Pentair jung pumpen Multistream ex 75/4 c5 ex User manual

EN Instruction Manual

www.pts-jung.co.uk B41990.42-2020.07

MULTISTREAM

55/2 B2 75/2 B5 100/2 B5 55/2 B2 EX 75/2 B5 EX 100/2 B5 EX

55/4 B6 75/4 B6 100/4 C2 55/4 B6 EX 75/4 B6 EX 100/4 C2 EX

55/4 C2 75/4 C2 100/4 C5 55/4 C2 EX 75/4 C2 EX 100/4 C5 EX

55/4 C5 75/4 C5 55/4 C5 EX 75/4 C5 EX

35/46 B6 55/26 C2 55/46 B6 UC 55/2 B2 UC 55/4 C5 UC 75/2 B5

UC 75/4 B6 UC 75/4 C5 UC 100/2 B5

ENGLISH

You have purchased a product made by

Pentair Jung Pum-

pen

and with it, therefore, also excellent quality and service.

Secure this service by carrying out the installation works

in accordance with the instructions, so that our product

can perform its task to your complete satisfaction. Please

remember that damage caused by incorrect installation or

handling will adversely affect the guarantee.

This appliance can be used by children aged 8 years or over

and by persons with limited physical, sensory or intellectual

capabilities, or with limited experience and knowledge, pro-

vided that they are supervised or have been instructed in

the safe use of the appliance and are aware of the dangers

involved. Children must not be allowed to play with the ap-

pliance. Cleaning and user maintenance must not be carried

out by children unless they are supervised.

Damage prevention in case of failure

Like any other electrical device, this product may fail due to a

lack of mains voltage or a technical defect.

If damage (including consequential damage) can occur as a re-

sult of product failure, the following precautions can be taken

at your discretion:

•Installation of a water level dependent (under circumstan-

ces, mains-independent) alarm system, so that the alarm

can be heard before damage occurs.

•Inspection of the collecting tank/chamber for tightness up

to the top edge before – or at the latest, during – installation

or operation of the product.

•Installation of backow protection for drainage units that can

be damaged by wastewater leakage upon product failure.

•Installation of a further product that can compensate in

case of failure of the other product (e.g. duplex unit).

•Installation of an emergency power generator.

As these precautions serve to prevent or minimise conse-

quential damage upon product failure, they are to be strictly

observed as the manufacturer’s guideline – in line with the

standard DIN EN specications as state of the art – when using

the product (Higher Regional Court Frankfurt/Main, Ref.: 2 U

205/11, 06/15/2012).

SAFETY INSTRUCTIONS

This instruction manual contains essential information that

must be observed during installation, operation and servic-

ing. It is therefore important that the installer and the respon-

sible technician/operator read this instruction manual before

the equipment is installed and put into operation. The manual

must always be available at the location where the pump or the

plant is installed.

Failure to observe the safety instructions can lead to the loss

of all indemnity.

In this instruction manual, safety information is distinctly la-

belled with particular symbols. Disregarding this information

can be dangerous.

General danger to people

Warning of electrical voltage

NOTICE!NOTICE!

Danger to equipment and operation

Qualication and training of personnel

All personnel involved with the operation, servicing, inspection

and installation of the equipment must be suitably qualied

for this work and must have studied the instruction manual in

depth to ensure that they are suciently conversant with its

contents. The supervision, competence and areas of responsi-

bility of the personnel must be precisely regulated by the ope-

rator. If the personnel do not have the necessary skills, they

must be instructed and trained accordingly.

Safety-conscious working

The safety instructions in this instruction manual, the existing

national regulations regarding accident prevention, and any

internal working, operating and safety regulations must be ad-

hered to.

Safety instructions for the operator/user

All legal regulations, local directives and safety regulations

must be adhered to.

The possibility of danger due to electrical energy must be pre-

vented.

Leakages of dangerous (e.g. explosive, toxic, hot) substances

must be discharged such that no danger to people or the envi-

ronment occurs. Legal regulations must be observed.

Safety instructions for installation, inspection and mainte-

nance works

As a basic principle, works may only be carried out to the equip-

ment when it is shut down. Pumps or plant that convey harmful

substances must be decontaminated.

All safety and protection components must be re-tted and/or

made operational immediately after the works have been com-

pleted. Their effectiveness must be checked before restarting,

taking into account the current regulations and stipulations.

