OF CONFORMITY : C45 ...................................................................... 35
4

PRUNING SHEARS C45
163529-A
1. INTRODUCTION
Dear Customer,
Thank you for purchasing your Pruning shears C45. Properly used and maintained, this equipment will give you
years of satisfaction.
Warning
Your machine contains numerous recoverable or recyclable materials. Return it to
your dealer or, failing this, to an approved servicing centre to be treated.
Comply with the regulations in force in your country as concerns environmental protection associated with your
activity.
Warning
It is imperative that you read through the ENTIRE user’s manual guide before using or servicing
the tool. Always comply with the instructions and illustrations provided in the user’s manual.
Throughout the user’s manual guide you will find advisory notes and information entitled: NOTE, IMPORTANT,
ATTENTION and WARNING.
Points marked “NOTE” indicate additional information.
Points marked "IMPORTANT" warn the user of a potential risk for the equipment.
Points marked “ATTENTION” warn the user of a potentially hazardous situations which if not avoided may result
in minor injuries.
Points marked “WARNING” warn the user of a potentially hazardous situation which if not avoided may result in
serious injury or death.
The warning indicates that damage resulting from failure to comply with the procedures and instructions is not
covered by the warranty and the owner will be liable for any repair costs.
Safety indications are also given on the tool; they remind you of the safety precautions to be taken. Identify and
read these indications before using the tool. Immediately replace any indications that may become partially illegible
or deteriorated.
Refer to Section 2.5, “Safety signage” for the location diagram of the safety stickers affixed to the tool.
No part of this manual may be reproduced without the written permission of the company PELLENC. The illustrations
provided in this manual are for information purposes only and are in no way contractual. The PELLENC company
reserves the right to make any modification or improvement to its products as deemed necessary without inform-
ing customers already in possession of a similar model. This manual forms an integral part of the tool and must
accompany the tool if it changes hands.
5

PRUNING SHEARS C45
163529-A
2. SAFETY
2.1. INTENDED USAGE
• The Pruning shears C45 is intended for wine and tree pruning, up to a diameter of 45 mm.
• The Pruning shears C45 must be operated from standing ground level or from a suitable platform that is completely
stable and secure.
• The Pruning shears C45 is intended for outdoor use only.
• The Pruning shears C45 is not intended for any other use.
• Only original or manufacturer approved spare parts (e.g. blade kit, maintenance kit) may be fitted to the Pruning
shears C45.
• The user is responsible for any accident resulting from improper use or unauthorized modification of the Pruning
shears C45.
2.2. GENERAL POWER TOOL SAFETY WARNINGS
Warning
Read all safety warnings, instructions, illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below may result in electric shock, fire and/
or serious injury.
Note
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cord-
less) power tool.
2.2.1. WORK AREA SAFETY
1. Keep the work area clean and well lit. Cluttered or dark areas invite accidents.
2. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids,
gases or dust. Power tools create sparks, which may ignite the dust or fumes.
3. Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control of the tool.
2.2.2. ELECTRICAL SAFETY
1. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs
with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
2. Avoid body contact with earthed surfaces or grounded surfaces such as pipes, radiators, ranges, and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of
electric shock.
4. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of
electric shock.
5. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
6. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) pro-
tected supply. Use of an RCD reduces the risk of electric shock.
6

