Pelonis NT15-13L User manual

PLEASE READ AND SAVE THESE INSTRUCTIONS
OWNER’S MANUAL
Oscillating Ceramic Heater
MODEL: NT15-13L

1
IMPORTANT INSTRUCTIONS
PLEASE READ AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic precautions should always be followed to reduce the
risk of fire, electric shock, and injury to persons, including the following:
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces.
If provided, use handles when moving this heater. Keep combustible materials, such
as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from
the front of the heater and keep them away from the sides and rear.
3. Extreme caution is necessary when any heater is used by or near children or invalids
and whenever the heater is left operating and unattended.
4. Always unplug heater when not in use.
5.
6. Do not use outdoors.
7. This heater is not intended for use in bathrooms, laundry areas and similar indoor
locations. Never locate heater where it may fall into bathtub or other water container.
8.
9. To disconnect heater, first turn controls to off, then remove plug from outlet.
10. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this
may cause an electric shock or fire, or damage the heater.
11. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not
use on soft surfaces, like a bed, where openings may become blocked.
12. A heater has hot and arcing or sparking parts inside. Do not use it in the areas where
gasoline, paint, or flammable liquids are used or stored.
13. Use this heater only as described in this manual. Any other use not recommended by
the manufacturer may cause fire, electric shock, or injury to persons.
14. Always plug heaters directly into a wall outlet/receptacle. Never use with an extension
cord or relocatable power tap (outlet/power strip).
15. This heater draws 12.5 amps during operation. To prevent overloading a circuit, do
not plug the heater into a circuit that already has other appliances working.
16. It is normal for the plug to feel warm to the touch; however, a loose fit between the AC
outlet (receptacle) and plug may cause overheating and distortion of the plug. Contact
a qualified electrician to replace loose or worn outlet.
17. The output of this heater may vary and its temperature may become intense enough to
burn exposed skin. Use of this heater is not recommended for persons with reduced
sensitivity to heat or an inability to react to avoid burns.
18.
19.
To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use on soft
surfaces, like a bed, where openings may become blocked.
“SAVE THESE INSTRUCTIONS”
Do not operate any heater with a damaged cord or plug or after the heater malfunctions,
has been dropped or damaged in any manner. Discard heater or return heater to
authorized service facility forexamination, electrical or mechanical adjustment, or repair.
Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar
coverings. Do not route cord under furniture or appliances. Arrange cord away from traffic
area and where it will not be tripped over.

2
Control Panel Functions
A
C
B
Power and Setting Control Power Indicator Light
Thermostat Control
OPERATION INSTRUCTIONS
CB
A
D
• Place the heater on a firm level surface that is free of obstructions, and at least 3’
3 ft. (0.9m) away from all walls and other objects such as furniture, curtains, plants or
combustible material.
• With the Power and Setting Control “A” in the “OFF” position, plug the heater into
a grounded 120V outlet.
• Turn the heater “ON” by turning the Power and Setting Control “A” clockwise to
the desired power setting (LOW, HIGH, LOW & OSC or HIGH & OSC). The Power
Indicator Light “B” will illuminate. The power settings operate as follows:
LOW: The Fan and heating elements operate at LOW setting.
HIGH: The Fan and heating elements operate at 1500W.
LOW&OSC: The Fan and heating elements operate at LOW setting with oscillation.
HIGH&OSC: The Fan and heating elements operate at 1500W with oscillation.
• Turn the Thermostat Control “C” to the desired setting between “MIN” and “MAX.”
Tip-over switch: As a safety measure, the unit will shut off automatically if it is
knocked over. Should this occur, simply turn the heater off and stand it back up to a
regular upright position, then switch it back on.
IMPORTANT!
Your heater is equipped with a
polarized alternating current line plug
(a plug having one blade wider than
the other). This plug will fit into the
power outlet only one way. This is a
safety feature. If you are unable to
insert the plug fully into the outlet, try
reversing the plug. If the plug still fails
to fit, contact your electrician to
replace your outlet. DO NOT defeat
the safety purpose of the polarized
plug.

