Pelpro PP60 User manual

7083-171B • July 23, 2013 (877) 427- 33161
This heater meets the U.S. Environmental Protection Agency’s emission limits for wood heaters sold after July 1, 1990.
PP60 Pellet Stove
Model(s):
PP60
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
replace.
• Alert children and adults to hazards of high temperatures
• High temperatures may ignite clothing or other
ammablematerials.
• Keepclothing,furniture,draperiesandotherammable
materials away.
WARNING
If the information in these instruc-
tionsisnotfollowedexactly,are
may result causing property dam-
age, personal injury, or death.
• Donotstoreorusegasolineorotheram-
mablevaporsandliquidsinthevicinityof
this or any other appliance.
• Donotoverre-Ifheaterorchimneycon-
nectorglows,youareoverring.Overring
will void your warranty.
• Complywithallminimumclearancesto
combustiblesasspecied.Failuretocom-
plymaycausehousere.
Questions, problems, missing parts?
Before returning to your retailer, call our
customer service department at 877-427-3316.
WARNING
SAFETY NOTICE: PLEASE READ THIS ENTIRE MANUAL
BEFORE INSTALLATIONAND USE OF THIS PELLET FUEL-
BURNING ROOM HEATER.  FAILURE TO FOLLOW THESE
INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE,
BODILYINJURYOREVENDEATH.CONTACTLOCALBUILD-
INGOFFICIALSABOUTRESTRICTIONSANDINSTALLATION
INSPECTIONREQUIREMENTSINYOURAREA.
Owner’s Manual
Installation & Operation
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE: DO NOT DISCARD THIS MANUAL
NOTE
ToobtainaFrenchtranslationofthismanual,pleasecontact
your dealer or visit www.pelprostoves.com
Pourobtenirunetraductionfrançaisedecemanuel,s’ilvous
plaît contacter votre revendeur ou visitez www.pelprostoves.com

