Huck 2015 Series User manual

c Huck International, Inc. 1999 HK 958 Rev. 06/05/01
U.S. patents Des. 369732; 369733; 371299, 5490311
INSTRUCTION MANUAL
2015 ALL MODELS
PNEUDRAULIC INSTALLATION TOOL
HUCK FASTENERS
HUCK FASTENERS
HUCK FASTENERS
HUCK FASTENERS
HUCK FASTENERS
HUCK FASTENERS
HUCK FASTENERS
HUCK FASTENERS

EU Declaration of Conformity
Manufacturer:
Huck International Inc., Installation Systems Division, 85 Grand Street, Kingston, NY, 12401,
USA
Description of Machinery:
Model number 201 family of fastener installation tools
Relevant provisions complied with:
Council Directive related to Machinery, (89/392/EEC), (91/368/EEC), (93/44/EEC),
(93/68/EEC)
European Representative:
Rob Pattenden, Huck International, Ltd. Unit C Stafford Park 7, Telford Shropshire TF3 3BQ,
England, United Kingdom
Authorized Signature/date:
I, the undersigned, do hereby declare that the equipment specified
above conforms to the above Directive(s) and Standard(s).
Signature:
Full Name: Renno Budziak
Position: Vice President of Engineering, Installation Systems Division
Place: Kingston, New York, USA
Date: November, 1995
2015 TOOLING HUCK FASTENERS

2015 TOOLING HUCK FASTENERS
Huck Model 201 (family) Sound Level
SEL --- 75.7 dB (A)
peak value = 104.4 dB (C)
For an eight hour work day, installing 3000 typical Huck fasteners will result in an
equivalent noise level (Leq) of 65.9 dB (A).
To calculate equivalent noise level for other quantities of fasteners in an eight hour
period, use the formula:
Leq = SEL + 10 log (n/28,800)
where n = number of fasteners in eight hours.
Huck Model 201 (family) Vibration Level
For an eight hour work day, installing 3000 typical Huck fasteners will result in an
equivalent weighted RMS vibration level (Aeq) of 12.25rn/s2.
To calculate the equivalent vibration level for other quantities of fasteners in an eight
hour period, use the formula:
Equivalent Vibration Level, Aeq (rn/s2) = (n/480) x 1.96
where n = number of fasteners in eight hours, and 1.96 (m/s2) = Aeq for 60 seconds
Test data to support the above information is on file at Huck International, Inc. Kingston, N.Y. Vibration
measurements are frequency weighted in accordance with ISO 8041 (1990).

2015 TOOLING HUCK FASTENERS
CONTENTS
Section Page
Summary of Safety Guidelines 1, 2, 3
Description 5
Specifications 5
2015 series Outline Dimensions 6, 7
Principle of Operation 8
Preparation for Use 9
Operating Instructions 10
Maintenance 10
Good Service Practices 10
Standard Tools 11
Preventive Maintenance 11
Tool Maintenance 11
Nose Assembly Maintenance 11
Filling and Bleeding/Measuring Stroke Procedure 12 - 15
Troubleshooting 16
Spare Parts and Service Kits 16
Disassembly 17 - 30
Assembly 19 - 32
Sub-assembly Part Numbers and Notes 33
Specifications for Standard Parts 34
Accessories: Tools, Components and Kit 35, 38
Service Kits, 2012KIT and 2012BKIT 36
Service Kit, 2012VKIT 37

2015 TOOLING HUCK FASTENERS
ILLUSTRATIONS
Figure Page
1. 2015 series Outline Dimensions 6, 7
2. Main Components 8
3. Filling and Bleeding Procedure 12 - 15
3.5 Checking Tool Stroke with Stall-nut 14
3.6 Checking Tool Stroke without Stall-nut 15
4. 2015 Head/handle 19
5. Air Cylinder and Gland Assembly 20
5.1 Gland Assembly, 116134-1 20
6. Throttle Valve Sub-assembly and Related Components 21
7. Swivel Sub-assembly and Fill Plug Sub-assembly 22
8. 2015B Head/handle 23
9. 2015V Head/handle 24
10. 2015V Assembled Vacuum Attachment 25
11. Exploded View of Vacuum Attachment 26
12. Removing Piston and Front Gland 28
13. Installing Piston and Front Gland 29
14. Anvil Inserts used With Pintail Tube 35
15. 2015 with Suspension Spring 38