Unauthorised modications, manufacture of spare parts

The equipment may only be modied or altered in agreement

with the manufacturer. The use of original spare parts and

accessories approved by the manufacturer is important for

safety reasons. The use of other parts can result in liability for

consequential damage being rescinded.

Unauthorised operating methods

The operational safety of the supplied equipment is only guar-

anteed if the equipment is used for its intended purpose. The

limiting values given in the "Technical Data" section may not be

exceeded under any circumstances.

Instructions regarding accident prevention

Before commencing servicing or maintenance works, cordon

off the working area and check that the lifting gear is in perfect

condition.

Never work alone. Always wear a hard hat, safety glasses and

safety shoes and, if necessary, a suitable safety belt.

Before carrying out welding works or using electrical devices,

check to ensure there is no danger of explosion.

People working in wastewater systems must be vaccinated

against the pathogens that may be found there. For the sake of

your health, be sure to pay meticulous attention to cleanliness

wherever you are working.

Make sure that there are no toxic gases in the working area.

Observe the health and safety at work regulations and make

sure that a rst-aid kit is to hand.

In some cases, the pump and the pumping medium may be hot

and could cause burns.

ENGLISH

For installations in areas subject to explosion hazards, special

regulations apply!

AREAS OF APPLICATION

Submersible pumps in the MultiStream range are suitable for

pumping wastewater in municipal and industrial pumping sta-

tions, and in rainwater retention tanks.

MultiStream pumps are favoured for use with:

–wastewater containing bres

– wastewater containing solids (without stones)

– mixed wastewater

– untreated water

– raw sludge

– surface water and rainwater

The submersible pumps are supplied without explosion pro-

tection or with explosion protection.

When using the pumps, the relevant national laws, regulations

and stipulations must be adhered to, for example:

•Installation of low-voltage systems (e.g., VDE 0100 in Germa-

ny)

•Safety and working materials (e.g., BetrSichV and BGR 500

in Germany)

•Safety in wastewater systems (e.g., GUV-VC5, GUV-R104 and

GUV-R126 in Germany)

•Electrical systems and operating resources (e.g., GUV-VA3

in Germany)

•Explosion protection EN 60079-0, EN 60079-1 and EN 1127-1

For non-standard utilisation conditions in areas subject to ex-

plosion hazards, please ask the local authority responsible.

In Germany, this would be, for example, the Trade Supervisory

Centre (Gewerbeaufsicht), the Technical Inspection Agency

(TÜV), the building authority (Bauamt) or professional organi-

sation (Berufsgenossenschaft).

The installation and operation of this equipment is regulated by

the ordinance concerning the protection of health and safety in

the provision of work equipment and its use at work, concerning

safety when operating installations subject to monitoring, and

concerning the organisation of industrial health and safety at

work, (Betriebssicherheitsverordnung), Article 1.

Where no explosion protection is stipulated for the pumping

of foul wastewater at the installation location, pumps without

explosion protection may also be used.

Modes of operation

with the pumped medium at a temperature of 40°C:

Motor submersed: continuous operation S1

Motor emerged: short duration operation S2; see "Technical

Data"

Motor emerged: intermittent operation S3; see "Technical Data"

The submersible pump is frost-resistant down to -20°C when

stored in dry conditions. When installed, however, it must not

be allowed to freeze in the water.

Transport

The pump must never be lifted by the power supply cable! The

pump should only be lowered by using a chain.

ELECTRICAL CONNECTION

Circuitry

Alterations to the circuitry are to be made using crimp con-

nectors (X) between the coni plug connection (Y) and the built-

in motor. The new crimp connection must be professionally

made.

By using our controls, you can be sure that the requirements of

the EU type-testing certicate are met.

NOTICE! Only qualied electricians may carry out electrical

works to the pump or the controls.

The standards applicable in each case (e.g. EN), the country-

specic regulations (e.g. VDE in Germany), and the regulations

of the local supply network operator must be observed.

NOTICE! Never lay the end of cables in water! Penetrating wa-

ter may cause malfunctions.

Only slow-blow fuses or automatic fuses with C or D character-

istics are to be used as pre-fuses for the pump. Necessary fuse

protection for for star-delta start 16A for pumps 55..., 20A for

pumps 75... and 25A for pumps100...

The pump must be protected via an overload trip. Setting for

direct on-line start = nominal current, and for star-delta start =

nominal current x 0.58.

If the protective device has been triggered, the cause of the

malfunction must be eliminated before switching on again.