7083-171B • July 23, 2013 (877) 427- 33162
7077-195•June27,2013
QUICK START GUIDE
4.
Checkallthreebafesare
hookedintoslots.
*Beforeyoupluginthisappliance,followtheseinstructions*
3.
Veryrepot’sorientationis
correct.
5.
Plugpowercordintowall
receptacle.
*Greenlightwillstartashingone
timepersecond*
NOTE:Ifthelightdoesnotchange
tosolidgreen,turnthecontrolback
tooff,unplugtheapplianceand
repeatsteps5&6.
7.
Stovewillfeedfortwominutes.
*Greenlightwillstartblinking
continuously,toindicatestartup
sequence*
NOTE:Allowtheunitve
minutesforignitiontotakeplace.
8.
Oncearehasbeen
establishedintheunit,leave
theunitburningonMAXfor30
minutestoallowthepaintto
cure.
NOTE:Odorsandvaporsreleased
duringinitialoperation.
•Curingofhightemperaturepaint.
•Openwindowsforaircirculation.
*Odorsmaybeirritatingto
sensitiveindividuals.
9.
After30minuteshavepassed,
turndialcontroltoOFF,and
allowunittocoolcompletely.
Onceunithascooled,open
doorandcleanrepotaccording
tothecleaninginstructions
foundontheinsideofthe
hopperlid,orintheowners
manual.
*Unitisnowreadytoresume
normaloperation*
6.
Toprimethefeedtube,
QUICKLYturnthedialcontrol
fromOFFtoMAX,backtoOFF,
thenbacktoMAX.
*Thelightshouldstopblinkingand
lightupsolidgreen*
NOTE:Primingisonlyrequired
thersttimetheapplianceislit,
orafterthehopperhasrun
completelyoutofpellets.
If ignition is missed, empty the
 repot and repeat step 4.
0
-
1
-
2
-
3
-
4
+
1
+
2
+
3
+
4
A
U
T
O
M
A
T
I
C
/
A
U
T
O
M
Á
T
I
C
O
/
A
U
T
O
M
A
T
I
Q
U
E
O
F
F
M
A
X
M
I
N
O
N
A
U
T
O
A
L
A
R
M
1.
TurnDialControltoOFF.
All material needs to be
removed from the door
glass and  rebox before
operation (including door
cling, EPA card, hardware
kit and desi-pack)
2.
Addpelletstohopperandclose
lid.
0
-
1
-
2
-
3
-
4
+
1
+
2
+
3
+
4
A
U
T
O
M
A
T
I
C
/
A
U
T
O
M
Á
T
I
C
O
/
A
U
T
O
M
A
T
I
Q
U
E
O
F
F
M
A
X
M
I
N
O
N
A
U
T
O
A
L
A
R
M
Back
HoleforIgniter
MAXIMUM
PELLET LEVEL
Front
of
repot
has
thelip
CONFIDENTIAL PROPERTY OF HEARTH & HOME TECHNOLOGIES INC.
PART NAME:
DRAWN BY: SCALE: MATERIAL:
SHEET:
PART NUMBER: REV:
THIS PRINT IS CHECKED AND CONTROLLED BY THE ENGINEERING
DEPARTMENTS OF HEARTH & HOME TECHNOLOGIES INC.
ECO # DATE BY REV
UNLESS OTHERWISE SPECIFIED DIMS ARE INCHES[MM] & : TOLERANCES ARE: (2) PLACE DEC : ± 0.03 (3) PLACE DEC: ± 0.005 ANGLE: ± 2° FRACTION: ± 1/16
OUTSIDE MATERIAL. NORMAL DIM & INSIDE MATERIAL. OUTSIDE APEX INSIDE APEX - DIMS ENCLOSED BY AN OVAL ARE CRITICAL DIMENSIONS
REVISIONS
ITEM PART NUMBER PART NAME QTY
02 RELEASE FOR TOOLING 72901 04/29/13 MCW
LABEL CONTROL PANEL
MCW 1:1 SEE NOTE
1 OF 1
7083-167 02
NOTE:
1. MATERIAL: MYLAR
2. ADHESIVE: 3M #468 PERMANENT ACRYLIC
3. TEMPERATURE RATING: INK @ 325°F
TOOLING
3.75
2.81 4X R0.13
2
1
4
3
56
7
8
9
10
LO
OFF HI
0
-
1
-
2
-
3
-
4
+
1
+
2
+
3
+
4
O
N
A
U
T
O
A
L
A
R
M
CONFIDENTIAL PROPERTY OF HEARTH & HOME TECHNOLOGIES INC.
PART NAME:
DRAWN BY: SCALE: MATERIAL:
SHEET:
PART NUMBER: REV:
THIS PRINT IS CHECKED AND CONTROLLED BY THE ENGINEERING
DEPARTMENTS OF HEARTH & HOME TECHNOLOGIES INC.
ECO # DATE BY REV
UNLESS OTHERWISE SPECIFIED DIMS ARE INCHES[MM] & : TOLERANCES ARE: (2) PLACE DEC : ± 0.03 (3) PLACE DEC: ± 0.005 ANGLE: ± 2° FRACTION: ± 1/16
OUTSIDE MATERIAL. NORMAL DIM & INSIDE MATERIAL. OUTSIDE APEX INSIDE APEX - DIMS ENCLOSED BY AN OVAL ARE CRITICAL DIMENSIONS
REVISIONS
ITEM PART NUMBER PART NAME QTY
A RELEASED 72906 06/20/13 MCW
LABEL OPERATION AND MAINTENANCE
MCW NTS SEE NOTE
1 OF 1
7083-168 A
NOTE:
1. MATERIAL: NON-ANODIZED ALUMINUM 0.020 THICK
2. BACKGROUND: BLACK
3. COPY: SILVER
4. ADHESIVE: 3M #468 PERMANENT ACRYLIC
5. TEMPERATURE RATING: -50°F TO 350°F
RELEASED - ---- ----- -
6.75
11.75 4X R0.13
2X
Broken Exhaust Probe
Sonde d'échappement cassé
Sonda de escape roto
1X
Empty Hopper
trémie vide
tolva vacía
OFF
3X
Broken Ambient Probe
Cassé la sonde ambiante
Sonda ambiente roto
4X
Failed Ignition
allumage échoué
de encendido no
OFF
8X
High Exhaust Temperature
Température d'échappement haute
Alta temperatura de escape
Troubleshooting
Dépannage / Solución de problemas
Reset From Error
1. Determine error from above table.
2. Correct error condition. (see Owner’s Manual for additional information.)
3. Turn dial control to OFF position, wait 10 seconds.
4. Follow STARTING instructions.
Réinitialisation des erreurs
1. Déterminer l'erreur de tableau ci-dessus.
2. Condition d'erreur correct. (voir le manuel du propriétaire pour plus
d'informations.)
3. Tourner le cadran de commande en position OFF, attendez 10 secondes.
4. Suivez les instructions de démarrage.
Restablecer de error
1. Determinar el error de la tabla anterior.
2. Condición de error correcto. (consulte el Manual del Propietario para
obtener información adicional.)
3. Gire el dial de control en la posición OFF, espere 10 segundos.
4. Siga las instrucciones de arranque.
Customer Service / Service Clients / Servicio al Cliente
877-427-3316
www.pelprostoves.com
Daily / Quotidien / Todos los días 1 Bag / 1 Sac / 1 Bolsa
Empty Firepot / Creuset Vide / Brasero De Fuego Vacía Clean Firepot / Clean Creuset / Limpieza Brasero De Fuego
Weekly / Hebdomandair / Semanalmente 5 Bags / 5 Sacs / 5 Bolsas
Clean Holes / Nettoyer Les Trous / Limpie Los Oricios
Remove Ash / Retirez Les Cendres / Quitar Las Cenizas
Monthly / Mensuel / Mensualmente 25 Bags / 25 Sacs / 25 Bolsas
1
2
3
Remove / Supprimer / Quitar Vacuum / Vide / Vacío
Maintenance / Entretien / Mantenimiento
7083-168
Operation / Opération / Operación
Automatic Mode *
mode Automatique
Modo Automático
Priming Fuel
carburant d'amorçage
cebado de combustible
Minimum / Maximum **
minimale / maximale
mínimo / máximo
Starting
1. Turn dial control to OFF position.
2. Fill hopper with pellets.
3. Turn dial control to desired setting.
Départ
1. Tourner le cadran de commande en
position OFF.
2. Remplir la trémie avec des granulés.
3. Tourner le cadran de commande au réglage
désiré.
A partir
1. Gire el dial de control en la posición OFF.
2. Llene la tolva con perdigones.
3. Gire el dial de control hasta la posición deseada.
Stopping
1. Turn dial control to OFF position.
2. Allow unit to cool before performing any maintenance.
Arrêt
1. Tourner le cadran de commande en position OFF.
2. Laissez refroidir avant d'eectuer toute opération de maintenance.
Parada
1. Gire el dial de control en la posición OFF.
2. Deje enfriar la unidad antes de realizar cualquier trabajo de mantenimiento.
* The appliance will automatically maintain the desired comfort level and shut down when level
has been achieved.
L'appareil passera automatiquement maintenir le niveau de confort désiré et arrêter lorsque le
niveau a été atteint.
El aparato mantendrá automáticamente el nivel de confort deseado y se cerrará cuando el nivel
se ha logrado.
** The appliance will run continuously until switched to OFF or AUTOMATIC mode.
L'appareil fonctionne de façon continue jusqu'à ce que passe en mode OFF ou AUTOMATIQUE.
El aparato funciona continuamente hasta que cambia al modo OFF o AUTOMÁTICO.
2
1
4
3
56
7
8
9
10
LO
OFF HI
CONFIDENTIAL PROPERTY OF HEARTH & HOME TECHNOLOGIES INC.
PART NAME:
DRAWN BY: SCALE: MATERIAL:
SHEET:
PART NUMBER: REV:
THIS PRINT IS CHECKED AND CONTROLLED BY THE ENGINEERING
DEPARTMENTS OF HEARTH & HOME TECHNOLOGIES INC.
ECO # DATE BY REV
UNLESS OTHERWISE SPECIFIED DIMS ARE INCHES[MM] & : TOLERANCES ARE: (2) PLACE DEC : ± 0.03 (3) PLACE DEC: ± 0.005 ANGLE: ± 2° FRACTION: ± 1/16
OUTSIDE MATERIAL. NORMAL DIM & INSIDE MATERIAL. OUTSIDE APEX INSIDE APEX - DIMS ENCLOSED BY AN OVAL ARE CRITICAL DIMENSIONS
REVISIONS
ITEM PART NUMBER PARTNAME QTY
02 RELEASE FOR TOOLING 72901 04/29/13 MCW
LABEL CONTROL PANEL
MCW 1:1 SEE NOTE
1 OF 1
7083-167 02
NOTE:
1. MATERIAL: MYLAR
2. ADHESIVE: 3M #468 PERMANENT ACRYLIC
3. TEMPERATURE RATING: INK @ 325°F
TOOLING
3.75
2.81 4X R0.13
2
1
4
3
56
7
8
9
10
LO
OFF HI
0
-
1
-
2
-
3
-
4
+
1
+
2
+
3
+
4
O
N
A
U
T
O
A
L
A
R
M
CONFIDENTIAL PROPERTY OF HEARTH & HOME TECHNOLOGIES INC.
PART NAME:
DRAWN BY: SCALE: MATERIAL:
SHEET:
PART NUMBER: REV:
THIS PRINT IS CHECKED AND CONTROLLED BY THE ENGINEERING
DEPARTMENTS OF HEARTH & HOME TECHNOLOGIES INC.
ECO # DATE BY REV
UNLESS OTHERWISE SPECIFIED DIMS ARE INCHES[MM] & : TOLERANCES ARE: (2) PLACE DEC : ± 0.03 (3) PLACE DEC: ± 0.005 ANGLE: ± 2° FRACTION: ± 1/16
OUTSIDE MATERIAL. NORMAL DIM & INSIDE MATERIAL. OUTSIDE APEX INSIDE APEX - DIMS ENCLOSED BY AN OVAL ARE CRITICAL DIMENSIONS
REVISIONS
ITEM PART NUMBER PART NAME QTY
A RELEASED 72906 06/20/13 MCW
LABEL OPERATION AND MAINTENANCE
MCW NTS SEE NOTE
1 OF 1
7083-168 A
NOTE:
1. MATERIAL: NON-ANODIZED ALUMINUM 0.020 THICK
2. BACKGROUND: BLACK
3. COPY: SILVER
4. ADHESIVE: 3M #468 PERMANENT ACRYLIC
5. TEMPERATURE RATING: -50°F TO 350°F
RELEASED - ---- ----- -
6.75
11.75 4X R0.13
2X
Broken Exhaust Probe
Sonde d'échappement cassé
Sonda de escape roto
1X
Empty Hopper
trémie vide
tolva vacía
OFF
3X
Broken Ambient Probe
Cassé la sonde ambiante
Sonda ambiente roto
4X
Failed Ignition
allumage échoué
de encendido no
OFF
8X
High Exhaust Temperature
Température d'échappement haute
Alta temperatura de escape
Troubleshooting
Dépannage / Solución de problemas
Reset From Error
1. Determine error from above table.
2. Correct error condition. (see Owner’s Manual for additional information.)
3. Turn dial control to OFF position, wait 10 seconds.
4. Follow STARTING instructions.
Réinitialisation des erreurs
1. Déterminer l'erreur de tableau ci-dessus.
2. Condition d'erreur correct. (voir le manuel du propriétaire pour plus
d'informations.)
3. Tourner le cadran de commande en position OFF, attendez 10 secondes.
4. Suivez les instructions de démarrage.
Restablecer de error
1. Determinar el error de la tabla anterior.
2. Condición de error correcto. (consulte el Manual del Propietario para
obtener información adicional.)
3. Gire el dial de control en la posición OFF, espere 10 segundos.
4. Siga las instrucciones de arranque.
Customer Service / Service Clients / Servicio al Cliente
877-427-3316
www.pelprostoves.com
Daily / Quotidien / Todos los días 1 Bag / 1 Sac / 1 Bolsa
Empty Firepot / Creuset Vide / Brasero De Fuego Vacía Clean Firepot / Clean Creuset / Limpieza Brasero De Fuego
Weekly / Hebdomandair / Semanalmente 5 Bags / 5 Sacs / 5 Bolsas
Clean Holes / Nettoyer Les Trous / Limpie Los Oricios
Remove Ash / Retirez Les Cendres / Quitar Las Cenizas
Monthly / Mensuel / Mensualmente 25 Bags / 25 Sacs / 25 Bolsas
1
2
3
Remove / Supprimer / Quitar Vacuum / Vide / Vacío
Maintenance / Entretien / Mantenimiento
7083-168
Operation / Opération / Operación
Automatic Mode *
mode Automatique
Modo Automático
Priming Fuel
carburant d'amorçage
cebado de combustible
Minimum / Maximum **
minimale / maximale
mínimo / máximo
Starting
1. Turn dial control to OFF position.
2. Fill hopper with pellets.
3. Turn dial control to desired setting.
Départ
1. Tourner le cadran de commande en
position OFF.
2. Remplir la trémie avec des granulés.
3. Tourner le cadran de commande au réglage
désiré.
A partir
1. Gire el dial de control en la posición OFF.
2. Llene la tolva con perdigones.
3. Gire el dial de control hasta la posición deseada.
Stopping
1. Turn dial control to OFF position.
2. Allow unit to cool before performing any maintenance.
Arrêt
1. Tourner le cadran de commande en position OFF.
2. Laissez refroidir avant d'eectuer toute opération de maintenance.
Parada
1. Gire el dial de control en la posición OFF.
2. Deje enfriar la unidad antes de realizar cualquier trabajo de mantenimiento.
* The appliance will automatically maintain the desired comfort level and shut down when level
has been achieved.
L'appareil passera automatiquement maintenir le niveau de confort désiré et arrêter lorsque le
niveau a été atteint.
El aparato mantendrá automáticamente el nivel de confort deseado y se cerrará cuando el nivel
se ha logrado.
** The appliance will run continuously until switched to OFF or AUTOMATIC mode.
L'appareil fonctionne de façon continue jusqu'à ce que passe en mode OFF ou AUTOMATIQUE.
El aparato funciona continuamente hasta que cambia al modo OFF o AUTOMÁTICO.
2
1
4
3
56
7
8
9
10
LO
OFF HI