An important notice:
Operator must read and understand any
WARNING and Caution stickers/labels
supplied with equipment before connecting
equipment to any primary power supply — as
applicable, the following sections each have
specific safety, and other, information:
• WARNINGS and CAUTIONS
• DESCRIPTION
• SPECIFICATIONS
• PRINCIPLE OF OPERATION
• PREPARATION FOR USE
• PREVENTIVE MAINTENANCE
• OPERATION AND TOOL HANDLING
As applicable, the disassembly and assembly
sections contain specific overhaul and safety
procedures.
Only persons who have read and understood all
applicable manuals or received training
approved by Huck International, Inc. will be
able to use Huck equipment with personal
safety and efficiency.
If you require additional information, contact
your local Huck representative or the nearest
office listed on the back cover.
SAFETY GLOSSARY
WARNINGS must be understood to avoid
severe personal injury.
Cautions show conditions that will damage
equipment and/or structure.
Notes are reminders of required procedures.
Italic type and underlining strengthens a
specific instruction.
1
2015 TOOLING HUCK FASTENERS
WARNINGS
When operating Huck installation equipment
always wear approved eye protection.
Whenever within the working environment,
wear approved eye protection, with side
shields, to protect from anything that
breaks on the fastening system including:
Erupting fluid lines, flying fastener particles
or any other dirt/debris that could cause eye
injury. Where applicable, refer to ANSI
Z87.1 - 1989.
Disconnect primary power source before
doing maintenance on Huck equipment.
• For electrically operated POWERIG®
Hydraulic Units, unplug the power cord
from the socket. If there is no plug, turn
off the power at the disconnect switch.
Follow lockout/tagout procedures In
force by your employer.
• For equipment powered by compressed
air, disconnect the air hose before doing
any maintenance.
• For hydraulic tools, or other hydraulic
equipment, disconnect the hydraulic
hoses from the hydraulic unit before
doing any maintenance.
If any equipment shows signs of damage or
leakage, DO NOT connect it to the primary
power supply (either electrical or
compressed air) - - and do not continue to
use equipment that deveiops erratic
symptoms. If equipment is damaged, or
there are other serious discrepancies,
affected equipment may rupture violently
- - parts may strike the operator, and/or
other personnel, and cause severe personal
injury. Ensure that ALL air and/or
hydraulic hose and/or electrical
plugs/connectors are correctly connected
before switching on power supply to
equipment. If incorrectly connected, the
tool may respond erratically and cause
severe personal injury.
continued. . . 7-1-97

Except where noted, these are WARNINGS
and involve possible serious personal
injury. There may be other WARNINGS,
Cautions and Notes in the manual that
must be checked before operating
installation tools:
1. Only Huck Installation Equipment should
be used to install Huck fasteners.
2. Only persons that have received training
approved by Huck International, Ltd.
should use Huck Installation Equipment.
3. The Manuals, Nose Assembly Data
Sheets, and WARNING stickers supplied
with the installation equipment should be
studied before connecting the equipment to
any primary power supply, in particular
the following sections require complete
understanding:
• WARNINGS and Cautions
• SPECIFICATIONS
• ELECTRICAL and/or AIR SUPPLY
• PRINCIPLE OF OPERATION
• PREPARATION FOR USE
• OPERATING INSTRUCTIONS
• MAINTENANCE
4. With hydraulic tooling, be sure that it is
suitable for use with the POWERIG®
Hydraulic Unit or Huck approved
handpump being used.
2
2015 TOOLING HUCK FASTENERS
5. Check that hydraulic unit or approved
hand pump PULL and RETURN
pressures have been adjusted to suit the
tool being used. Refer to the specific
instruction manual supplied with the
equipment.
6. Caution: Check that the nose assembly is
the correct type and size suitable for
installing the fastener being used.
7. Visually check ALL pneumatic and
hydraulic hoses, electrical cables,
hydraulic units. hand pumps and hand
tools for any visible signs of damage and
leakage.
8. Do not connect any equipment to primary
power supplies. or attempt to use any
equipment that shows signs of damage or
leakage.
9. Be sure that ALL air and hydraulic hoses
and electrical cords are correctly connected
before switching on power supply to
equipment
10.Disconnect primary power source before
doing ANY maintenance on either
hydraulic unit or on equipment
connected to the unit.
2-18-9 7
Preparing to Safely Operate
Huck Fastener Installation Equipment
Using CE and General Safety Guidelines

