Pentair SPEEDEO CONNECT User manual

VS
SB-PF-SPO-004A
PENTAIR AQUATIC SYSTEMS SB-CU-IMP-069 (Rev. 11/2022)
SPEEDEO CONNECT
Wi-Fi
POOL AUTOMATION SYSTEM
VALID
SPEEDEO® Connect
INSTALLATION AND USER MANUAL
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
3 assignable outlets
4 controllable speeds
* Speedeo Connect optimises the speed variation of the IntelliFlo pump
and is compatible with variable speed pumps with an external
connection which permits them to be externally controlled.
The list of compatible pumps is constantly changing in
accordance with releases of new models.
1 Intelli RS-485
2 assignable inputs
01:03 Water:+24.3°C
Filtration: V2
S1:OFF S2:ON S3:OFF
AIR:+25.9°C
EN

Lausanne, 2022 01 26
Speedeo Connect
SB-PF-SPO-004A
PART NUMBERS:
SB-SE-TEC-008A
SAFETY EN 62368-1:2014; EN 62311: 2008
RED 2014/53/EU
EMC EN 301 489-1 V2.2.0; EN 301 489-3 V2.1.1; EN 55024: 2010 / A1: 2015
RADIO EN 300 220-2 V3.1.1
Jacques Van Bouwel
Engineering Mgr
Pentair thanks you for placing your trust in the company and purchasing a Speedeo Connect, the variable speed pump control automaton, with 3
assignable pieces of equipment. Speedeo Connect will start up the correct speed of the connected variable speed pump according to the hydraulic
requirements linked to the event.
Please carefully read this user manual to fully benet from all of the functions of Speedeo Connect. Store it carefully so that it can be consulted
at any time.
Declaration of conformity
Directives – Harmonised standards
Pentair International Sarl - Avenue de Sévelin 20 - 1004 Lausanne - Switzerland
We declare, under our own responsibility, that the product meets the directives
Waste treatment of electronic devices at the end of their service life:
The crossed-out bin placed on the main parts which make up the product indicates that it
must not be disposed of with household waste. It must be returned to an appropriate collection
point for electronic device recycling (information available from the local household waste
collection service). This product contains potentially dangerous substances which may have adverse
effects on the environment and human health.
Customer Support: [phone] website : www.pentairpooleurope.com
- Warranty (excluding probes and consumables): 2 years
© 2022 Pentair International LLC, All rights reserved - The document is subject to change without notice
Trademarks and disclaimers: Speedeo®, Soleo® and Pentair® are trademarks and/or registered trademarks of Pentair and/or its aliated companies.
Unless indicated otherwise, names and brands of others that may be used in this document are not used to indicate an aliation or endorsement
between the owners of these names and brands and Pentair. Those names and brands may be the trademarks or the registered trademarks of
these parties, or others.
Product specications: SB-PF-SPO-004A model
Operating temperature: 0° to 40° C Operating hygrometry: 40% at 75° C Power supply: 230V ~, 50 Hz
Maximum operating altitude: 2000 m Weight (excluding probes): 1.2 kg Consumption: 3.2 W
Main box (internal use): IP 64
Other normative documents Authorised person for technical documentation
Pentair International S.a.r.l
Avenue de Sévelin 20
1004 Lausanne - Switzerland

Summary
PRESENTATION
> Possibilities for a pump with variable speeds p 04
> Packaging contents / Functions of the device p 06
> Description p 06
INSTALLATION - SPECIFIC POINTS
> Fixing connections / hygiene p 07
> Examples of installation types p 09
> Water and air temperature probes p 10
> Connection of IntelliFlo to IntelliRS-485 and other pumps with variable speeds p 11
MENUS
> Main menu / Radio menu p 14
> Install / Heating pump / Information menu p 15
> Filtration time p 16
> Filtration Speed / Set Time p 17
CONNECTIONS Inlets / Outlets
> Inlet: connection for the end of a cover line / switch or remote control p 18
> Outlet: connections for a controller and an IntelliChlor p 19
> Outlet: connections for heating pump and solar heating p 20
> Outlet: connections for lighting and a 3-way motorised valve p 22
> Outlet: connections and automatic washing for a pneumatic valve p 23
> Washing assisted by 6-way valve p 24
> Wi-Fi Installation p 25
> Navigating the menus p 26
OTHERS
> Updating internal rmware / History menu p 28
> pH / RedOx / chlorine ratio p 29