www.pelprostoves.com  7083-171B•July23,2013 3
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicatesahazardoussituationwhich,ifnotavoidedwillresultindeathorseriousinjury.
• WARNING!Indicatesahazardoussituationwhich,ifnotavoidedcouldresultindeathorseriousinjury.
• CAUTION! Indicatesahazardoussituationwhich,ifnotavoided,couldresultinminorormoderateinjury.
• NOTICE:Indicatespracticeswhichmaycausedamagetotheapplianceortoproperty.
1 Listing and Code Approvals
A.ApplianceCertication......................................................5
B.MobileHomeApproved....................................................5
C.GlassSpecications.........................................................5
D.ElectricalRating(OnHigh)...............................................5
E.BTU&EfciencySpecications........................................5
2 General Information
A.FireSafety.........................................................................6
B.Non-CombustibleMaterials..............................................6
C.CombustibleMaterials.......................................................6
D.FuelMaterialandFuelStorage........................................6
E.BeforeYourFirstFire.......................................................6
3 General Operating Information
A.UserDialControl...............................................................7
B.FillingtheHopper...............................................................7
C.PrimingtheFeedTube......................................................7
D.FirepotBurnDown.............................................................8
E.Shutdown...........................................................................8
F.StartingYourFirstFire........................................................8
G.FireCharacteristics...........................................................8
H.YourPelletAppliance-GeneralOperatingParts...............9
I.LEDColorCodingChartandExplanation..........................10
J.IgnitionCycles...................................................................11
K.RunninginMinimumorMaximum.....................................11
L.RunningintheComfortLevelMode..................................11
M.ClearSpace......................................................................11
N.TrimAdjustment.................................................................11
4 Maintaining & Servicing the Appliance
A.ProperShutdownProcedure.............................................12
B.QuickReferenceMaintenanceChart.................................12
C.GeneralMaintenance........................................................12
D.HighAshFuelContentMaintenance.................................16
E.FrequentlyAskedQuestions..............................................17
5 Replacement Parts
A.ConvectionBlowerReplacement......................................18
B.ExhaustBlowerReplacement............................................18
C.SnapDiscReplacement...................................................19
D.IgniterReplacement..........................................................19
E.BafeRemoval&Replacement........................................19
F.GlassReplacement............................................................20
G.ControlBoardReplacement..............................................20
H.FuseReplacement............................................................20
I.FeedMotorReplacement..................................................20
J.FeedSpringReplacement.................................................20
6 Getting Started
A . Design,Installation&LocationConsiderations......................... 21
B.Draft ..............................................................................21
C.NegativePressure.............................................................21
D.LocatingYourAppliance&Chimney.................................22
E.InspectAppliance&Components......................................22
F.ToolsAndSuppliesNeeded..............................................22
7 Dimensions and Clearances
A.ApplianceDimensions......................................................23
B.ClearancestoCombustibles(ULandULC).......................23
C.HearthPadRequirements(ULandULC)..........................24
8 Vent Information
A.ChimneyandExhaustConnection....................................25
B.VentingTerminationRequirements....................................25
C.PelletVentingCharts.........................................................26
9 Venting Systems
A.Vertical-Interior-TypicalInstallation................................27
B.ThroughTheWall&Vertical-External-Horizontal..........27
C.VerticalintoExistingClassAChimney..............................27
D.Masonry.............................................................................28
E.AlternateMasonry..............................................................28
F.ThroughTheWall...............................................................29
10 Mobile Home
A.MobileHomeInstallation...................................................30
11 Appliance Set-Up
A.OutsideAirKitInstructions................................................31
B.PoweruptheUnit.............................................................31
12 Troubleshooting
13 Reference Materials
A.ComponentFunction.........................................................35
B.WiringDiagram..................................................................36
C.ReplacementParts............................................................37
D.Service&MaintenanceLog...............................................38
E.Warranty............................................................................39

7083-171B • July 23, 2013 (877) 427- 33164
CAUTION
After reading these instructions, if you have any doubt
aboutyour ability to completeyourinstallation in apro-
fessional manner you should obtain the services of an
installerversedinallaspectsastothecorrectandsafe
installation.  Do not use temporary makeshift compro-
misesduringinstallation.
BEFORE INSTALLATION OF YOUR APPLIANCE
1.Checkwiththebuildinginspector’sofcefor
compliancewithlocalcodes;apermitmaybe
required.
2.Use3”or4”(76-102mm)diametertype“L”or
“PL”ventingsystem.Itcanbeventedverticallyor
horizontally.Approvedadaptorscanbeusedto
connectthe“L”or”PL”toapprovedwoodstove
ventingsuchassinglewallordoublewallventing
previouslyusedtoventawoodburningappliance.
INSTALLVENTATCLEARANCESSPECIFIEDBY
THEVENTMANUFACTURE.
3.Alwaysconnectthisunittoanapprovedchimney
systemandNEVERventtoanotherroomorinside
abuilding.
4.DONOTINSTALLAFLUEDAMPERINTHE
EXHAUSTVENTINGSYSTEMOFTHISUNIT.
5.DO NOT CONNECT THIS UNIT TO A CHIMNEY
FLUE SERVING ANOTHER APPLIANCE.
6.Theconnectorpipeandchimneyshouldbe
inspectedperiodicallyandcleanedifnecessary.
Reviewadditionalinformationlocatedinthemainte-
nancesectionofthisOwner’sManual.
7.Remembertheclearancedistanceswhenyou
placefurnitureorotherobjectswithinthearea.
Thisincludesheatsensitivematerialssuchas
candles,seasonaldecorationsordraperies.DO
NOTSTOREWOOD,FLAMMABLELIQUIDSOR
OTHERCOMBUSTIBLEMATERIALSTOOCLOSE
TOTHEUNIT.
8.Beawareoftherequiredclearanceswhenlocat-
ingtheunit.Refertothelabelontherearofthe
unitforrequiredclearances.
9.Contactyourlocalmunicipalorprovincialre
authorityforinformationofhowtohandleachim-
neyre.Haveaclearunderstoodplantohandlea
chimneyre.Intheeventofachimneyre,CALL
THE FIRE DEPARTMENT.
10.Priortoburningtheunitforthersttimemake
surethehardwarekithasbeenremovedfromthe
rebox.
IMPORTANT
Itishighlyrecommendedthatthepelletheater
andchimneybeinstalledbyaqualiedinstaller.A
qualiedinstallerisapersonorentitywhoregularly
installssolidburningfuelproductsandchimneysin
thecourseoftheirordinarybusiness.
If the information in these
instructions is not followed
exactly, a re may result causing
property damage, personal injury,
or death.
• Donotstoreorusegasolineorotheram-
mablevaporsandliquidsinthevicinityof
thisoranyotherappliance.
• Donotoverre-Ifheaterorchimneycon-
nectorglows,youareoverring.Overring
willvoidyourwarranty.
• Complywithallminimumclearancesto
combustiblesasspecied.Failureto
complymaycausehousere.
WARNING
Hot glass will cause burns.
• Donottouchglassuntilitiscooled
• NEVERallowchildrentotouchglass
• Keepchildrenaway
• CAREFULLYSUPERVISEchildreninsameroomas
replace.
• Alertchildrenandadultstohazardsofhigh
temperatures.
High temperatures may ignite clothing or other
ammable materials.
• Keepclothing,furniture,draperiesandotherammable
materialsaway.
HOT SURFACES!
Glassandothersurfacesarehot
duringoperationANDcooldown.
WARNING
Fire Risk.
Testedandapprovedforwood
pellets.Burningofanyovertype
offuelwillvoidyourwarranty.
WARNING

www.pelprostoves.com  7083-171B•July23,2013 5
A. Appliance Certication
This appliance is equipped with 5mm ceramic glass.
Replaceglassonlywith5mmceramicglass.Pleasecontact
Pelproforreplacementglass.
B. Mobile Home Approved
NOTE: Thisinstallationmustconformwithlocalcodes.
Intheabsenceoflocalcodesyoumustcomplywiththe
ASTM E1509-04, ULC S627-00, (UM) 84-HUD,
*BTUinputwillvary,dependingonthebrandoffuelyouuse
inyourstove.**Heatingcapacitydependsonclimatezone,
structurelayout,insulation,windows,etc.
MODEL: PP60
Particulate Emissions
Rating: 0.34grams/hr
*BTU Input: 11,000-35,000/hr
Efciency: 85%
**Heating Capacity: 750to1450sq.ft.depending
onclimatezone
Hopper Capacity: (Approx) 60lbs
Fuel: WoodPellets
Shipping Weight: 205lbs
Series: PP60
Laboratory: Intertek
Report No. 10072262PRT-001
Type: SolidFuelRoomHeater/Pellet
FuelBurningType
Standard: ASTME1509-04andULCS627-
00,RoomHeaterPelletFuel
Burningtypeand(UM)84-HUD,
MobileHomeApproved.
TheseheatersmeettheUSEvironmentalProtectionAgency’s
Emissionlimitsforpelletheaters.Underspecicconditions
thePP60stovehasshowntodeliverheatatratesranging
from9,550to25,080BTU/hr.
 • This appliance is approved for mobile home
installationswhennotinstalledinasleepingroomand
whenanoutsidecombustionairinletisprovided.
 • The structural integrity of the mobile home oor,
ceiling,andwallsmustbemaintained.
 • Theappliancemustbeproperlygroundedtotheframe
ofthemobilehomewith#8coppergroundwire,and
useonlylisteddouble-wallconnectorpipe.
 • Outside Air Kit provided with each unit must be
installedinamobilehomeinstallation.
WARNING! Risk of Fire! Pelprodisclaimsanyresponsibility
for,andthewarrantyandagencylistingwillbevoidedbythe
belowactions.
DO NOT:
 • Installoroperatedamagedappliance
 • Modifyappliance
 • Installotherthanasinstructedbythemanufacturer.
 • Operatetheappliancewithoutfullyassemblingall
components
 • Overre
 • Installanycomponentnotapprovedbythe
  manufacturer
 • InstallpartsorcomponentsnotListedorapproved
 • Disablesafetyswitches
Improper installation, adjustment, alteration, service or
maintenancecancauseinjuryorpropertydamage.
Forassistanceoradditionalinformation,consultaqualied
installer,serviceagencyoryourdealer.
PP60 Series: 115VAC,60Hz,Start2.6Amps,
Run0.9Amps
C. Glass Specications
D. Electrical Rating (On High)
E. BTU & Efciency Specications
1 Listing and Code Approvals

