Pensar Medical WoundPro Reference guide

Quick Reference Card
This Quick Reference Card provides guidelines for the use of the Pensar Medical WoundPro® Negative
Pressure Therapy System. These guidelines DO NOT replace instructions from the patient’s physician.
To Operate the WoundPro Control Unit
●To turn the unit on press the Power button 1.
The unit will enter Standby Mode.
●To change the settings, enter the
Programming Mode by pressing
and holding the Power button
and then pressing the Menu Button 2.
●Either Continuous Mode or Intermittent
Mode will flash depending on the last therapy
chosen prior to turning o the unit.
❍To change between Continuous and Intermittent
Modes, press either the Up or Down Arrow key. Press
the Menu button to enter the mode you wish to use.
❍Press the Up 3and Down 4Arrows to change the
pressure (in intermittent mode press the menu button
to cycle through the pressure and time settings).
●When you have achieved the desired settings press the Power
button to exit the Programming Mode (the unit will then enter
the Standby Mode).
●Press the Power button again to begin therapy.
Canister Changes
●Disconnect the canister tubes from the wound dressing tubes.
❍Create a circular loop with the tubes, or clamp them
(depending on the kit style), to prevent any fluid leakage
during the canister change procedure.
●Depress the blue canister release button 7on the top of the unit while
pulling the canister away from the unit.
●Release the canister release button and slide the new canister into the unit.
You should hear an audible “click” to ensure a secure connection.
●Attach the new canister tubes to the wound dressing tubes and recommence
the therapy on the wound.
Lock Out
●To avoid improper settings by untrained personnel, the WoundPro
automatically enters a Therapy Lock Out Mode aer being programmed.
When in the Lock Out Mode a visible symbol will be displayed on the
control panel.
●To disengage the Lock Out Mode press and hold the Power Button
and then press the Menu button to enter the programming mode.
1. Power button
2. Menu button
3. Up button
4. Down button
5. Canister Light
6. Alarm button
7. Canister Release Button
continued on other side
1
3
4
2
5
6
7

4/16 Rev B UPC 84635400491
Informational Alarms
The informational alarms do not immediately stop the operation of the pump. They allow the
caregiver to correct the condition without an undue or prolonged stoppage of the desired therapy.
In both situations the unit will continue to run normally for a finite period of time. If not addressed,
in time the unit will stop operating depending on the condition.
Low Battery Power: (3 beeps every minute)
●To correct this alarm, plug the WoundPro control unit into an outlet to recharge the battery.
The battery is recharging whenever the unit is plugged into an electrical wall outlet.
Canister Full: (3 beeps every minute) canister full
●Alerts the caregiver the canister is nearly full.
●To correct this alarm, pause the pump and replace the canister.
●Unit will eventually stop operating if canister reaches a full condition.
Warning Alarms
These alarms alert the caregiver of a situation requiring their immediate attention. These conditions
directly aect the ability of the system to deliver therapy.
The increased frequency of the warning alarm sounds clearly dierentiates these conditions
from the informational alarm conditions.
Suction Line Blocked: (3 beeps every 5 seconds) line blocked
●To fix this alarm condition pause the pump and replace the canister and tubing. If condition
persists aer canister replacement, the dressing and its tubing may also need to be replaced.
Vacuum Leak: (3 beeps every 5 seconds) vacuum leak
●The unit will continue to run for the first 30 minutes of a vacuum leak alarm. If the alarm cause
is not addressed within 30 minutes, the pump will stop and the alarm will continue to sound.
●To correct this alarm condition, check to ensure:
❍The canister is properly attached to the control unit.
❍The extension tubing is securely attached to the canister.
❍The drain tubing is securely attached to the extension tubing.
❍The dressing is sealed around the wound and drain tubing.
Standby Alarm
Standby: (Rapid triple beep aer 30 minutes of non-operation) standby
❍If the WoundPro Unit is le in the Standby Mode over 30 minutes, an alarm will sound to
alert the user to correct the condition. To disengage this alarm, the user can either resume
therapy or power down the unit if therapy is no longer required.
Warning Alarms need to be addressed as soon as possible. The therapy is stopped or lessened as long as the cause of
the alarm is not corrected. If you are unable to correct the cause of the alarm contact the physician for instructions.
If you are unable to reach the physician, contact an emergency room for assistance.
Additional Precautions – Additional care should be taken when using the WoundPro on patients taking
anticoagulants or platelet aggregation inhibitors, patients with active bleeding, patients with wound hemostasis,
patients that have a history of irradiated blood vessels, wounds that involve a fistula, wounds with sinus tracks,
wounds with tunneling, or when using the WoundPro in close proximity to blood vessels or organs.
Failure to obtain and follow instructions from the treating physician could result in injury or death.
For further instructions see the WoundPro Operator’s Manual.
800.669.4757 |www.pensarmedical.com
42225 Remington Ave. |#A3 |Temecula, CA 92590