Coil thermostats

NOTICE! In addition to the overload trip or protective switch

of the motor, the thermostats integrated in the motor winding

must also be connected. The thermostats are suitable for 250

V / 1.2 A (cos phi = 0.6) and are labelled 30 and 32 for connection

purposes.

Thermostat connection without explosion

protection

The thermostats are to be connected in such a way that the

motor is switched off via the control circuit when the response

temperature is reached. The motor is switched on again auto-

matically after the winding has cooled down.

Thermostat connection with explosion

protection

The thermostats are to be connected in such a way that the

motor is switched off via the control circuit when the response

temperature is reached. It must not be possible for the motor

to switch on again automatically after the winding has cooled

down.

ENGLISH

WARNING!

After an automatic cut-out via the temperature limiters, the

cause of the malfunction must rst be eliminated. Only then

may the motor be switched on again manually.

The restart interlock must be "non-resetting on power failure",

i.e. the lock must be in place to prevent restarting even after a

power cut (in Europe: Directive 2014/34/EU , Appendix II 1.5, EN

60079-17 Table1, B10).

Operation with frequency converter

Frequency converters may only be used for controlling the fre-

quency of special models of three-phase pumps. For hydraulic

reasons we do not recommend operation below 30 Hz.

NOTICE! For physical reasons, pumps may not be operated at

a higher frequency than that shown on the type plate. If the

frequency increases beyond the value on the type plate, the

power input increases and the motor is then overloaded.

For special models of three-phase pumps that are designed for

frequency converter operation, the motor type shown on the

type plate is labelled with an additional "K" (e.g. D90-2/75 CK).

These pumps also have a sticker on the end of the cable that

indicates their suitability for use with a frequency converter.

These motors are tted with PTC thermistors as winding pro-

tectors. Voltages of more than 2.5 V may not be connected to

the winding protection terminals 40 and 41! For explosion pro-

tected pumps, a type-tested tripping unit that complies with

the EU type-testing requirements is also necessary.

Rotational direction

The rotational direction must be checked before installation! If

the rotational direction is correct, the start-up jolt should be in

the opposite direction to the rotational direction arrow on the

motor housing. The wrong rotational direction is also indicated

if the pump performs inadequately when installed, or if loud

noises can be heard during operation. If the rotational direc-

tion is wrong, 2 phases of the supply cable must be swapped

over.

CAUTION!

The start-up jolt can be very forceful.

Potential equalisation

To comply with EN 60079-14 and EN 1127-1, an additional equi-

potential bonding must be installed for facilities with protec-

tive earth conductors in TN/TT networks in areas subject to

explosion hazards. In Germany, for example, the design must

be in accordance with VDE 0100, Part 540 (Association of Ger-

man Electrical Engineers).

No additional potential equalisation is required on site for

JUNG PUMPEN concrete or plastic chambers in explosion

zones 1 and 2 (statement made by TÜV Nord (Technical Inspec-

tion Agency) in March 2008).

Exception: if conductive parts, such as cable protection

sleeves made of corrugated pipe or a pressure pipe made of

metal, are connected to the chamber from the outside. In this

case, an electrically conductive connection must be made be-

tween the conductive parts and the housing of the pump(s).

For corrosion protection reasons, the connection should be

made using stainless steel.

Explosion protected pumps have a special connection point at

the cable entry point.

INSTALLATION

ATTENTION! Before the pump can be installed, the 4 plastic

packaging feet must be unscrewed from the bottom of the

pump housing and removed.

The pump must be installed as shown in the examples. For in-

stallations in accordance with EN 12056-4, the pressure pipe

must be laid in a loop above the local back pressure level and

protected with a back pressure prevention valve.

Example installation with guide rail system

Assembly: Fix the coupling base rmly to the oor of the col-

lection chamber using plugs and then mount the guide rails.

Next, install the pressure pipe including the necessary ttings,

such as the non-return valve and shut-off valves.

Finally, t the pump with the screwed-on coupling catch on to

the guide rails and lower it into place using a chain xed to the

shackle.

A xing facility for lifting gear should be provided above the

chamber opening at a sucient height.

Level monitoring can be carried out using various systems.

Their specic characteristics and requirements can be found

in the relevant operating manuals.

WARNING!

In accordance with the explosion protection laws and regula-

tions, JUNG Ex-pumps should never be allowed to run dry or to

operate in "snore" mode.