3
TROUBLESHOOTING
CLEANING AND STORAGE
Model No.: NT15-13L
Voltage: 120V, 60Hz
Current: Maximum continuous draw: 12.5 Amps
Output: 5200 BTUs
Power: LOW=900 Watts, HIGH=1500 Watts
Tolerances on all specifications:Approximately +5%,-10%
SPECIFICATIONS
CAUTION: This heater includes a thermal cut-off that shuts the heater off if it overheats due to
abnormal conditions. If this occurs, turn the heater “off,” unplug it, and inspect and remove any
objects on or adjacent to the heater. Allow it to cool for a few minutes, and then plug it back in
and resume normal operation.
If your heater fails to operate, please follow these instructions:
•Ensure that your circuit breaker or fuse is working properly.
•Be sure the heater is plugged in and that the electrical outlet is working properly.
•Check for any obstruction. If you find an obstruction, turn the heater “OFF.” Unplug
the heater and wait a few minutes for it to cool down. Carefully remove the
obstruction. Plug the heater in and turn it on again by referring to the OPERATING
INSTRUCTIONS.
NOTE: IF YOU EXPERIENCE A PROBLEM WITH YOUR HEATER, PLEASE SEE THE WARRANTY
INFORMATION FOR INSTRUCTIONS. PLEASE DO NOT ATTEMPT TO OPEN OR REPAIR THE
HEATER YOURSELF. DOING SO MAY VOID THE WARRANTY AND COULD CAUSE DAMAGE OR
PERSONAL INJURY. IF THE PROBLEM STILL PERSISTS, PLEASE CONTACT US BY REFERRING TO
THE SERVICE & SUPPORT INFORMATION ON THE FOLLOWING PAGE.
It is recommended that the heater be cleaned at least one time during the operating season in
order to provide the optimum level of performance. ALWAYS TURN THE POWER SWITCH OFF
AND UNPLUG THE HEATER BEFORE CLEANING.Be sure to save the box for off-season storage
•Turn the heater “OFF,” unplug it and wait for the heater to cool down.
•Use a dry cloth to clean only external surfaces of the heater.
•Do not use any cleaning agents or detergents.
•Never immerse the heater in water.
•Pack the heater in the original carton and store it in a cool and dry place.

4
SERVICE & SUPPORT
In the event of a warranty claim or if service is required for this heater, please contact us at the
following:
Toll Free: 1-866-646-4332
Email us at: [email protected]
For questions or comments, please write to:
For your records, staple your sales receipt to this manual and record the following:
DATE OF PURCHASE: ________________________________
PLACE OF PURCHASE: ________________________________
(STAPLE SALES RECEIPT HERE)
NOTE: PROOF OF PURCHASE IS REQUIRED FOR ALL
WARRANTY CLAIMS
PRINTED IN CHINA
Midea America Corporation
Medley, FL 33178
Customer Care Center
11800 NW 100th Rd., Suite 4

5
ONE (1) YEAR LIMITED WARRANTY
Please read all instructions before attempting to use this product.
Please return the Warranty Registration card within fifteen (15) days from the date of
purchasing this product.
PELONIS warrants as limited herein to the original purchaser of retail that each new Pelonis
heater, shall be free of defects in material and workmanship for a period of one (1) year from
the date of original purchase. This one (1) year warranty is limited to the heating elements,
motor, and electric control circuit board.
In the event of malfunctions or failure of your Pelonis heater, simply deliver or send the heater,
postage prepaid along with PROOF OF PURCHASE, within the warranty period of one (1) year,
to PELONIS. PELONIS reserves the right to inspect the claimed defective part or parts to determine
if the defect or malfunction complaint is covered by this warranty. PELONIS shall, within sixty (60)
days after receipt of the product, at its option, repair and/or replace the defective part or parts
free of charge. This warranty shall only cover defects arising from normal usage. PELONIS
assumes no responsibility whatsoever if the heater should fail during the warranty period by
reason of:
Misuse, negligence, physical damage or accidents.
Lack of maintenance (see instructions for proper maintenance).
Repair by any unauthorized party during the warranty period.
Damage caused by connection to an improper input voltage (see specification label on
your heater).
PELONIS makes no further warranties or representations, express or implied except those
contained herein. No representative or dealer is authorized to assume any other liability regarding
the heater. The duration of the implied warranty granted under State law, including warranties
of merchantability and fitness for particular purpose are limited in duration should the duration
of the express warranty grant it hereunder. PELONIS shall in no event be liable for direct,
indirect, special or consequential damages.
Some states do not allow limitations on how long an implied warranty lasts, and/or the above
limitations or exclusion may not apply to you. This warranty gives you specific legal rights and
you may have other rights which vary from state to state.