IMPORTANT SAFETY GUIDELINES, READ AND FOLLOW ALL OF THE INSTRUCTIONS, KEEP THESE INSTRUCTIONS
GENERAL POINTS
- DANGER - INSTALLERS, POOL SPECIALISTS AND OWNERS MUST CAREFULLY READ THESE WARNINGS AND ALL
INSTRUCTIONS BEFORE USING THIS PRODUCT.
- WARNING - Most countries regulate the construction, installation and operation of public swimming pools and spas, and the construction of
residential pools and spas. It is important to comply with these regulations, many of which directly regulate the installation and use of this product.
Consult your local building and health codes for more information.
- ATTENTION - This installation and user guide contains important information on the installation, operation and safety of this product. This guide
should be provided to the owner and/or user of this product.
INSTALLATION
- DANGER - RISK OF ELECTRIC SHOCK or electrocution
- BEFORE WORKING ON THIS DEVICE - Always cut the supply to the device at the circuit breaker before maintenance. Failure to do this may lead
to death or serious injury to service staff, pool users or others, due to an electric shock.
- DANGER - SERIOUS BODILY INJURY OR DEATH CAN RESULT IF THIS PRODUCT IS NOT INSTALLED AND USED CORRECTLY.
- WARNING - Before installing this product, read and follow the warnings and instructions of this guide. Failing to follow these warnings and
instructions may lead to serious injuries, death or material damage. Refer to www.pentairpooleurope.com for more information linked to this product.
- WARNING - Connect the device to a differential interrupter. If this system is used to control the underwater lighting devices, a differential
interrupter must be installed upstream of these devices. Conductors downstream of the differential interrupter shall not occupy conduits, junction
boxes or enclosures containing other conductors, except if the conductors are also protected by a differential interrupter. Refer to valid local
codes for more details.
- WARNING - This product must be installed by an authorised or certied electrician or a qualied swimming pool professional. All of the applicable
installation codes and local regulations must also be respected. Poor installation will create an electrical hazard which could result in serious injury
or the death of pool users, installers or others due to electric shocks, and may also cause damage to property.
- DANGER - DISCONNECT THE SUPPLY CONNECTIONS BEFORE WORKING ON THIS DEVICE; ELECTRICAL POWER MAY BE SUPPLIED TO THE RELAY
TERMINALS FROM OTHER SOURCES.
- WARNING – CHEMICAL BURN HAZARD: Make sure all pumps are switched off at the main circuit breakers at the domestic distribution board
before drilling into any pipes. Set rules for all handling related to electrical aspects, water and chemical products. Group the supply pumps and
chemical product tanks in a safe and secured area.
- WARNING - Do not use this product to control an automatic swimming pool cover. There is a risk that swimmers could become trapped under
the cover.
- WARNING – Devices which are not intended for use in single-family dwellings may require additional safety equipment to comply with local
regulations.
- DANGER – Except for remote controls, maintain a distance from the inside wall of the pool or spa that shall comply with the standards in force
in your country.
- DANGER - This product is intended for use in swimming pool applications only.
- WARNING - If the device is installed and / or used contrary to specications and recommendations, the protections will be compromised.