The pump must switch off when the water level sinks to the

upper edge of the pump housing (x in the illustration), at the

very latest. This shut-down must be implemented via a sepa-

rate switching circuit. Dry running for servicing or inspection

purposes may only take place outside the potentially explosive

area.

A correspondingly larger diameter pipe should be used for

longer pressure pipelines to avoid pipe friction losses.

Rising pressure pipes must be protected from frost! A cham-

ber cover must be selected that is suitable for the intended use

and has the required load-bearing capacity.

If necessary, the pump housing can be ventilated by unscrew-

ing the "Luft" sealing screw. A ushing pipe, available as an ac-

cessory, can be installed to minimise deposits and the forma-

tion of oating layers in the chamber.

If the pump is malfunctioning, part of the contents of the oil

reservoir could escape into the pumping medium.

Not Ex-pumps. If a hose is used as a pressure line, care must

be taken to ensure that for every pumping operation the hose

is completely empty before the pump is submersed. Any resid-

ual liquid would obstruct the ventilation of the pump housing

and therefore also hinder the pumping operation.

ENGLISH

This situation can also occur if the pump runs dry, pumps down

to a lower lever than that shown in the installation drawing, or

runs in "snore" mode during the daily test run.

In these cases, the pump housing must be ventilated by un-

screwing the "LUFT" sealing screw.

SERVICING

Maintenance and inspection of this product must be carried

out in accordance with EN 12056-4 and EN 60074-19.

To ensure continued reliability of service, we recommend that

you take out a service contract.

WARNING!

Before carrying out any works: disconnect the pump and the

controls from the mains and take steps to ensure that it cannot

be emergized again.

WARNING!

Check the mains cable for signs of mechanical and chemical

damage.

Damaged or kinked cables must be replaced by the

manufacturer.

NOTICE! When using a chain to lift the pump, please observe

the relevant national regulations regarding accident preventi-

on. Lifting gear must be checked regularly by an expert in ac-

cordance with the legal regulations.

NOTICE! Motors in the Ex-range conform to the "ameproof

enclosures" ignition protection category. Maintenance works

that affect the explosion protection may only be carried out by

authorised specialists or by the manufacturer. When carrying

out repairs, all areas next to ameproof gaps must be checked

for damages and, if necessary, replaced by genuine parts.

Oil check

The drain plug is labelled "OEL". In order to check the mechani-

cal seal, the oil, including any residue, must be drained from

the oil reservoir and collected in a clean measuring container.

•If the oil is contaminated with water (milky), an oil change

must be carried out. Check again after a further 300 operat-

ing hours, but at the very latest after 6 months!

•However, if the oil is contaminated with both water and pol-

lutants, then not only the oil must be replaced, but the me-

chanical seal as well.

For monitoring the oil reservoir, it is also possible to retrot the

electrode of our "DKG" or "DKG-Ex" seal leak control device in

place of the "DKG" sealing screw.

Changing the oil

To ensure operational liability, the rst oil change should be

carried out after 300 operating hours, with further oil changes

carried out after every 1000 operating hours.

If the number of operating hours is very low, an oil change

should still be carried out at least once a year.

If wastewater with strongly abrasive constituents is being

pumped, the oil changes should be carried out at correspond-

ingly shorter intervals.

Use HLP hydraulic mineral oil, viscosity class 22 to 46, e.g. Mo-

bil DTE 22, DTE 24, DTE 25, to replace the oil in the oil reservoir.

The quantity of oil required is 1700 cm³.

NOTICE! The oil reservoir may only be lled with the specied

quantity of oil. Overlling will result in the pump being rendered

inoperable.

Cleaning

To clean the impeller and the spiral housing, simply remove the

4 hexagonal screws and lift the motor unit off the spiral hous-

ing.

CAUTION!

Worn impellers can have sharp edges.

NOTICE! If the wrong screws are unscrewed, the oil will run out

of the oil reservoir.

Tightening torque MAfor A2 screw materials

for M 6 MA= 8 Nm

for M 8 MA= 20 Nm

for M 10 MA= 40 Nm

for M 12 MA= 70 Nm

for M 16 MA= 160 Nm

Checking the pump unit

The housing screws for the pump, and the connecting and x-

ing screws of the installation must be checked to ensure they

are xed securely. They should be tightened if necessary.

If the pump performance decreases, or if increasingly loud

noises can be heard during operation, the gap dimension be-

tween the impeller face and the wear plate must be checked

for wear by an expert and replaced if necessary. Nominal di-

mension: 0.5 - 0.8 mm.