7083-171B • July 23, 2013 (877) 427- 33166
A. Fire Safety
To provide reasonable re safety, the following should be
givenseriousconsideration:
• Installatleastonesmokedetectoroneachoorofyour
home.
• Installatleastonecarbonmonoxidedetectoroneachoor
ofyourhome.
• Locatesmokedetectorawayfromtheheatingappliance
andclosetothesleepingareas.
• Followthesmokedetectormanufacturer’splacementand
installationinstructionsandmaintainregularly.
• Followthecarbonmonoxidemanufacturer’splacementand
installationinstructionsandmaintainregularly.
• ConvenientlylocateaClassAreextinguishertocontend
withsmallres.
• Intheeventofahopperre:
 • Evacuatethehouseimmediately.
• Notifyredepartment.
B. Non-Combustible Materials
Materialwhichwillnotigniteandburn,composedofany
combinationofthefollowing:
 -Steel   -Plaster
 -Brick   -Iron
 -Concrete  -Tile
 -Glass   -Slate
MaterialsreportedaspassingASTM E 136, Standard
Test Method for Behavior of Metals, in a Vertical Tube
Furnace of 750° C.
C. Combustible Materials
Materialmadeof/orsurfacedwithanyofthefollowing
materials:
 -Wood  -CompressedPaper
 -PlantFibers  -Plastic
 -Plywood/OSB  -SheetRock(drywall)
Anymaterialthatcanigniteandburn:ameproofedornot,
plasteredorun-plastered.
D. Fuel Material and Fuel Storage
Pelletfuelqualitycangreatlyuctuate.Werecommendthat
youbuyfuelinmulti-tonlotswheneverpossible.However,
wedorecommendtryingvariousbrandsbeforepurchasing
multi-tonlotstoensureyoursatisfaction.
FuelMaterial
• Madefromsawdustorwoodby-products
• Dependingonthesourcematerialitmayhaveahighor
lowashcontent.
HigherAshContentMaterial
• Hardwoodswithahighmineralcontent
• Fuelthatcontainsbark
• Standardgradepelletsorhighashpellets
Fuel Material and Fuel Storage (Cont’d)
LowerAshContentMaterial
• Mostsoftwoods
• Fuelswithlowmineralcontent
•Mostpremiumgradepellets
Clinkers
Mineralsandothernon-combustiblematerialssuchassand
willturnintoahard,glass-likesubstancecalledaclinkerwhen
heatedintherepot.
Treesfromdifferentareaswillvaryinmineralcontent.That
iswhysomefuelsproducemoreclinkersthanothers.
Moisture
Alwaysburndryfuel.Burningfuelwithhighmoisturecontent
takes heat from the fuel and tends to cool the appliance,
robbingheatfromyourhome.Damppelletfuelcanclogthe
feedsystem.
Size
• Pelletsareeither1/4inchor5/16inch(6-8mm)indiameter
• Lengthshouldbenomorethat1-1/2inches(38mm)
• Pellet lengths can vary from lot to lot from the same
manufacturer
• Duetolengthvariations,thefeedratemayneedadjusting
occasionally
Performance
• Higherashcontentrequirestherepotandtheashdrawer
tobeemptiedmorefrequently
• Hardwoodsrequiremoreairtoburnproperly
• Premiumwoodpelletsproducethehighestheatoutput
• Burningpelletslongerthan1-1/2inches(38mm)cancause
aninconsistentfuelfeedrateand/ormissedignitionsof
feedjams.
Storage
• Woodpelletsshouldbeleftintheiroriginalsealedbaguntil
usingtopreventmoistureabsorption
• Donotstoreanypelletfuelwithintheclearancerequirements
or in an area that would hinder routine cleaning and
maintenance
E. Before Your First Fire
1. First, make sure your appliancehas been properly
installedandthatallsafetyrequirementshavebeenmet.
Payparticularattentiontothereprotectionandventing.
2. Doublecheckthatthereboxisemptyandtherepotis
inplace!
3. Closeandlatchthedoor.
2 General Information

www.pelprostoves.com  7083-171B•July23,2013 7
A. User Dial Control
Theappliancehasonedialcontrollocatedonthesideof
theunitusedfordailyoperation.Therearefourprimary
settingsonthisdial.
1)   OFF: When the dial indicator is in the off position
theunitwillgointoashutdownandremainoffuntilthe
dialisturnedtooneoftheotherthreesettings.TheLED
willashgreenoncepersecondwhenintheoffposition.
2)LO:WhenthedialindicatorisdirectedtotheLO
setting(smallameonthelabel)theunitwillburnon
lowuntilthehopperrunsoutofpelletsorthedialcon-
trolisturnedtoadifferentsetting.Wheninthissetting
theLEDwillbeamberincolorandcontinuouslyon.
Whenburninginthismode,theunitshouldbeturned
offatleastoncedailyforcleaning.Iflowerqualityfuels
areused,additionaldailyshutdownsmayberequired
forcleaning.
3)HI:SimilartotheLOmode,theunitwillruncontinu-
ouslyatthehighburnrateuntiltheunithasrunoutof
fuelorthedialisturnedtoadifferentsetting.Tooper-
ateinthismode,turnthedialclockwiseuntilitstops.
Thedialindicatorwillpointtothelargeame.Whenin
thissettingtheLEDwillbeamberincolorandcontinu-
ouslyon.Followthedailycleaningrecommendations
whenoperatinginthismode.Iflowerqualityfuelsare
used,additionaldailyshutdownsmayberequiredfor
cleaning.
4)COMFORTLEVEL:ToburnintheComfortLevel
mode,turnthedialcontrolclockwisetothedesired
comfortlevel.Whenoperatingintheautomaticmode,
theunitchangestheburnsettingbasedonthediffer-
encebetweentheroomtemperatureandthedesired
setpoint.Inotherwords,theunitwillburnonHighifthe
differencebetweenthedesiredandroomtemperatureis
greaterthan8degreesFahrenheit.Astheroomheats
upandthegapcloses,theunitwillautomaticallyreduce
theburnrate.Whentheroomtemperatureiscloseto
thesetpointthelightwillstopashingstaysolidgreen.
atthistimethestovewillbeburningonthelowestburn
rate.Whenthedesiredtemperatureisachievedtheunit
willshutdown.Astheroomcools,theunitwillrestart
automatically.WhenburninginthismodetheLEDwill
beblinkinggreen.Thenumberofgreenashescorre-
spondstothecurrentsetting.
B. Filling the Hopper
Slowlyopenthehopperlidbyliftingthehandle.The
mediumandlargeunitshavealockinglatchthatwill
engagewhenthehopperlidisfullyopened.Thehopperlid
forthecabinetwillopenpastninetydegreesandstayopen
automatically.Fillthehopperwithfuel.FOR USE WITH
ONLY WOOD PELLET FUEL.Slowlyclosethehopperlid.
Seegurebelowforreleasingthelatch.NOTE:Theunit
willnotfeedwiththehopperlidopen.Ifleftopen,there
willgoout.
Push Bottom of Latch
Inward to Release
C. Priming the Feed Tube
Onlyifthehopperisbeinglledforthersttimeorthe
unithadpreviouslyrunoutofpellets,thefeedtubemay
needtobeprimed.Todothis,turnthedialcontrolfrom
theOFFpositiontotheHIpositiontwotimes.Thiswillrun
thefeedmotorcontinuouslyfortwominuteswithoutturning
theigniteron.Whentheaugerisrunningcontinuously,
theLEDwillbeacontinuousgreencolor.Thesystemwill
runtheaugerfor2minutes.Whenpelletsstarttodropinto
therepot,thefeedtubeisprimed;turnthedialcontrol
tothedesiredpositionandthestovewillbeginitsignition
sequence(ThegreenLEDwillashrapidly).
CONFIDENTIAL PROPERTY OF HEARTH & HOME TECHNOLOGIES INC.
PART NAME:
DRAWN BY: SCALE: MATERIAL:
SHEET:
PART NUMBER: REV:
THIS PRINT IS CHECKED AND CONTROLLED BY THE ENGINEERING
DEPARTMENTS OF HEARTH & HOME TECHNOLOGIES INC.
ECO # DATE BY REV
UNLESS OTHERWISE SPECIFIED DIMS ARE INCHES[MM] & : TOLERANCES ARE: (2) PLACE DEC : ± 0.03 (3) PLACE DEC: ± 0.005 ANGLE: ± 2° FRACTION: ± 1/16
OUTSIDE MATERIAL. NORMAL DIM & INSIDE MATERIAL. OUTSIDE APEX INSIDE APEX - DIMS ENCLOSED BY AN OVAL ARE CRITICAL DIMENSIONS
REVISIONS
ITEM PART NUMBER PART NAME QTY
02 RELEASE FOR TOOLING 72901 04/29/13 MCW
LABEL CONTROL PANEL
MCW 1:1 SEE NOTE
1 OF 1
7083-167 02
NOTE:
1. MATERIAL: MYLAR
2. ADHESIVE: 3M #468 PERMANENT ACRYLIC
3. TEMPERATURE RATING: INK @ 325°F
TOOLING
3.75
2.81 4X R0.13
2
1
4
3
56
7
8
9
10
LO
OFF HI
0
-
1
-
2
-
3
-
4
+
1
+
2
+
3
+
4
O
N
A
U
T
O
A
L
A
R
M
CONFIDENTIAL PROPERTY OF HEARTH & HOME TECHNOLOGIES INC.
PART NAME:
DRAWN BY: SCALE: MATERIAL:
SHEET:
PART NUMBER: REV:
THIS PRINT IS CHECKED AND CONTROLLED BY THE ENGINEERING
DEPARTMENTS OF HEARTH & HOME TECHNOLOGIES INC.
ECO # DATE BY REV
UNLESS OTHERWISE SPECIFIED DIMS ARE INCHES[MM] & : TOLERANCES ARE: (2) PLACE DEC : ± 0.03 (3) PLACE DEC: ± 0.005 ANGLE: ± 2° FRACTION: ± 1/16
OUTSIDE MATERIAL. NORMAL DIM & INSIDE MATERIAL. OUTSIDE APEX INSIDE APEX - DIMS ENCLOSED BY AN OVAL ARE CRITICAL DIMENSIONS
REVISIONS
ITEM PART NUMBER PART NAME QTY
A RELEASED 72906 06/20/13 MCW
LABEL OPERATION AND MAINTENANCE
MCW NTS SEE NOTE
1 OF 1 7083-168 A
NOTE:
1. MATERIAL: NON-ANODIZED ALUMINUM 0.020 THICK
2. BACKGROUND: BLACK
3. COPY: SILVER
4. ADHESIVE: 3M #468 PERMANENT ACRYLIC
5. TEMPERATURE RATING: -50°F TO 350°F
RELEASED - ---- ----- -
6.75
11.75 4X R0.13
2X
Broken Exhaust Probe
Sonde d'échappement cassé
Sonda de escape roto
1X
Empty Hopper
trémie vide
tolva vacía
OFF
3X
Broken Ambient Probe
Cassé la sonde ambiante
Sonda ambiente roto
4X
Failed Ignition
allumage échoué
de encendido no
OFF
8X
High Exhaust Temperature
Température d'échappement haute
Alta temperatura de escape
Troubleshooting
Dépannage / Solución de problemas
Reset From Error
1. Determine error from above table.
2. Correct error condition. (see Owner’s Manual for additional information.)
3. Turn dial control to OFF position, wait 10 seconds.
4. Follow STARTING instructions.
Réinitialisation des erreurs
1. Déterminer l'erreur de tableau ci-dessus.
2. Condition d'erreur correct. (voir le manuel du propriétaire pour plus
d'informations.)
3. Tourner le cadran de commande en position OFF, attendez 10 secondes.
4. Suivez les instructions de démarrage.
Restablecer de error
1. Determinar el error de la tabla anterior.
2. Condición de error correcto. (consulte el Manual del Propietario para
obtener información adicional.)
3. Gire el dial de control en la posición OFF, espere 10 segundos.
4. Siga las instrucciones de arranque.
Customer Service / Service Clients / Servicio al Cliente
877-427-3316
www.pelprostoves.com
Daily / Quotidien / Todos los días 1 Bag / 1 Sac / 1 Bolsa
Empty Firepot / Creuset Vide / Brasero De Fuego Vacía Clean Firepot / Clean Creuset / Limpieza Brasero De Fuego
Weekly / Hebdomandair / Semanalmente 5 Bags / 5 Sacs / 5 Bolsas
Clean Holes / Nettoyer Les Trous / Limpie Los Oricios
Remove Ash / Retirez Les Cendres / Quitar Las Cenizas
Monthly / Mensuel / Mensualmente 25 Bags / 25 Sacs / 25 Bolsas
1
2
3
Remove / Supprimer / Quitar Vacuum / Vide / Vacío
Maintenance / Entretien / Mantenimiento
7083-168
Operation / Opération / Operación
Automatic Mode *
mode Automatique
Modo Automático
Priming Fuel
carburant d'amorçage
cebado de combustible
Minimum / Maximum **
minimale / maximale
mínimo / máximo
Starting
1. Turn dial control to OFF position.
2. Fill hopper with pellets.
3. Turn dial control to desired setting.
Départ
1. Tourner le cadran de commande en
position OFF.
2. Remplir la trémie avec des granulés.
3. Tourner le cadran de commande au réglage
désiré.
A partir
1. Gire el dial de control en la posición OFF.
2. Llene la tolva con perdigones.
3. Gire el dial de control hasta la posición deseada.
Stopping
1. Turn dial control to OFF position.
2. Allow unit to cool before performing any maintenance.
Arrêt
1. Tourner le cadran de commande en position OFF.
2. Laissez refroidir avant d'eectuer toute opération de maintenance.
Parada
1. Gire el dial de control en la posición OFF.
2. Deje enfriar la unidad antes de realizar cualquier trabajo de mantenimiento.
* The appliance will automatically maintain the desired comfort level and shut down when level
has been achieved.
L'appareil passera automatiquement maintenir le niveau de confort désiré et arrêter lorsque le
niveau a été atteint.
El aparato mantendrá automáticamente el nivel de confort deseado y se cerrará cuando el nivel
se ha logrado.
** The appliance will run continuously until switched to OFF or AUTOMATIC mode.
L'appareil fonctionne de façon continue jusqu'à ce que passe en mode OFF ou AUTOMATIQUE.
El aparato funciona continuamente hasta que cambia al modo OFF o AUTOMÁTICO.
2
1
4
3
56
7
8
9
10
LO
OFF HI
About65•F About82•F
3 General Operating Information