PRUNING SHEARS C45
163529-A
2.2.3. PERSONAL SAFETY
1. Stay alert, watch what you are doing, and use common sense when operating a power tool. Do not use
a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal injury.
2. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal
injuries.
3. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power
source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the
switch or plugging in power tools with the switch in the on position can cause accidents.
4. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in personal injury.
5. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power
tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or jewelry. Keep your hair and clothing away from moving
parts. Loose clothes, jewelry or long hair can be caught in moving parts.
7. If devices are provided for connection of dust extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can reduce dust-related hazards.
8. Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool
safety principles. A careless action can cause severe injury within a fraction of a second.
2.2.4. POWER TOOL USE AND CARE
1. Do not force the power tool. Use the correct power tool for your application. The correct power tool will
do the job better and safer at the rate for which it was designed.
2. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
3. Disconnect the plug from the power source and/or remove the battery pack, if detachable, if from the
power tool before making any adjustment, changing accessories, or storing power tools. Such preven-
tive safety measures reduce the risk of starting the power tool accidentally.
4. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained
users.
5. Maintain power tools and accessories. Check for misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by poorly maintained power tools.
6. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely
to bind and are easier to control.
7. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into
account the working conditions and the work to be performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
8. Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasp-
ing surfaces do not allow for safe handling and control of the tool in unexpected situations.
2.2.5. BATTERY TOOL USE AND CARE
1. Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with another battery pack.
2. Use power tools only with specifically designated battery packs. Use of any other battery packs may
create a risk of injury and fire.
3. When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can make a connection from one terminal to another.
Shorting the battery terminals together may cause burns or a fire.
4. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.
7

PRUNING SHEARS C45
163529-A
5. Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion or risk of injury.
6. Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature
above 130 °C (or 265°F) may cause explosion.
7. Follow all charging instructions and do not charge the battery pack or tool outside the temperature
range specified in the instructions. Charging improperly or at temperatures outside the specified range may
damage the battery and increase the risk of fire.
2.2.6. SERVICING
1. Have your power tool serviced by a qualified repair person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
2. Never service damaged battery packs. Service of battery packs should only be performed by the manufac-
turer or authorized service providers.
2.2.7. MANAGEMENT OF THE RECYCLING AND RECOVERY OF WASTE FROM YOUR TOOL
1. When the tool reaches the end of its life, PELLENC keeps the end of life sheet of the equipment at
disposal. The end of life sheet provides instructions for safely removing components.
2.3. SAFETY MEASURES RELATED TO THE USE OF THE BATTERY AND THE CHARGER "PEL-
LENC"
Note
Please refer to the battery operating instructions.
Warning
Read all safety warnings and all instructions. Retain all the safety measures and instructions for
later reference.
8

PRUNING SHEARS C45
163529-A
2.4. SAFETY WARNINGS FOR BATTERY-POWERED SHEARS
This device is not intended for use by individuals (including children) with reduced physical, sensory or mental
capabilities, nor by anyone lacking in experience or knowledge, except if they are supervised or have received prior
instructions from a person responsible for their safety.
Warning
Read all the instructions on the ActivSecurity of your Pruning shears C45 carefully before use,
see Section 5.2, “Tool safety”.
1. Never modify the connector in any way whatsoever.
2. This tool may cause severe injuries. Read the instructions carefully about the proper handling, operation, main-
tenance, start-up and stopping of the tool. Familiarize yourself with all its controls and the proper use of the tool.
3. When the machine is not in use, always switch off the battery (both LEDs on the tool must be off).
4. Do not leave the pruning shears on the ground or outside exposed to the weather.
5. Make sure that the blade is not in contact with any object before starting the tool.
6. Never use the tool if it is damaged, incorrectly set or incompletely assembled.
7. Never remove or disable a safety device. Have the safety device repaired if is faulty.
8. Never disconnect the power cord of the tool without having checked that the red and green LEDs on the left
and right of the battery display are off.
9. Never carry the pruning shears suspended from the power cord.
10. Do not disassemble the pruning shears.
11. Do not try to cut pieces of wood that are too large or other materials than wood.
12. Please test the machine before use to check that it is working properly.
2.5. SAFETY SIGNAGE
Tool compliant with EC standards.
Tool compliant with Moroccan stan-
dards.
Read the user guide. Tool compliant with UKCA standards.
Lithium-ion battery.
At the end of its life, the battery must be returned to the authorized distributor from whom it was
purchased to be recycled in accordance with waste regulations.
9