USE
- DANGER - DO NOT LET CHILDREN OPERATE THIS EQUIPMENT.
- WARNING – Strictly respect the safety and handling procedures from the acid manufacturers, including protective measures for hands, body and
eyes during transferring and using acid. Follow the prescribed safety precautions for handling muriatic acid intended for checking the water pH.
Muriatic acid may cause serious physical harm and may damage the swimming pool equipment. Extra care must be taken when installing, maintaining
and operating the acid pump feed systems. Acid is dangerous to handle and should be properly contained, transported, poured, stored and dispensed.
- WARNING – Check the pH and sanitizer levels of the water before using the pool and make sure the ltration device is not obstructed.
- WARNING – Periodically use an independent pH and chlorine testing kit to ensure that the pH and chlorine is at a safe level. If the pH and Oxidation
Reduction Potential (ORP) or conductivity probes are broken, depleted or dirty with oils, lotions, or other contaminants, they can report inaccurate
results to the system causing incorrect water chemistry, which could harm people or equipment.
- WARNING – Consult the device display daily to ensure there are no alarm messages.
- DANGER – Water temperatures greater than 37.7° C (100° F) are a health hazard. Prolonged immersion in hot water may induce hyperthermia.
Hyperthermia occurs when the internal body temperature exceeds the normal temperature of 37° C (98.6 °F) by several degrees. Hyperthermia
may produce the following effects: (1) Unawareness of impending danger. (2) Failure to perceive heat. (3) Failure to recognise the need to leave the
spa. (4) Physical inability to leave the spa. (5) Harm to the foetus in pregnant women. (6) Unconsciousness leading to the risk of drowning. The use
of alcohol, drugs or medicine is a factor which increases the risk of hyperthermia in hot tubs and spas.
- WARNING - When mixing acid with water, ALWAYS ADD THE ACID TO THE WATER. Never add water to the acid. When adding a chemical product to
the swimming pool, carefully follow the manufacturer instructions.
- DANGER - DO NOT MIX SODIUM HYPOCHLORITE AND MURIATIC ACID.
- DANGER - Keep standard solutions away from children, ensure that the bottles are securely closed, store them in a dry and ventilated location
and do not let them freeze. The pH 4 calibration solution is acidic.
ELECTRICAL WIRING RULES : This product must be installed by a licensed or certied electrician or a qualied pool professional in accordance
with the local regulation depending country :
A= ÔVE 8001-4-702
B=AREI / RGIE
D= OIN VDE 0100-702
EW = EVHS-HD 384-7-702
GB = 6S7671:1992
I= CEi 64-8/7
LUX = 384-7.702 S2
NL = NEN 1010-7-702
PL = PN-IEC 60364-7-702:1999
SLO = SIST HD 384-7-702.S2
CZ = CSN 33 2000 7-702
E= UNE 20460-7-702 1993, RECBT ITC-BT-31 2002 F = NF C15-100
H= MSZ 2364-702/1994/MSZ 10-553 1/1990
IRL = Wiring Rules + IS HD 384-7-702
M=MSA HD 384-7-702.S2
P= RSIUEE
SK = STN 33 2000-7-702
TR = TS IEC 60364-7-702
All applicable local installation codes and ordinances must also be adhered to. Improper installation will create an electrical hazard which could result
in death or serious injury to pool users, installers or others due to electrical shock, and may also cause damage to power source. Always disconnect
the power to the pool light at the circuit breaker before installing or removing the light. Failure to do so could result in death or serious injury.

24h12h 15h6h 9h 18h
V2 V3 V4V1
0h
V1 V2 V3 V4
4
Speedeo Connect is intended to optimally control (via dry contacts [of which one is shared and one is a
controllable speed contact, a maximum of four]) the different rotation speeds of a variable speed ltration
pump. There are usually 4 speeds: V1, V2, V3, V4. Speedeo Connect makes it possible to launch up to 3 pieces
of equipment, whose operation is linked to a speed. The rotation speeds at different speeds are directly pre-
set on the control unit (drive) of the pump. Speedeo Connect will therefore select the most appropriate power
according to the requirements to save as much electricity as possibility without impairing the ltration quality.
Max. ow
pump
Min. pump
pump
Example: typical day for a pool at 25.0°C in June in Europe
Consumption of a classic ltration pump
At night, the curtain is
closed. Filtration runs at the
minimum speed V1 at night. V1
is very quiet.
At 9:00 am, the curtain
is manually opened; the
speed automatically
changes to V2.
At midday, ltration goes up to V3 for one hour
to ensure the surface is well-skimmed. In the
afternoon, the NAC command and cascade
timer launch the pump at V3.
Backwashing the
filter (a few minutes)
triggers v4
Dividing the rotation speed of the lter pump by 2 divides its power consumption by 8.
The average saving of Speedeo Connect driving a VS pump compared to a conventional 1.5 hp ltration is
several hundred euros per year.
- Speed 1 : Permits minimal circulation. Speed V1 is used for frost protection and is selected when the cover is
placed over the pool (if applicable). V1 will function 24h/day if the water T° > +28.0 °C. This speed is therefore
used when there are no bathers in the pool.
- Speed 2 : Permits circulation of a larger amount of water when the cover is stowed (if relevant). This speed
is used when swimmers are in the pool.
- Speed 3 : Permits a strong ow of water when an accessory requires it. It is often chosen for a counter-
current jet, heating, cascade, etc. It is triggered in accordance with the parameters, either by a timer or a
wired remote control.
- Speed 4 : Only used for backwashing of the lter. On some pumps, V4 cannot be adjusted and automatically
represents the maximum power.
Foreword: management possibilities for a pump with variable speed control