7083-171B • July 23, 2013 (877) 427- 33168
D. Firepot Burn Down
Afeatureofthesepelletstovesistherepotburndown
cycle.Thefrequencyofthecycleisonceeveryhourthe
unitisburning.Duringthisevent,thefeedisreducedto
thelowestsettingandtheexhaustblowerrampsupto
thehighestsetting.Thepurposeoftheburndowncycle
istohelpremovedebrisfromtherepotandhelptheunit
burnasefcientaspossible.Thecyclelasts99seconds.
Pleasebeawarethattheburndowndoesnotreplacedaily
cleaningactivitiesbutmakesthemeasier.
E. Shutdown
Toshuttheappliancedown,turnthedialcontrolcounter
clockwisetotheOFFposition.Duringtheshutdownpro-
cess,theLEDwillashgreenrapidlyjustliketheignition
sequence.Therepotburndowncyclewillbeginbutwith-
outthefeedmotorrunning.Thefeedwillbeterminated
duringthisshutdownprocess.Theexhaustandconvection
blowerswillremainonduringtheshutdownprocessuntil
theexhausthascooled.
Ifmaintenanceordailycleaningisgoingtobeconducted
immediatelyfollowingashutdown,pleaseusecautionas
componentsespeciallythoseinsidethereboxmaystillbe
hot.
Please note that if the dial control is turned to the off
position and back on even if by mistake, the unit will
go through the shutdown sequence.
F. Starting Your First Fire
1) Turn the dial control to “OFF”.
2) Make sure the repot is clean, inplace, and free of
debris.
3) Plug the unit into the wall and ll the hopper with
wood pellets. Shut the hopper lid.
4) Turn the dial control to the desired burn setting.
Theunitwillgointotheignitionsequencefollowedby
startup(ThegreenLEDwillashrapidly).Theigni-
tionsequenceinvolvestheexhaustblowerturningon,
theigniterturningon,andthefeedmotorrunningintwo
stages.Therststageinvolvesthefeedmotorrunning
continuouslyforaboutaminutetopreloadpelletsintothe
repot.Followingthepreloadandadelay,thefeedmotor
willbegincyclingonandoff.Whenthepelletsarewarming
upandonthevergeofigniting,itisnotuncommonforthe
reboxtollwithsmoke.Onceignitionactuallyhappens,
thesmokeshouldevacuatequickly.Duringthisstageas
wellasanypartduringtheburnprocess,thefrontdoor
shouldnotbeopened.Thiscyclecontinuesuntiltheunit
sensesignitionbyariseintheexhausttemperatureorthe
unittimesout.Followingtheignitioncycletheunitbegins
tofeedadditionalpelletsgraduallyforafewminutesto
buildupthere.Thisisimportanttohaveacontrolledstart
uptokeeptheunitinbalance.
G. Fire Characteristics
Theoverallheightoftheamewillvarythroughoutthe
burnforacoupleofreasons.Firstisthattheamewill
varybasedontypeoffuelorevenbatchoffuel.Secondly,
theunitadjuststheburnrateaccordingtothehowfar
awaytheroomtemperatureisfromthesettemperature.
Thisshouldnotcausealarm.Thethirdcharacteristicthat
affectsthererelatestogeneralmaintenanceandclean-
ing.Infrequentorpoorgeneralmaintenancewillresultis
poorerperformance.Indicatorsoftheneedforadditional
maintenanceactivitiesincludealazyame,blacksooted
glass,pelletsnotigniting,orpelletsfallingtothesideofthe
repot.Seethemaintenancesectionforadditionalinfor-
mation.
Odorsandvaporsreleasedduringinitialoperation.
• Curingofhightemperaturepaint.
• Openwindowsforaircirculation.
Odorsmaybeirritatingtosensitiveindividuals.
CAUTION
C. Priming the Feed Tube (Cont’d)
AFIREPOTTHATISMORETHANHALFFULLISOVER-
FILLED.DONOTOVERFILLFIREPOTFORIGNITION.
Ifthereareexcessivepelletsintherepotthestartswill
beextremelysmokeyandcauseanunstableignitionthat
includesbutnotlimitedtorumblingandwhistling.
MAXIMUM
PELLET LEVEL

www.pelprostoves.com  7083-171B•July23,2013 9
H. Your Pellet Appliance - General Operating Parts
WARNING
Hot glass will cause burns.
• DO NOTtouchglassuntilitiscooled
• NEVERallowchildrentotouchglass
• Keepchildrenaway
• CAREFULLYSUPERVISEchildreninsameroomasappliance.
• Alertchildrenandadultstohazardsofhightemperatures.
High temperatures may ignite clothing or other ammable materials.
• Keepclothing,furniture,draperiesandotherammablematerialsaway.
HOT SURFACES!
GlassandothersurfacesarehotduringoperationANDcooldown.
NOTICE:Ifyouexpectthatchildrenmaycomeintocontactwiththisappliance,werecom-
mendabarriersuchasadecorativescreen.Seeyourretailerforsuggestions.
2
1
4
3
56
7
8
9
10
LO
OFF HI
0
-
1
-
2
-
3
-
4
+
1
+
2
+
3
+
4
O
N
A
U
T
O
A
L
A
R
M
Baffles (3)
Firepot
Drop Tube
Hopper Lid Switch Dial Control

7083-171B • July 23, 2013 (877) 427- 331610
LED
Color
Number of
Flashes between
pauses
Description Notes
Green SteadyONwhile
primingfeedtube
(maxtime2min-
utes)
FeedMotorisrunningcontinuously.
(Thisprimesthefeedtube).
Whenprimingthefeedsystemandlling
therepot,DO NOT OVERFILL FIREPOT
FOR IGNITION.Theunitwillautomatically
gointostartupfollowingtheprimefunction.
Green SteadyONwhile
burning
Roomtemperatureisclosetoset
pointandburningonlowestburnt
rate.
Green 1x Unitisoffandready. Tostartappliance,followstartupsequence.
Green 3x Applianceisinthestartup/ignition
sequenceorinshutdown.
Duringshutdown,theblowerswillshutoff
whentheexhausttemperaturehascooled.
Green Varies Whenintheautomaticmode,the
numberofashesbetweenpauses
indicatestheburnrate(1forlowupto
5forhigh).
Adjustthedialcontroltochangethedesired
roomtemperature.
Amber SteadyON Applianceissetandrunningateither
theminimumormaximumpower
levels.
Theunitwillshutoffonlywhenthehopper
runsoutoffuel,theuserchangesthe
dialcontroltoadifferentstate,ortheunit
sensesanerror.
Red 1x EmptyHopperAlarm Thisalarmiscausedbytheregoingout
fromlackoffuel.Seetroubleshootingsec-
tionformoreinformation.
Red 2x ExhaustProbeAlarm Failedcomponenterror.Seetroubleshoot-
ingsectionformoreinformation.
Red 3x AmbientProbeAlarm Failedcomponenterror.Seetroubleshoot-
ingsectionformoreinformation.
Red 4x MissedIgnition Thereareatotalof2triesperignition
sequence.Ifafter2triesthereisnorisein
exhausttemperaturethiserrorwilloccur.
Seethetroubleshootingsectionforaddi-
tionalinformationandcorrection.
Red 8x ExhaustGasOverTemperatureAlarm Theexhausttemperatureexceedtheallow-
ablelimit.Seethetroubleshootingsection
formoreinformationandcorrection.
I. LED Color Coding Chart and Explanation
WARNING
FireRisk
DoNOToperateappliance:
• Withappliancedooropen.
• Firepotooropen.
DoNOTstorefuel:
• Closerthanrequiredclearancestocom-
bustiblestoappliance
• Withinspacerequiredforloadingorash
removal.