Adjust the impeller gap

1. Block the impeller.

2. Loosen the central impeller screw located in the impeller

hub.

3. Loosen the impeller by knocking it gently with a hammer.

4. Tighten the impeller screw until it is “hand tight”.

5. Adjust the impeller gap by pulling the impeller down to the

nominal dimension 0.5 - 0.8 mm.

6. Block the impeller again and tighten the impeller screw to

160 Nm.

The maximum adjustment possible is 3 mm

Replace the wear plate

1. Loosen the four cylinder head screws on the wear plate on

the lower pump case.

2. Take out the old wear plate with the seal.

3. Clean the wear plate seat and insert the new wear plate with

ENGLISH

a new seal.

4. Tighten the four cylinder head screws again.

5. After this, readjust the impeller gap again.

Replacing the impeller

CAUTION!

Worn impellers can have sharp edges.

1. Remove the 4 hexagonal screws and lift the motor unit off

the spiral housing.

2. Block the impeller.

3. Loosen the central impeller screw located in the impeller

hub.

4. Loosen the impeller by knocking it gently with a hammer

and then slide it off the shaft.

5. Clean all the parts of the impeller mounting.

6. Grease the shaft cover on the inside. Notice! Do not use

grease containing graphite, such as "Molykote".

7. Fix all the parts of the impeller mounting in place and tigh-

ten the impeller screw until it is “hand tight”.

8. Slide the new impeller over the preassembled impeller

mounting onto the shaft.

9. Mount the motor unit on the spiral housing; the cable entry

point is opposite the discharge branch.

10.Set the gap dimension to 0.5 - 0.8 mm and then tighten the

impeller screw to 160 Nm.

WHAT TO DO IN THE EVENT OF

ANY PROBLEMS

Pump does not work

•Check mains current (do not use a pin gauge)

•Fuse faulty = may be too weak (please refer to Electrical

Connection)

•Mains supply cable damaged = repair to be carried out by

manufacturer only

Pump runs but does not pump

•Empty pressure pipe or hose to allow the non-return valve to

open and let the air escape from the pump housing.

•Ventilate the pump housing by unscrewing the "LUFT" (air)

sealing screw.

The impeller is blocked

•Solids and brous matter have become lodged in the pump

housing (please refer to Maintenance)

Decreased pumping performance

•The impeller is blocked (please refer to maintenance)

•Rotor gap too large = adjust (please refer to maintenance)

•The impeller or the wear plate is worn out = replace it (please

refer to maintenance)

•Wrong direction of rotation = change 2 phases of the power

supply

0197

JUNG PUMPEN GmbH - Industriestr. 4-6 - 33803 Steinhagen, Germany

412.14.1910

EN 12050-1:2001

Fäkalienhebeanlage

55/2 B2 (JP09663/2)

55/4 B6 (JP00486/3)

55/4 C2 (JP00487/3)

55/4 C5 (JP09901/2)

75/2 B5 (JP00485/3)

75/4 B6 (JP00489/3)

75/4 C2 (JP00490/3)

75/4 C5 (JP09904/2)

100/2 B5 (JP09740/1)

100/4 C2 (JP09678/1)

100/4 C5 (JP09275/1

55/2 B2, EX (JP09664/2)

55/4 B6, EX (JP09666/2)

55/4 C2, EX (JP09668/2)

55/4 C5, EX (JP09902/2)

75/2 B5, EX (JP09665/2)

75/4 B6, EX (JP09667/2)

75/4 C2, EX (JP09669/2)

75/4 C5, EX (JP09905/2)

100/2 B5, EX (JP09741/1)

100/4 C2, EX (JP09679/1)

100/4 C5, EX (JP09276/1)

Sammeln und automatisches Heben von fäkalienfreiem und

fäkalienhaltigem Abwasser über die Rückstauebene

BRANDVERHALTEN NPD

WASSERDICHTHEIT Bestanden

WIRKSAMKEIT (HEBEWIRKUNG)

- Förderung von Feststoffen Bestanden

- Rohranschlüsse Bestanden

- Mindestmaße von Lüftungsleitungen NPD

- Mindestießgeschwindigkeit Bestanden

- Freier Mindestdurchgang der Anlage Bestanden

- Mindestnutzvolumen NPD

MECHANISCHE FESTIGKEIT

- Tragfähigkeit und strukturelle Stabilität des Sammelbe-

hälters für die Verwendung außerhalb von Gebäuden

NPD

- Strukturelle Stabilität des Sammelbehälters für die Ver-

wendung innerhalb von Gebäuden

NPD

GERÄUSCHPEGEL 70 dB(A)