5
Functions
Filtration control:
- By calculating the time according to the pool temperature (automatic mode).
- By constant ow management in IntelliFlo pumps
- By programming a 24 hour cycle (makes it possible to benet from off hours).
- By integrating the frost protection function (activation of the ltration below 3°C, modiable
value).
- By giving priority to the heating (if the value of this reference exceeds the set value, and if the
ltration is cut, ltration starts in the next 15 minutes).
- Possibility to select the start time and end time of the ltration in automatic mode (to prevent
noise at night). If Speedeo Connect is connected to a SOLEO, this function is found on SOLEO.
- Possibility to increase or reduce the ltration time according to the use of the swimming pool
(economical mode = pool with a low number of visitors, turbo mode = pool with a high number
of visitors) or by default + or - 30% (value can be adjusted).
- Possibility to change into “SHOCK” mode (forcing of the ltration and electrolyser for 24 hours).
- Possibility to change the speed according to the position of the pool cover (motorised cover) if
there is a position contact connection on the dedicated inlet.
- Possibility to change the speed according to the position of a command (interrupter, end position
sensor of the motorised cover).
Control of 3 devices:
- By synchronisation with operation of the pump (each connected device will only be authorised
to operate if the ltration runs at a sucient rate).
Speedeo Connect also makes it possible to visualise, on its screen (in the technical room):
- time
- water temperature
- operating speed (S1 to S4)
- status of the 3 outlets (S1 S2 S3, ON or OFF)
- air temperature (if second sensor present)
THEREFORE IN SUMMER AND WINTER, YOU NO LONGER NEED TO WORRY ABOUT YOUR
FILTRATION AND YOU LIMIT THE INTERVENTIONS IN THE TECHNICAL ROOM TO A BARE MINIMUM.

SB-PF-SPO-003C SB-SE-TEC-006A
S/N 1234ABCD1234ABCD1234ABCD01
QC Passed
Pentair International Sarl
Avenuede Sévelin 20
CH-1004 Lausanne
Mfg Year
Apr-2019
MADE IN ITALY
SCAN
ME
230V 50Hz~ / IP64 / 3,2 W
433,4 MHz
POOL AUTOMATION SYSTEM
VALID
SPEEDEO® Connect
6
Description
FRONT VIEW
Backlit screen
(4 x 20 characters)
Menu navigation buttons
(Esc/Bottom/Top/Valid.)
Manufacturer’s plate
Serial number
Fuse holder (1 A 250 VAC)
Replace the soft cover
after each opening.
Connector cover
(Removable with a at screwdriver)
Screw cover
(Insulator of acidic vapours
and humidity circulating
via the screw hole)
Elastomer cover
(Insulator of acidic vapours
and humidity)
USB / mini USB
Update of the software
Status light
(for updates)
Water or air
temperature sensor
(see p10)
Clamp band
For mounting the water temperature probe
Speedeo Connect automatically controls the pump rotation speed with variable speed, enabling the function
of programmed or activated events.

1
85
m
m
1
5
0
m
m
1
2
3
1
2
4
3
4
20 cm
7
Wall xing
- This device is intended to be used inside, installed in a technical room which cannot
be accessed by children.
- Set the device at a height lower than 2 m using three screws (4 to 5 mm diameter) in
appropriate plugs for the type of support and x the device vertically on a clean support
which is able to bear a minimum vertical load of 5 kg.
Pierce three holes in accordance with the below dimensions then place 3 suitable plugs.
1 - Tighten the screw at the top, leaving 2 mm under the screw head, then hang the device on this.
2 - Place the 2 lower screws.
3 - Add the 2 lower screw covers to ensure a full seal.
4 - No metallic element or electrical cable must pass less than 20cm from the top/right corner of the
device (radio zone).
A safety cover which cannot be unclipped without a tool is positioned above the connectors which provide
the voltage. > Place a at screwdriver on the at part of clips 2 and 3, while keeping pressure on to unclip it.
This symbol alerts you to the risk of electric
shock or electric shock that could result in
serious bodily injury or death. After each
intervention, put the orange safety cover and
then the soft grey cover back in place.

OUT 1 OUT 2
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
RS-485
IN 1 IN 2
OUT 3
N L
230 V ~
Ø 8 / 8.8 mm
30 mm max5 mm Ø 8 / 8.8 mm
30 mm max5 mm
= RO2V (3 x 1.5 mm2mini) = RO2V (2 x 1.5 mm2mini)
35 mm
185 mm
150 mm
8
Electrical connections regulation
- The device must be installed by a qualied technician according to valid local regulation
- This device is permanently connected.
- The 2 poles of the power supply of the device is cut by its interrupter, which must be close and
must remain accessible at all times.
- The device needs to be connected to the earth and its power supply needs to be protected
by 16A 30 mA differential protection. This protection must be cut before any intervention on
the device.
- Overvoltage category II (2,500 V peak) electrical device. If necessary, place overvoltage
protection equipment before the device.
- The device must be placed close to the electrical cabinet to aid connections (3 m max.).
The supply cable as well as the cables of the dry power contacts must be placed in a channel according
to the EN 50085-2-1 standard, 35mm thick, plated and closed under the device and installed according
to the IEC 60364 standard.
BOTTOM VIEW
Channel
Support, wall.
REAR VIEW
Interchangeable fuse
FST 5x20 250 V AC 1A 5x20 fast
Screw terminals
Slotted screwdriver 2.5 mm/0.5-0.6 Nm
Caps
- must be installed if an outlet is not in use
(to stop any humidity or acidic vapour entering)
Cable ducts
- must be installed if an outlet is in use,
(to stop any humidity or acidic vapour entering)
POWER SUPPLY 230 V / 50Hz +- 10%
OUT 1- 230 V 10A Max
OUT 2 - 230 V 10A Max
OUT 3 - 230 V 10A Max
Compatible power supply cables 230 V Compatible dry contact cables