2015 TOOLING HUCK FASTENERS
3
Except where noted, these are WARNINGS
and involve possible serious personal
injury. There may be other WARNINGS,
Cautions and Notes in the manual that
must be observed when operating the
equipment:
I. Approved eye protection (e.g. safety
glasses) must be worn by the operator.
2. When using fasteners in some types of
structure, the fracturing of the pintail
during installation may generate noise
levels above the first action level of the
Noise at Work Regulations and therefore
approved hearing protection must be worn.
3. NEVER look directly at the front or rear
of the installation tool when it is in use.
4. NEVER use the nose assembly for a tool
handle. Do not grip the nose assembly
during fastener installation.
5. Keep hands/fingers clear of any moving
parts and away from holes in nose
assemblies.
6. DO NOT pull on a pin (fastener) without a
collar. When there is only one collar
chamfer, it MUST be out toward the tool
-- NOT against the workpiece. Fastener
will eject at high velocity when pintail
fractures and may cause serious injury.
7. DO NOT pull on a fastener’s pintail
without first placing the fastener in a
workpiece. Fasteners installed “in
air” will eject at high velocity when the
pintail fractures and may cause serious
injury.
8. Keep fingers clear from the underside of
the head (blind side) and collar of the
fastener. Keep fingers from within the
joint.
9. Do not look directly at the head, or blind
side, of fasteners during the installation
cycle.
10.KEEP HANDS CLEAR during the
installation cycle as the tool will pull and
straighten itself to the axis of the fastener.
Beware of hands being trapped against
any nearby structure.
11. NOTE: The trigger on the tool is the
operator’s direct link to controling swaging
movement. Releasing the trigger at any
time during the installation cycle will
immediately put the tool into reverse.
12.Beware of fastener pintails which are
ejected, (sometimes forcibly), when pintail
breaks during the installation cycle. The
pintail deflector, bottle, or catcher must
always be in place on the tool - - direct
deflector away from people.
13.Do not continue to use any equipment that
develops any type of malfunction while
being used.
14.Do not drag hoses and electrical cables.
Avoid kinking hoses.
Safe Operation and Handling
of Huck Fastener Installation Equipment
Using CE and General Safety Guidelines

4
2015 TOOLING HUCK FASTENERS
-------------------- SERVICE NOTES:---------------------

5
Pulling action of the pull piston is provided by
a pneumatic-hydraulic (pneudraulic)
intensifier system powered by 90-100 psi air
pressure. The air inlet is equipped with a
connector with 1/4-18 female pipe threads to
accept your air hose or quick connect fitting.
The piston return stroke is spring actuated.
SPECIFICATIONS
•Min. Stroke: .683
•Air Pressure: 90-100 psi
•Speed/Cycles: 30 per minute
•Air Consumption: 4.3 CFM
MODEL 2015 TOOL All Models HUCK FASTENERS
DESCRIPTION
The Model 2015 series tools are lightweight,
high speed production tools designed to
install 3/32 and 1/4 nail type blind fasteners.
An integral nose asembly increases
reliability and simplifies use of this tool.
The 2015V, with vacuum boost selector
switch ON, has two functions:
1. With tool in any position, vacuum holds
fastener firmly in nose assembly.
2. Vacuum expels broken pintail into pintail
collector.
•Weight of 2015: 4.9 lbs
•Weight of 2015B & 2015V: 5.2 lbs
•Min. Capacity: 2670 lbs @ 90 psi
Fasteners installed: Consult your Huck representative or available FASTENER SELECTION
CHARTS.
Hydraulic Fluid: Automatic Transmission Fluid, DEXRON Ill, or equivalent.

2015 TOOLING HUCK FASTENERS
6
Figure 1 - 2015 and 2015B Outline Dimensions

2015 TOOLING HUCK FASTENERS
7
Figure 1A - 2015V Outline Dimensions

When tool is connected to proper air supply,
air pressure holds throttle valve in the up
position - - air pressure is directed to the top of piston
keeping it down. Depressing trigger moves throttle
valve to the down position - - air is
directed to the bottom of the piston moving it
upward, air from above piston is exhausted
downward thru the throttle valve and exits the
muffler at bottom of tool. Air piston
rod is a hydraulic piston. Pressurized
fluid is forced into the cylinder head moving
pull piston rearward. The nose, which
is connected to the pull piston, will install the
fastener during the rearward piston movement.
8
2015 TOOLING HUCK FASTENERS
When fastener installation is completed, and
upon trigger release, air pressure causes
throttle valve to return to its up position - - air
flow reverses. The air piston and rod move
down to their starting position, exhausting air
from below the piston through the muffler at
bottom of tool. As rod moves downward and
hydraulic pressure is released from pull piston,
a spring behind pull piston returns it to its
starting position.
Figure 2 - Main Components
PRINCIPLE OF OPERATION