DAUERHAFTIGKEIT

- der Wasserdichtheit und Luftdichtheit Bestanden

- der Hebewirkung Bestanden

- der mechanischen Festigkeit Bestanden

GEFÄHRLICHE SUBSTANZEN NPD

0197

JUNG PUMPEN GmbH - Industriestr. 4-6 - 33803 Steinhagen, Germany

412.14.1910

EN 12050-1:2001

Lifting plant for wastewater containing faecal matter

55/2 B2 (JP09663/2)

55/4 B6 (JP00486/3)

55/4 C2 (JP00487/3)

55/4 C5 (JP09901/2)

75/2 B5 (JP00485/3)

75/4 B6 (JP00489/3)

75/4 C2 (JP00490/3)

75/4 C5 (JP09904/2)

100/2 B5 (JP09740/1)

100/4 C2 (JP09678/1)

100/4 C5 (JP09275/1

55/2 B2, EX (JP09664/2)

55/4 B6, EX (JP09666/2)

55/4 C2, EX (JP09668/2)

55/4 C5, EX (JP09902/2)

75/2 B5, EX (JP09665/2)

75/4 B6, EX (JP09667/2)

75/4 C2, EX (JP09669/2)

75/4 C5, EX (JP09905/2)

100/2 B5, EX (JP09741/1)

100/4 C2, EX (JP09679/1)

100/4 C5, EX (JP09276/1)

Collection and automatic lifting of wastewater without sewage and

wastewater containing faecal matters above the backow level

REACTION TO FIRE NPD

WATERTIGHTNESS Pass

EFFECTIVENESS (LIFTING EFFECTIVENESS)

- Pumping of solids Pass

- Pipe connections Pass

- Minimum dimensions of ventilating pipes system NPD

- Minimum ow velocity Pass

- Minimum free passage of the plant Pass

-Minimum useful volume NPD

MECHANICAL RESISTANCE

- Load bearing capacity and structural stability of collec-

tion tank for use outside buildings

NPD

- Structural stability of collection tank for use inside buil-

dings

NPD

NOISE LEVEL 70 dB(A)

DURABILITY

- of structural stability Pass

- of lifting effectiveness Pass

- of mechanical resistance Pass

DANGEROUS SUBSTANCES NPD

DEUTSCH ENGLISH

JUNG PUMPEN GmbH - Industriestr. 4-6 - 33803 Steinhagen - Germany -

www.jung-pumpen.de

DE - Wir erklären in alleiniger Verantwortung, dass das Produkt den aufgeführten Richtlinien entspricht.

CS - Prohlašujeme na svou výlučnou odpovědnost, že výrobek odpovídá jmenovaným směrnicím.

DA - Vi erklærer under ansvar at produktet i overensstemmelse med de retningslinjer

EN - We hereby declare, under our sole responsibility, that the product is in accordance with the specied Directives.

FI - Me vakuutamme omalla vastuullamme, että tuote täyttää ohjeita.

FR - Nous déclarons sous notre propre responsabilité que le produit répond aux directives.

HU - Kizárólagos felelősségünk tudatában kelentjük, hogy ez a termék megfelel az Európai Unió fentnevezett irányelveinek.

IT - Noi dichiariamo sotto la nostra esclusiva responsabilità che il prodotto è conforme alle direttive citate

NL - W verklaren geheel onder eigen verantwoordelkheid dat het product voldoet aan de gestelde richtlnen.

PL - Z pełną odpowiedzialnością oświadczamy, że produkt odpowiada postanowieniom wymienionych dyrektyw.

PT - Declaramos, sob nossa exclusiva responsabilidade, que o produto está em conformidade com as Diretivas especicadas.

RO - Declarăm pe proprie răspundere că produsul corespunde normelor prevăzute de directivele mai sus menţionate.

SK - Na výlučnú zodpovednosť vyhlasujeme, že výrobok spíňa požiadavky uvedených smerníc.

SV - Vi försäkrar att produkten på vårt ansvar är utförd enligt gällande riktlinjer.