PRUNING SHEARS C45
163529-A
2.6. PERSONAL PROTECTION EQUIPMENT
Equipment Wearing of
1 Safety helmet --
2 Protective visor --
3 Pellenc ActivSecurity gloves Recommended
4 Safety footwear Mandatory
5 Ear protection --
6 Protective goggles Recommended
7 Jacket or over-sleeves --
8 Work trousers --
3. DESCRIPTION AND TECHNICAL FEATURES
3.1. DESCRIPTION OF THE TOOL
10

PRUNING SHEARS C45
163529-A
1. Upper conductive pad
2. Blade shaft
3. Nut
4. Washer
5. Knurled adjustment washer
6. Blade
7. Hook
8. “Mode” LED (left side of the tool)
9. Guard
10. Drive trigger
11. “ActivSecurity” LED (right side of the tool)
12. Optical sensor
13. Lower conductive pad
14. Power cord connector
3.2. TECHNICAL FEATURES OF THE PRUNING SHEARS C45
Cutting capacity 45 mm
Pruning shears power supply voltage 43.2 V
Motor rated power 180 W
Battery life Depending on the use and type of battery
Weight of pruning shears 862 g
Total vibration values (triaxial vector sum) determined in ac-
cordance with EN 62841-1 (uncertainty of K=1.5 m/s²)
ah = 2.5 m/s²
Noise value measured according to EN 62841-1
Acoustic power level measured (uncertainty of K=3 dB) LWA=74 dB MAX
Level of acoustic pressure measured at the work station (un-
certainty of K=3 dB)
LpA=67 dB MAX
• The declared total vibration value (s) and the declared noise emission value (s) were measured in accordance
with a standard test method and can be used to compare tools.
• The declared total vibration value (s) and the declared noise emission value (s) may also be used in a preliminary
exposure assessment.
• It is necessary to identify safety measures to protect the operator that are based on an estimate of exposure
under actual use conditions (taking account of all parts of the operating cycle such as the times when the tool is
switched off and when it is running idle in addition to the trigger actuation time).
11

PRUNING SHEARS C45
163529-A
4. COMMISSIONING
Note
For further information on commissioning instructions, please refer to the operating instructions of the battery.
4.1. CONNECTING THE TOOL TO THE BATTERY
1. To commission the battery, refer to its operating in-
structions.
2. Make sure the battery is switched off before plug-
ging in the tool.
3. Align the marker (1) of the tool power cord with the
slot (2) of the tool connector.
4. Connect the tool power cord (3) to the tool.
5. Tighten the tightening ring (4) of the tool cord com-
pletely.
Important
Risk of false contact and tool stoppage if the tight-
ening ring is not fully tightened.
4.2. TURNING ON THE TOOL WITH ACTIVSECURITY ACTIVATED (FACTORY SETTING)
1. Turn on the battery by pressing the on/off button
and wait for the battery to beep 5 times. The "Ac-
tivSecurity" LED flashes red.
2. Take the tool in your hand, making sure your fin-
gers are in contact with one of the conductive pads.
3. Position the index finger of the hand holding the
tool on the trigger.
4. Pinch each side of the blade shaft with the other
hand. The "ActivSecurity" LED turns solid red.
5. Release the blade shaft. The "ActivSecurity" LED
lights up blue and the tool beeps.
Note
The light is blue when there is contact with one of the conductive pads and the trigger.
6. Press the trigger to activate the tool.
Note
Do not touch the cutting head and maintain contact with at least one of the two conductive pads for the tool
to work.
12