9
WARNING
As applicable, do not use without deflec-
tors or pintail bottles.
If deflectors are removed or damaged,
separated pintails may eject forcibly from
rear of tool. Unshielded eyes, especially,
may be permanently injured. Other severe
injuries can be caused by flying pintails. If
there is any chance of a projectile-like
ejection, always point rear of tool in a safe
direction, or be sure there is some struc-
ture that will stop ejecting pintails.
WARNING
To avoid pinch points, be sure there is
adequate clearance for tool and operator’s
hands before proceeding. Tool moving
toward structure may crush hands or
fingers between tool and structure if
clearance is limited.
The 2015 is equipped with a plastic plug in
the air inlet connector. Connector has 1/4-18
female pipe threads to accept the hose fitting.
Quick connect fittings and 1/4 inch inside
diameter air hose are recommended. An air
supply of 90-100 psi, capable of 4.3 CFM,
must be available. Air supply should be
equipped with a filter-regulator-lubricator unit.
PREPARATION FOR USE
MODEL 2015 TOOL All Models HUCK FASTENERS
1. Remove plastic plug from air inlet
connector and drop in a few drops of
Automatic Transmission Fluid, DEXRON
Ill, or equivalent.
2. Screw quick-connect fitting into air inlet
connector.
3. Set air pressure on regulator to 90-100 psi.
4. Attach optional air hose, part number
115436 (supplied with tool), to air inlet
connector.
5. Connect air hose to tool.
6. Cycle tool a few times by depressing and
releasing trigger.
7. Disconnect air hose from tool.
8. Remove retaining nut.
9. Select correct nose assembly from the
available SELECTION CHARTS or speak
with your Huck representative.
NOTE:
Quick disconnect fittings and air hoses are not
available from Huck.

2015 TOOLING HUCK FASTENERS
10
NOTE: 2015V is sold with the ribbed
vacuum control ON/OFF slide in the forward
or OFF position. See FIGURE 10 for slides
location which is shown in the ON (rear)
position. While tool is not being used, move
slide to the OFF (forward) position to prevent
unnecessary air loss.
Nail Type Blind Fastener Installation:
The fastener may be placed, either in the work
hole or, in the end of the nose assembly. In
either case, tool and nose assembly must be
held against work and at right angles to it.
Depress trigger and hold it depressed until
fastener is installed and pintail breaks.
Release trigger.
Warnings
Inspect tool for damage before each use.
Do not operate if damaged as severe
personal injury may occur.
Broken pintails eject from deflector with
speed and force - - be sure pintail deflector
is directed safely away from operator or other
personnel in the area. Ejecting pintails
striking anyone may cause serious personal
injury. For Models 2015B and 2015V,
pintail bottles must always be used. Replace
damaged pintail deflectors and bottles as
serious personal injury may occur from
pintails when using these defective parts.
Good Service Practice
Service Kits, 2015KIT and 20I5VKIT,
include perishable parts and should be on hand
at all times. Other components, as experience
dictates, should also bo kept for replacements.
ALWAYS REPLACE O-RINGS AND
BACK-UP RINGS WHEN TOOL IS
DISASSEMBLED FOR ANY REASON.
The efficiency and life of any tool depends
upon proper maintenance and good service
practices. Tool should be serviced by
personnel who are thoroughly familiar with it
and how it operates.
A clean, well-lighted area should be available
for servicing the tool. Special care must be
taken to prevent contamination of pneumatic
and hydraulic systems. Proper hand tools and
soft materials to protect tools must be
available. Use only standard hand tools, brass
drift and wood block. Vise with soft jaws
should be available. Unsuitable hand tools
will cause installation tool damage.
All parts must be handled carefully and
examined for damage and/or wear.
Components should be disassembled and
assembled in a straight line without bending,
cocking or undue force. Disassembly and
assembly procedures outlined in this manual
should be followed. If Huck recommended
procedures are not followed, the tool may be
damaged.
Rub SLIC-TITE TEFLON* thread compound,
or equivalent, on pipe plug threads and quick
connect fitting.
CAUTION: Do not use TEFLON tape on
pipe threads. Pipe threads may cause tape
to shred resulting in tool malfunction.
(SLIC-TITE is available in stick form, as
503237, from Huck.)
OPERATING INSTRUCTIONS
MAINTENANCE