CE 312-16-1910

Steinhagen, 10-10-2019

______________________ i.A. ____________________

Stefan Sirges, General Manager Pascal Kölkebeck, Sales Manager

• 2006/42/EG (MD) EN 809:1998/AC:2010, EN ISO 12100:2010

• 2011/65/EU (RoHS)

• 2014/30/EU (EMC) EN 60034-1:2010, EN 61000-3-2:2014, EN 61000-3-3:2013

• 2014/34/EU (ATEX) EN 60079-0:2011/A11:2013, EN 60079-1:2014

DE - Richtlinien - Harmonisierte Normen

CS - Směrnice - Harmonizované normy

DA - Direktiv - Harmoniseret standard

EN - Directives - Harmonised standards

FI - Direktiivi - Yhdenmukaistettu standardi

FR - Directives -

Normes harmonisées

HU - Irányelve - Harmonizá szabványok

IT - Direttive - Norme armonizzate

NL - Richtlnen - Geharmoniseerde normen

PL - Dyrektywy - Normy zharmonizowane

PT – Directiva - Normas harmonizadas

RO - Directivă - Norme coroborate

SK - Smernice - Harmonizované normy

SV - Direktiv - Harmoniserade normer

55/2 B2, EX (JP09664/2)

55/4 B6, EX (JP09666/2)

55/4 C2, EX (JP09668/2)

55/4 C5, EX (JP09902/2)

75/2 B5, EX (JP09665/2)

75/4 B6, EX (JP09667/2)

75/4 C2, EX (JP09669/2)

75/4 C5, EX (JP09905/2)

100/2 B5, EX (JP09741/1)

100/4 C2, EX (JP09679/1)

100/4 C5, EX (JP09276/1)

55/4 BW2, EX (JP48268)

55/4 CW2, EX (JP47373)

75/2 BW1, EX (JP46874)

75/2 CW1, EX (JP47229)

75/4 BW2, EX (JP46878)

75/4 CW2, EX (JP47235)

100/2 BW1, EX (JP46872)

100/2 CW1, EX (JP46880)

100/4 BW2, EX (JP46876)

100/4 CW3, EX (JP47355)

75/2 M, EX (JP09913)

76/2 M, EX (JP09263)

II 2 G Ex d IIB T4 PTB 08 ATEX 1115 X

Physikalisch-Technische Bundesanstalt

Zertizierungssektor Explosionsschutz (0102)

Bundesallee 100 - 38116 Braunschweig - Germany

EU-Konformitätserklärung

EU-Prohlášeni o shodě

EU-Overensstemmelseserklæring

EU-Declaration of Conformity

EU-Vaatimustenmukaisuusvakuutus

EU-Déclaration de Conformité

EU-Megfelelöségi nyilatkozat

EU-Dichiarazione di conformità

EU-Conformiteitsverklaring

EU-Deklaracja zgodności

EU-Declaração de Conformidade

EU-Declaraţie de conformitate

EU-Vyhlásenie o zhode

EU-Försäkran om överensstämmelse

DE-Weitere normative Dokumente CS-Jinými normativními dokumenty DA-Andre norma-

tive dokumenter EN-Other normative documents FI-Muiden normien FR-Autres docu-

ments normatifs HU-Egyéb szabályozó dokumentumokban leírtaknak IT-Altri documenti

normativi NL-Verdere normatieve documenten PL-Innymi dokumentami normatywnymi

PT-Outros documentos normativos RO-Alte acte normative SK-Iným záväzným dokumen-

tom SV-Vidare normerande dokument:

EN 60034-5:2001/A1:2007

EN 60079-14:2007

DE-Bevollmächtigter für technische Dokumentation CS-Oprávněná osoba pro technickou

dokumentaci DA-utoriseret person for teknisk dokumentation EN-Authorized person for

technical documentation FI-Valtuutettu henkilö tekninen dokumentaatio FR-Personne

autorisée à la documentation technique HU-Hivatalos személy műszaki dokumentáció

IT-Persona abilitata per la documentazione tecnica NL-Bevoegd persoon voor techni-

sche documentatie PL-Pełnomocnik ds. dokumentacji technicznej PT-Pessoa autoriz-

ada para documentação técnica RO-Persoană autorizată pentru documentatiei tehnice

SK-Oprávnená osoba pre technickú dokumentáciu SV-Auktoriserad person för teknisk

dokumentation:

JUNG PUMPEN - Stefan Sirges - Industriestr. 4-6 - 33803 Steinhagen