O.R.P.
pH
pH
T° Eau
Flow switch
SOLEO
FILTRATION, PH & ORP CONTROLLER
VALID
ESC
POOL AUTOMATION SYSTEM
VALID
SPEEDEO® Connect
POOL AUTOMATION SYSTEM
VALID
SPEEDEO® Connect
T° Air
9
Examples of installation types
Controlling a solenoid valve with Speedeo Connect makes it
possible to benet from full power for activities using V3.
Controlling a solenoid valve
with Speedeo Connect makes
it possible to benet from full
power for activities using V3.
Opening the solenoid valve
will stop the ows in the main
circuit and cut the ow-switch
of the devices with this safety
device (electrolyser, heating).
Opening the solenoid valve will stop the ows in the main
circuit and cut the ow-switch of the devices with this safety
device (electrolyser, heating).
- Inlet connections: Water temperature, cover presence sensor
- Outlet connections: Heating, electro-pneumatic valve, solenoid valve
- Inlet connections: Cover presence sensor
- Outlet connections: Heating, solenoid valve
Indicative connections
Indicative connections
T° Water
01:03 Water:+24.3°C
Filtration: V2
S1:OFF S2:ON S3:OFF
AIR:+25.9°C
01:03 Water:+24.3°C
Filtration: V2
S1:OFF S2:ON S3:OFF
AIR:+25.9°C
16:03 Water:+26.3°C
Filtration: ON
RedOx: 736mV
AIR:+25.0°C pH: 7.2

Ø 10 mm
12
3
Ø 50 / 70 mm
RS-485
IN 1 IN 2
4
1 2
NO OK
10
Water and air temperature probes.
Speedeo Connect is supplied with a temperature probe which is suitable for water. It is possible to mount
a second temperature probe for the air temperature used to manage the frost protection process of heated
technical rooms. The probe time can be staggered via the Temperature Menu > Calibration: (see p15)
INSTALLATION OF THE WATER TEMPERATURE PROBE
The temperature probe can be installed outside the bypass in front of the lter of the pump or in front of the
lter inlet in order to improve the reading precision.
1 - Pierce the PVC pipe (diam. 50-70 mm) to a diameter of 10 mm (3/8 inch).
2 - Remove the burrs and check the O-ring under the probe.
3 - Place the sensor in the hole, then place the clamp band in the groove and tighten.
4 - Connect wires to dedicated terminal block.
1 - Connect the cables to Inlet 2 in accordance with the diagram.
2 - Start the secured Install menu (on the main menu, press Esc and Valid at the same time for
3 secs. A star appears in the top right corner of the home screen).
3 - In the Inlets / E1-E2 sub-menu (in accordance with chosen terminal), select T° Air to indicate
that a temperature sensor is connected to the corresponding inlet.
INSTALLATION OF THE AIR TEMPERATURE PROBE (OPTION)
- If the air temperature probe is connected, it automatically becomes the reference value for freeze protection
management (unless Speedeo Connect is connected to a SOLEO). The air temperature probe is placed outdoors,
away from direct sunlight so that the measurement is not distorted. It can be easily moved due to its 6 m long
cable.
1 – Mount it on a wall with screws. 2 – Mount it on a horizontal bar of a grate with a cable tie.
- Once Speedeo Connect is linked to a SOLEO, the temperature values saved and displayed by
Speedeo Connect are picked up by the SOLEO.
The temperature sensor provided can also be used as an air temperature sensor.