www.pelprostoves.com  7083-171B•July23,2013 11
N. Trim Adjustment
NOTE:Therightsidepanelmustberemovedto
maketrimadjustmentswiththedialcontrol
Toseeavisual,gotopage18&referencesidepanelreplacementpart
Thesmalldiallocatedbelowthemaindialcontrolisused
toadjusttheamountofcombustionairforthere.You
mayneedtoadjustthecombustionairtotherefor:
 Elevation
 Venting/InstallationCongurations
 FuelQuality
Ifyourreistoolarge,lazy,orproducingblacksoot,you
needMOREair.Toincreasetheamountofcombus-
tionair,rotatecounterclockwiseonelevelatatimeand
allow15minutesforstabilizationpriortomakinganother
adjustment.Ifyourreistoosmallandsometimesgoes
outwhentherearepelletsinthehopper,youmayhave
toomuchair(toolean).Todecreasetheamountof
combustionair,rotateclockwiseonelevelatatimeand
allow15minutesforstabilizationpriortomakinganother
adjustment.
J. Ignition Cycles
1. Atthebeginningofeachignitioncycle,itisnormaltosee
somesmokeintherebox.Thesmokewillstoponce
therestarts.
2. The convection blower will automatically turn on after
yourappliancehasbeenburningforapproximately10
minutes.
Thisblowertransfersheatfromyourapplianceintothe
room,andwill continue torunevenafter the unithas
shutdown.Itwillturnoffaftertheexhausttemperature
hascooled.
3. Occasionallytheappliancemayrunoutoffuelandshut
itselfdown.Whenthishappenstheemptyhopperalarm
willbetriggered.
WARNING! RISK OF FIRE! Keepcombustiblematerials,
gasolineandotherammablevaporsandliquidsclearof
appliance.
• DoNOTstoreammablematerialsintheappliance’s
vicinity.
• DoNOTusegasoline,lanternfuel,kerosene,charcoal
lighteruidorsimilarliquidstostartor“freshenup”are
inthisheater.
Keepallsuchliquidswellawayfromtheheaterwhileitisin
useascombustiblematerialsmayignite.
M. Clear Space
WARNING! RISK OF FIRE! DoNOTplacecombustible
objectsinfrontortothesidesoftheappliance.Hightem-
peraturesmayigniteclothing,furnitureordraperies.
NOTICE: Clearancesmayonlybereducedbymeansap-
provedbytheregulatoryauthorityhavingjurisdiction.
Mantel:   Avoid placing candles and other heat-sensitive
objects on mantel or hearth.  Heat may damage these
objects.
K. Running in Minimum or Maximum
WhenthedialcontrolissettorunontheLOorHIsetting,
theappliancewillcontinuetorunwithoutregardtothe
actualtemperatureintheroom.Theappliancewillshutoff
onlyifthedialcontrolissettoadifferentsettingorthereis
anerrorsuchasanemptyhopper.
WhenrunningonLOorHIitisimportanttofollowthedaily
cleaningactivitiesespeciallycleaningtherepot.Failure
todosowillreducetheperformanceoftheappliance.
L. Running in the Comfort Level Mode
Whenthedialcontrolissettorunintheautomaticmode
theunitwilladjusttheactualburnratebasedonthe
differencebetweentheroomtemperatureassensedby
theprobelocatedintherearoftheunitandthedesired
comfortlevelassetonthedialcontrol.
Thecomfortlevelrangeisfrom65degreesFahrenheitto
82degreesFahrenheit.
Oncethedesiredcomfortlevelisachievedtheappliance
willautomaticallyshutdownandturnoff.Whenthe
temperatureintheroomdrops3degreesbelowthe
desiredcomfortlevel,theappliancewillautomatically
restart.
CONFIDENTIAL PROPERTY OF HEARTH & HOME TECHNOLOGIES INC.
PART NAME:
DRAWN BY: SCALE: MATERIAL:
SHEET:
PART NUMBER: REV:
THIS PRINT IS CHECKED AND CONTROLLED BY THE ENGINEERING
DEPARTMENTS OF HEARTH & HOME TECHNOLOGIES INC.
ECO # DATE BY REV
UNLESS OTHERWISE SPECIFIED DIMS ARE INCHES[MM] & : TOLERANCES ARE: (2) PLACE DEC : ± 0.03 (3) PLACE DEC: ± 0.005 ANGLE: ± 2° FRACTION: ± 1/16
OUTSIDE MATERIAL. NORMAL DIM & INSIDE MATERIAL. OUTSIDE APEX INSIDE APEX - DIMS ENCLOSED BY AN OVAL ARE CRITICAL DIMENSIONS
REVISIONS
ITEM PART NUMBER PART NAME QTY
A RELEASED 72906 06/20/13 MCW
LABEL OPERATION AND MAINTENANCE
MCW NTS SEE NOTE
1 OF 1 7083-168 A
NOTE:
1. MATERIAL: NON-ANODIZED ALUMINUM 0.020 THICK
2. BACKGROUND: BLACK
3. COPY: SILVER
4. ADHESIVE: 3M #468 PERMANENT ACRYLIC
5. TEMPERATURE RATING: -50°F TO 350°F
RELEASED - ---- ----- -
6.75
11.75 4X R0.13
2X
Broken Exhaust Probe
Sonde d'échappement cassé
Sonda de escape roto
1X
Empty Hopper
trémie vide
tolva vacía
OFF
3X
Broken Ambient Probe
Cassé la sonde ambiante
Sonda ambiente roto
4X
Failed Ignition
allumage échoué
de encendido no
OFF
8X
High Exhaust Temperature
Température d'échappement haute
Alta temperatura de escape
Troubleshooting
Dépannage / Solución de problemas
Reset From Error
1. Determine error from above table.
2. Correct error condition. (see Owner’s Manual for additional information.)
3. Turn dial control to OFF position, wait 10 seconds.
4. Follow STARTING instructions.
Réinitialisation des erreurs
1. Déterminer l'erreur de tableau ci-dessus.
2. Condition d'erreur correct. (voir le manuel du propriétaire pour plus
d'informations.)
3. Tourner le cadran de commande en position OFF, attendez 10 secondes.
4. Suivez les instructions de démarrage.
Restablecer de error
1. Determinar el error de la tabla anterior.
2. Condición de error correcto. (consulte el Manual del Propietario para
obtener información adicional.)
3. Gire el dial de control en la posición OFF, espere 10 segundos.
4. Siga las instrucciones de arranque.
Customer Service / Service Clients / Servicio al Cliente
877-427-3316
www.pelprostoves.com
Daily / Quotidien / Todos los días 1 Bag / 1 Sac / 1 Bolsa
Empty Firepot / Creuset Vide / Brasero De Fuego Vacía Clean Firepot / Clean Creuset / Limpieza Brasero De Fuego
Weekly / Hebdomandair / Semanalmente 5 Bags / 5 Sacs / 5 Bolsas
Clean Holes / Nettoyer Les Trous / Limpie Los Oricios
Remove Ash / Retirez Les Cendres / Quitar Las Cenizas
Monthly / Mensuel / Mensualmente 25 Bags / 25 Sacs / 25 Bolsas
1
2
3
Remove / Supprimer / Quitar Vacuum / Vide / Vacío
Maintenance / Entretien / Mantenimiento
7083-168
Operation / Opération / Operación
Automatic Mode *
mode Automatique
Modo Automático
Priming Fuel
carburant d'amorçage
cebado de combustible
Minimum / Maximum **
minimale / maximale
mínimo / máximo
Starting
1. Turn dial control to OFF position.
2. Fill hopper with pellets.
3. Turn dial control to desired setting.
Départ
1. Tourner le cadran de commande en
position OFF.
2. Remplir la trémie avec des granulés.
3. Tourner le cadran de commande au réglage
désiré.
A partir
1. Gire el dial de control en la posición OFF.
2. Llene la tolva con perdigones.
3. Gire el dial de control hasta la posición deseada.
Stopping
1. Turn dial control to OFF position.
2. Allow unit to cool before performing any maintenance.
Arrêt
1. Tourner le cadran de commande en position OFF.
2. Laissez refroidir avant d'eectuer toute opération de maintenance.
Parada
1. Gire el dial de control en la posición OFF.
2. Deje enfriar la unidad antes de realizar cualquier trabajo de mantenimiento.
* The appliance will automatically maintain the desired comfort level and shut down when level
has been achieved.
L'appareil passera automatiquement maintenir le niveau de confort désiré et arrêter lorsque le
niveau a été atteint.
El aparato mantendrá automáticamente el nivel de confort deseado y se cerrará cuando el nivel
se ha logrado.
** The appliance will run continuously until switched to OFF or AUTOMATIC mode.
L'appareil fonctionne de façon continue jusqu'à ce que passe en mode OFF ou AUTOMATIQUE.
El aparato funciona continuamente hasta que cambia al modo OFF o AUTOMÁTICO.
2
1
4
3
56
7
8
9
10
LO
OFF HI