PRUNING SHEARS C45
163529-A
4.3. TURNING ON THE TOOL WITH ACTIVSECURITY DISABLED
1. Turn on the battery by pressing the on/off button and wait for the battery to beep 5 times. The "ActivSecurity"
LED flashes red.
2. Take the tool in hand and pull the trigger.
The tool emits three alarm beeps and then the blade opens. The tool is ready for use.
Deactivating the safety system exposes the user to the risk of serious and deep cuts.
Warning
The tool operates with the safety system off, exposing the user to the risk of serious and deep
cuts.
5. USAGE
5.1. USAGE TIPS
• You must take all necessary care to prevent catching the lead of the pruning shears in the branches. To do this,
attach the cord to the arm using the armband provided (see battery operating instructions manual).
• The operating time and service life of the pruning shears mainly depend keeping the blade properly sharpened
and tightened.
• It is imperative to remove the burrs from the cutting edge of the blade and to perform the first sharpening within
the first 15 minutes of use, see Section 6.3, “Sharpening the blade”.
• For an optimal cutting quality, check the blade tightening regularly, see Section 6.4, “Check the tightening of the
blade”.
• We recommend that you do not disconnect the lead of the pruning shears from the battery unit after use each
day, but instead wind it around the "battery" unit and replace them both in their carry-case.
Different operating modes are available to best suit your working habits (indicated on the display).
5.2. TOOL SAFETY
5.2.1. DEACTIVATION OF ACTIVSECURITY
Warning
The user is strongly advised against disabling ActivSecurity.
Disabling ActivSecurity exposes the user to the risk of serious and deep cuts.
The user is responsible for any accidents that occur as a result of deactivating the ActivSecurity.
The deactivation of the safety system is recorded in the battery's black box.
Important
Carry out this operation without gloves. Do not wear gloves.
1. Turn on the battery by pressing the on/off button and wait for the battery to beep 5 times.
13

PRUNING SHEARS C45
163529-A
Note
Do not have your finger over the optical sensor when switching on the battery.
Within 10 seconds of starting the tool:
2. Take the tool in your hand, making sure that your
fingers are in contact with one of the two conductive
pads (1).
3. Place the index finger in front of the optical sensor
(2) for 1 second.
4. Press the trigger (3) in fully and release it.
5. Place the index finger in front of the optical sensor
(2) for 1 second.
Note
• An alarm sound and the "mode" LED (4) turning
red means that the ActivSecurity is deactivated.
• When the security is deactivated, the tool emits
an alarm sound each time it is switched on and
off.
5.2.2. ACTIVATION OF ACTIVSECURITY
Warning
ActivSecurity is based on electrical conduction and is only optimal with the use of Pellenc Ac-
tivSecurity Gloves.
When working in wet conditions, wearing gloves increases safety effectiveness.
If you put on gloves that you did not have at the beginning of the day, or if you change your
conductive gloves during the day, make sure they are compatible with the ActivSecurity system
by restarting the tool and activating the security.
Warning
The safety system only protects the user holding the tool, any other persons is not protected.
ActivSecurity and Pellenc gloves reduce the risk of cuts but risk remains. Always be careful
when using the pruning shears.
Important
Carry out this operation without gloves. Do not wear gloves.
14

PRUNING SHEARS C45
163529-A
1. Turn on the battery by pressing the on/off button and wait for the battery to beep 5 times.
Note
Do not have your finger over the optical sensor when switching on the battery.
Within 10 seconds of starting the tool:
2. Take the tool in your hand, making sure that your
fingers are in contact with one of the two conductive
pads (1).
3. Place the index finger in front of the optical sensor
(2) for 1 second.
4. Press the trigger (3) in fully and release it.
5. Place the index finger in front of the optical sensor
(2) for 1 second. The tool issues a warning to con-
firm the activation of ActivSecurity.
6. Check the correct functioning of the ActivSecurity,
see Section 5.2.3, “Checking the ActivSecurity sys-
tem”.
Important
The safety systems have their limits. The user of the tool will need to be vigilant to ensure that the tool works
properly.
5.2.3. CHECKING THE ACTIVSECURITY SYSTEM
Each time the tool is switched on, the safety device is waiting to be initialised.
Warning
In the event of any problem, consult an authorized distributor PELLENC.
Warning
For the proper functioning of the safety system, it is imperative to wear Pellenc ActivSecurity
gloves or no gloves at all. The use of any other gloves is prohibited.
15