2015 TOOLING HUCK FASTENERS
Tool Maintenance
The 2015 series require a minimum amount of
maintenance. Regular inspection and
correction of minor problems will keep the
tool operating efficiently and prevent
downtime.
Using filter-regulator-lubricator unit is highly
recommended for safe and reliable tool
operation. If a filter-regulator-lubricator unit is
not being used in the air supply: (1) remove
hose fitting from air inlet connector and drop
in a few drops of automatic transmission fluid
or light oil (2) blow out air line to remove dirt
and water before connecting air hose to tool.
At regular intervals, depending upon use,
replace all seals in tool. Service Kits should
be kept on hand. (See SPARE PARTS AND
SERVICE KITS.) Inspect both hydraulic
pistons, and their piston rods for scored
surfaces, excessive wear or damage, and
replace as necessary.
Always replace seats and back-up rings when
tool is disassembled for any reason to assure
proper sealing and tool function.
Nose Assembly Maintenance
Caution
Damaged jaw teeth, or debris packed
between teeth, will result in failure to install
fastener or improperly installed fastener.
Frequently cleaning the nose assembly is
recommended. Remove nose assembly from
tool and disassemble - - see DISASSEMBLY.
Check components for any signs of damage,
e.g. cracks, scores and damaged spring. Check
gripper teeth for damage. Remove any debris
packed between teeth with a sharp pointed
“pick”. Periodically dip nose, while cycling
tool, in mineral spirits, isopropyl alcohol or
other suitable solvent, to clean jaws and wash
away metal chips and dirt.
Smear LUBRIPLATE* 130AA, or equivalent
lubricant, on O-rings and mating surfaces to
aid assembly and to prevent damage to
O-rings. (LUBRIPLATE 13OAA is available
in a tube, as 502723, from Huck.)
auto
Use VIBRA-TITE* or equivalent on Gland Housing
Assem., 16134-1, threads. Torque to 75-80 ft. lbs.
Apply LOCKTITE* #271 Adhesive/sealant to
Locknut, 505420. (LOCKTITE is available
from Huck, in a tube, as 503657.) Torque to
25-30 ft. lbs.
* TEFLON is a trademark of E.I. DuPont
de Nemours & Co.
* LOCTITE is a trademark of Loctite Corp.
* TRUARC is a trademark of Waldes
Kohinoor, Inc.
* VIBRA-TITE is a trademark of the
Oakland Corporation.
* LUBRIPLATE is a Trademark of Friske
Brothers Refining Co.
Standard Tools Available from Huck
1/8 hex key, 502294, used on button head
screw, 504127.
5/32 hex key, 502295, used on socket cap
screw, 123756.
(0400) TRUARC* pliers, 502866, used on
(N5100-l00) retaining ring.
11
MAINTENANCE (continued)
PREVENTIVE MAINTENANCE

2015 TOOLING HUCK FASTENERS
12
Equipment Required:
• Shop airline with 90- 100 psi max.
• Air regulator
• Fill bottle, 120337, (supplied with
tool).
• Large flat blade screwdriver
• Nose assembly or optional stall nut
• Fasteners (optional)
• Optional stall nut and stop
Stall nut, 125340 and stop, 125341
Stall nut is used to load tool during bleeding
and for measuring stroke.
Preparation:
• Install air regulator in airline and set
pressure to 20 - 40 psi.
2. Fill bleed bottle almost full of
DEXRON III - - ATF (automatic
transmission fluid) - - see
FIGURE 3.
Procedure to Fill Empty Tool (new or
rebuilt) - - as Applicable:
1. Attach the tool air source momentarily
to seat air piston at bottom of cylinder -
- disconnect tool. With fillport facing
up, lay tool on its side.
2. With a screwdriver, remove bleed
plug from fillport.
WARNING
Air pressure MUST be set to 20 - 40 psi to
prevent possible injurious high pressure
spray. Never cycle tool without bleed plug
tightened, fill bottle tightened in tool, or
fillport held over a receptacle (see
FIGURE 3.1). When not properly
contained any fluid present in tool will
spray out. Severe injury may result.
3. Screw fill bottle into fillport in the head.
4. Set airline pressure to 20-40 psi and
connect airline to tool.
FILLING AND BLEEDING PROCEDURE
Fig. 3
Fig. 3.1