Unconnected
POOL AUTOMATION SYSTEM
RS-485
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
Unconnected Unconnected
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
230 V
TERRE
NEUTRE (N)
PHASE (L)
11
PENTAIR IntelliFlo: Connections and functions
PENTAIR VS2 (Superflo, SuperMax, Ultraflow, S5P2R, Challenger &
Whispero): Connections and functions
1 - Connect the cables in accordance with the diagram.
2 - Start the secured Install menu (on the main menu, press Esc and Valid at the same time for 3 secs. A star
appears in the top right corner of the home screen).
3 - On the Filtration Speed / Type sub-menu, select 4 speeds and hold down Valid.
4 - Connect wires to dedicated terminal block.
Control the speeds S1 < S2 < S3 < S4 and S4 at 100% on the pump drive.
Connect the pump to the 230 V, connect to the 10-m long IntelliFlo cable (ref 350122), the green/yellow to
the ‘RS-485’, adhering to the colours.
01:03 Water:+24.3°C
Filtration: V2
S1:OFF S2:ON S3:OFF
AIR:+25.9°C IntFlo
Old cable
New cable
EARTH
NEUTRAL

STEP 1
+12
A
B
COM
STEP 2
STEP 3
OVRD
ICOM
ON
12345
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
12
PENTAIR VS1 (Supero, Ultraow, SuperMax and S5P2R): Connections
and functions
HAYWARD VSTD: Connections and functions
SPECK Eco Touch: Connections and functions
Control the speeds S1 < S2 < S3 < S4 and S4 at 100% on the pump drive.
Set the DIP switches 1, 2, 3, 4 on the pump drive to ON.
Set the appropriate speed 1(Eco), 2(Normal), 3(Max) on the HAYWARD pump.
Control the appropriate speeds for the pump, 1 (Eco), 2 (Normal) and 3 (Max).
- The SPECK Eco Touch pump functions for 5 minutes at maximum speed after starting.
1 - Connect the cables in accordance with the diagram.
2 - Start the secured Install menu (on the main menu, press Esc and Valid at the same time for 3 secs. A star
appears in the top right corner of the home screen).
3 - On the Filtration Speed / Type sub-menu, select 3 speeds and hold down Valid.
1 - Connect the cables in accordance with the diagram.
2 - Start the secured Install menu (on the main menu, press Esc and Valid at the same time for 3 secs. A star
appears in the top right corner of the home screen).
3 - On the Filtration Speed / Type sub-menu, select Invertek and hold down Valid.
1 - Connect the cables in accordance with the diagram.
2 - Start the secured Install menu (on the main menu, press Esc and Valid at the same time for 3 secs. A star
appears in the top right corner of the home screen).
3 - On the Filtration Speed / Type sub-menu, select 4 speeds and hold down Valid.

INPUT 1
INPUT 2
INPUT 3
INPUT 4
COMMON
Commun = 50
Vitesse 1 = 51
Vitesse 2 = 52
Vitesse 3 = 53
Vitesse 4 = 54
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
!! Terminal under the user interface!!
13
SPECK 90 Eco Motion: Connections and functions
ZODIAC FloPro VS: Connections and functions
On the pump, control the speeds N1 < N2 < N3 < N4 and N4 at 100% / ‘EXTERNAL = FIX SPEED’
and ‘SIGNAL = CONTINUED’. - The pump functions for 5 minutes at maximum speed after starting.
Control speeds 1 < 2 < 3 < 4 on the pump drive
- Control all operation lengths at ‘0’
1 - Connect a 5 x 0.75 mm2 cable in accordance with the diagram.
2 - Start the secured Install menu (on the main menu, press Esc and Valid at the same time for 3 secs. A star
appears in the top right corner of the home screen).
3 - On the Filtration Speed / Type sub-menu, select 4 speeds and hold down Valid.
1 - Connect the cables in accordance with the diagram.
2 - Start the secured Install menu (on the main menu, press Esc and Valid at the same time for 3 secs. A star
appears in the top right corner of the home screen).
3 - On the Filtration Speed / Type sub-menu, select 4 speeds and hold down Valid.
Commun = 50
Speed 1 = 51
Speed 2 = 52
Speed 3 = 53
Speed 4 = 54