PRUNING SHEARS C45
163529-A
Once the tool has been activated, ensure that the Ac-
tivSecurity system is working properly:
1. Take the tool in your hand, making sure that your
fingers are in contact with one of the two conductive
pads (1).
2. Place the index finger of the hand holding the tool
on the trigger (2).
3. Apply pressure to the lower edge of the hook (3) with
the opposite hand. The "ActivSecurity" LED turns
solid red.
4. Remove the opposite hand from the hook (3) and
ensure that the "Activsecurity" LED (4) lights up blue.
5. Check the correct operation of the blade according
to the position of the trigger.
Note
When the blade is held in the open position and the battery beeps upon simultaneous contact with all 3
conductive surfaces, the ActivSecurity is functioning. In case of malfunction, try to increase the contact area
with the tool and wear/replace your conductive gloves.
5.3. OPTICAL TRIGGER - HALF OPENING
In half-open mode, the blade remains in half-open position as long as the optical system (4) detects that your finger
is in front of the trigger (2). When your finger moves away from the trigger, the optical system controls the full
opening of the blade (3).
For more information on adjusting the sensitivity of the optical sensor, refer to the operating instructions manual
of the battery.
Note
The kind of gloves worn can have an effect on the way the optical trigger works. We recommend not wearing
black gloves.
Important
If the optical trigger stops working properly, check that there is nothing obstructing the slot in the trigger or
clean the window of the optical sensor with rubbing alcohol.
16

PRUNING SHEARS C45
163529-A
5.4. USAGE MODES
When leaving the factory, the pruning shears are set in "progressive" mode (C2).
5.4.1. CHANGING USAGE MODE
1. Turn the battery on, with the tool connected,
2. Press the "mode" button,
3. Select modes C1, C2, C3 or C4 by pressing + or -,
4. Press the "mode" button to validate.
5.4.2. PRESENTATION OF USAGE MODES
Mode C1: PROGRESSIVE WITH HALF-OPENING
• Progressive operation with half-opening.
17

PRUNING SHEARS C45
163529-A
Mode C2: PROGRESSIVE (factory mode)
• Progressive operation without half-opening.
Mode C3: ON/Off HALF-OPENING
• Fast, "On/Off" operation, with half-opening.
Mode C4: ON/Off
• Fast On/Off operation without half-opening.
18

PRUNING SHEARS C45
163529-A
5.5. "FUNCTIONAL" SETTINGS MODES
5.5.1. CHANGING THE "FUNCTIONAL" SETTINGS MODE
1. Turn the battery on, with the tool connected,
2. Press the "mode" button,
3. Select the mode by pressing + or -,
4. Press the "mode" button to validate,
5. Press + or - to adjust the setting from 1 to 9, see Section 5.5.2, “Presentation of "functional" settings modes”,
6. Press the "mode" button to validate.
19

PRUNING SHEARS C45
163529-A
5.5.2. PRESENTATION OF "FUNCTIONAL" SETTINGS MODES
Pruning shears mode Description Adjusting the setting
F5: Blade crossing setting Adjust the blade crossing. 1 - 9: Low crossing - high crossing
F6: Adjusting the half-opening Adjust the blade half-opening. 1 - 9: Narrow opening - wide opening
F7: Adjusting optical sensor
sensitivity
Adjust the sensitivity of the blade's
optical sensor.
1 - 9: Very sensitive - not very sensitive
1 - 8: Minimum time limit - maximum time
limit
F8: Tool standby delay setting Adjust the amount of time the trig-
ger is held down before the tool
goes to standby. 9: No standby mode
5.6. AUTHORISATION MODES
5.6.1. CHANGE OF AUTHORISATION MODE
1. Disconnect the pruning shears and turn on the battery,
2. Press the "mode" button,
3. Select the mode by pressing + or -,
4. Press the "mode" button to confirm,
5. After setting the mode, turn off the battery and then reconnect the tool.
5.6.2. PRESENTATION OF AUTHORISATION MODES
You can set the parameters for the tool's adjustment level to make it easier to use.
• L1: “Normal" mode: the user has access to the 4 operating modes C1 to C4 but without any possibility of adjust-
ments.
•
L2: “Expert" mode: the user has access to the 4 operating modes C1 to C4 and the four settings F5 to F8.
20