2015 TOOLING HUCK FASTENERS
13
5. Stand tool upright on bench. While
triggering tool slowly (20 - 30 cycles),
bend fill bottle at right angles to tool - -
see FIGURE 3.2. Air bubbles will
emerge from tool, When bubbles stop,
cycling may be discontinued.
6. When trigger is released, pull piston
returns to idle position (full forward).
Disconnect tool from airline.
7. Lay tool on its side. Remove fill
bottle. Top off fluid in fillport. Install
bleed plug and tighten.
8. Connect airline to tool. There is a choice
of two procedures for measuring the
stroke - - with and without a stall-nut - -
see appropriate section and follow the
selected procedure. If stroke is less than
specified, remove bleed plug and top off
fluid. Reinstall bleed plug.
9. Increase air pressure to specification.
Install two fasteners to check function
and installation in a single stroke, or
cycle tool with stall-nut fully threaded
onto piston to load up tool. Measure
stroke again. Remove plug and top off
fluid. Reinstall plug and cycle again - -
measure again. Continue this process
until stroke meets minimum requirements.
Bleed Procedure for Partially Filled Tool
in Field Use - - as Applicable:
1. Disconnect tool from airline. With
fillport facing up, lay tool on its side.
2. Remove bleed plug from bleed port.
3. Hold tool over suitable container with
fillport facing into container.
WARNING
Air pressure MUST be set to 20 - 40 psi to
prevent possible injurious high pressure
spray. Never cycle tool without bleed plug
tightened, fill bottle tightened in the tool,
or the fillport held over a receptacle (see
FIGURE 3.3). When not properly contained
any fluid present in tool will spray out.
Severe injury may result.
4. Connect tool to airline. Cycle tool several
times to drain the old fluid, air and foam.
5. Screw fill bottle into fillport.
6. See WARNING above. With air pressure
set at 20-40 psi, connect airline to tool.
Fig. 3.3
Fig. 3.2

2015 TOOLING HUCK FASTENERS
14
7. Stand tool upright on bench. While
actuating the trigger slowly (20 - 30
cycles), bend fill bottle at right angles to
tool - - see FIGURE 3.4. Observe that air
bubbles emerge from tool. When bubbles
are no longer observed, cycling may be
discontinued.
8. When trigger is released, pull piston
returns to idle position (full forward).
Disconnect tool from airline with piston
full forward.
9. Lay tool on its side. Remove fill bottle.
Top off fluid in fillport. Install bleed plug
and tighten with screwdriver.
10. Connect airline to tool. There is a choice
of two procedures for measuring the
stroke - - with and without a stall-nut - -
see appropriate section and follow the
selected procedure. If stroke is less than
specified, remove bleed plug and top off
fluid. Reinstall bleed plug.
11. Install two fasteners to check function
and installation in a single stroke, or
cycle tool with stall nut fully threaded
onto piston. Measure stroke again.
Remove plug and top off fluid. Reinstall
plug and cycle again - - measure again.
Continue this process until stroke meets
minimum requirements.
Fig. 3.4
Fig. 3.5
1. Disconnect tool from airline - - remove
nose from tool.
2. With piston fully forward (end of
RETURN stroke), bottom the stall-nut
on piston- Back stall-nut off five (5)
turns.
3. Cycle tool and hold trigger depressed - -
this keeps piston fully to the rear and at
end of PULL stroke. Thread stall-nut
back onto piston until it contacts stop.
4. Release trigger. Stall-nut will move
forward with piston. See FIGURE 3.5
and measure ‘X” dimension. This is the
tool’s stroke.
To measure stroke of tool with stall-nut
threaded onto piston:
How to Measure Stroke
5. If stroke is less than .650, refer to
appropriate previous section. Follow’
filling and topping off instructions.

2015 TOOLING HUCK FASTENERS
15
To measure stroke of tool without
stall-nut:
1. Disconnect tool from airline - - remove
nose from tool.
2. With piston fully forward (end of
RETURN stroke), measure and record
“X” dimension - - see FIGURE 3.6.
3. Hold trigger depressed. Piston is now
fully to the rear and at end of PULL
stroke. Measure and record “Y”
dimension.
5. Subtract “X” dimension from “Y”
dimension.
6. If stroke is less than .650, refer to
appropriate previous section. Follow
filling and topping off instructions.
How to Measure Stroke (continued)
Fig. 3.6
-------------------- SERVICE NOTES:---------------------