VALID VALID VALID
„
o
w
14
Main menu
Radio menu (radio pairing between SOLEO and Speedeo Connect)
The default radio channel is Channel 01 (same for SPEEDEO). The devices have a range
of 30 m. A SOLEO and a Speedeo Connect set on the same radio channel and at a distance
maximum 30 m will automatically be paired. If several different Combi installations are
close to each other, it is possible to shift the radio channel of one of the installations to
one of the other 9 channels (2 to 10) to prevent interference. It is therefore important
to choose the same channel number on the 2 devices to be paired.
01:22 Water:+26.6°C „
Filtration : V3
S1:OFF S2:ON S3:OFF
Air:+26.8°C WASHING
16:03 Water:+26.3°C „
Filtration: ON
RedOx: 736mV
Air:+25.0°C pH: 7.2
Information
Language
Update
-Radio
-Radio Chanel : 01 -Radio Chanel: 01
Time Water temperature
This symbol (antenna) indicates that Speedeo Connect is connected to a SOLEO.
Home menu > Radio menu :
Pairing with a SOLEO
Cloud connection
Wi-Fi connection
Filter clean required
(not displayed for
automatic washing on pneumatic valve)
Operating speed
Status of outlets S1, S2, S3
Air temperature
(if 2nd sensor connected, see p10)
If Speedeo Connect is linked to a SOLEO, the SOLEO ltration outlet is only supplied with power
when Speedeo Connect starts the VS pump (whatever the speed). This SOLEO ltration outlet
can for example be used to supply a UV light.
- Once Speedeo Connect is linked to a SOLEO, the temperature values saved and displayed by
Speedeo Connect are picked up by the SOLEO.

POOL AUTOMATION SYSTEM
VALID
SPEEDEO® Connect
01:03 Eau:+24.3°C
Filtration: V2
S1:OFF S2:ON S3:OFF
AIR:+25.9°C
*
15
Access to restricted access mode ‘Install’
Menu organisation / Heating menu / Information menu
Below this temperature, the ltration runs 24/7 to prevent the pool from freezing (active wintering).
- If the air temperature probe is connected: it becomes the reference value for freeze protection management. Place it outdoors,
out of direct sunlight so that the measurements are not distorted (see p06). - If the air temperature probe is not connected: the
water temperature becomes the reference value for freeze protection management. Please check that the technical room is not heated
or has a signicantly different temperature in comparison with the temperature outside. If this is the case, the difference must be
compensated by Calibration.
AUTO Activate the heating pump until the set point value has been
reached. Priority: NO Make sure the heating pump does not start
until the ltration is already running. Priority: YES Start ltration
so that the heating can function.
This setting makes it possible to deliberately correct any difference
with another reference thermometer.
Choice between French and
English
Informs about the version of
the OS
Choice between 14 lighting
modes
Speedeo Connect controls the equipment in the technical room, and the wrong settings may have serious
consequences for the safety of the pool. Because of this, access to certain initial conguration functions
is reserved for professionals, or people whose experience enables them to modify these parameters while
being fully aware of the consequences. In order to limit accidental
access, the Install menu menu has secured access. (from the main
menu, simultaneously hold down Esc and Valid for 3 secs. A star
appears in the top right corner of the home screen).
See p17 (this menu no longer exists if a SOLEO is paired)
See p17
See p 24
See p18 (accessed through Install)
See p19 (accessed through Install)
See p17 (this menu no longer exists if a SOLEO is paired)
See p28 (accessed through Install)
See p10
See p25
The Install menu menu is active.
It automatically deactivates after 15 mins of inactivity.
16:03 Water:+26.3°C *
Filtration: ON
RedOx: 061mV
Air:+25.0°C pH: 7.2
Speedeo Connect
Version : X.X
pentairpooleurope.com
-Mode : Californian
-Heating pump
Calibration
Antifreeze : +3°C
-Heating pump: AUTO
Set point : 30°C
Priority : NO
01:03 Eau:+24.3°C *
Filtration: V2
S1:OFF S2:ON S3:OFF
AIR:+25.9°C
CALIBRATION
-Temp. Water:+23.2°C
-Temp. Air :+23.3°C
-LANGUAGE : French
-Filtration time
Filtration speed
Filter backwash
Inputs
Outputs
-Setting the time
Temperatures
Information
Languages
Update
Radio
Lighting
Local pairing
Cloud Connection

5°0°
0 h
5 h
3 h
10 h
15 h
20 h
24 h
10° 15° 20° 25° 30° 35°
VS
t=T
VS
Blue Class.
Blue
t=T/2
Class.
ltration [h/j]
16
Menu: Filtration time (daily) / Algorithm
t=T VS (the daily ltration time is equal to the temperature value in ° Celsius): At 10°C, ltration will function 10hrs/day, at
20°C 20h/day... Aimed at pumps with variable speed control, this mode lters the most.
BlueVS Aimed at pumps with variable speed control, this mode lters less, particularly at temperatures below 15°C, where
bacteria do not easily develop.
t=T/2Classic (the daily ltration time is equal to half the temperature value in ° Celsius): At 10°C, ltration will function 5hrs/
day, at 20°C 10hrs/day ...Aimed at pumps with xed speeds, this mode lters the most.
Blue Classic Aimed at pumps with xed speeds, this mode lters less, particularly at temperatures below 15°C, where bacteria
do not easily develop.
Speedeo Connect proposes 4 different algorithms to suit different preferences concerning the
ratio of the number of hours for ltration according to the water temperature.
1 - Start the secured Install menu (from the main menu, simultaneously hold down Esc and Valid for 3 secs. A star appears in the top
right corner of the home screen).
2 - On the Filtration time / Algorithmsub-menu, select your chosen mode.
- Once the Speedeo Connect is linked to a SOLEO, this menu Filtration time disappears. The
SOLEO will manage the Filtration time.
Water temperature [°C]