7083-171B • July 23, 2013 (877) 427- 331612
1. Types of Fuel
Thetypeoffuelyouareburningwilldictatehowoftenyou
havetocleanyourrepot.
Ifthefuelyouareburninghasahighdirtorashcontent,it
maybenecessarytocleantherepotmorethanonceaday.
Poorqualityfuelwillcauseclinkerstoformintherepot.A
clinkerisformedwhendirt,ashoranon-burnablesubstance
isheatedto2000°F(1093°C)andbecomesglass-like.See
sectionDfollowingformoredetailsonfuelswithhighash
content.
Shock and Smoke Hazard
• TurndialcontroltoOFF,letappliancecomplete-
lycoolandexhaustblowermustbeoff.Now
youcanunplugappliancebeforeservicing.
• Smokespillageintoroomcanoccurifappliance
isnotcoolbeforeunplugging.
• Riskofshockifappliancenotunpluggedbefore
servicingappliance.
CAUTION
Cleaning or Inspection Frequency Daily Weekly Monthly Yearly
Firepot Every3bagsoffuel OR X
AshRemovalfromFirebox Every5bagsoffuelormore
frequentlydependingonash
build-up
OR X
Glass Whenclearviewofrepot
becomesobscure OR X
Hopper Every25bagsoffuel OR X
ExhaustPath,DropTubeandBehind
Bafes
Every25bagsormorefre-
quentlydependingonash
build-up
OR X
DoorHandle&GasketInspection Priortoheatingseason OR X
Blower,Convection Every25bagsormorefre-
quentlydependingonoperat-
ingenvironment.
OR X
Blower,Exhaust Morefrequentlydependingon
thefueltype OR X
Firebox-PrepareforNon-BurnSeason Atendofheatingseason OR X
VentingSystem Every3tonsormorefre-
quentlydependingonthefuel
type
OR X
B. Quick Reference Maintenance Chart
Follow the detailed instructions found in this
section for each step listed as referenced in
the chart below.
NOTICE: Thesearerecommendations.Cleanmorefrequentlyifyouencounterheavybuild-upof
ashattherecommendedintervaloryouseesootcomingfromthevent.Not properly
cleaning your appliance on a regular basis will void your warranty.
A. Proper Shutdown Procedure C. General Maintenance
4 Maintaining & Servicing the Appliance

www.pelprostoves.com  7083-171B•July23,2013 13
2. Cleaning Firepot with the Firepot Clean-Out Tool;
• Frequency:Dailyormoreoftenasneeded
• By:Homeowner
3. Ash Removal from Firebox
• Frequency:Weeklyormorefrequentlydependingon
ashbuild-up.
• By:Homeowner
 a.Theappliancemustbeincompleteshutdownandcool
andtheexhaustbloweroff.Ifyouarejustcleaningthe
repot,thereisnoneedtounplugtheappliance.
 b.Open the front dooroftheappliance and liftoutthe
firepot.  Use the firepot cleaning tool to break up
depositsinsidetherepotanddisposeinanapproved
container.Dependingonthequalityoffuelused,the
frontoftherepotmayneedtoberemovedforbetter
accessforcleaning.
 c.Usethenarrowendoftherepotcleaningtooltoclean
theholes.
 d.Withtherepotoutcleantheareabelowtherepot.
e.Reassembletherepotandplacebackinsidetherepot
riser.Makesuretherepotisinthecorrectdirection
withtheslanted lip intherear.Failure to installthe
repotcorrectlymayresultinmissedignitions.
 a.Theremustnotbeanyhotashesinthereboxduring
cleaningsoallowtheappliancetocompletelycool.The
reboxashshouldberemovedeverytimetheexhaust
pathiscleaned.Frequentcleaningoftheashinthe
reboxwillhelpslowdownthebuild-upofashinthe
exhaustblowerandventsystem.
 b.Vacuumoutthereboxthoroughlyonbothsidesofthe
reboxandtheoorandceiling.Remembertoplace
the ash and debris into a metal or non-combustible
container.
See Disposal of Ashes.
DisposalofAshes
WARNING
• Ashesshouldbeplacedinmetalcontainer
withtightttinglid.
• Ashesshouldberetainedinclosedcontainer
untilallcindershavethoroughlycooled.
4. Disposal of Ashes
• Frequency:Asneeded
• By:Homeowner
Ashes should be placed in a metal container with a
tight-ttinglid.Theclosedcontainerofashesshould
beplacedonanon-combustibleoororontheground,
wellawayfromallcombustiblematerials,pendingnal
disposal.
Iftheashesaredisposedofbyburialinsoilorotherwise
locally dispersed, they should be retained in the
closedcontaineruntilallcindershavebeenthoroughly
cooled.

7083-171B • July 23, 2013 (877) 427- 331614
8. Cleaning the Exhaust Path, Bafes & Drop Tube
• Frequency:Monthlyorevery25bagsormorefre-
quentlydependingonashbuild-up.
• By:Homeowner
 a.Appliancemustbecompletelycool.
 b. Openthedoorandremovethecenterbaferstand
thentherightandleftbafes.Thoroughlyvacuumthe
exhaustpathanddroptubeandcontinuethroughout
therestofthe rebox. Also vacuum thefrontand
backofthebafes.
 c. Using a small brush, brush the inner walls of the
exhaustoutletfromtheaccessholeinsidetherebox.
Theaccessholewillbevisiblefollowingtheremoval
oftheleftsidebafe.Afterlooseningupdebrison
theinnerwallsoftheoutlet,vacuumout.
This is important as the exhaust temperature
probe is attached to the right side of the outlet.
If this is not maintained on a regular basis, the
appliance will experience nuisance shut downs
and/or missed ignitions.
 d. Replacetherightandleftbafesandthenthecenter
bafeandcloseandlatchthedoor.
7. Cleaning the Hopper
• Frequency:Monthlyorafterburning25bagsoffuel
• By:Homeowner
After burning approximately 25 bags of fuel you will
needtocleanthehoppertopreventsawdustbuild-up.
A combination of sawdust and pellets on the bottom
endoftheaugerreducestheamountoffuelsupplyto
therepot.Thiscanresultinnuisanceshutdownsand
mis-starts.
 a. The appliance must be in complete shutdown.
Allowtheappliancetocompletelyrunoutofpellets
andcooldown.
 b. Emptythehopperofanyremainingpellets.
 c. Vacuumthehopperandfeedtube.Toaccessthe
feedtuberemovethefourscrewsfromtheauger
coverlocatedinsideofthehopper.
6. Cleaning the Glass
• Frequency:Whenclearviewoftherepotbecomes
obscure
• By:Homeowner
 a.Appliancemustbecompletelycool before cleaning
glass.
 b. Vacuumyashfromglassanddoorrope.
 c.Useadamppapertoweloranynon-abrasiveglass
cleaner.Wipeoffwithdrytowel.
Handleglassassemblywithcare.
When cleaning glass:
• Avoidstriking,scratchingor
slammingglass.
• DoNOTcleanglasswhenhot.
CAUTION
• DoNOTuseabrasivecleaners.
• Refertomaintenanceinstructions.
• DoNOToperatewithglasscracked,
brokenorscratched.
9. Door Handle Inspection
• Frequency:Monthlyorpriortoheatingseason
• By:Homeowner
The gasketing between the glass and rebox should be
inspectedperiodicallytomakesurethereisagoodseal.
NOTE: Pelpro recommends using a heavy duty vacuum
cleaner specically designed for solid fuel appli-
ance cleaning.
1
2
3

www.pelprostoves.com  7083-171B•July23,2013 15
13. Soot and Fly Ash: Formation & Need for Removal
in Exhaust Venting System.
• Frequency:Yearlyormorefrequentlydependingon
ashbuild-up.
• By:QualiedServiceTechnician/Homeowner
Besuretheapplianceisallowedtocool,hasbeenunplugged
andtheexhaustblowerisoff.
Theproductsofcombustionwillcontainsmallparticlesofy
ash.Theyashwillcollectintheexhaustventingsystem
andrestricttheowoftheuegases.
Atstart-upifthereisincompletecombustion,orifthereisa
shutdownorincorrectoperationoftheapplianceitwilllead
tosomesootformation.Thiswillcollectintheexhaustvent-
ingsystem.
Theventing(chimney)systemmayneedtobecleanedat
leastonceayearormoreoftendependinguponthequal-
ityofyourfuelorifthereareanyhorizontalpipesections.
Ashwillbuildupmorequicklyinthehorizontalsectionsand
elbows.
11. Cleaning Exhaust Blower - Requires No
Lubrication
• Frequency:Yearlyormorefrequentlydependingon
ashbuild-up
• By:HomeownerorQualiedServiceTechnician
10. Cleaning Convection Blower - Requires No
Lubrication
• Frequency:MonthlydependingonDust/Dirtbuild-up
• By:HomeownerorQualiedServiceTechnician
12. Preparing Firebox for Non-Burn Season
• Frequency:Yearly
• By:Homeowner
 a.Besuretheapplianceisallowedtocool,hasbeen
unpluggedandtheexhaustblowerisoff.
 b. Removeallashfromthereboxandvacuumthoroughly.
 c. Paintallexposedsteel,includingcast-iron.
• Purchasehightemperaturepaintfromyourlocal
retailer.
• Mustuseahigh-temperaturepaintmadespeci-
callyforheatingappliances.
 a.Besure the appliance is allowed to cool, has been
unpluggedandtheexhaustblowerisoff.
 b.Removetheleftsidepanel.
 c.Remove the six screws holding the exhaust blower
motortothehousingandremovethemotor.Using
cautionastonotdamagethegasketwhenremoving
theblower.Ifdamageoccurs, install anewgasket
availableasareplacementpart.
 d.Vacuumtheblower’simpellers.Usecarenottobend
ordamagetheblowerns.
e.Usingabrushorvacuumattachment,cleantheinside
oftheexhaustoutlet.
f.Reattachthemotor.Makesurethewiresareattached
totheterminalsontheblower.
 a.Besuretheapplianceisallowedtocoolandhasbeen
unplugged.
 b.Removetherightsidepanel.
 c.Sweeporvacuumoutanybuild-upontheimpellers.
Useabrushorcompressedairtoloosendirtifneeded.
Avoiddamagingtheimpellers.