17
Menu: Filtration time / Auto/On/Off/Timer/Shock Mode
Filtration speed menu
Time set menu
Select current mode:
AUTO = Automatically calculates the Filtration time according to the water
temperature.
ON = Filtration runs 24/7.
OFF = Filtration stops (note - anti freeze mode becomes inactive).
TIMER = Filtration runs during the selected time period (see below)
CHOCK = Activates 24-hour ltration. This function can be useful after the pool has
been used by many visitors and when the pool temperature is high. At the end of the
mode CHOCK, Speedeo Connect returns to normal AUTO.
- Once the Speedeo Connect is linked to a SOLEO, this menu Filtration time disappears. The
SOLEO will manage the Filtration time.
- Once the Speedeo Connect is linked to a SOLEO, this menu Setting the time disappears.
The SOLEO will manage the time settings.
Home menu > Filtration time menu:
Home menu > Filtration time menu:
This menu gives you control of the ltration start and end time, to control the level of noise linked to your pool (ltration noise), for the
sake of the neighbourhood. By default, leave End on AUTO.
In AUTO, Speedeo Connect calculates the ltration end time.
In AUTO, these events which adjust the different rotation speeds for
the pumps with variable speeds. The eld for Events will appear.
Makes it possible to set the time of the device. If the power supply is interrupted for more than
30 min., reinstalling the time is necessary.
Event creation:
S2 timer = If YES the pump is running at S2 from the Start time to End.
S3 timer = If YES the pump is running at S3 from the Start time to End.
Cover open = Opening the cover (if connected) changes the speed from S1 to S2.
Heating = Starting the heating pump (see p15) activates S2.
Inlet 1 S3 = Closing a contact at Inlet 1 starts S3 (e.g. connecting a switch for
activating a waterfall, an animation, swimming against the current...).
MANUAL displays the eld Speed which enables manual
selection of the rotation speed for the pumps with variable
speeds.
-Filtration : ON
Start : 05:00
Stop : AUTO
mode : TURBO
S2 timer : YES
Start : 11:00
End : 16:00
S3 timer : YES
Start : 17:00
End : 18:00
Cover open : NO
Heating : NO
S3 inlet 1 : YES
-Heure : 16 h
Minute : 03 min
-Mode: AUTO
Events -Mode : MANUAL Speed : S2

OUT 1 OUT 2
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
RS-485
IN 1 IN 2
OUT 3
N L
230 V ~
OUT 1 OUT 2
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
IN 1 IN 2
OUT 3
N L
230 V ~
RS-485
18
Inlet: connection for the end of a cover line
Inlet: connection for a switch, a remote control...
Inlet: connection for an air temperature probe (see p10)
1 - Connect the cables in accordance with the diagram.
2 - Start the secured Install menu (from the main menu, simultaneously hold down Esc and Valid for 3 secs. A star appears in the top
right corner of the home screen).
3 - On the Inlets / E1-E2 sub-menu (in accordance with chosen terminal), select COVER CONTACT to indicate that a limit contact has
been connected to the corresponding inlet.
4 - On the Filtration time / Cover Open sub-menu, select YES so that ltration is carried out while the cover is open (the cover does
not cover the pool). This is the primary function of the Filtration time / Start setting (despite the setting of an hour from the start
and/or end of ltration, if the cover does not cover the pool all day, ltration will run all day).
5 - On the Filtration Speed / Events / Cover Open sub-menu, select YES so that the ltration speed changes from S1 to S2.
1 - Connect the cables in accordance with the diagram.
2 - Start the secured Install menu (from the main menu, simultaneously hold down Esc and Valid for 3 secs. A star appears in the top
right corner of the home screen).
3 - On the Inlets / E1-E2 sub-menu (in accordance with chosen terminal), select OTHER to indicate that a dry contact has been connected
to the corresponding inlet.
It is possible to connect any type of dry contact inlet (switch, remote control, relay) which
activates an outlet.
The contact is closed when the cover is covering the pool