7083-171B • July 23, 2013 (877) 427- 331616
D. High Ash Fuel Content Maintenance
• Frequency:Asneeded
• By:Homeowner
Poorqualitypelletfuel,lackofmaintenance,orifthesmall
dialcontrolissettoalessthanoptimumsetting,poorcom-
bustionconditionsthatmaketherepotllquicklywithashes
andclinkers.
Thisconditionmakestheappliancesusceptibletooverlling
the repot with pellets which may result in smoking, soot-
ingandpossiblehopperres.Thegurebelowshowsan
examplewheretherepotoverlls,pelletsbackupintothe
feedtubeandashhasaccumulatedintherebox.
Aninefcientandnon-economicalmethodofburningoffuel
causedbypoorqualitypelletfuelisshownbelow.
If the ash buildup exceeds the half way point in the repot
IMMEDIATE ATTENTION AND CLEANING IS REQUIRED.
Incorrect Flame Height
Tall, Lazy Flame
Orange in Color
Pellets Back-up in Feed Tube
Ash build-up in Firebox
Firepot Overfills

www.pelprostoves.com  7083-171B•July23,2013 17
E. Frequently Asked Questions
What causes my glass to become dirty?
Iftheglasshaswhiteashbuildupitisnormalandthe
glassshouldbecleaned.Ifitisablacksootbuildup
airowthrutheunitmayberestricted.Themostoften
causeisoverduemaintenanceandcleaning.See
“MaintainingandServicingAppliance”intheowner’s
manualand/ormakeadjustmentstothetrimcontrol.
How can I get more heat out of the appliance?
Themostoftencauseofdiminishedheatoutputis
overduemaintenanceandcleaning.See“Maintaining
andServicingAppliance”intheowner’smanual.
What should I do if I smell smoke or there is ash/
soot coming from the appliance?
Whiletherewillalwaysbesomesmokesmellfrom
woodburningappliances(includingpellet)youshould
investigateallventingtomakesureitissealedprop-
erly.Mostventingrequiressiliconetosealtheseams.
Inadditionmosthomesarebuiltverytighttodayand
withexhaustsystemscancreatenegativepressure
inthehome.See“NegativePressure”under“Getting
Started”intheowner’smanualifyouhavecheckedthe
ventingbutstillhavesmokecomingfromtheappli-
ance.Forashorsootchecktheaboveandtheexhaust
blowerhousingandseals.
Why would my appliance run ne last winter but
not start this fall?
Itispossiblethatthestovewasnotproperlyprepared
fortheNon-burnseason.See“Troubleshooting”inthe
owner’smanual.
Why would the metal on the inside of the appliance
begin to ake?
Therearesomepelletmillsthatgettheirrawmaterials
fromlumbermillsthatpurchaselogsthataretrans-
portedinseawater.Thesepelletscanhaveahigher
saltcontentandcausethemetalsintheunittocorrode
prematurelyanddeteriorate.Ifyouareseeingany
componentsinsidethereboxdeteriorateitisrecom-
mendedtochangepelletbrandsimmediately.
Is there a place to lubricate the blowers to quiet
them down?
Themostoftencauseofnoisyblowersisfromthe
impellersbecomingdirtyovertime.See“GeneralMain-
tenance&Cleaning”under“Maintaining&Servicing
Appliance”intheowner’smanual.Noformoflubrica-
tionshouldeverneedappliedtotheblowers.
What is the metal object with the bend in it for that
came inside the plastic bag?
Itisaclean-outtoolusedtohelpcleantherepotand
removeanyjamsintherareeventtheyoccurinthe
feedtube.
Why is there a black residue building up on the
outside of my home?
Windcancausethistohappen.Iftheapplianceis
operatingcorrectlyverylittlesootshouldeverexitthe
terminationcap.Alsochecktobesuretheventingis
installedpertheowner’smanualandlocalcodes.
Do I need an outside air kit?
Outsideairisrequiredformobilehomeinstallsandin
somejurisdictions.Referto“Listing&CodeApprov-
als”,“MobileHomeInstallation”and“ApplianceSet-up”
owner’smanual.Alsorefertolocalbuildingcodes.
I am seeing sparks coming out of my pipe (termina-
tion cap) outside is this safe?
Thisisnormal.Aslongasclearancestocombustibles
werefollowedthisissafe.
I have no power to anything. Does this unit have a
circuit breaker or fuse or a reset button?
Thisunithasoneserviceablefuseonthecontrolboard
andaresetablesnapswitchmountedtothefeedtube.
Can I burn corn in my unit?
NO,cornisnotanapprovedfuel.
Where is the serial # of my unit is located?
Theserial#islocatedonthebackofthestove.

7083-171B • July 23, 2013 (877) 427- 331618
A. Convection Blower Replacement
1. Turnthedialcontroltotheoffposition.Unplugthepower
totheunit.
2. Theconvectionblowerislocatedintherearoftheunit.
3. Using #2 Phillips screwdriver, loosen the bolts on the
rearoftheunitholdingonthesidepanels.Youdonot
need to remove the screws. Remove side panels by
liftingupandout.
4. Unplugthewiresfromtheconvectionblowermotorfrom
therightsideoftheunit.
5. Removethetwoscrewsholdingtheconvectionblower
housing to the sheet metal plenum.  Using a slight
twistingmotion,rotatetheblowerbackanditwillrelease.
B. Exhaust Blower Replacement
1. Turnthedialcontroltotheoffposition.Unplugthepower
totheunit.
2. Removetheleftsidepanelbylooseningthetwoorthree
boltsintherearoftheunit.
3. Disconnect2whitewiresfromthewhiteandbluewiresof
theexhaustblower.
4. Removetheblowermotorattachedtoaremovableplate
on the exhaust blower.  Depending on the model, use
a 1/4 inch socket, or 1/4 inch Nut Driver or #2 Phillips
Headscrewdrivertoloosenthe6screwsinthekeyhole
shapedholesandrotatetheplate.Itisonlynecessaryto
loosenscrews.
5. Removetheexhaustblowerandgasket.
6. Check for degradation on the gasket and replace if
necessaryusingthegasketincludedinthekit.
7. Re-installinreverseorder.
Loosen Screws,
Do Not Remove
5 Replacement Parts

www.pelprostoves.com  7083-171B•July23,2013 19
C. Snap Disc Replacement
Power - Manual Reset
1. Turnthedialcontroltotheoffposition.Unplugthepower
totheunit.
2.Using#2Phillipsscrewdriver,loosentheboltsontherear
oftheunitholdingontheleftsidepanel.Youdonotneed
toremovethescrews.Removesidepanelsbyliftingup
andout.
3.Locate the snap disk on the top side of the feed tube
where it meets the hopper.  Disconnect the wire leads
fromthesnapdisk.
4.Usinga#1Phillipsscrewdriver,removetwo6-32fasten-
ersretainingthesnapdiskontothesideofthefeedtube.
5.Using the same fasteners, attach the new snap disk.
Attachthewireleads.
6.Restorepower.
D. Igniter Replacement
 1. Turnthedialcontroltotheoffposition.Unplugthe
powertotheunit.
 2. Unplugthewireleadstotheigniter.
 3. Removethescrewinthesideoftheigniterchamber.
Pinchtheendsofthebrackettogetherandpullthe
igniterstraightoutoftheigniterchamber.
 4. Ifthereisdifcultyinremovingtheigniterfromthe
chamber,thechambercanberemovedfromtherear
ofthereboxbyremovingthe1/4-20bolt.
 5. Re-installthenewigniterintothechamberusingthe
bracket.
 6. Inspect the igniter from the front of the unit by
removing the repot and looking into the end of
the chamber.  MAKE SURE THE IGNITER IS
CENTEREDINTHECHAMBER.
E. Bafe Removal & Replacement
1. Turnthedialcontroltotheoffposition.Makesurethe
unitiscool.
2. Remove the center bafe rst by using the handle at
thetopofthebafeandpullupandthentowardsyou.
Thehooksonthebafewillslideoutoftheslotsinthe
bracket.
3 . Removetheleftbafeandthentherightbafebypulling
upandthentowardsyou.Theleftandrightbafeshave
similarhooksandslots.

7083-171B • July 23, 2013 (877) 427- 331620
• Glassis5mmthickhightemperatureheat-
resistantceramicglass.
• DONOTREPLACEwithanyothermaterial.
• Alternatematerialmayshatterandcause
injury.
WARNING
F. Glass Replacement
1. Openthedoorfromtheappliancebyliftingdooroffofhinge
pinsandlayonaatsurfacefacedown.
2. UsingaPhillipsHeadscrewdriver,removethe3brackets
andsetaside.
3. Removeoldglassandreplacewiththenewglass.
4. Re-installthebracketsusingthesamescrews.
G. Control Board Replacement
1. Turnthedialcontroltotheoffposition.Unplugthepower
totheunit.
2. Unplugthewiresfromthecontrolboard.Theconnectors
arelockingconnectors.Pinchthereleasetaboneach
connectorandgentlytugandrockloose.
3. Pinchthe4plasticpinsfromtherearoftheunittorelease
thecontrolboardconnectors.
4. Installnewboardfollowingthestepsinreverse.
H. Fuse Replacement
1. Turnthedialcontroltotheoffposition.Unplugthepower
totheunit.
2. Pulltheplasticfuseholdercoveroffthecontrolboard.
3. Replacefusewith5AMP120VACfuseonly.
4. Replacethecoveronthefuseholderandrestartunit.
I. Feed Motor Replacement
1. Turnthedialcontroltotheoffpositionandunplugtheunit.
Removetherightsidepanelandfeedmotorcoverplate
intherearoftheunit.
2. Unplugtheconnectorfromthefeedmotor.
3. Usingpliers,removethecotterpin.
4. Removethefeedmotorfromthefeedshaft.
5. Reinstall the new feed motor by aligning the clearance
holeinthefeedmotorshaftwiththeaugerspringshaft.
6. Plugthefeedmotorleadsbackinandrestorepower.
J. Feed Spring Replacement
1.Emptythehopperofallpellets.thenfollowthestepsto
removethefeedmotorabove.
2. Removethefourscrewsholdingthefeedmotorbracket
on.
3. Slidetheaugerassemblyoutfromthebottomintherear
oftheunit.
4. Inspectthebronzebearings,replaceifneeded.
5. Install new spring assembly following reverse steps
includingreattachingthefeedmotor.
